EAW EP2 User guide

POWER AMPLIFIER
13.75
FRONT 2.13 5.52
8.56
11.00
A
(11.00)
30°
C
L
DIMENSIONS APPLY
TO TOP & BOTTOM
BOTTOM
14.39
11.00
11.50
BOTTOM
ONLY
TOP HAT
PRODUCTION
EP2
DIMENSIONS APPLY
TO BOTH SIDES
VIEW A-A
A
1.53
22.74
NOTES:
1. SYMBOL INDICATES MOUNTING POINT,
3/8-16 THREADED HOLE (FLYTRACK).
2. SYMBOL INDICATES 3.00 X 1.35
FLYTRACK.
3. SYMBOL INDICATES CENTER OF BALANCE.
4. WEIGHT APPROX 130 LBS.
5. SHIPPINF WEIGHT APPROX. 145 LBS.
19.75
GRILLE PARTIALLY SHOWN
27.00
6.12
2X HANDLE
6.44
8.75
3.48 AMPLIFIER
VENT INTAKE
EASTERN ACOUSTIC WORKS
BACK
C2.13
22.74
L
