EAW SB625P User manual

EASTERN ACOUSTIC WORKS
One Main Street, Whitinsville, MA 01588 • (508) 234 - 6158 • FAX (508) 234 - 8251 • Email [email protected] • Web http://www.eaw.com
EAW products are continually improved. All specifications are therefore subject to change without notice. • PUB# SB625P-888097 (A)/2 pp/2/1/99 • Printed In USA
A
C
O
U
S
T
I
C
A
L
P
E
R
F
O
R
M
A
N
C
E
P
A
R
T
N
E
R
S
H
I
P
TECHNICAL SPECIFICATIONS SB625P
DESCRIPTION
A dedicated subwoofer system with 2x 15-in transducers in a
vented rectangular enclosure. Each driver is in its own opti-
mally vented subenclosure.
APPLICATIONS
The SB625 is optimized for permanent installation as a sub
bass complement to medium format MH/CH-BH/BV arrays.
Tuned enclosure venting extends LF response and minimizes
driver strain. MX Series processors extend LF response and
safeguard against cone excursion damage. Comprehensive
mounting/suspension points. Six year warranty.
Applications include:
Band PA
Corporate Events
Small HOW’s
Dance Clubs
Live Music Clubs
DESCRIPTIVE DATA
Part Number 999137
Product Group M
Components & Loading 2x 15-in Vented
System Configuration Dedicated Subwoofer
Recommended High-Pass
Frequency (24 dB/Octave) 25Hz
Cabinet Type (shape) Rectangular
Enclosure Materials Baltic Birch Plywood
Finish Black Catalyzed Polyurethane
Connectors 4-Terminal Barrier Strip
Suspension Hardware (16) 3/8”-16 threaded mounting/
suspension points (4 each top,
bottom, sides)
Grill Vinyl Coated Perforated Steel
NOMINAL DATA
Frequency Response (Hz)
±3 db 33Hz (44Hz w/out CCEP) to 200Hz
-10 dB 30Hz (34Hz w/out CCEP)
Axial Sensitivity (dB SPL/1 Watt/1m)
98
Impedance (Ohms) 4 or 2x 8
Power Handling (Watts)
AES Standard 2000
Calculated Maximum Output (dB SPL, @ 1m)
Peak 137.0
Long Term 131.0
Recommended Complementary Systems
Full Range KF650e/KF695e
Dimensions inches millimeters
Height 33.25 845
Width 19.75 502
Depth 24.625 625
Weights pounds kilograms
Net Weight 130 59.2
Shipping Weight 138 62.8

Acoustic Performance Partnership Eastern Acoustic Works SB625P
One Main Street, Whitinsville MA, 01588 USA • Phone [phone] • Toll Free 800/992-5013 • Fax [phone] • Web http://www.eaw.com • email [e-mail]
A
C
O
U
S
T
I
C
A
L
P
E
R
F
O
R
M
A
N
C
E
P
A
R
T
N
E
R
S
H
I
P
TECHNICAL SPECIFICATIONS SB625P
DIMENSIONAL DRAWINGS
DIMENSIONAL DRAWING SERVICE ITEMS
Sub: Complete Cone Driver
EAW Part No. 804052
Filter/Crossover Network: Complete Assembly
EAW Part No. 201203
ARCHITECTURAL SPECIFICATIONS
The sub bass loudspeaker systems shall incorporate 2x 15-in
LF transducers mounted in separate vented subenclosures
tuned for optimum low frequency response.
System frequency response shall vary no more than ±3 dB
from 33 Hz to 200 Hz measured on axis with appropriate
signal processing. The loudspeaker shall produce a Sound
Pressure Level (SPL) of 98 dB SPL on axis at 1 meter with a
power input of 1 Watt, and shall be capable of producing a
peak output of 137 SPL on axis at 1 meter. The loudspeaker
shall handle 2000 Watts of amplifier power (AES Standard)
and shall have a nominal impedance of 4 (2x 8) Ohms.
The loudspeaker enclosure shall be rectangular in shape. It
shall be constructed of 15mm thickness void-free cross-grain-
laminated Baltic birch plywood and shall employ extensive
internal bracing. It shall be finished in black catalyzed poly-
urethane. Input connectors shall be 2-terminal barrier strip.
A total of sixteen 3/8"-16 threaded mounting/suspension
points (4 each top, bottom, sides) shall be provided. The
front of the loudspeaker shall be covered with a vinyl coated
perforated steel grill.
The sub bass loudspeaker shall be the EAW model SB625P.
3.50
11.38
SIDES
BACK
6.00 19.38
3.25
TOP
BOTTOM
(1.88)
19.38
1.88
19.75
16
FRONT
29.25
33.25
(2)
3/8-16 THREADED HOLE (TO BE DETERMINED)
CABINET TO BE SYMMETRICAL ABOUT ITS CENTERLINE DESIGNATIONS
CENTER OF BALANCE.
SB625P
510148
EXP 3/9/97 SHB
ALL DIMENSIONS IN INCHES UNLESS OTHERWISE NOTED.
C
L
C
L
