1 Overview
1.1 Introduction
E810-RS485-U01 is an intelligent universal interconversion converter that converts
USB signals to RS485 signals. It is designed in accordance with universal standards.
Transient suppression protection function to prevent internal chip damage caused by incompatible levels, with anti-lightning and
anti-static impact, limited slope drive, effective suppression of interference; solve the superposition of effective and invalid signals on
the transmission circuit, error-free data transmission. The rate is as high as 115200.
1.2 Function
TVS transient suppression protection;
Maximum baud rate of 115200;
USB direct power supply without external power supply, stable performance;
Connect with various 485 interfaces, the transmission distance up to 1200;
With receiving and sending indicators to monitor the data transmission status;
External 5v debugging power;
For win98, 2000, XP / Vista / Win7, 8 Linux and other systems.
2 Parameters
2.1 Operating parameters
Operating voltage
USB driver，5V
Serial baud rate
Max 115200
Distance
1200m
System
win98, 2000, XP/Vista/Win7,8 Linux
Operating temperature
-40～85℃
Operating humidity
5%～95%
Size
70×27×12mm

Chengdu Ebyte Electronic Technology Co.,Ltd E810-RS485-U01 User Manual
Copyright ©2012–2020，Chengdu Ebyte Electronic Technology Co.,Ltd
2
3 Pin definition
5P binding post
Indicator
Signal
Notes
1
VCC
Debugging product
VCC（5V）
Need to plug in
power supply for
debugging product,
othwise it is idle.
2
GND
Debugging product
GND
3
GND2
485 device GND
With real GND for
RS485 device
grounding is better.
Without GND, it is
idle.
4
B
485 device B（D-）
5
A
485 device A（D+）

Chengdu Ebyte Electronic Technology Co.,Ltd E810-RS485-U01 User Manual
Copyright ©2012–2020，Chengdu Ebyte Electronic Technology Co.,Ltd
3
4 Driver install
1) Install the driver: first insert the converter into the computer, then open the driver folder to find the driver of the corresponding
operating system, and click the exe file to install it. When the driver is successfully installed, unplug the converter and plug it
into the computer, the system will view a virtual serial port (such as: com5) in my computer device manager port to view Within
7, if the port number is too large it will affect the stability;
2) Set com port: set the virtual serial port number to the corresponding position of the software. If set to the COM port of the serial
debugging software;
3) Connect the hardware line, send data, the indicator light flashes during communication, and the USB converter works normally;
Download drive from ：
http://www.jlink-tech.com/file/1/15902 12345
Revision history
Version
Date
Remark
By
1.0
2019-3-11
First version
All
