Ecco ED3777 Series User manual

Installation and Operation Instructions
ED3777 Warning Light
1. Proper installation combined with operator training in the use, care, and maintenance of emergency warning devices are
essential to ensure the safety of you and those you are seeking to protect.
2. Exercise caution when working with live electrical connections.
3. This product must be properly grounded. Inadequate grounding and/or shorting of electrical connections can cause high
current arcing, which can cause personal injury and/or severe vehicle damage, including re.
4. Proper placement and installation are vital to the performance of this warning device. Install this product so that output
performance of the system is maximized and the controls are placed within convenient reach of the operator so that s/he
can operate the system without losing eye contact with the roadway.
5. Do not install this product or route any wires in the deployment area of an air bag. Equipment mounted or located in an air
bag deployment area may reduce the effectiveness of the air bag or become a projectile that could cause serious personal
injury or death. Refer to the vehicle owner’s manual for the air bag deployment area. It is the responsibility of the user/
operator to determine a suitable mounting location ensuring the safety of all passengers inside the vehicle particularly
avoiding areas of potential head impact.
6. It is the responsibility of the vehicle operator to ensure during use that all features of this product work correctly. In use,
the vehicle operator should ensure the projection of the warning signal is not blocked by vehicle components (i.e., open
trunks or compartment doors), people, vehicles or other obstructions.
7. The use of this or any other warning device does not ensure all drivers can or will observe or react to a warning signal.
Never take the right-of-way for granted. It is your responsibility to be sure you can proceed safely before entering an inter-
section, driving against trafc, responding at a high rate of speed, or walking on or around trafc lanes.
8. This equipment is intended for use by authorized personnel only. The user is responsiblefor understanding and obeying
all laws regarding warning signal devices. Therefore, the user should check all applicable city, state, and federal laws and
regulations. The manufacturer assumes no liability for any loss resulting from the use of this warning device.
Do not install and/or operate this safety product unless you have read and understand the safety informa-
tion contained in this manual.
WARNING!
Failure to install or use this product according to manufacturer's recommendations may result in property
damage, serious injury, and/or death to those you are seeking to protect!
ED3777 directional LEDs are bright and versatile 180
degree warning light, work light and puddle light combina-
tions that are suited to a wide variety of applications. Their
low prole, narrow shape and multiple mounting options
(surface, edge, self-adhesive and permanent) and 30
degrees of adjustable pivoting, provide superior exibiltiy
when positioning the lights for optimum warning capability.
Both models offer multiple ash patterns and multiple units
can be synchronized to operate either simultaneously or
alternately with each other.
Available in solid colors: ED3777X (A,B,R,G,W)
dual colors: ED3777XX (AB, AG, AR, AW, BW, RW, RB)
Page 1 of 9

Wire: ED3777
1 Light Head
1 Multi-Mount Base:
Includes-
2- M4x25 Sheet metal screws
2- Split washers
4- M3.5x10 screws
2- M3 washers
1 Adhesive Pad
1 1- EVA foam gasket
1 Edge Mount Bracket
1 Surface Mount Bezel
CONTENTS:
Input Voltage 12-24VDC
Work Current ED3777 = 1.8A Max @ DC12V
ED3777XX = 3.6A Max @ DC12V
SPECIFICATIONS:
Important! This unit is a safety device and it must be
connected to its own separate, fused power point to assure its
continued operation should any other electrical accessory fail.
Caution: When drilling into any vehicle surface, make sure the
area is free from any electrical wires, fuel lines, vehicle upholstery,
etc. that could be damaged
Mounting:
RED: Positive (need to add 2A Fuse)
BLACK: Negative
BLUE: Pattern Switch
YELLOW: Synchronized Function
(Up to 8 units can be Synchronized)
ORANGE: Takedown Light Operation (need to add 2A Fuse)
GREEN: Ground Light Operation (need to add 2A Fuse)
Operation Environment:
Ambient Temperature: -30 to 50°C
Wire: ED3777XX
RED: Positive, Colors 1 & 3 (need to add 5A Fuse)
WHITE: Positive, Colors 2 & 4 (need to add 5A Fuse)
BLACK: Negative
BLUE: Pattern Select to negative
YELLOW: Synchronized Function
(Up to 8 units can be Synchronized)
ORANGE: Takedown Light Operation (need to add 2A Fuse)
GREEN: Ground Light Operation (need to add 2A Fuse)
RED WHITE
PRODUCT 1 & 3 COLORS 2 & 4 COLORS
ED3777AW AMBER WHITE
ED3777BW BLUE WHITE
ED3777RB RED BLUE
ED3777RW RED WHITE
ED3777AG AMBER GREEN
ED3777AB AMBER BLUE
ED3777AR AMBER RED
Surface Mount
Edge Mount
Adhesive Mount
Permanent Mount
PHASE OPERATION:
Phase 1 (Ph1) ashes simultaneously with Ph1
Phase 2 (Ph2) ashed simultaneously with Ph2
(Up to 8 units can be Synchronized)
Apply BLUE TO BLACK wire:
-Less than 1 sec. for next pattern
-Between 1-3 sec. for previous pattern
-Between 3-5 sec. for factory default pattern
-More than 5 sec. default to pattern #13 (ED3777) and pattern
#12 (ED3777XX)
Page 2 of 9

WARNING!
When drilling into any vehicle surface, make sure the area is free from any electrical wires, fuel lines, vehicle upholstery, etc. that could
be damaged.
WARNING!
This unit is a safety device and it must be connected to its own seperate fused power point to assure its continued operation should
any other electrical accessory fail.
PATTERN MODE FLASH PATTERNS SYNC.
SAE J595 CA T13 SAE J845 ECE R65
RED AMBER BLUE WHITE RED AMBER BLUE RED AMBER BLUE WHITE RED AMBER BLUE
(140°) (140°) (140°) (100°)
ED3777X Series Flash Pattern Chart:
1
1Single Flash 75FPM
sim. Phase1 yes Class
1Class 1 Class
1Class 1 Class
BClass B Class
BClass 1 Class 1 Class 1 Class 1 N/C N/C N/C
2Single Flash 75FPM
sim. Phase2 yes Class
1Class 1 Class
1Class 1 Class
BClass B Class
BClass 1 Class 1 Class 1 Class 1 N/C N/C N/C
3Single Flash 75FPM
Alt. yes N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C
2
4Single Flash 120FPM
sim. Phase1 yes Class
1Class 1 Class
1Class 1 N/C N/C N/C Class 1 Class 1 Class 1 Class 1 Class
1Class 1 Class
1
5Single Flash 120FPM
sim. phase2 yes Class
1Class 1 Class
1Class 1 N/C N/C N/C Class 1 Class 1 Class 1 Class 1 Class
1Class 1 Class
1
6Single Flash 120FPM
Alt. yes N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C
3
7Double Flash 75FPM
sim. Phase1 yes Class
1Class 1 Class
1Class 1 N/C N/C N/C Class 1 Class 1 Class 1 Class 1 N/C N/C N/C
8Double Flash 75FPM
sim. phase2 yes Class
1Class 1 Class
1Class 1 N/C N/C N/C Class 1 Class 1 Class 1 Class 1 N/C N/C N/C
9Double Flash 75FPM
Alt. yes N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C
4
10 Double Flash
120FPM sim. Phase1 yes Class
1Class 1 Class
1Class 1 N/C N/C N/C Class 1 Class 1 Class 1 Class 1 Class
1Class 1 Class
1
11 Double Flash
120FPM sim. phase2 yes Class
1Class 1 Class
1Class 1 N/C N/C N/C Class 1 Class 1 Class 1 Class 1 Class
1Class 1 Class
1
12 Double Flash
120FPM Alt. yes N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C
5
13-De-
fault
Quad Flash 75FPM
sim. Phase1 yes Class
1Class 1 Class
1Class 2 N/C N/C N/C Class 1 Class 1 Class 1 Class 2 N/C N/C N/C
14 Quad Flash 75FPM
sim. Phase2 yes Class
1Class 1 Class
1Class 2 N/C N/C N/C Class 1 Class 1 Class 1 Class 2 N/C N/C N/C
15 Quad Flash 75FPM
Alt. yes N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C
6
16 Quad Flash 150FPM
sim. Phase1 yes Class
1Class 1 Class
1Class 2 N/C N/C N/C Class 1 Class 2 Class 2 Class 2 N/C N/C N/C
17 Quad Flash 150FPM
sim. Phase2 yes Class
1Class 1 Class
1Class 2 N/C N/C N/C Class 1 Class 2 Class 2 Class 2 N/C N/C N/C
18 Quad Flash 150FPM
Alt yes N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C
Page 3 of 9

7
19 Triple 75FPM sim.
Phase1 yes Class
1Class 1 Class
1Class 1 N/C N/C N/C Class 1 Class 1 Class 1 Class 1 N/C N/C N/C
20 Triple 75FPM sim.
Phase2 yes Class
1Class 1 Class
1Class 1 N/C N/C N/C Class 1 Class 1 Class 1 Class 1 N/C N/C N/C
21 Triple 75FPM Alt. yes N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C
8
22 Quint Flash 150FPM
sim. Phase1 yes Class
1Class 1 Class
1Class 2 N/C N/C N/C Class 1 Class 2 Class 2 Class 2 N/C N/C N/C
23 Quint Flash 150FPM
sim. Phase2 yes Class
1Class 1 Class
1Class 2 N/C N/C N/C Class 1 Class 2 Class 2 Class 2 N/C N/C N/C
24 Quint Flash 150FPM
Alt. yes N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C
9 25 Steady - Single NO N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C
10 26 Steady Burn NO N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C
11 27 Modulaon NO N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C
12 28 2 Double Flash,2
Triple Alt. NO N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C
13 29 4 Single Flash ,2
Quad Flash Alt. NO N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C N/C
PATTERN MODE FLASH PATTERNS SYNC.
SAE J595 CA T13 SAE J845 ECE R65
RED AMBER BLUE WHITE RED AMBER BLUE RED AMBER BLUE WHITE RED AMBER BLUE
(140°) (140°) (140°) (100°)
Page 4 of 9
