ECD SmartDRY SD Series Manual instruction

SD Series Dry Cabinets
Setup and Operation Manual

CONTENTS
Operators Safety Information.............................................................................. 1
Quick Start ........................................................................................................... 2
Safety and Installation ..................................................................................... 4
Location............................................................................................................ 4
filiment Reel Rack Configuration ..................................................................... 5
Power ............................................................................................................... 6
Time Settings.................................................................................................... 7
Clear History..................................................................................................... 9

OPERATORS SAFETY INFORMATION
The safety information in this section is for the benefit of operat-
ing personnel. Warnings and Cautions will also be found through-
out the manual where they apply.
The ECD SmartDRY™ Cabinet is ETL listed and self-de-
clared to meet the requirements of CE for the storage
of components at low relative humidity and tempera-
tures. It is not intended for the storage of flammable,
volatile or combustible materials. These units have
been tested per the requirements indicated in topic:
Declaration of Conformity.
Hardware changes or modifications to the ECD SmartDRY™ Cabi-
net or components are not expressly approved by ECD and could
void the warranty.
THE WARRANTY WILL NOT COVER DAMAGE CAUSED
BY NEGLECT OR ABUSE OF ANY ECD PRODUCTS. TO
MAINTAIN THE SAFETY FEATURES INCORPORATED,
OPERATION MUST BE IN STRICT COMPLIANCE WITH
THE REQUIREMENTS SPECIFIED HEREIN.
Make sure you have read and follow the 4.0 Operators Safety In-
formation and 5.0 Setup & Installation recommendations of the
Setup and Operation Manual for additional information.

SmartDRY™ 3D Quick Start Guide | A62-3337-16 REV: 1.0.0 Page 2
QUICK START
This Quick Start Guide is designed to help the user to familiarize
themselves with the equipment and perform basic setup. For de-
tailed information, please refer to the Setup and Operation Man-
ual.
The ECD SmartDRY™ Cabinet is ready to plug in and begin using as
soon as it is safely set up. No additional programming is required.
Once unpacked, here are some steps to quickly get your Cabinet
up and running.
Although pre-programmed, the Cabinet must run for a minimum
of 8 hours to acclimate and regenerate its dryer module. Please
allow this time before adding your filiment. Also, the alarm limits
have been pre-programmed however, are not enabled. Once the
Cabinet has stabilized at set point, the alarms can be enabled if
desired. You may also want to explore the other Alarms:
SmartDRY™ Temperature, SmartBAKE™ RH, and SmartBAKE™
Temperature, enabling them as you wish. Refer to section 9.1.2
Alarms (SmartDRY™) in the Setup and Operation Manual for de-
tailed information.

SmartDRY™ 3D Quick Start Guide | A62-3337-16 REV: 1.0.0 Page 3
WHEN ACCESSING OPTIONS THAT REQUIRE A
PASSCODE THE SYSTEM DEFAULT PASSCODE IS 314. AS
YOU ENTER PROTECTED OPTIONS, YOU WILL BE
PROMPTED TO ENTER IT USING THE UP OR DOWN
BUTTONS. ONCE SELECTED, ALL LOCKED OPTIONS RE-
MAIN “UNLOCKED” UNTIL YOU RETURN TO THE MAIN
DISPLAY.
1) When prompted, Press and hold the Up or
Down button to navigate to Passcode 314. Press
the OK button to be able to edit the protected
field.

SmartDRY™ 3D Quick Start Guide | A62-3337-16 REV: 1.0.0 Page 4
SAFETY AND INSTALLATION
Make sure you have read and follow the 4.0 Operators Safety In-
formation and 5.0 Setup recommendations in the of the ECD
SmartDRY™ SD Series Dry Cabinets Setup and Operation Manual.
LOCATION
Move the ECD SmartDRY™ Cabinet into the desired position.
When selecting a site for the Cabinet, consider conditions which
may affect performance, such as heat from radiators, ovens, pro-
duction equipment, etc. Avoid direct sun, fast-moving air cur-
rents, heating/cooling ducts etc. To ensure air circulation, allow a
minimum of 75 mm (3”) between the unit and any walls or parti-
tions which might obstruct free air flow.

SmartDRY™ 3D Quick Start Guide | A62-3337-16 REV: 1.0.0 Page 5
FILIMENT REEL RACK CONFIGURATION
Install the filiment reel racks to meet your storage requirements.

SmartDRY™ 3D Quick Start Guide | A62-3337-16 REV: 1.0.0 Page 6
POWER
Connect to properly grounded power plug.

SmartDRY™ 3D Quick Start Guide | A62-3337-16 REV: 1.0.0 Page 7
TIME SETTINGS
Set the Real Time Clock and ALL time settings for your location.
To set the Time:
1) From the Main Display, enter the Main menu by pressing
the Menu button. enter the Other Settings menu by press-
ing the Settings button.
2) Enter the Date/Time Settings by pressing the Time button.

SmartDRY™ 3D Quick Start Guide | A62-3337-16 REV: 1.0.0 Page 8
3) Edit the desired settings selecting the OK button to accept
each edited value.
4) To exit the screen, select the Back button which takes you
“Back” to the previous menu.

SmartDRY™ 3D Quick Start Guide | A62-3337-16 REV: 1.0.0 Page 9
CLEAR HISTORY
Clear the stored memory. Performing this step clears unwanted
data and starts logging data new data from this point on.
To clear history:
1) From the Main Display, enter the Main menu by pressing
the Menu button. enter the Other Settings menu by press-
ing the Settings button.
2) Enter the Data Logging Settings by pressing the button.
Press the Clear History button.
3) To exit the screen, select the Back button which takes you
“Back” to the previous menu.
