Safety Instructions
Levelflex
FMP51/52/53/54/55/56/57
PROFIBUS PA
Zone 0/1 Ex ia IIC T6 Ga/Gb
Zone 20/21 Ex iaD 20/21 T*
en - Document: XA00644F-A
Safety instructions for electrical apparatus for explosion-hazardous areas
Èä3
zh - 文档：XA00644F-A
爆炸环境中电气仪表的安全指南
Èä11

Levelflex FMP51/52/53/54/55/56/57 XA00644F-A
2Endress+Hauser

XA00644F-A Levelflex FMP51/52/53/54/55/56/57
Endress+Hauser 3
Levelflex
FMP51/52/53/54/55/56/57
PROFIBUS PA
Table of Contents
Associated documentation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Supplementary documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Manufacturer's certificates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Extended order code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Safety instructions: General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Safety instructions: Special conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Safety instructions: Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Safety instructions: Zone 0 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Temperature tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Connection data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Levelflex FMP51/52/53/54/55/56/57 XA00644F-A
4Endress+Hauser
Associated documentation This document is an integral part of the following Operating Instructions:
BA01006F/00 (FMP51/52/54), BA01007F/00 (FMP53), BA01008F/00 (FMP55),
BA01009F/00 (FMP56/57)
The Operating Instructions pertaining to the device apply.
Supplementary
documentation
Explosion-protection brochure:
CP021Z/00
The Explosion-protection brochure is available:
• In the download area of the Endress+Hauser website: www.endress.com →Download →Advanced →
Documentation Code: CP021Z
• On the CD for devices with CD-based documentation
Manufacturer's certificates NEPSI Declaration of Conformity
Certificate number:
GYJ11.1553X
Affixing the certificate number certifies conformity with the standards:
• GB3836.1-2010
• GB3836.4-2010
• GB12476.1-2000
• GB12476.4-2010, with the following standard under www.IECEx.com:
- IEC61241-0:2004
Extended order code The extended order code is indicated on the nameplate, which is affixed to the device in such a way that it is
clearly visible. Additional information about the nameplate is provided in the associated Operating Instructions.
Structure of the extended order code
• Basic specifications
The features that are absolutely essential for the device (mandatory features) are specified in the basic
specifications. The number of positions depends on the number of features available.
The selected option of a feature can consist of several positions.
• Optional specifications
The optional specifications describe additional features for the device (optional features). The number of
positions depends on the number of features available.
The features have a 2-digit structure to aid identification (e.g. JA). The first digit (ID) stands for the feature
group and consists of a number or a letter (e.g. J = test, certificate).
The second digit constitutes the value that stands for the feature within the group (e.g. A = 3.1 material
(wetted parts), inspection certificate).
More detailed information about the device is provided in the following tables. These tables describe the
individual positions and IDs in the extended order code which are relevant to hazardous locations.
FMP5x - ************* + A*B*C*D*E*F*G*..
------------------ ------------------------ ------------------------------
Device type Basic specifications Optional specifications
* = Placeholder
At this position, an option (number or letter) selected from the specification is displayed instead of the
placeholders.

XA00644F-A Levelflex FMP51/52/53/54/55/56/57
Endress+Hauser 5
Device type: FMP51, FMP52, FMP53, FMP54, FMP55, FMP56, FMP57
Basic specifications
Optional specifications
Position Selected option Description
1, 2 Approval N2 Zone 0/1 Ex ia IIC T6 Ga/Gb,
Zone 20/21 Ex iaD 20/21 T*
3 Power Supply; Output G 2-wire, PROFIBUS PA
4 Display; Operation A
C
Without LCD, via communication
LCD SD02, push button + data backup function
5Housing B
C
Dual compartment, 316L (GT18)
Dual compartment, Alu coated (GT20)
9, 10 Seal AB (only FMP56)
A4 (only FMP51/57)
B3 (only FMP51/56/57)
B5 (only FMP53)
C3 (only FMP51)
C4 (only FMP53)
D1 (only FMP54)
D2 (only FMP54)
Viton, –30...120 °C
Viton, –30...150 °C
EPDM, –40...120 °C
EPDM, FDA, USP Cl. VI, –20..130 °C
Kalrez, –20...200 °C
Kalrez, FDA, USP Cl. VI, –20...150 °C
Graphite, –196...280 °C (XT)
Graphite, –196...450 °C (HT)
ID Selected option Description
Mx Probe Design MA (only FMP53)
MB
MC (only FMP53)
ME (only FMP51/54)
Sensor compact, detachable
Sensor remote, 3 m/9 ft cable, detachable +
mounting bracket
Sensor remote, 6 m/18 ft cable, detachable +
mounting bracket
Coax ground tube multiple punched
Nx Accessory Mounted NC (only FMP51/52/55) Gas-tight feed through

Levelflex FMP51/52/53/54/55/56/57 XA00644F-A
6Endress+Hauser
Safety instructions:
General
• Staff must meet the following conditions for mounting, electrical installation, commissioning and
maintenance of the device:
- Be suitably qualified for their role and the tasks they perform
- Be trained in explosion protection
- Be familiar with national regulations
• For installation, use and maintenance of the device, users must also observe the requirements stated in the
Operating Instructions and the standards:
- GB50257-1996: "Code for construction and acceptance of electric device for explosion atmospheres and
fire hazard electrical equipment installation engineering".
- GB3836.13-1997: "Electrical apparatus for explosive gas atmospheres, Part 13: Repair and overhaul for
apparatus used in explosive gas atmospheres".
- GB3836.15-2000: "Electrical apparatus for explosive gas atmospheres, Part 15: Electrical installations in
hazardous area (other than mines)".
- GB3836.16-2006: "Electrical apparatus for explosive gas atmospheres, Part 16: Inspection and
maintenance of electrical installation (other than mines)".
- GB15577-2007: "Safety regulations for dust explosive prevention and protection".
- GB12476.2-2006: "Electrical apparatus for use in the presence of combustible dust,
Part 1-2: Electrical apparatus protected by enclosures and surface temperature limitation -
Selection, installation and maintenance".
• Install the device according to the manufacturer's instructions and national regulations.
• Do not operate the device outside the specified electrical, thermal and mechanical parameters.
• Only use the device in media to which the wetted materials have sufficient durability.
• Refer to the temperature tables for the relationship between the permitted ambient temperature for the
sensor and/or transmitter, depending on the range of application, and the temperature class.
• Modifications to the device can affect the explosion protection and must be carried out by staff authorized
to perform such work by Endress+Hauser.
• When replacing the probe electronics or opening the connection between the remote cable and the probe,
a jumper plug must be used or a short-circuit must be established between the probe contact and the
potential equalization conductor to avoid electrostatically charging the probe.
• After mounting and connecting the probe, ingress protection of the housing must be at least IP66.
Perform the following to achieve the degree of protection:
- Screw the cover tight.
- Mount the cable entry correctly.
• When using in hybrid mixtures (gas and dust occurring simultaneously), observe additional measures for
explosion protection.
Safety instructions:
Special conditions
Permitted ambient temperature range at the electronics housing: –40 °C ≤Ta≤+80 °C.
Observe the information in the temperature tables.
Device type FMP52, FMP55
• A probe coated with non-conductive material can be used if avoiding electrostatic charging of the probe
(e.g. through friction, cleaning, maintenance, strong medium flow).

XA00644F-A Levelflex FMP51/52/53/54/55/56/57
Endress+Hauser 7
Safety instructions:
Installation
XA00634Fxx01
å1
A
Zone 1, Zone 21
1 Tank; Zone 0/1 or Zone 20/21
2 Electronic insert
3 Certified associated apparatus
4 Potential equalization line
5 Potential equalization
• In the case of process connections made of polymeric material or with polymeric coatings, avoid electrostatic
charging of the plastic surfaces.
• After aligning (rotating) the housing, retighten the fixing screw (see Operating Instructions).
• When mounting the device:
- Exclude any mechanical damage or friction during the application.
- Pay particular attention to flow conditions and tank fittings.
• Continuous service temperature of the connecting cable: –40 to ≥+85 °C; in accordance with the range of
service temperature taking into account additional influences of the process conditions
(Ta,min and Ta,max +20 K).
• In the event of additional or alternative special varnishing on the housing or other metal parts:
- Observe the danger of electrostatic charging and discharge.
- Do not rub surfaces with a dry cloth.
• Only use certified cable entries or sealing plugs.
The metal sealing plugs supplied meet this requirement.
• Before operation:
- Screw in the cover all the way.
- Tighten the securing clamp on the cover.
Intrinsic safety
• The device is only suitable for connection to certified, intrinsically safe equipment with explosion protection
Ex ia / Ex ib.
• The intrinsically safe input power circuit of the device is isolated from ground. If the device is only equipped
with one input, the dielectric strength of the input is at least 500 Vrms. If the device is equipped with more
than one input, the dielectric strength of each individual input to ground is at least 500 Vrms, and the
dielectric strength of the inputs vis-à-vis one another is also at least 500 Vrms.
• Observe the pertinent guidelines when interconnecting intrinsically safe circuits (GB3836.13, GB3836.15,
GB3836.16).
• The device can be connected to the Endress+Hauser FXA291 service tool: refer to the Operating
Instructions.
• When the intrinsically safe Ex ia circuits of the device are connected to certified intrinsically safe circuits of
Category Ex ib for Equipment Groups IIC or IIB, the type of protection changes to Ex ib[ia] IIC or Ex ib[ia] IIB.
Regardless of the power supply, all the internal circuits correspond to Ex ia IIC type of protection (e.g. service
interface, external display, sensor).
A
–
+
1
2
4
4
5
3

Levelflex FMP51/52/53/54/55/56/57 XA00644F-A
8Endress+Hauser
Potential equalization
• Integrate the device into the local potential equalization.
• For grounding the screen → å2.
XA00640Fxx02
å2
A
Version 1
Use small capacitors (e.g. 1 nF, 1500 V, dielectric strength, ceramic).
Total capacitance connected to the screen may not exceed 10 nF.
B
Version 2
1 Terminating resistor
2 Distributor/T box
3 Screen insulated
4 Supply unit/Segment coupler
5 Potential equalization (secured in high degree)
6 Field device
Overvoltage protection
• For installations which require overvoltage protection to comply with national regulations or standards
(GB3836.13, GB3836.15, GB3836.16), install the device using overvoltage protection (e.g. HAW56x from
Endress+Hauser).
• Observe the safety instructions of the overvoltage protection.
221
C
6 6
4
A
B
3
4
5

XA00644F-A Levelflex FMP51/52/53/54/55/56/57
Endress+Hauser 9
Safety instructions:
Zone 0
• In the event of potentially explosive vapor/air mixtures, only operate the device under atmospheric
conditions.
- Temperature: –20 to +60 °C
- Pressure: 80 to 110 kPA (0.8 to 1.1 bar)
- Air with normal oxygen content, usually 21 % (V/V)
• Associated devices with galvanic isolation between the intrinsically safe and non-intrinsically safe circuits are
preferred.
• If there is a risk of dangerous potential differences within Zone 0 (e.g. through the occurrence of atmospheric
electricity), implement suitable measures for intrinsically safe circuits in Zone 0 (e.g. in accordance with the
requirements of GB3836.13, GB3836.15, GB3836.16).
Temperature tables Èä19
Connection data Basic specification, Position 1, 2 (Approval) = N2
Ex ia
• Power supply and signal circuit with protection type: intrinsic safety Ex ia IIC or IIB
Service interface (CDI)
Taking the following values into consideration, the device can be connected to the Endress+Hauser FXA291
service tool or a similar interface:
Basic specification, Position 3 (Power Supply; Output) = G TRC [06]
Terminal 1 (+), 2 (–) Terminal 3 (+), 4 (–)
FISCO: Entity: Ausgang PFS:
Ui= 17.5 V
Ii= 550 mA
Pi= 5.5 W
Ui= 30 V
Ii≤ 300 mA
Pi= 1.2 W
Ui= 30 V
Ii= 300 mA
Pi= 1 W
Uo= 0 V
effective inner inductance Li= 10 μH
effective inner capacitance Ci= 5 nF
leak current ≤ 50 μA
effective inner inductance Li= 0 mH
effective inner capacitance Ci= 24 nF
Service interface
Ui= 7.3 V
effective inner inductance Li= negligible
effective inner capacitance Ci= negligible
Uo= 7.3 V
Io= 100 mA
Po= 160 mW
permitted outer inductance Lo= negligible
permitted outer capacitance Co= negligible

Levelflex FMP51/52/53/54/55/56/57 XA00644F-A
10 Endress+Hauser

XA00644F-A Levelflex FMP51/52/53/54/55/56/57
Endress+Hauser 11
Levelflex
FMP51/52/53/54/55/56/57
PROFIBUS PA
目录
相关资料 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
辅助文档 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
制造商证书 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
扩展订货号 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
安全指南：概述 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
安全指南：特殊条件 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
安全指南：安装 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
安全指南：区域 0 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
温度表 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
连接数据 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Levelflex FMP51/52/53/54/55/56/57 XA00644F-A
12 Endress+Hauser
相关资料 本文档是下列操作手册的组成部分：
BA01006F/00 (FMP51/52/54), BA01007F/00 (FMP53), BA01008F/00 (FMP55),
BA01009F/00 (FMP56/57)
应遵守设备的操作手册。
辅助文档 防爆手册：
CP021Z/00
防爆手册获取方式：
• Endress+Hauser 网站的下载区：www.endress.com →Download →Advanced →文档代码：CP021Z
•设备的文档光盘
制造商证书 NEPSI 一致性声明
证书编号：
GYJ11.1553X
粘贴证书编号，证明符合标准：
• GB3836.1-2010
• GB3836.4-2010
• GB12476.1-2000
• GB12476.4-2010，满足 www.IECEx.com 中的下列标准：
- IEC61241-0:2004
扩展订货号 扩展订货号标注在铭牌上，铭牌粘贴在设备醒目处。关于铭牌的附加信息请见相关操作手册。
扩展订货号的结构
•基本规格
设备的关键功能 (强制功能 )在基本规格中指定。位置数目取决于可用功能的数目。
从一个功能选择的可选规格可占据多个位置。
•可选规格
可选规格描述了设备的附加功能 (可选功能 )。位置数目取决于可用功能的数目。
功能采用 2位结构帮助识别 (例如， JA)。第一位 (ID) 代表功能组，包含一个数字或字母
(例如， J = 测试 , 证书 )。
第二位则是代表组内功能的值 (例如， A = 3.1 型材料 (接液部件 ), 检验证书 )。
关于设备的详细信息请见下列表格。这些表格描述了扩展订货号的各个位置和 ID，它们与危险场
所有关。
FMP5x - ************* + A*B*C*D*E*F*G*..
------------------ ------------------------ ------------------------------
设备类型 基本规格 可选规格
* = 占位符
此位置显示所选的规格选项 (数字或字母 )，而不是占位符。

XA00644F-A Levelflex FMP51/52/53/54/55/56/57
Endress+Hauser 13
设备类型：FMP51, FMP52, FMP53, FMP54, FMP55, FMP56, FMP57
基本规格
可选规格
位置 选中的可选规格 描述
1, 2 认证 N2 区域 0/1 Ex ia IIC T6 Ga/Gb,
区域 20/21 Ex iaD 20/21 T*
3电源；输出 G两线制 , PROFIBUS PA
4显示屏；运行 A
C
无LCD, 通过通信
LCD SD02, 按钮 +数据备份功能
5外壳 B
C
双接线柜 , 316L (GT18)
双接线柜 , 镀铝 (GT20)
9, 10 密封 AB ( 仅FMP56)
A4 ( 仅FMP51/57)
B3 ( 仅FMP51/56/57)
B5 ( 仅FMP53)
C3 ( 仅FMP51)
C4 ( 仅FMP53)
D1 ( 仅FMP54)
D2 ( 仅FMP54)
VITON, -30...120 °C
VITON, -30...150 °C
EPDM, -40...120 °C
EPDM, FDA, USP Cl. VI, -20..130 °C
Kalrez, -20...200 °C
Kalrez, FDA, USP Cl. VI, -20..150 °C
石墨 , -196...280 °C (XT)
石墨 , -196...450 °C (HT)
ID 选中的可选规格 描述
Mx 探针设计 MA ( 仅FMP53)
MB
MC ( 仅FMP53)
ME ( 仅FMP51/54)
紧凑拆卸型传感器
远程传感器 , 3 m/9 ft 电缆 , 拆卸型 +安装架
远程传感器 , 6 m/18 ft 电缆 , 拆卸型 +安装架
多孔同轴接地管
Nx 附件已安装 NC ( 仅FMP51/52/55) 气密馈通

Levelflex FMP51/52/53/54/55/56/57 XA00644F-A
14 Endress+Hauser
安全指南：
概述
•安装电气装置 , 调试和维护设备的人员必须满足下列规定：
-具备合适资格，能适应其职责和所执行任务的要求
-接受防爆培训
-熟悉国家法规
•在安装 , 使用和维护设备时，用户必须遵守操作手册和下列标准中规定的要求：
- GB50257-1996：“电气设备安装工程 爆炸和火灾危险环境电气装置施工及验收规范”。
- GB3836.13-1997：“爆炸性气体环境用电气设备 第13 部分：爆炸性气体环境用电气设备的
检修”。
- GB3836.15-2000：“爆炸性气体环境用电气设备 第15 部分：危险场所电气安装 (煤矿除外 )”。
- GB3836.16-2006：“爆炸性气体环境用电气设备 第16 部分：电气装置的检查和维护
(煤矿除外 )”。
- GB15577-2007：“粉尘防爆安全规程”。
- GB12476.2-2006：“可燃性粉尘环境用电气设备 第1-2 部分：用外壳和限制表面温度保护的电
气设备 - 电气设备的选择 , 安装和维护”。
•根据制造商的说明和国家规章安装设备。
•使用设备时请勿超出指定的电 , 热和机械参数。
•当设备的接液部件对介质具有足够耐久性时，才可在介质中使用设备。
•关于在不同应用范围和温度组别下，传感器和 /或变送器允许的环境温度，请参考温度表。
•对设备进行改装可能会影响其防爆能力，必须由获得 Endress+Hauser 授权的人员进行。
•在更换探针电子部件或打开远程电缆和探针之间的连接时，必须使用跳线插头或者将探针触点
和接地导体短接，避免对探针静电充电。
•在安装并连接探针之后，外壳的 IP 防护等级必须至少达到 IP66。
完成下列操作，实现所需的防护等级：
-拧紧盖子。
-正确安装电缆入口。
•当用于混杂环境 (同时有气体和粉尘 )中时，应遵守附加的防爆措施。
安全指南：
特殊条件
电子部件外壳处的允许的环境温度范围：-40 °C ≤Ta≤+80 °C。
应遵守温度表中的信息。
设备类型 FMP52, FMP55
•为避免探针静电充电 (例如，由于摩擦 , 清洁 , 维护 , 强介质流 )，可使用镀有不导电材料的
探针。

XA00644F-A Levelflex FMP51/52/53/54/55/56/57
Endress+Hauser 15
安全指南：
安装
XA00634Fxx01
å1
A
区域 1, 区域 21
1液罐；区域 0/1 或区域 20/21
2电子插件
3经认证的关联设备
4电位均衡线
5电位均衡
•对于由聚合材料制成的或有聚合材料涂层的过程连接，应避免塑料表面静电充电。
•在对齐 (旋转 )外壳后，重新拧紧固定螺丝 (参见操作说明 )。
•在安装设备时：
-避免应用期间发生任何机械损坏或摩擦。
-尤其要注意流量状况和液罐装置。
•连接电缆的连续工作温度：-40 至≥+85 °C ；根据工作温度范围，考虑过程条件的附加影响
(Ta,min 和Ta,max +20 K)。
•如果外壳或金属部件上有其他特殊涂漆：
-请注意静电充电和放电危险。
-请勿用干布擦拭表面。
•仅用于经过认证的电缆入口或密封塞。
提供的金属密封塞满足该要求。
•在运行之前：
-将盖子拧紧到底。
-拧紧盖子上的固定夹。
本安型
•设备仅适合连接到经认证的 , 防爆等级为 Ex ia/Ex ib 的本质安全型设备上。
•设备的本质安全型输入电源电路与地电势在电气上隔离。如果设备仅配有一个输入，输入的绝
缘强度至少应达到 500 Vrms。如果设备配有一个以上输入，每个输入的对地绝缘强度至少要达到
500 Vrms，各个输入之间的绝缘强度也至少要达到 500 Vrms。
•在互连本安型电路 (GB3836.13, GB3836.15, GB3836.16) 时，应遵守相关的指导方针。
•可将设备连接到 Endress+Hauser FXA291 维修工具：参考相应操作说明。
•如果将设备的Ex ia类本安型电路连接到经过认证的IIC或IIB设备组的 Ex ib 类本安型电路上，则需
要将防护类型改为 Ex ib[ia] IIC 或Ex ib[ia] IIB。
不管电源情况如何，所有内部电路都要符合 Ex ia IIC 防护类型 (例如，维修接口 , 外部显示屏 ,
传感器 )。
A
–
+
1
2
4
4
5
3

Levelflex FMP51/52/53/54/55/56/57 XA00644F-A
16 Endress+Hauser
电位均衡
•将设备集成到本地电位均衡系统。
•用于屏蔽接地 → å2。
XA00640Fxx02
å2
A
版本 1
使用小型电容器 (例如 1 nF, 1500 V, 绝缘强度 , 陶瓷 )。
连接到屏蔽的总电容不得超过 10 nF。
B 版本 2
1终端电阻
2配电盘 /接线盒
3屏蔽层绝缘
4电源单元 /分段耦合器
5电位均衡 (保持在高等级 )
6现场设备
过电压保护
•对于为了遵守国家规章或标准 (GB3836.13, GB3836.15, GB3836.16) 而需要采用过电压保护的安装
情况，安装设备时应使用过电压保护装置 (例如， Endress+Hauser 的HAW56x)。
•请遵守过电压保护安全指南。
221
C
6 6
4
A
B
3
4
5

XA00644F-A Levelflex FMP51/52/53/54/55/56/57
Endress+Hauser 17
安全指南：
区域 0
•若环境空气为存在爆炸性危险的空气蒸汽混合气，则仅可在大气条件下操作设备。
-温度：-20 至+60 °C
-压力：80 至110 kPA (0.8 至1.1 bar)
-具有正常氧含量 (通常为 21 % (V/V)) 的空气
•本安型电路和非本安型电路之间最好采用电气隔离的关联设备。
•如果在区域0中有存在危险电位差的风险(例如，由于出现大气电)，必须为区域0中的本安型电路
采取适当的应对措施 (例如，按照 GB3836.13, GB3836.15, GB3836.16 的指导进行 )。
温度表 Èä19
连接数据 基本规格，位置 1, 2 ( 认证 ) = N2
Ex ia
•电源和信号电路的防护类型：本安型 Ex ia IIC 或IIB
维修接口 (CDI)
在考虑了下列值之后，可将设备连接到 Endress+Hauser FXA291 维修工具或类似的接口：
基本规格，位置 3 ( 电源；输出 ) = G TRC [06]
端子 1 (+), 2 (-) 端子 3 (+), 4 (-)
FISCO： 实体： 输出端 PFS：
Ui= 17.5 V
Ii= 550 mA
Pi= 5.5 W
Ui= 30 V
Ii≤ 300 mA
Pi= 1.2 W
Ui= 30 V
Ii= 300 mA
Pi= 1 W
Uo= 0 V
有效内部电感 Li= 10 μH
有效内部电容 Ci= 5 nF
泄漏电流 ≤ 50 μA
有效内部电感 Li= 0 mH
有效内部电容 Ci= 24 nF
维修服务接口
Ui= 7.3 V
有效内部电感 Li= 可忽略
有效内部电容 Ci= 可忽略
Uo= 7.3 V
Io= 100 mA
Po= 160 mW
允许的外部电感 Lo= 可忽略
允许的外部电容 Co= 可忽略

Levelflex FMP51/52/53/54/55/56/57 XA00644F-A
18 Endress+Hauser

XA00644F-A Levelflex FMP51/52/53/54/55/56/57
Endress+Hauser 19
Tables / 表
Temperature tables Unless otherwise indicated, the positions always refer to the basic specification.
!Note!
Observe the permitted probe temperature range.
温度表 除非另有说明，否则位置始终参考基本规格。
!注意 !
请遵守允许的探针温度范围。
XA00634Fxx02
å3
A
Version / 类型 1
B Version / 类型 2
*1= Functional
Max. permissible process temperature
*1= 功能型
最大允许的过程温度
Ta
Ta
Tp
Tp
P1
P1
P2
P2
P5
P5
P6
P3
P3
P4
P4
A
B

Levelflex FMP51/52/53/54/55/56/57 XA00644F-A
20 Endress+Hauser
Probe and electronics housing: Zone 1 / 探针和电子部件外壳：区域 1
FMP51
Position / 位置 5 (Housing / 外壳 ) = B
Position / 位置 3
(Power Supply; Output /
电源；输出 ) =
Temperature class /
温度组别
P 1 P 2 P 3 P 4 P 5 P 6
TpTaTpTaTpTaTpTaTpTaTpTa
1 canal used /
使用了 1个槽
T6 ( 85 °C) –40 °C 60 °C 60 °C 60 °C 85 °C 51 °C 85 °C –40 °C –40 °C –40 °C - -
T5 (100 °C) –40 °C 73 °C 73 °C 73 °C 100 °C 66 °C 100 °C –40 °C –40 °C –40 °C - -
T4 (135 °C) –40 °C 73 °C 73 °C 73 °C 135 °C 57 °C 135 °C –40 °C –40 °C –40 °C - -
T3 (200 °C) –40 °C 73 °C 73 °C 73 °C 200 °C 42 °C 200 °C –40 °C –40 °C –40 °C - -
2 canal used /
使用了 2个槽
T6 ( 85 °C) –40 °C 56 °C 56 °C 56 °C 85 °C 49 °C 85 °C –40 °C –40 °C –40 °C - -
T5 (100 °C) –40 °C 61 °C 61 °C 61 °C 100 °C 52 °C 100 °C –40 °C –40 °C –40 °C - -
T4 (135 °C) –40 °C 61 °C 61 °C 61 °C 135 °C 44 °C 135 °C –40 °C –40 °C –40 °C - -
T3 (200 °C) –40 °C 61 °C 61 °C 61 °C 200 °C 28 °C 200 °C –40 °C –40 °C –40 °C - -
Position / 位置 5 (Housing / 外壳 ) = C
Position / 位置 3
(Power Supply; Output /
电源；输出 ) =
Temperature class /
温度组别
P 1 P 2 P 3 P 4 P 5 P 6
TpTaTpTaTpTaTpTaTpTaTpTa
1 canal used /
使用了 1个槽
T6 ( 85 °C) –40 °C 60 °C 60 °C 60 °C 85 °C 53 °C 85 °C –40 °C –40 °C –40 °C - -
T5 (100 °C) –40 °C 73 °C 73 °C 73 °C 100 °C 67 °C 100 °C –40 °C –40 °C –40 °C - -
T4 (135 °C) –40 °C 73 °C 73 °C 73 °C 135 °C 60 °C 135 °C –40 °C –40 °C –40 °C - -
T3 (200 °C) –40 °C 73 °C 73 °C 73 °C 200 °C 47 °C 200 °C –40 °C –40 °C –40 °C - -
2 canal used /
使用了 2个槽
T6 ( 85 °C) –40 °C 56 °C 56 °C 56 °C 85 °C 50 °C 85 °C –40 °C –40 °C –40 °C - -
T5 (100 °C) –40 °C 61 °C 61 °C 61 °C 100 °C 54 °C 100 °C –40 °C –40 °C –40 °C - -
T4 (135 °C) –40 °C 61 °C 61 °C 61 °C 135 °C 47 °C 135 °C –40 °C –40 °C –40 °C - -
T3 (200 °C) –40 °C 61 °C 61 °C 61 °C 200 °C 34 °C 200 °C –40 °C –40 °C –40 °C - -
