Echo 99944200490 User manual

Specifications, descriptions and illustrative material in this literature are as accurate as known at the time
of publication, but are subject to change without notice. Illustrations may include optional equipment and
accessories, and may not include all standard equipment.
Operator’s Manual
X7702095403
© 10/2013 ECHO Inc.
x7722271404 / x772000164
99944200490
Power Blower Attachment
FOR MODELS: SRM-2100SB, 2400SB, 210SB, 211SB, 225SB,
260SB, 261SB, PAS-2100, 2400, 2601, 210, 211, 225, 225VP,
225VPB, 230, 231, 260, 261, 265, 266, 280
Users of this equipment risk injury to themselves and others if the unit is used
improperly and/or safety precautions are not followed. ECHO provides an operator’s
manual. It must be read and understood for proper and safe operation. Failure to do so
could result in serious injury.

2X7702095403
© 10/2013 ECHO Inc.
TABLE OF CONTENTS 99944200490
TABLE OF CONTENTS
Table of Contents .............................................................................................................................. 2
Introduction ........................................................................................................................................ 3
The Operator’s Manual ................................................................................................................ 3
Servicing Information ......................................................................................................................... 3
Parts/Serial Number..................................................................................................................... 3
Service......................................................................................................................................... 3
Echo Consumer Product Support ................................................................................................ 3
Warranty Registration .................................................................................................................. 3
Additional or Replacement Manuals ............................................................................................ 3
Safety................................................................................................................................................. 4
Manual Safety Symbols and Important Information..................................................................... 4
International Symbols .................................................................................................................. 5
Personal Condition and Safety Equipment .................................................................................. 5
Equipment.................................................................................................................................... 8
Description......................................................................................................................................... 9
Contents .......................................................................................................................................... 10
Assembly ......................................................................................................................................... 11
Power Head Shaft/Lower Shaft Assembly................................................................................. 11
Operation ......................................................................................................................................... 12
Operating Blower ....................................................................................................................... 12
Maintenance .................................................................................................................................... 13
Skill Levels................................................................................................................................. 13
Maintenance Intervals................................................................................................................ 13
Storage ............................................................................................................................................ 14
Storage Hook Installation........................................................................................................... 14
Specifications................................................................................................................................... 15
Warranty Statements ....................................................................................................................... 16
Notes ............................................................................................................................................... 18

99944200490 INTRODUCTION
© 10/2013 ECHO Inc.
X7702095403 3
INTRODUCTION
Welcome to the ECHO family. This ECHO product was designed and manufactured to provide long life and
on-the-job dependability. Read and understand this manual. You will find it easy to use and full of helpful
operating tips and SAFETY messages.
The Operator’s Manual
Keep it in a safe place for future reference. Contains specifications and information for safety, operation,
maintenance, storage and assembly specific to this product.
SERVICING INFORMATION
Parts/Serial Number
Genuine ECHO Parts and ECHO REPOWER™ Parts and
Assemblies for your ECHO products are available only from an
Authorized ECHO Dealer. When you do need to buy parts always
have the Model Number and Serial Number of the unit with you. You
can find these numbers on the engine housing. For future
reference, write them in the space provided below.
Model No. _________________ SN. ___________________
Service
Service of this product during the warranty period must be performed by an Authorized ECHO Service
Dealer. For the name and address of the Authorized ECHO Service Dealer nearest you, ask your retailer or
call: 1-800-432-ECHO (3246). Dealer information is also available on our Web Site. When presenting your
unit for Warranty service/repairs, proof of purchase is required.
Echo Consumer Product Support
If you require assistance or have questions concerning the application, operation or maintenance of this
product you may call the ECHO Consumer Product Support Department at 1-800-673-1558 from 8:30 am to
4:30 pm (Central Standard Time) Monday through Friday. Before calling, please know the model and serial
number of your unit.
Warranty Registration
To ensure trouble free warranty coverage it is important that you register your ECHO equipment on-line at
www.echo-usa.com or by filling out the warranty registration card supplied with your unit. Registering your
product confirms your warranty coverage and provides a direct link between you and ECHO if we find it
necessary to contact you.
Additional or Replacement Manuals
Replacement Operator, Safety Manuals, and Parts Catalogs
are available from your ECHO dealer or at www.echo-usa.com
or by contacting ECHO Inc., 400 Oakwood Road, Lake Zurich,
IL 60047 (800-673-1558). Always check the ECHO Web Site for
updated information.
For more information
scan this QR code.

4X7702095403
© 10/2013 ECHO Inc.
SAFETY 99944200490
Safety Videos are available from your Echo dealer. A $5.00 shipping charge will be required for each video.
SAFETY
Refer to your Pro Attachment Series or Split Boom Operator's Manual for correct engine fueling,
starting and stopping instructions.
Manual Safety Symbols and Important Information
Throughout this manual and on the product itself, you will find safety alerts and helpful, informational
messages preceded by symbols or key words. The following is an explanation of those symbols and key
words and what they mean to you.
The safety alert symbol accompanied by the word “DANGER” calls attention to an act or condition
which WILL lead to serious personal injury or death if not avoided.
The safety alert symbol accompanied by the word “WARNING” calls attention to an act or condition
which CAN lead to serious personal injury or death if not avoided.
The safety alert symbol accompanied by the word “CAUTION” calls attention to an act or condition
which may lead to minor or moderate personal injury if not avoided.
The enclosed message provides information necessary for the protection of the unit.
Note: This enclosed message provides tips for use, care and maintenance of the unit.
CIRCLE AND SLASH SYMBOL
This symbol means the specific action shown is prohibited. Ignoring these prohibitions can result
in serious or fatal injury.

99944200490 SAFETY
© 10/2013 ECHO Inc.
X7702095403 5
International Symbols
Personal Condition and Safety Equipment
Users of this product risk injury to themselves and others if the unit is used improperly and/or safety
precautions are not followed. Proper clothing and safety gear must be worn when operating unit.
Physical Condition
Your judgment and physical dexterity may not be good:
• if you are tired or sick,
• if you are taking medication,
• if you have taken alcohol or drugs.
Operate unit only if you are physically and mentally well.
Eye Protection
Eye protection that meets ANSI Z87.1, CE, or CSA Z94.3 requirements must be worn whenever you operate
the unit.
Hand Protection
Wear no-slip, heavy duty work gloves to improve your grip on the handles. Gloves also reduce the
transmission of machine vibration to your hands.
Breathing Protection
Wear a facemask to protect against dust.
Symbol Description Symbol Description Symbol Description Symbol Description
Warning, See
Operator’s
Manual
Safety/Alert
DO NOT USE
BLADES - Line
Head Only
Thrown
objects
Wear eye, ear
and head
protection
Finger Severing
Plan retreat
pathfromfalling
objects
Wear hand
and foot
protection
RotatingCutting
Attachment
A V O I D K I C K O U T .
Keep bystanders at least 15 meters
(50 feet) away.
Wear Face
Shield
Wear slip
resistant foot
wear
Beware Thrown Objects
Wear Eye Protection
Keep feet
away from
blade
Do not operate
closer than 15 M
(50 ft.) from
electricalhazards.
Keep
bystanders at
l e a s t 1 5 m e t e r s
(50 feet) away
Keep bystanders and helpers
away 15 m (50 ft.).

6X7702095403
© 10/2013 ECHO Inc.
SAFETY 99944200490
Hearing Protection
ECHO recommends wearing hearing protection whenever unit is used.
Proper Clothing
Wear snug fitting, durable clothing;
• Pants should have long legs, shirts with long sleeves.
• DO NOT WEAR SHORTS,
• DO NOT WEAR TIES, SCARVES, JEWELRY, or clothing with loose or hanging items that could become
entangled in moving parts or surrounding growth.
Wear sturdy work shoes with nonskid soles;
• DO NOT WEAR OPEN TOED SHOES,
• DO NOT OPERATE UNIT BAREFOOTED.
Wear no-slip, heavy duty work gloves.
Keep long hair away from engine and air intake. Retain hair with cap or net.
Hot Humid Weather
Heavy protective clothing can increase operator fatigue which may lead to heat stroke. Schedule heavy work
for early morning or late afternoon hours when temperatures are cooler.
The ignition componentsof this machine generate an electromagnetic fieldduring operation which
may interfere with some pacemakers.To reduce the risk of serious or fatal injury, persons with
pacemakers should consult with their physician and the pacemaker manufacturer before operating
this machine.In the absence of such information, ECHO does not recommend the use ofECHO
products by anyonewho has a pacemaker.
Vibration and Cold
It is believed that a condition called Raynaud’s Phenomenon,
which affects the fingers of certain individuals, may be brought
about by exposure to vibration and cold. Exposure to vibration
and cold may cause tingling and burning sensations, followed
by loss of color and numbness in the fingers. The following
precautions are strongly recommended, because the minimum
exposure, which might trigger the ailment, is unknown.
• Keep your body warm, especially the head, neck, feet, ankles,
hands, and wrists.
• Maintain good blood circulation by performing vigorous arm exercises during frequent work breaks, and
also by not smoking.
• Limit the hours of operation. Try to fill each day with jobs where operating the unit or other hand-held
power equipment is not required.
• If you experience discomfort, redness, and swelling of the fingers followed by whitening and loss of feeling,
consult your physician before further exposing yourself to cold and vibration.

99944200490 SAFETY
© 10/2013 ECHO Inc.
X7702095403 7
Repetitive Stress Injuries
It is believed that overusing the muscles and tendons of the
fingers, hands, arms, and shoulders may cause soreness,
swelling, numbness, weakness, and extreme pain in those
areas. Certain repetitive hand activities may put you at a high
risk for developing a Repetitive Stress Injury (RSI). An extreme
RSI condition is Carpal Tunnel Syndrome (CTS), which could
occur when your wrist swells and squeezes a vital nerve that
runs through the area. Some believe that prolonged exposure to
vibration may contribute to CTS. CTS can cause severe pain for
months or even years.
To reduce the risk of RSI/CTS, do the following:
• Avoid using your wrist in a bent, extended, or twisted position. Instead try to maintain a straight wrist
position. Also, when grasping, use your whole hand, not just the thumb and index finger.
• Take periodic breaks to minimize repetition and rest your hands.
• Reduce the speed and force with which you do the repetitive movement.
• Do exercise to strengthen the hand and arm muscles.
• Immediately stop using all power equipment and consult a doctor if you feel tingling, numbness, or pain in
the fingers, hands, wrists, or arms. The sooner RSI/CTS is diagnosed, the more likely permanent nerve
and muscle damage can be prevented.
All over head electrical conductors and communications wires can have electricity flow with high
voltages. This unit is not insulated against electrical current. Never touch wires directly or indirectly,
otherwise serious injury or death may result.
Do not operate this product indoors or in inadequately ventilated areas. Engine exhaust contains
poisonous emissions and can cause serious injury or death.
Read the Manuals
• Provide all users of this equipment with the Operator’s Manual
and Safety Manual for instructions on Safe Operation.
Clear the Work Area
• Spectators and fellow workers must be warned, and children
and animals prevented from coming nearer than 15 m (50 ft.)
while the unit is in use.
• Take wind conditions into account: avoid open doors and
windows.
• Do not point blower at people or animals.
• Review area to be cleared. Look for potential hazards such as
stones or metal objects.

8X7702095403
© 10/2013 ECHO Inc.
SAFETY 99944200490
Keep a Firm Grip
• Always hold throttle handle and support handle with thumbs and fingers tightly encircling the handles.
Keep a Solid Stance
• Maintain footing and balance at all times. Do not stand on slippery, uneven or unstable surfaces. Do not
work in odd positions or on ladders. Do not over reach.
Avoid Hot Surfaces
• During operation, the drive shaft housing and attachment
bearing housing may become very hot, too hot to touch. Avoid
contact during and immediately after operation.
Equipment
Use this attachment with ECHO approved models only. Serious injury may result from the use of this
attachment combined with a non approved ECHO product.
• Check unit for loose/missing nuts, bolts, and screws. Tighten and/or replace as needed.
• Do not use blower if any part is missing or damaged.
• Have repairs done only by an authorized ECHO Service dealer.
Note: ECHO, INC. will not be responsible for the failure of cutting devices, attachments or accessories
which have not been tested and approved by ECHO.
Moving parts can amputate fingers or cause severe injuries. Keep hands, clothing and loose objects
away from all openings.
◆ALWAYS stop engine, disconnect spark plug, and make sure all moving parts have come to a complete
stop before removing obstructions, clearing debris, or servicing unit.
◆DO NOT start or operate unit unless all guards and protective covers are properly assembled to unit.
◆NEVER reach into any opening while the engine is running. Moving parts may not be visible through
openings.

99944200490 DESCRIPTION
© 10/2013 ECHO Inc.
X7702095403 9
DESCRIPTION
Locate the safety decal(s) on your unit. Make sure the decal(s) is legible and that you understand and follow
the instructions on it. If a decal cannot be read, a new one can be ordered from your ECHO dealer. See
PARTS ORDERING instructions for specific information.
1. DRIVE SHAFT ASSEMBLY – Lightweight aluminum drive shaft. 2-position shaft design permits unit to be
rotated in 180-degree steps.
2. BLOWER PIPE - Concentrates air stream.
1
2
General Warning Decal (located on blower housing)
Sound Label (located on blower housing)

10 X7702095403
© 10/2013 ECHO Inc.
CONTENTS 99944200490
CONTENTS
The ECHO product you purchased has been factory pre-assembled for your convenience.
After opening the carton, check for damage. Immediately notify your retailer or ECHO Dealer of damaged or
missing parts. Use the contents list to check for missing parts.
____ - 1 - Power Blower Attachment
____ 1 - Operator’s Manual
____ 1 - Warranty Registration Card
____ 1 - Storage Hook Assembly
Specifications,descr iptionsand illustrativematerial in thisliterature areas accurate as known at the time
of publication, but are subject to changewithout notice. Illustrationsmay include optional equipment and
accessories, and may not include all standardequipment.
Operator’s Manual
X7722271404 / X772000164
© 4/2011 ECHO Inc.
X7722271404 / X772000164
Read rulesfor safe oper ationand instructionscarefully.E CHO providesanOperator’s Manual
and aSafety Manual. Both must be read and understood for proper and safe operation.
Power Blower
Attachment
