Echo Echo246F User manual

USER
Manual
USER
Manual
1.0.0 Edition 20181008
8th Gen Intel®Xeon®/Core™ i7/i5/i3 Fanless Embedded System
Workstation-grade, 10GigE LAN, Extended Temperature
Echo246F

ii
©Echo246F User Manual
Version Date Page Description Remark
0.10 10/05/2018 All Preliminary Release
1.0 10/08/2018 All O󰀩cial Release
Record of Revision

iii
©Echo246F User Manual
This manual is released by CappuccinoPC. for reference purpose only. All
product o󰀨erings and specications are subject to change without prior notice.
It does not represent commitment of CappuccinoPC. CappuccinoPC shall not be
liable for direct, indirect, special, incidental, or consequential damages arising out
of the use of the product or documentation or any infringements upon the rights of
third parties, which may result from such use.
Disclaimer
This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy, and if it is not installed and used
in accordance with the instruction manual, it may cause harmful interference to
radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference in which case the user will be required to correct
the interference at his own expense.
FCC
The products described in this manual complies with all applicable European
Union (CE) directives if it has a CE marking. For computer systems to
remain CE compliant, only CE-compliant parts may be used. Maintaining CE
compliance also requires proper cable and cabling techniques.
CE
Declaration of Conformity
This document contains proprietary information protected by copyright. No part
of this publication may be reproduced in any form or by any means, electric,
photocopying, recording or otherwise, without prior written authorization
by CappuccinoPC. The rights of all the brand names, product names, and
trademarks belong to their respective owners.
Copyright and Trademarks

iv
©Echo246F User Manual
Part Number Description
Echo246F-G9R 9 GigE LAN with 4 PoE+, 2 Front-access SSD Tray,
2 M.2, 6 USB 3.1, 4 COM, 2 SIM, 16 Isolated DIO
Echo246F-G99 GigE LAN with 4 PoE+, 2 M.2, 6 USB 3.1, 4 COM,
2 SIM, 16 Isolated DIO
Echo246F-PoER 6 GigE LAN with 4 PoE+, 2 Front-access SSD Tray,
2 M.2, 6 USB 3.1, 4 COM, 2 SIM, 16 Isolated DIO
Echo246F-PoE 6 GigE LAN with 4 PoE+, 2 M.2, 6 USB 3.1, 4 COM, 2
SIM, 16 Isolated DIO
Echo246F-FOR6 GigE LAN with 2 SFP, 2 Front-access SSD Tray,
2 M.2, 6 USB 3.1, 4 COM, 2 SIM, 16 GPIO
Echo246F-FO6 GigE LAN with 2 SFP, 2 M.2, 6 USB 3.1, 4 COM,
2 SIM, 16 GPIO
Echo246F-G4R 4 GigE LAN, 2 Front-access SSD Tray, 2 M.2,
6 USB 3.1, 4 COM, 2 SIM, 16 GPIO
Echo246F-G44 GigE LAN, 2 M.2, 6 USB 3.1, 4 COM, 2 SIM,
16 GPIO
Echo246FR2 GigE LAN, 2 Front-access SSD Tray, 2 M.2,
6 USB 3.1, 4 COM, 2 SIM, 16 GPIO
Echo246F 2 GigE LAN, 2 M.2, 6 USB 3.1, 4 COM, 2 SIM,
16 GPIO
Echo 246F-10GJR
6 GigE LAN with 4 PoE+, 2 10GigE LAN, 2 Front-
access SSD Tray, 2 M.2, 6 USB 3.1, 4 COM, 2 SIM, 16 Isolated
DIO
Echo 246F-10GJ 6 GigE LAN with 4 PoE+, 2 10GigE LAN, 2 M.2, 6
USB 3.1, 4 COM, 2 SIM, 16 Isolated DIO
Echo 246F-10GSR
6 GigE LAN with 4 PoE+, 2 10G SFP+, 2 Front-
access SSD Tray, 2 M.2, 6 USB 3.1, 4 COM, 2 SIM,
16 Isolated DIO
Echo 246F-10GS 6 GigE LAN with 4 PoE+, 2 10G SFP+, 2 M.2,
6 USB 3.1, 4 COM, 2 SIM, 16 Isolated DIO
Order Information

v
©Echo246F User Manual
Part Number Description
E-2176G Intel® Xeon® E-2176G Processor (12M Cache, up to 4.70GHz)
E-2124G Intel® Xeon® E-2124G Processor (8M Cache, up to 4.50GHz)
i7-8700 8th Gen Intel® Core™ i7-8700 Processor
(12M Cache, up to 4.60GHz)
i7-8700T 8th Gen Intel® Core™ i7-8700TE Processor
(12M Cache, up to 4.00GHz)
i5-8500 8th Gen Intel® Core™ i5-8500 Processor
(9M Cache, up to 4.10GHz)
i5-8500T 8th Gen Intel® Core™ i5-8500TE Processor
(9M Cache, up to 3.50GHz)
i3-8100 8th Gen Intel® Core™ i3-8100 Processor
(6M Cache, 3.60GHz)
i3-8100T 8th Gen Intel® Core™ i3-8100TE Processor
(6M Cache, 3.10GHz)
DDR4 32G Certied DDR4 32GB 2666MHz RAM
DDR4 16G Certied DDR4 16GB 2666/2400/2133MHz RAM
DDR4 8G Certied DDR4 8GB 2666/2400/2133MHz RAM
DDR4 4G Certied DDR4 4GB 2666/2400/2133MHz RAM
P280W-WT 280W, 24V, 85V AC to 264V AC Power Adaptor with 3-pin
Terminal Block, Wide Temperature -30°C to +70°C
P160W-WT 160W, 24V, 85V AC to 264V AC Power Adaptor with 3-pin
Terminal Block, Wide Temperature -30°C to +70°C
VESA Mount VESA Mounting Kit
DIN-RAIL Kit DIN Rail and VESA Mounting Kit
Rack Mount 2U Rackmount Kit
T20P-100 Terminal Block 20-pin to Terminal Block 20-pin Cable, 100cm
T20P-500 Terminal Block 20-pin to Terminal Block 20-pin Cable, 500cm
TMB-T20P Terminal Board with One 20-pin Terminal Block Connector and
DIN-Rail Mounting
4G Module Mini PCIe 4G/GPS Module with Antenna
WiFi & Bluetooth WiFi & Bluetooth Module with Antenna
Order Accessories

vi
©Echo 246F User Manual
Table of Contents
CHAPTER 1 GENERAL INTRODUCTION 1
1.1 Overview 1
1.2 Features 2
1.3 Product Specication 3
1.3.1 Specications of Echo 246F-G9R 3
1.3.2 Specications of Echo 246F-G9 5
1.3.3 Specications of Echo 246F-PoER 7
1.3.4 Specications of Echo 246F-PoE 9
1.3.5 Specications of Echo 246F-FOR 11
1.3.6 Specications of Echo 246F-FO13
1.3.7 Specications of Echo 246F-G4R 15
1.3.8 Specications of Echo 246F-G4 17
1.3.9 Specications of Echo 246F-2R 19
1.3.10 Specications of Echo 246F2G 21
1.3.11 Specications of Echo 246F-10GJR 23
1.3.12 Specications of Echo 246F-10GJ 25
1.3.13 Specications of Echo 246F-10GSR 27
1.3.14 Specications of Echo 246F-10GS 29
1.4 Supported CPU List 31
1.5 Mechanical Dimension 31
1.5.1 Dimensions of Echo 246F-G9R 31
1.5.2 Dimensions of Echo 246F-G9 31
1.5.3 Dimensions of Echo 246F-PoER 32
1.5.4 Dimensions of Echo 246F-PoE 32
1.5.5 Dimensions of Echo 246F-FOR 32
1.5.6 Dimensions of Echo 246F-6FO33
1.5.7 Dimensions of Echo 246F-G4R 33
1.5.8 Dimensions of Echo 246F-G4 33
1.5.9 Dimensions of Echo 246FR 34
1.5.10 Dimensions of Echo 246F 34
1.5.11 Dimensions of Echo 246F-10GJR 34
1.5.12 Dimensions of Echo 246F-10GJ 35
1.5.13 Dimensions of Echo 246F-10GSR 35
1.5.14 Dimensions of Echo 246F-10GS 35

vii
©Echo 246F User Manual
CHAPTER 2 GETTING TO KNOW YOUR Echo 246F 36
2.1 Packing List 36
2.2 Front Panel I/O Functions 38
2.3 Rear Panel I/O & Functions 47
2.4 Main Board Expansion Connectors 53
2.5 Main Board Jumper Settings 65
2.6 Ignition Control 68
CHAPTER 3 SYSTEM SETUP 71
3.1 How to Open Your Echo 246F 71
3.2 Installing CPU 77
3.3 Installing DDR4 SO-DIMM Modules 88
3.4 Installing Mini PCIe Card 90
3.5 Installing Antenna Cable 92
3.6 Installing CFast Card 94
3.7 Installing SIM Card 95
3.8 Installing SSD/HDD 96
3.9 Installing M.2 100
3.10 Mounting Your Echo 246F 101
CHAPTER 4 BIOS SETUP 103
4.1 Entering BIOS Setup 103
4.2 Main 104
4.3 Advanced 104
4.4 Chipset 116
4.5 Security 121
4.6 Boot 123
4.7 Save & Exit 124

viii
©Echo 246F User Manual
APPENDIX A : Isolated DIO Guide 125
APPENDIX B : Software Functions 132
APPENDIX C : Power Consumption 137
APPENDIX D : RAID Functions 141
APPENDIX E : Supported Memory & Storage List 147

1
©Echo 246F User Manual GENERAL INTRODUCTION
GENERAL INTRODUCTION
1.1 Overview
Echo 246F Series is a workstation-grade compact integrated Fanless
Embedded System. LGA1151 Socket supports workstation-grade 6-core 8th
Generation Intel® Xeon®/Core™ i7/i5/i3 processor (Coffee Lake-S) running
with workstation-grade Intel® C246 chipset, dual channel DDR4 2666MHz up
to 64GB ECC memory, advanced Intel® UHD Graphics P630/630 supporting
DirectX 12, OpenGL 4.5 and OpenCL 2.0 API, onboard DVI-I, DVI-D and
DisplayPort display interface for Ultra HD 4K resolution. Echo 246F delivers
new generation CPU & chipset performance, power efficiency, and graphics
performance; multiple 10GigE (10Gbps), PCIe 3.0 (8GT/s), SATA III (6Gbps),
USB 3.1 (5Gbps), PoE (1Gbps) LAN and wireless connections make seamless
real-time high-speed data conveying possible. Echo 246F Series Fanless
Embedded System delivers outstanding system performance and power
productivity for demanding workloads in real-time mission critical embedded
computing applications.
Fanless -40°C to 75°C operating temperature, onboard DVI-I, DVI-D and
DisplayPort display interfaces support triple independent displays, 9 GigE
LAN ports with 4 IEEE 802.3at (25.5W/48V) PoE+ without additional power
connections, max 6 external USB 3.1 connections, 2 Front-access 2.5" SSD/
HDD trays, up to 5 Mini PCIe expansions for multiple WiFi/4G/3G/LTE/GPRS/
UMTS wireless data transfer, 1 Front-access CFast socket, 2 SATA III support
software RAID function, 4 COM RS-232/422/485, 2 M.2 expansions, 16 Isolated
DIO, 6V to 36V wide range power input with 80V surge protection, congurable
ignition power control, smart remote management features, remote power
switch, EN50155 and EN50121-3-2 compliant, optional full function SUMIT A,
B expansion supports multiple 10GigE RJ45/SPF+ Fiber connections, the
Echo 246F Series Fanless Embedded System serves new-generation compact
integrated functions for any AI-oriented embedded applications.
With outstanding system performance, leading integrated features & functions,
smart manageability, flexible mobile availability, secure power protection and
rugged reliability, Echo 246F Series Fanless Embedded System is your
great solution for Machine Vision, Intelligent Automation, Smart Manufacturing,
Intelligent Surveillance, Vehicle Computing, Robotic Control, and any Articial
Intelligence oriented real-time Industrial IoT or Industry 4.0 embedded
applications.
1

2
©Echo 246F User Manual GENERAL INTRODUCTION
1.2 Features
• LGA 1151 Socket supports 6 cores 8th Generation Intel® Xeon®/Core™ i7/i5/i3
Processor (Coffee Lake) with workstation-grade Intel® C246 Chipset
• Fanless, -40°C to 75°C Operating Temperature
• 2 DDR4 2666MHz Memory, up to 64GB
• Up to 9 GigE LAN with 4 IEEE 802.3at PoE+, iAMT 12.0 supported
• 6 Independent GigE LAN with 2 SFP, iAMT 12.0 supported
(Echo 246F-FOR/Echo 246F-FO)
• DVI-I, DVI-D and DisplayPort display interface, up to 4K display
• 6 USB 3.1, 4 COM RS-232/422/485, 16 Isolated DIO
• 2 External SIM Card sockets support WiFi/4G/3G/LTE/GPRS/UMTS
• Storage : Up to 2 Front-access 2.5" HDD/SSD Tray, 1 Front-access CFast
Socket, 1 M.2 Socket
• Expansion : SUMIT A, B, M.2, up to 5 Mini PCIe
• 6V to 36V DC Power Input with 80V Surge Protection
• Configurable Ignition Power Control
• Optional supports multiple 10GigE RJ45/10GigE SFP+ Configuration
(Echo 246F-10GJR/Echo 246F-10GJ/Echo 246F-10GSR/Echo 246F-10GS)

3
©Echo 246F User Manual GENERAL INTRODUCTION
1.3 Product Specication
1.3.1 Specications of Echo 246F-G9R
System
Processor 6 cores Intel® Xeon®/Core™ i7/i5/i3 Processor (Co󰀨ee Lake-S)
Chipset Intel® C246 Chipset
BIOS AMI
SIO IT8786E
Memory • DDR4 2666MHz (ECC/Non-ECC)
• Up to 64GB
• 2 260-pin SO-DIMM Socket
I/O Interface
Serial 4 COM RS-232/422/485 (ESD 8KV)
USB • 6 USB 3.1 (External)
• 1 USB 2.0 (Internal)
Isolated DIO 16 Isolated DIO : 8 DI, 8 DO
LED Power, HDD, Wireless, PoE
SIM Card 2 SIM Card Socket (External)
Expansion
Mini PCIe 2 Full-size Mini PCIe Socket for PCIe/USB/External SIM Card/
mSATA
M.2 1 M.2 Key E Socket
Graphics
Graphics Processor Intel® UHD Graphics P630/630
Interface • DVI-I : Up to 1920 x 1200 @ 60Hz
• DVI-D : Up to 1920 x 1080 @ 60Hz
• DisplayPort : Up to 4096 x 2304 @ 60Hz
Storage
SATA 2 SATA III (6Gbps) support S/W RAID 0, 1
mSATA 2 SATA III (Mini PCIe Type, 6Gbps)
Storage Device • 1 CFast Socket, Push-in/Push-out Ejector
• 2 Front-access 2.5" SSD/HDD Tray
• 1 M.2 Key M Socket
Audio
Audio Codec Realtek ALC892, 5.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Ethernet
LAN 1 Intel® I219LM GigE LAN supports iAMT 12.0
LAN 2 Intel® I210 GigE LAN
LAN 7 Intel® 82574L GigE LAN
LAN 8 Intel® 82574L GigE LAN
LAN 9 Intel® 82574L GigE LAN

4
©Echo 246F User Manual GENERAL INTRODUCTION
PoE
LAN 3 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel®I210
LAN 4 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel®I210
LAN 5 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel®I210
LAN 6 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel®I210
Power
Input Voltage 6V to 36V, DC-in
Power Interface • 3-pin Terminal Block : V+, V-, Frame Ground
• Mini-DIN 4-pin
Ignition Control 16 Mode (Internal)
Remote Switch 3-pin Terminal Block : On, O󰀨, IGN
Surge Protection Up to 80V/1ms Transient Power
Others
TPM Optional Inneon SLB9665 supports TPM 2.0, LPC interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control when
CPU overheats.
Software Support
OS Windows 10, Linux
Mechanical
Dimensions (WxDxH) 260mm x 175mm x 79mm (10.2" x 6.9" x 3.1")
Weight 3.8 kg (8.38 lb)
Mounting • Wallmount by mounting bracket
• DIN Rail Mount (Optional)
• 2U Rackmount (Optional)
Environment
Operating
Temperature
35W TDP CPU : -40°C to 75°C (-40°F to 167°F)
65W TDP CPU : -40°C to 55°C (-40°F to 131°F)
80W TDP CPU : -40°C to 45°C (-40°F to 113°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% humidity, non-condensing
Relative Humidity 95% at 75°C
Shock • IEC 60068-2-27
• SSD : 50G @ wallmount, Half-sine, 11ms
Vibration • IEC 60068-2-64
• SSD : 5Grms, 5Hz to 500Hz, 3 Axis
EMC CE, FCC, EN50155, EN50121-3-2

5
©Echo 246F User Manual GENERAL INTRODUCTION
1.3.2 Specications of Echo 246F-G9
System
Processor 6 cores Intel® Xeon®/Core™ i7/i5/i3 Processor (Co󰀨ee Lake-S)
Chipset Intel® C246 Chipset
BIOS AMI
SIO IT8786E
Memory • DDR4 2666MHz (ECC/Non-ECC)
• Up to 64GB
• 2 260-pin SO-DIMM Socket
I/O Interface
Serial 4 COM RS-232/422/485 (ESD 8KV)
USB • 6 USB 3.1 (External)
• 1 USB 2.0 (Internal)
Isolated DIO 16 Isolated DIO : 8 DI, 8 DO
LED Power, HDD, Wireless, PoE
SIM Card 2 SIM Card Socket (External)
Expansion
Mini PCIe 2 Full-size Mini PCIe Socket for PCIe/USB/External SIM Card/
mSATA
M.2 1 M.2 Key E Socket
Graphics
Graphics Processor Intel® UHD Graphics P630/630
Interface • DVI-I : Up to 1920 x 1200 @ 60Hz
• DVI-D : Up to 1920 x 1080 @ 60Hz
• DisplayPort : Up to 4096 x 2304 @ 60Hz
Storage
SATA 2 SATA III (6Gbps) support S/W RAID 0, 1
mSATA 2 SATA III (Mini PCIe Type, 6Gbps)
Storage Device • 1 CFast Socket, Push-in/Push-out Ejector
• 2 2.5" SSD/HDD Bracket (Internal)
• 1 M.2 Key M Socket
Audio
Audio Codec Realtek ALC892, 5.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Ethernet
LAN 1 Intel® I219LM GigE LAN supports iAMT 12.0
LAN 2 Intel® I210 GigE LAN
LAN 7 Intel® 82574L GigE LAN
LAN 8 Intel® 82574L GigE LAN
LAN 9 Intel® 82574L GigE LAN

6
©Echo 246F User Manual GENERAL INTRODUCTION
PoE
LAN 3 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel®I210
LAN 4 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel®I210
LAN 5 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel®I210
LAN 6 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel®I210
Power
Input Voltage 6V to 36V, DC-in
Power Interface • 3-pin Terminal Block : V+, V-, Frame Ground
• Mini-DIN 4-pin
Ignition Control 16 Mode (Internal)
Remote Switch 3-pin Terminal Block : On, O󰀨, IGN
Surge Protection Up to 80V/1ms Transient Power
Others
TPM Optional Inneon SLB9665 supports TPM 2.0, LPC interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control when
CPU overheats.
Software Support
OS Windows 10, Linux
Mechanical
Dimensions (WxDxH) 260mm x 175mm x 79mm (10.2" x 6.9" x 3.1")
Weight 3.8 kg (8.38 lb)
Mounting • Wallmount by mounting bracket
• DIN Rail Mount (Optional)
• 2U Rackmount (Optional)
Environment
Operating
Temperature
35W TDP CPU : -40°C to 75°C (-40°F to 167°F)
65W TDP CPU : -40°C to 55°C (-40°F to 131°F)
80W TDP CPU : -40°C to 45°C (-40°F to 113°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% humidity, non-condensing
Relative Humidity 95% at 75°C
Shock • IEC 60068-2-27
• SSD : 50G @ wallmount, Half-sine, 11ms
Vibration • IEC 60068-2-64
• SSD : 5Grms, 5Hz to 500Hz, 3 Axis
EMC CE, FCC, EN50155, EN50121-3-2

7
©Echo 246F User Manual GENERAL INTRODUCTION
1.3.3 Specications of Echo 246F-PoER
System
Processor 6 cores Intel® Xeon®/Core™ i7/i5/i3 Processor (Co󰀨ee Lake-S)
Chipset Intel® C246 Chipset
BIOS AMI
SIO IT8786E
Memory • DDR4 2666MHz (ECC/Non-ECC)
• Up to 64GB
• 2 260-pin SO-DIMM Socket
I/O Interface
Serial 4 COM RS-232/422/485 (ESD 8KV)
USB • 6 USB 3.1 (External)
• 1 USB 2.0 (Internal)
Isolated DIO 16 Isolated DIO : 8 DI, 8 DO
LED Power, HDD, Wireless, PoE
SIM Card 2 SIM Card Socket (External)
Expansion
Mini PCIe 2 Full-size Mini PCIe Socket for PCIe/USB/External SIM Card/
mSATA
M.2 1 M.2 Key E Socket
Graphics
Graphics Processor Intel® UHD Graphics P630/630
Interface • DVI-I : Up to 1920 x 1200 @ 60Hz
• DVI-D : Up to 1920 x 1080 @ 60Hz
• DisplayPort : Up to 4096 x 2304 @ 60Hz
Storage
SATA 2 SATA III (6Gbps) support S/W RAID 0, 1
mSATA 2 SATA III (Mini PCIe Type, 6Gbps)
Storage Device • 1 CFast Socket, Push-in/Push-out Ejector
• 2 Front-access 2.5" SSD/HDD Tray
• 1 M.2 Key M Socket
Audio
Audio Codec Realtek ALC892, 5.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Ethernet
LAN 1 Intel® I219LM GigE LAN supports iAMT 12.0
LAN 2 Intel® I210 GigE LAN

8
©Echo 246F User Manual GENERAL INTRODUCTION
PoE
LAN 3 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel®I210
LAN 4 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel®I210
LAN 5 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel®I210
LAN 6 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel®I210
Power
Input Voltage 6V to 36V, DC-in
Power Interface • 3-pin Terminal Block : V+, V-, Frame Ground
• Mini-DIN 4-pin
Ignition Control 16 Mode (Internal)
Remote Switch 3-pin Terminal Block : On, O󰀨, IGN
Surge Protection Up to 80V/1ms Transient Power
Others
TPM Optional Inneon SLB9665 supports TPM 2.0, LPC interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control when
CPU overheats.
Software Support
OS Windows 10, Linux
Mechanical
Dimensions (WxDxH) 260mm x 175mm x 79mm (10.2" x 6.9" x 3.1")
Weight 3.8 kg (8.38 lb)
Mounting • Wallmount by mounting bracket
• DIN Rail Mount (Optional)
• 2U Rackmount (Optional)
Environment
Operating
Temperature
35W TDP CPU : -40°C to 75°C (-40°F to 167°F)
65W TDP CPU : -40°C to 55°C (-40°F to 131°F)
80W TDP CPU : -40°C to 45°C (-40°F to 113°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% humidity, non-condensing
Relative Humidity 95% at 75°C
Shock • IEC 60068-2-27
• SSD : 50G @ wallmount, Half-sine, 11ms
Vibration • IEC 60068-2-64
• SSD : 5Grms, 5Hz to 500Hz, 3 Axis
EMC CE, FCC, EN50155, EN50121-3-2

9
©Echo 246F User Manual GENERAL INTRODUCTION
1.3.4 Specications of Echo 246F-PoE
System
Processor 6 cores Intel® Xeon®/Core™ i7/i5/i3 Processor (Co󰀨ee Lake-S)
Chipset Intel® C246 Chipset
BIOS AMI
SIO IT8786E
Memory • DDR4 2666MHz (ECC/Non-ECC)
• Up to 64GB
• 2 260-pin SO-DIMM Socket
I/O Interface
Serial 4 COM RS-232/422/485 (ESD 8KV)
USB • 6 USB 3.1 (External)
• 1 USB 2.0 (Internal)
Isolated DIO 16 Isolated DIO : 8 DI, 8 DO
LED Power, HDD, Wireless, PoE
SIM Card 2 SIM Card Socket (External)
Expansion
Mini PCIe 2 Full-size Mini PCIe Socket for PCIe/USB/External SIM Card/
mSATA
M.2 1 M.2 Key E Socket
Graphics
Graphics Processor Intel® UHD Graphics P630/630
Interface • DVI-I : Up to 1920 x 1200 @ 60Hz
• DVI-D : Up to 1920 x 1080 @ 60Hz
• DisplayPort : Up to 4096 x 2304 @ 60Hz
Storage
SATA 2 SATA III (6Gbps) support S/W RAID 0, 1
mSATA 2 SATA III (Mini PCIe Type, 6Gbps)
Storage Device • 1 CFast Socket, Push-in/Push-out Ejector
• 2 2.5" SSD/HDD Bracket (Internal)
• 1 M.2 Key M Socket
Audio
Audio Codec Realtek ALC892, 5.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Ethernet
LAN 1 Intel® I219LM GigE LAN supports iAMT 12.0
LAN 2 Intel® I210 GigE LAN

10
©Echo 246F User Manual GENERAL INTRODUCTION
PoE
LAN 3 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel®I210
LAN 4 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel®I210
LAN 5 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel®I210
LAN 6 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel®I210
Power
Input Voltage 6V to 36V, DC-in
Power Interface • 3-pin Terminal Block : V+, V-, Frame Ground
• Mini-DIN 4-pin
Ignition Control 16 Mode (Internal)
Remote Switch 3-pin Terminal Block : On, O󰀨, IGN
Surge Protection Up to 80V/1ms Transient Power
Others
TPM Optional Inneon SLB9665 supports TPM 2.0, LPC interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control when
CPU overheats.
Software Support
OS Windows 10, Linux
Mechanical
Dimensions (WxDxH) 260mm x 175mm x 79mm (10.2" x 6.9" x 3.1")
Weight 3.8 kg (8.38 lb)
Mounting • Wallmount by mounting bracket
• DIN Rail Mount (Optional)
• 2U Rackmount (Optional)
Environment
Operating
Temperature
35W TDP CPU : -40°C to 75°C (-40°F to 167°F)
65W TDP CPU : -40°C to 55°C (-40°F to 131°F)
80W TDP CPU : -40°C to 45°C (-40°F to 113°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% humidity, non-condensing
Relative Humidity 95% at 75°C
Shock • IEC 60068-2-27
• SSD : 50G @ wallmount, Half-sine, 11ms
Vibration • IEC 60068-2-64
• SSD : 5Grms, 5Hz to 500Hz, 3 Axis
EMC CE, FCC, EN50155, EN50121-3-2

11
©Echo 246F User Manual GENERAL INTRODUCTION
1.3.5 Specications of Echo 246F-FOR
System
Processor 6 cores Intel® Xeon®/Core™ i7/i5/i3 Processor (Co󰀨ee Lake-S)
Chipset Intel® C246 Chipset
BIOS AMI
SIO IT8786E
Memory • DDR4 2666MHz (ECC/Non-ECC)
• Up to 64GB
• 2 260-pin SO-DIMM Socket
I/O Interface
Serial 4 COM RS-232/422/485 (ESD 8KV)
USB • 6 USB 3.1 (External)
• 1 USB 2.0 (Internal)
GPIO 16 GPIO
LED Power, HDD, Wireless
SIM Card 2 SIM Card Socket (External)
Expansion
Mini PCIe 2 Full-size Mini PCIe Socket for PCIe/USB/External SIM Card/
mSATA
M.2 1 M.2 Key E Socket
Graphics
Graphics Processor Intel® UHD Graphics P630/630
Interface • DVI-I : Up to 1920 x 1200 @ 60Hz
• DVI-D : Up to 1920 x 1080 @ 60Hz
• DisplayPort : Up to 4096 x 2304 @ 60Hz
Storage
SATA 2 SATA III (6Gbps) support S/W RAID 0, 1
mSATA 2 SATA III (Mini PCIe Type, 6Gbps)
Storage Device • 1 CFast Socket, Push-in/Push-out Ejector
• 2 Front-access 2.5" SSD/HDD Tray
• 1 M.2 Key M Socket
Audio
Audio Codec Realtek ALC892, 5.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Ethernet
LAN 1 Intel® I219LM GigE LAN supports iAMT 12.0
LAN 2 Intel® I210 GigE LAN
LAN 3 Intel® I210 GigE LAN
LAN 4 Intel® I210 GigE LAN

12
©Echo 246F User Manual GENERAL INTRODUCTION
SFP
LAN 5 1000BASE SFP by Intel® I350
LAN 6 1000BASE SFP by Intel® I350
Power
Input Voltage 6V to 36V, DC-in
Power Interface • 3-pin Terminal Block : V+, V-, Frame Ground
• Mini-DIN 4-pin
Ignition Control 16 Mode (Internal)
Remote Switch 3-pin Terminal Block : On, O󰀨, IGN
Surge Protection Up to 80V/1ms Transient Power
Others
TPM Optional Inneon SLB9665 supports TPM 2.0, LPC interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control when
CPU overheats.
Software Support
OS Windows 10, Linux
Mechanical
Dimensions (WxDxH) 260mm x 175mm x 79mm (10.2" x 6.9" x 3.1")
Weight 3.8 kg (8.38 lb)
Mounting • Wallmount by mounting bracket
• DIN Rail Mount (Optional)
• 2U Rackmount (Optional)
Environment
Operating
Temperature
35W TDP CPU : -40°C to 75°C (-40°F to 167°F)
65W TDP CPU : -40°C to 55°C (-40°F to 131°F)
80W TDP CPU : -40°C to 45°C (-40°F to 113°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% humidity, non-condensing
Relative Humidity 95% at 75°C
Shock • IEC 60068-2-27
• SSD : 50G @ wallmount, Half-sine, 11ms
Vibration • IEC 60068-2-64
• SSD : 5Grms, 5Hz to 500Hz, 3 Axis
EMC CE, FCC, EN50155, EN50121-3-2
