Advantech UNO-2184G User manual

User Manual
UNO-2184G/2174G/
2174GL
電腦
Automation Computers with
Intel® Core™ i7 / Celeron®
Processors, 4 x GbE, 2 x Mini-
PCIe, DVI/DP/HDMI

UNO-2184G/2174G/2174GL User Manual ii
限用物質含有情況標示聲明書
Declaration of the Present Condition of the Restricted Substances Marking
設備名稱 : 電腦
Equipment name
型號 ( 型式 )：
Type designation
(Type)
UNO-2174G/UNO-2184G (系列型號請參見次頁
說明書 )
單元 Unit
限用物質及其化學符號
Restricted substances and their chemical symbols
鉛
Lead
(Pb)
汞
Mercury
(Hg)
鎘
Cadmium
(Cd)
六價鉻
Hexavalent
chromium
(Cr+6)
多溴聯苯
Polybrominated
biphenyls
(PBB)
多溴二苯醚
Polybromi-
nateddiphenyl
ethers
(PBDE)
電路板 － ○○ ○ ○ ○
內外殼
( 外殼、內部
框架…等)
○○ ○ ○ ○ ○
其它固定組件
(螺絲)
－○○ ○ ○ ○
配件
(線材)
○○○ ○ ○ ○
記憶卡 － ○○ ○ ○ ○
備考 1. 〝超出 0.1 wt % 〞及〝超出 0.01 wt % 〞係指限用物質之百分比含量超出百分比含
量基準值
Note 1: “Exceeding 0.1 wt %” and “exceeding 0.01 wt %” indicate that the percentage con-
tent of the restricted substance exceeds the reference percentage value of presence condi-
tion.
備考 2. 〝○〞係指該項限用物質之百分比含量未超出百分比含量基準值。
Note 2: “○” indicates that the percentage content of the restricted substance does not exceed
the percentage of reference value of presence.
備考 3. 〝－〞係指該項限用物質為排除項目。
Note 3: The “−” indicates that the restricted substance corresponds to the exemption.

iii UNO-2184G/2174G/2174GL User Manual
UNO-2174G-C54E
UNO2174G1301E-T
UNO2174GC541301E-T
UNO2174GC541401E-T
UNO2174GC541402E-T
UNO2174GC541403E-T
UNO2174GC541601E-T
UNO2174GC54E01E-ES
UNO-2174GL-C44E
UNO2174GL441301E-T
UNO2174GL1401E-T
UNO2174GLC44E-ES
UNO-2184G-D44E
UNO2184G1201E-T
UNO2184G1301E-T
UNO2184G1302E-T
UNO2184G1303E-T
UNO2184G1401E-T
UNO2184G1403E-T
UNO2184GD1501E-T
UNO2184GD441301E-T
UNO2184GD441401E-T
UNO2184GD441402E-T
UNO2184GD441403E-T
UNO2184GD441601E-T
UNO-2184G-D45E
UNO2184GD451401E-T
UNO2184GD451402E-T
UNO2184GD451601E-T
UNO-2184G-D64E
UNO2184GD641502E-T
UNO2184GD641503E-T
UNO2184GD641504E-T
UNO2184GD641601E-T
UNO-5080G-D54E
UNO-5080G-D55E

UNO-2184G/2174G/2174GL User Manual iv
Copyright
The documentation and the software included with this product are copyrighted 2018
by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right
to make improvements in the products described in this manual at any time without
notice. No part of this manual may be reproduced, copied, translated or transmitted
in any form or by any means without the prior written permission of Advantech Co.,
Ltd. Information provided in this manual is intended to be accurate and reliable. How-
ever, Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringe-
ments of the rights of third parties, which may result from its use.
Acknowledgements
IBM, PC/AT, PS/2 and VGA are trademarks of International Business Machines Cor-
poration.
Intel® and Pentium® are trademarks of Intel Corporation.
Microsoft Windows and MS-DOS are registered trademarks of Microsoft Corp.
C&T is a trademark of Chips and Technologies, Inc.
All other product names or trademarks are properties of their respective owners.
Support
For more information on this and other Advantech products, please visit our website
at: http://www.advantech.com
For technical support and service, please visit the support website at:
http://www.advantech.com/support/
Part No. 2003218402 Edition 3
Printed in China December 2018

v UNO-2184G/2174G/2174GL User Manual
Product Warranty (2 years)
Advantech warrants to you, the original purchaser, that each of its products will be
free from defects in materials and workmanship for two years from the date of pur-
chase.
This warranty does not apply to any products which have been repaired or altered by
persons other than repair personnel authorized by Advantech, or which have been
subject to misuse, abuse, accident or improper installation. Advantech assumes no
liability under the terms of this warranty as a consequence of such events.
Because of Advantech’s high quality-control standards and rigorous testing, most of
our customers never need to use our repair service. If an Advantech product is defec-
tive, it will be repaired or replaced at no charge during the warranty period. For out-
of-warranty repairs, you will be billed according to the cost of replacement materials,
service time and freight. Please consult your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example, CPU
speed, Advantech products used, other hardware and software used, etc.) Note
anything abnormal and list any onscreen messages you get when the problem
occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA (return merchandize
authorization) number from your dealer. This allows us to process your return
more quickly.
4. Carefully pack the defective product, a fully-completed Repair and Replacement
Order Card and a photocopy of the proof of purchase date (such as your sales
receipt) in a shippable container. A product returned without proof of the pur-
chase date is not eligible for warranty service.
5. Write the RMA number visibly on the outside of the package and ship it prepaid
to your dealer.
Declaration of Conformity
CE
This product has passed the CE test for environmental specifications when shielded
cables are used for external wiring. We recommend the use of shielded cables. This
kind of cable is available from Advantech. Please contact your local supplier for
ordering information.
FCC Class A
Note: This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Opera-
tion of this equipment in a residential area is likely to cause harmful interference, in
which case the user will be required to correct the interference at his own expense.

UNO-2184G/2174G/2174GL User Manual vi
警告使用者
這是甲類測試產品，在居住的環境中使用時，可能會造成射頻干擾，在這種情況下，
使用者會被要求採取某些適當的對策。
Technical Support and Assistance
1. Visit the Advantech web site, at www.advantech.com/support, where you can
find the latest information about the product.
2. Contact your distributor, sales representative, or Advantech's customer service
center for technical support if you need additional assistance. Please have the
following information ready before you call:
–Product name and serial number.
–Description of your peripheral attachments.
–Description of your software (operating system, version, application software,
etc.).
–A complete description of the problem.
–The exact wording of any error messages.
Safety Precaution - Static Electricity
Follow these simple precautions to protect yourself from harm and the products from
damage.
To avoid electrical shock, always disconnect the power from your PC chassis
before you work on it. Don't touch any components on the CPU card or other
cards while the PC is on.
Disconnect power before making any configuration changes. The sudden rush
of power as you connect a jumper or install a card may damage sensitive elec-
tronic components.

vii UNO-2184G/2174G/2174GL User Manual
Safety Instructions
1. Read these safety instructions carefully.
2. Keep this User Manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Use a damp
cloth. Do not use liquid or spray detergents for cleaning.
4. For plug-in equipment, the power outlet socket must be located near the equip-
ment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Dropping it or letting
it fall may cause damage.
7. The openings on the enclosure are for air convection. Protect the equipment
from overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before connecting the
equipment to the power outlet.
9. Position the power cord so that people cannot step on it. Do not place anything
over the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the power source
to avoid damage by transient overvoltage.
12. Never pour any liquid into an opening. This may cause fire or electrical shock.
13. Never open the equipment. For safety reasons, the equipment should be
opened only by qualified service personnel.
14. If one of the following situations arises, get the equipment checked by service
personnel:
The power cord or plug is damaged.
Liquid has penetrated into the equipment.
The equipment has been exposed to moisture.
The equipment does not work well, or you cannot get it to work according to the
user's manual.
The equipment has been dropped and damaged.
The equipment has obvious signs of breakage.
15. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT WHERE THE
STORAGE TEMPERATURE MAY GO BELOW -20° C (-4° F) OR ABOVE 60° C
(140° F). THIS COULD DAMAGE THE EQUIPMENT. THE EQUIPMENT
SHOULD BE IN A CONTROLLED ENVIRONMENT.
16. CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY
REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE
RECOMMENDED BY THE MANUFACTURER, DISCARD USED BATTERIES
ACCORDING TO THE MANUFACTURER'S INSTRUCTIONS.
17. The sound pressure level at the operator's position according to IEC 704-1:1982
is no more than 70 dB (A).
DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech
disclaims all responsibility for the accuracy of any statements contained herein.

UNO-2184G/2174G/2174GL User Manual viii
安全指示
1. 請仔細閱讀此安全操作說明。
2. 請妥善保存此用戶手冊供日後參考。
3. 用濕抹布清洗設備前，請確認拔除電源線。請勿使用液體或去污噴霧劑清洗設
備。
4. 對於使用電源線的設備，設備周圍必須有容易接觸到的電源插座。
5. 請勿在潮濕環境中試用設備。
6. 請在安裝前確保設備放置在可靠的平面上，意外摔落可能會導致設備損壞。
7. 設備機殼的開孔適用於空氣對，從而防止設備過熱。請勿覆蓋開孔。
8. 當您連接設備到電源插座前，請確認電源插座的電壓符合要求。
9. 請將電源線佈置在人們不易絆倒的位置，請勿在電源線上覆蓋任何雜物。
10. 請注意設備上所有的警告標示。
11. 如果長時間不使用設備，請拔除與電源插座的連結，避免設備被超標的電壓波動
損壞。
12. 12. 請勿讓任何液體流入通風口，以免引起火灾或短路。
13. 13. 請勿自行打開設備。為了確保您的安全，請透過經認證的工程師來打開設
備。
14. 如遇下列情况，請由專業人員維修：
電源線或插頭損壞；
設備內部有液體流入；
設備曾暴露在過度潮濕環境中使用；
設備無法正常工作，或您無法透過用戶手冊來正常工作；
設備摔落或損壞；
設備有明顯外觀損；
15. 請勿將設備放置在超出建議溫度範圍的環境，即不要低於 -20°C （-4°F）或高
於 60°C （140°F），否則可能會造成設備損壞。
16. 注意：若電池更換不正確，將有爆炸危險。因此，只可以使用製造商推薦的同一
種或者同等型號的電池進行替換。請按照製造商的指示處理舊電池。
17. 根據 IEC 704‐1:1982 規定，操作員所在位置音量不可高於 70 分貝。
18. 免責聲明：請安全訓示符合 IEC 704‐1 要求。研華公司對其內容之準確性不承
擔任何法律責任。

ix UNO-2184G/2174G/2174GL User Manual
Contents
Chapter 1 Overview...............................................1
1.1 Introduction ............................................................................................... 2
1.2 Hardware Specifications ........................................................................... 2
1.2.1 General ......................................................................................... 2
1.3 System Hardware...................................................................................... 3
1.3.1 Daughterboard (Additional Purchase Required) ........................... 3
1.3.2 I/O Interfaces ................................................................................ 3
1.3.3 Environment.................................................................................. 3
1.4 Safety Precautions .................................................................................... 4
1.5 Chassis Dimensions.................................................................................. 4
Figure 1.1 UNO-2184G/2174G/2174GL Chassis Dimensions .... 4
1.6 Accessories............................................................................................... 4
Chapter 2 Hardware Functionality.......................5
2.1 Introduction ............................................................................................... 6
Figure 2.1 Front Panel of UNO-2184G/2174G/2174GL .............. 6
Figure 2.2 Rear Panel of UNO-2184G/2174G/2174GL ............... 6
2.2 UNO-2184G/2174G/2174GL Interface (COM1~COM4) ........................... 6
2.2.1 RS-232/422/485 Interface (COM 1 ~ 2)........................................ 7
2.2.2 16C550 UARTs with 128-byte Standard....................................... 7
2.2.3 RS-422/485 Detection................................................................... 7
2.2.4 Automatic Data Flow Control Function for RS-485 ....................... 7
2.3 RS-232/422/485 Selection ........................................................................ 7
2.4 LAN: Ethernet Connector .......................................................................... 8
2.5 Power Connector ...................................................................................... 8
2.6 PS/2 Keyboard and Mouse Connector...................................................... 8
2.7 USB Connector ......................................................................................... 9
2.8 DVI-I/Display Port/HDMI Display Connector ............................................. 9
2.9 RTC Battery Specification ......................................................................... 9
Figure 2.3 RTC Battery Location ................................................. 9
2.10 Power Button/Power Management ........................................................... 9
2.11 Reset Button ........................................................................................... 10
2.12 HD Audio................................................................................................. 10
2.13 PCI Express Mini Card Socket................................................................ 10
2.14 Power eSATA.......................................................................................... 10
Chapter 3 Initial Setup ........................................11
3.1 Inserting a CFast Card ............................................................................ 12
3.2 Chassis Grounding.................................................................................. 12
Figure 3.1 Chassis Grounding Connection................................ 12
3.3 Connecting Power................................................................................... 12
3.4 Installing a Hard Disk .............................................................................. 13
3.5 Installing a Wireless LAN Card and Antenna .......................................... 14
3.6 BIOS Setup ............................................................................................. 15
3.7 AMT Configuration .................................................................................. 16
Appendix A Syst. Settings & Pin Assignments ...21
A.1 System I/O Address and Interrupt Assignment ....................................... 22
Table A.1: Interrupt Assignments............................................... 22

UNO-2184G/2174G/2174GL User Manual x
A.2 Board Connectors and Jumpers ............................................................. 23
Figure A.1 Connector & Jumper Locations (Front) .................... 23
Table A.2: Connectors and Jumpers ......................................... 23
A.3 RS-232 Standard Serial Port .................................................................. 24
Table A.3: RS-232 Serial Port Pin Assignments........................ 24
A.4 RS-232/422/485 Serial Port (COM1 ~ COM2)........................................ 24
Table A.4: RS-232/422/485 Serial Port Pin Assignments.......... 24
A.5 Power Connector (PWR) ........................................................................ 25
Table A.5: Power Connector Pin Assignments.......................... 25
A.6 PS/2 Keyboard and Mouse Connector ................................................... 25
Table A.6: Keyboard and Mouse Connector Pin Assignments.. 25
A.7 USB Connector ....................................................................................... 26
Table A.7: USB 2.0 Connector Pin Assignments....................... 26
Table A.8: USB 3.0 Connector Pin Assignments....................... 26
A.8 HDMI Display Connector ........................................................................ 27
Table A.9: HDMI Display Connector.......................................... 27
A.9 DVI-I Connector ...................................................................................... 28
Table A.10:DVI-I Connector Pin Assignments............................ 28
A.10 DisplayPort Display Connector ............................................................... 29
Table A.11:DisplayPort Adaptor Cable Pin Assignments ........... 29
A.11 Clear CMOS (JP1) .................................................................................. 30
Table A.12:JP2 Clear CMOS...................................................... 30
A.12 System Power AT or ATX Selection (JP3).............................................. 30
Table A.13:AT/ATX Selection ..................................................... 30

Chapter 1
1Overview
This chapter provides an overview
of UNO-2184G/2174G/2174GL’s
specifications.
Sections Include:
Introduction
Hardware Specifications
Safety Precautions
Chassis Dimensions

UNO-2184G/2174G/2174GL User Manual 2
1.1 Introduction
UNO-2184G/2174G/2174GL is an embedded Application Ready Platform (ARP) that
can shorten your development time and offers rich networking interfaces to fulfill
extensive needs in different projects. UNO-2184G/2174G/2174GL includes Intel’s lat-
est Core i7/Celeron technology and provides plenty of I/O interfaces, including up to
4 serial ports, 4 x GbE LAN, 6 x USB ports and Audio. UNO-2184G/2174G/2174GL
supports three display types, DVI, DisplayPort and HDMI for various high resolution
requirements.
UNO-2184G/2174G/2174GL can operate in wide temperatures (from -10 to 60°C).
UNO-2184G/2174G/2174GL even adopts Intel Core i7/Celeron CPU with great com-
puting power and come with up to 8G DDR3 RAM built-in for heavy programs.
UNO-2184G/2174G/2174GL provides great expansion, including 2 x Mini-PCIe and
SIM card support. An additional daughterboard is also available for 2 x PCI-104 plug-
in cards. With these expansions, UNO-2184G/2174G/2174GL has great expandabil-
ity for WiFi, 3G, I/O expansion and fieldbus card.
OS and driver support includes Windows XP/7 WES-2009, WES7, and embedded
Linux. Users can integrate applications easily in an application ready platform that
provides versatile functions to fulfill diverse requirements.
1.2 Hardware Specifications
1.2.1 General
Certification: CE, UL, CCC, FCC, C-Tick
Dimension (W x D x H): 255 x 152 x 69 mm (10" x 6.0" x 2.7")
Enclosure: Aluminum
Mounting: DIN-rail, Wallmount, VESA
Power Consumption: UNO-2174G/GL: 30 W/ 20 W (Typical)
UNO-2184G: 40 W (Typical)
Power Requirements: 9 ~ 36 VDC (e.g +24V @ 3A) (Min. 72W), AT/ATX
Weight: 3.0 kg
OS Support: Windows XP/7, WES7, WES-2009, Linux
System Design Fanless with no internal cabling (except COM3/COM4)
Remote Management: Built-in Advantech DiagAnywhere agent on WES2009 /
WES7

3 UNO-2184G/2174G/2174GL User Manual
Chapter 1 Overview
1.3 System Hardware
CPU: UNO-2174GL: Intel Celeron 807UE 1.0GHz
UNO-2174G: Intel Celeron 847E 1.1GHz
UNO-2184G: Intel Core i7-2655LE 2.2GHz/i7-3555LE 2.5GHz
Memory: UNO-2174G/GL: 4 GB DDR3 SDRAM built-in
UNO-2184G: 4 GB/8 GB DDR3 SDRAM built-in
Indicators: LEDs for Power, battery, LAN (Active, Status) and Serial (Tx, Rx)
Keyboard/Mouse: 1 x PS/2
PC/104 Slot: 2 x PCI-104 slot, supports +5 & 3.3V power
Storage:
CF: 1 x CFast slot
HDD: 1 x built-in 2.5" SATA HDD bracket (2 x HDD with RAID by project sup-
port)
Display: 1 x DVI-I, 1 x HDMI, 1 x DP (2 x independent displays)
Audio: Mic-in, Line-in, Line-out
Watchdog Timer: NCT6776F, programmable 256 levels timer interval, from 1 to
255 sec
Mini PCIe Expansion: 2 x Mini PCIe slots with 1 x SIM card
1.3.1 Daughterboard (Additional Purchase Required)
Expansion Slot: PCI-104 support (+5 & 3.3V power)
1.3.2 I/O Interfaces
Serial Ports 2 x RS-232, 2 x RS-232/422/485 with DB9 connectors; automatic
RS-485 data flow control
Serial Port Speed: RS-232: 50 ~ 115.2 kbps
RS-422/485: 50 ~ 115.2 kbps (Max.)
LAN: 4 x 10/100/1000Base-T RJ-45 ports
Supports AMT (UNO-2184G only), wake on LAN and built in boot ROM in flash
BIOS
USB Ports: 6 x USB ports (only UNO-2184G-D64E supports 2 x USB3.0 ports)
1.3.3 Environment
Humidity: 95% @ 40°„C (non-condensing)
Operating Temperature: -10 ~ 60°C (14 ~ 140°F) @ 5 ~ 85% RH. (with air
flow)
Safety Cert. Temperature: -10 ~ 55°C (14 ~ 131°F)
Shock Protection: IEC 60068-2-27
CFast: 50 G @ wall mount, half sine, 11 ms
HDD: 20 G @ wall mount, half sine, 11 ms
Vibration Protection: IEC 60068-2-64 (Random 1 Oct./min, 1hr/axis.)
CFast: 2 Grms @ 5 ~ 500 Hz,
HDD: 1 Grms @ 5 ~ 500 Hz

UNO-2184G/2174G/2174GL User Manual 4
1.4 Safety Precautions
The following sections provides information on how to make each connection. In
most cases, you will simply need to connect a standard cable.
1.5 Chassis Dimensions
Figure 1.1 UNO-2184G/2174G/2174GL Chassis Dimensions
1.6 Accessories
Please refer below for the accessory list:
3-pin connector for power wiring (Advantech P/N: 1652003206)
SATA signal cable (Advantech P/N: 1700013095)
SATA power cable (Advantech P/N: 1700006492)
2 PCS jumper (Advantech P/N: 1653302122)
Keyboard/Mouse Y cable (Advantech P/N: 1700060202)
Driver DVD
Warranty card
If anything is missing or damaged, contact your distributor or sales representative
immediately.
Warning! Always disconnect the power cord from your chassis whenever you are
working on it. Do not connect while the power is on. A sudden rush of
power can damage sensitive electronic components. Only experienced
electronics personnel should open the chassis.
Caution! Always ground yourself to remove any static electric charge before
touching UNO-2184G/2174G/2174GL. Modern electronic devices are
very sensitive to static electric charges. Use a grounding wrist strap at
all times. Place all electronic components on a static-dissipative surface
or in a static-shielded bag.

Chapter 2
2Hardware
Functionality
This chapter shows how to setup
the UNO-2184G/2174G/2174GL’s
hardware functions, including
connecting peripherals, setting
switches and indicators.
Sections Include:
Peripherals
RS-232 Interface
RS-422/485 Interface
LAN / Ethernet Connector
Power Connector
Power eSATA
PS/2 Mouse and Keyboard Con-
nector
Audio Connector
USB Connector
DVI/DP/HDMI Display Connector
Reset Button

UNO-2184G/2174G/2174GL User Manual 6
2.1 Introduction
The following figures show the connectors on UNO-2184G/2174G/2174GL. The fol-
lowing sections give you information about each peripheral.
Figure 2.1 Front Panel of UNO-2184G/2174G/2174GL
Figure 2.2 Rear Panel of UNO-2184G/2174G/2174GL
2.2 UNO-2184G/2174G/2174GL Interface
(COM1~COM4)
UNO-2184G/2174G/2174GL offers 2 standard RS-232/422/485 and 2 RS-232 (with
cable) serial communication inter-face ports: COM1 ~ COM4.
The IRQ and I/O address range of COM1 to COM4 are listed below:
COM1: 3F8h, IRQ4
COM2: 2F8h, IRQ3
COM3: 3E8h, IRQ10
COM4: 2E8h, IRQ10
The setting can be adjusted in the BIOS page. The driver will be installed automati-
cally during OS installation

7 UNO-2184G/2174G/2174GL User Manual
Chapter 2 Hardware Functionality
2.2.1 RS-232/422/485 Interface (COM 1 ~ 2)
The UNO-2184G/2174G/2174GL offers 2 RS-232/422/485 serial communication
interface ports: COM1 and COM2. Please refer to Appendix A.4 for their pin assign-
ments. The default setting of COM1 and COM2 are RS-422/485.
2.2.2 16C550 UARTs with 128-byte Standard
Advantech UNO-2184G/2174G/2174GL comes with OXuPCI952 UARTs containing
128 bytes FIFOs. These upgraded FIFOs greatly reduce CPU overhead and are an
ideal choice for heavy multitasking environments.
2.2.3 RS-422/485 Detection
In RS-422/485 mode, UNO-2184G/2174G/2174GL automatically detects signals to
match RS-422 or RS-485 networks (No jumper change required).
2.2.4 Automatic Data Flow Control Function for RS-485
In RS-485 mode, UNO-2184G/2174G/2174GL automatically detects the direction of
incoming data and switches its transmission direction accordingly. No handshaking
signal (e.g. RTS signal) is necessary. This lets users conveniently build an RS-485
network with just two wires. More importantly, application software previously written
for half duplex RS-232 environments can be maintained without modification.
2.3 RS-232/422/485 Selection
COM1 and COM2 support a 9-wire RS-232/422/485 interface. The system detects
RS-422 or RS-485 automatically for COM1 and COM2.
You can set the “Auto Flow Control” mode of RS-485 or “Master/Slave” mode of RS-
422 by using the external switch for COM1 and COM2.
Note! In S1 mode, COM 1 and COM 2 data re-transmission will not function
properly and may include error signals after wake up.
SW3 Note Function
Pin1 Pin2 Pin3
ON ON ON Disable COM1
ON ON OFF COM1 RS232 RS232
ON OFF ON COM1 RS485 RS485
ON OFF OFF COM1 Slave Mode RS422 (Default) RS422+RS485
OFF ON ON COM1 RS485 with Termination RS485
OFF ON OFF COM1 Slave Mode RS422 with Termination RS422+RS485
OFF OFF ON COM1 Master Mode RS422 RS422
OFF OFF OFF COM1 Master Mode RS422 With Termination RS422

UNO-2184G/2174G/2174GL User Manual 8
2.4 LAN: Ethernet Connector
UNO-2184G/2174G/2174GL is equipped with 4 Gigabit LAN controllers. The control-
ler chip used in both models are Intel 1 x 82579LM and 3 x 82574L Ethernet control-
lers that are fully compliant with IEEE 802.3u 10/100Base-T CSMA/CD standards
and IEEE 802.3ab specifications for 1000Mbps Ethernet. The Ethernet port provides
a standard RJ-45 jack on board and LED indicators on the front side to show Link
(Green LED) and Active (Yellow LED) status.
2.5 Power Connector
The UNO-2184G/2174G/2174GL comes with a Phoenix connector that carries 9~36
VDC external power input and features reversed wiring protection. It will not cause
any damage to the system by reversed wiring of the ground line and power line.
Please refer to Appendix A.6
2.6 PS/2 Keyboard and Mouse Connector
The UNO-2184G/2174G/2174GL provides a PS/2 keyboard and mouse connector. A
6-pin mini-DIN connector is located on the rear panel. The UNO-2184G/2174G/
2174GL comes with an adapter to convert from the 6-pin mini-DIN connector to 2 6-
pin mini-DIN connectors for PS/2 keyboard and PS/2 mouse connection.
SW3 Note Function
Pin4 Pin5 Pin6
ON ON ON Disable COM2
ON ON OFF COM2 RS232 RS232
ON OFF ON COM2 RS485 RS485
ON OFF OFF COM2 Slave Mode RS422 (Default) RS422+RS485
OFF ON ON COM2 RS485 with Termination RS485
OFF ON OFF COM2 Slave Mode RS422 with Termination RS422+RS485
OFF OFF ON COM2 Master Mode RS422 RS422
OFF OFF OFF COM2 Master Mode RS422 with Termination RS422
Note! Please restart your system if you change any setting.
Note! UNO-2184G with 82579LM LAN chip can support AMT7.0.

9 UNO-2184G/2174G/2174GL User Manual
Chapter 2 Hardware Functionality
2.7 USB Connector
The USB interface supports Plug & Play, which enables you to connect or disconnect
a device whenever you want without turning off the computer. UNO-2184G/2174G/
2174GL provides 6 connectors of USB inter-faces, which gives complete Plug & Play
and hot swapping for up to 127 external devices. 2 of the 6 connectors are compati-
ble with USB3.0 devices, although only with USB 2.0 speed (except UNO-2184G-
D64E). The USB interface complies with USB EHCI, Rev. 2.0 and can be disabled in
the system BIOS setup. Please refer to Appendix A.8 for its pin assignments.
2.8 DVI-I/DisplayPort/HDMI Display Connector
The UNO-2184G/2174G/2174GL provides a DVI-I/Display Port/HDMI controller for a
high resolution interface. UNO-2184G/2174G/2174GL supports up to full HD resolu-
tion for 2 independent displays.
2.9 RTC Battery Specification
UNO-2184G/2174G/2174GL has RTC Battery to ensure the settings in BIOS and the
system clock can be kept, even when power is disconnected for a short time.
Type: BR2032 (Using CR2032 is NOT recommended)
Output Voltage: 3 VDC
Location: BH1, please refer to below figure
Figure 2.3 RTC Battery Location
2.10 Power Button/Power Management
Press the "PWR" button to power on or power off UNO-2184G/2174G/2174GL (ATX
type). UNO-2184G/2174G/2174GL supports the ACPI (Advanced Configuration and
Power Interface). Besides power on/off, it supports multiple suspend modes, such as
Power on Suspend (S1), Suspend to RAM (S3), and Suspend to Disk (S4). In S3 and
S4 suspend modes, the power consumption can be less than 2W, which meets
Energy Star criteria.

UNO-2184G/2174G/2174GL User Manual 10
2.11 Reset Button
Press the "Reset" button to activate the hardware reset function.
2.12 HD Audio
UNO-2184G/2174G/2174GL is equipped with ALC892-GR, which is a High Definition
Audio Codec. UNO-2184G/2174G/2174GL provides 3 phone jack connectors for 5.1
channel output. Please configure the function through provided software utility.
2.13 PCI Express Mini Card Socket
UNO-2184G/2174G/2174GL supports 2 sockets for full size PCI Express mini cards.
This interface is mainly target on the wireless application such as WLAN GPRS and
3G. User can install the card easily by the optional kit, please refer to Chapter 3.5 for
the details.
An additional SIM card slot is used for 3G application. Please note you still require
3G Mini-PCIe module installed to be able to use 3G functions.
2.14 Power eSATA
UNO-2184G/2174G/2174GL support 1 x Power eSATA connector which is a combi-
nation connection for external storage devices. A single eSATAp, eSATA or USB
device can be plugged into an eSATA port. The socket has keyed cutouts for both
types of device to ensure that a connector can only be plugged in the right way
round.
