Hedge Clipper
Operator'sManual
MODELS:
HC-1500 - Type 1E Serial Number 001001 & Up
HC-1500 - Type 2E Serial Number 001001 & Up
HC-1600 - Type 1E Serial Number 001001 & Up
HC-2000 - Type 1E Serial Number 001001 & Up
HC-2400, 2410 - Type 1E Serial Number 001001 & Up
HC-2400, 2410 - Type 2E Serial Number 001001 & Up
WARNING DANGER
X7502249003 89865013263
12/00
Readrulesforsafeoperationandallinstructionscarefully. ECHOprovidesthis
Operator'sManualandaSafetyManual.Bothmustbereadandunderstoodfor
properandsafeoperation.

2
INTRODUCTION
Welcome to the ECHO family. This ECHO product was designed and manufactured to provide long life and on-the-job-
dependability. Read and understand this manual and the SAFETY MANUAL you found in the same package. You will
find both easy to use and full of helpful operations tips and SAFETY messages.
WARNING DANGER
Read rules for safe operation and instructions carefully. ECHO provides an Operator's Manual and a Safety Manual.
Both must be read and understood for proper and safe operation.
THE OPERATOR'SMANUAL
contains specifications and information for operation, starting,
stopping, maintenance, storage and assembly specific to this product.
THE SAFETY MANUAL
explains possible hazards involved with the use of Hedge Clippers and
what measures you should take to make their use safer.
TABLE OF CONTENTS
Introduction............................................................... 2
- The Operator's Manual....................................... 2
- The Safety Manual .............................................2
Manual Safety Symbols and Important Information .....3
Safety .........................................................................3
- Decals .................................................................3
- InternationalSymbols ........................................4
- Equipment ..........................................................4
- Fuel .....................................................................5
- Personal Condition and Safety Equipment.........5
- SafeOperation ....................................................7
- ExtendedOperation/ExtremeConditions............8
Description ................................................................9
- Contents .............................................................9
- EmissionsControl .............................................. 9
Specifications .......................................................... 12
- ModelsHC-1500/1600/2000/2400/2410 ............. 12
Assembly ................................................................. 12
Pre-Operation........................................................... 13
- Fuel ................................................................... 13
- EquipmentCheck.............................................. 15
- DetermineOperationArea ................................ 15
Operation ................................................................. 16
- StartingColdEngine......................................... 16
- StartingWarmEngine ...................................... 17
- Stopping Engine ............................................... 18
Maintenance............................................................ 18
- SkillLevels........................................................ 18
- Maintenance Intervals...................................... 19
- AirFilter ........................................................... 20
- FuelFilter.......................................................... 20
- SparkPlug ........................................................ 21
- CoolingSystem ................................................ 21
- ExhaustSystem ................................................ 22
- CarburetorAdjustmentEmission ..................... 23
- Carburetor Adjustment Non Emission ............. 24
- Lubrication ....................................................... 25
- BladeStiffenerRemove/Install ......................... 27
- Sharpening Blades............................................ 28
Troubleshooting...................................................... 29
Storage ..................................................................... 30
ServicingInformation .............................................. 32
- Parts .................................................................. 32
- Service .............................................................. 32
- Warranty Card .................................................. 32
- Additional or Replacement Manuals ................ 32
- Manual Ordering Instructions.......................... 32
Specifications, descriptions and illustrative material in this
literature are as accurate as known at the time of publica-
tion, but are subject to change without notice. Illustra-
tions may include optional equipment and accessories,
and may not include all standard equipment.
CopyRight© 2000 By Echo, Incorporated
All Rights Reserved.

HEDGE CLIPPER
OPERATOR'SMANUAL 3
Throughout this manual and on the product itself, you will find safety
alerts and helpful, information messages preceded by symbols or key
words. The following is an explanation of those symbols and key words
and what they mean to you.
This symbol accompanied by the words WARNING and
DANGER calls attention to an act or condition that can lead to
serious personal injury to operator and bystanders.
The circle with the slash symbol means whatever is shown
within the circle is prohibited.
IMPORTANT
The enclosed message provides
information necessary for the protec-
tion of the unit.
NOTE
This enclosed message provides tips
for use, care and maintenance of the
unit.
MANUAL SAFETY SYMBOLS AND IMPORTANT INFORMATION
SAFETY
DECALS
Locate these safety decals on your unit. The complete unit illustration found in the "DESCRIPTION" section, will help
you locate them. Make sure the decals are legible and that you understand and follow the instructions on them. If a
decal cannot be read, a new one can be ordered from your ECHO dealer. See PARTS ORDERING instructions for
specificinformation.
ALL HEDGE CLIPPER MODELS
HC-2000, HC-2400, HC-2410 ONLY
HC-1500, HC-1600 ONLY
P/NX505000270
P/NX505000290

4
Symbol
description/application Symbol form/shape Symbol
description/application
Symbol form/shape
Hot
Surface
Carburetor adjustment
- Idle speed
Carburetor adjustment
- High speed mixture
Symbol
description/application Symbol form/shape Symbol
description/application
Symbol form/shape
Read and understand
owners manual.
Wear eyes, ears and
head protection
Emergency stop
Fuel and oil mixture
Finger Severing
Carburetor adjustment
- Low speed mixture
Safety/Alert
Avoid all power
lines. This unit is not
insulated against
electrical current.
Do not operate clos-
er than 15 M (50 ft.)
from electrical haz-
ards.
Plan retreat path
from falling
objects.
Wear hand protec-
tion. Use two handed.
DO NOT smoke
near fuel.
DO NOT allow
flames or sparks
near fuel.
Wear slip resistant
foot wear.
Engine choke
control.
Ignition Ignition
ON/OFF
Chain lubrication Do not operate
without guards
in place.
Keep bystanders at least
4.5 meters (15 feet) away.
Primer bulb
INTERNATIONALSYMBOLS
EQUIPMENT
Before operation a complete check of the unit must be performed;
• Check unit for loose/missing nuts, bolts and screws. Tighten and/or
replace as needed.
• Inspect fuel lines, tank and area around carburetor for fuel leaks. DO
NOT operate unit if leaks are found.
• Never adjust blades when the engine is operating.
• Inspect hand guard for damage. Replace if damaged or missing.
• Check that the blade assembly is firmly attached and in safe operating
condition. Dull, loose or damaged blades should not be used.
• ECHO, INC. will not be responsible for the failure of cutting devices
or accessories which have not been tested and approved by ECHO
for use with this unit.

HEDGE CLIPPER
OPERATOR'SMANUAL 5
FUEL
WARNING DANGER
FuelisVERYflammable.Useextremecarewhenmixing,storingor
handling or serious personal injury may result.
• Use an approved fuel container.
• DONOTsmokenearfuel.
• DONOTallowflamesorsparksnearfuel.
• Fuel tanks/cans may be under pressure. Always loosen fuel caps
slowly allowing pressure to equalize.
• NEVERrefuelaunitwhen the engine is HOT!
• NEVERrefuelaunitwiththeenginerunning.
• DONOT fill fueltanks indoors.ALWAYS fillfuel tanksoutdoors
over bare ground.
• Securely tighten fuel cap after refueling.
• Inspect for fuel leakage. If fuel leakage is found, do not start or
operate unit until leakage is repaired.
IMPORTANT
Spilled fuel is a leading cause of hydrocarbon emissions. Some
states may require the use of automatic fuel shut-off containers to
reduce fuel spillage. Contact your ECHO dealer for ordering
information.
After Refueling;
• Wipe any spilled fuel from the unit.
• Move at lease 3 m (10 ft.) from refueling location before starting the
engine.
After use;
• DO NOT store a unit with fuel in its tank. Leaks can occur. Return
unused fuel to an approved fuel storage container.
3 m (10 ft.)
PERSONAL CONDITION AND SAFETY EQUIPMENT
WARNING DANGER
Hedge Clipper users risk injury to themselves and others if the hedge clipper is used improperly and or safety
precautions are not followed. Proper clothing and safety gear must be worn when operating a hedge clipper.

6
Physical Condition --
Eye Protection --
Eye protection that meet ANSI Z87.1 or CE requirements must be worn
whenever you operate the Hedge Clipper.
Hand Protection --
Wear no-slip, heavy duty work gloves to improve your grip on the
handles. Gloves also reduce the transmission of machine vibration to
your hands.
Hearing Protection --
Wearhearing protection. ECHO recommendswearing hearingprotec-
tion whenever unit is used.
Proper Clothing --
Wear snug fitting, durable clothing;
• Pants should have long legs, shirts with long sleeves.
• DONOTWEARSHORTS,
• DONOTWEARTIES,SCARFS,JEWELRY.
Wear protective hair covering to contain long hair.
Wear sturdy work shoes with nonskid soles;
• DONOTWEAROPENTOEDSHOES,
• DONOTOPERATEUNITBAREFOOTED.
Wear no-slip, heavy duty work gloves.
Hot Humid Weather --
Heavy protective clothing can increase operator fatigue which may
lead to heat stroke. Delay heavy work until temperature drops.
Your judgment and physical dexterity may not be good:
• if you are tired or sick,
• ifyou are taking medication,
• if you have taken alcohol or drugs
Operate unit only if you are physically and mentally well.

HEDGE CLIPPER
OPERATOR'SMANUAL 7
SAFE OPERATION
Determine Operation Area
• Do not operate this product indoors or in inadequately ventilated
areas.
• Review the area to be trimmed. Look for hazards that could contribute
to unsafe conditions.
• Spectators and fellow workers must be warned, and children and
animalspreventedfrom comingnearerthan4.5 m(15ft.)whilethe
Hedge Clipper is in use.
• Provide all users of this equipment with the Operator's Manual and
instructions for Safe Operation.
Operation
UseProperClothing&Equipment
• Before starting the unit, equip yourself and any other personworking
withinthe 4.5 m(15ft.) Safety Zonewith therequired Protective
Equipment and clothing.
KeepaSolidStance
• Maintain footing and balance at all times. Do not stand on slippery,
uneven or unstable surfaces. Do not work in odd positions or on
ladders. Do not over reach.
KeepaFirmGrip
• Hold the front and rear handles with both hands, with thumbs and
fingers tightly encircling the handles.
AvoidHotSurfaces
• During operation, the complete unit, especially the power head,
muffler area and cutting attachment may become very hot, too hot to
touch.Avoid contact during and immediately after operation.
4.5 m (15 ft.)

8
EXTENDED OPERATION/EXTREME CONDITIONS
Vibration and Cold
It is believed that a condition called Raynaud’s Phenomenon, which
affects the fingers of certain individuals may be brought about by
exposure to vibration and cold. Exposure to vibration and cold may
cause tingling and burning sensations followed by loss of color and
numbness in the fingers. The following precautions are strongly
recommendedbecause the minimum exposure whichmight trigger the
ailmentisunknown.
• Keep your body warm, especially the head, neck, feet, ankles, hands
and wrists.
• Maintain good blood circulation by performing vigorous armexercises
during frequent work breaks and also by not smoking.
• Limit the hours of operation. Try to fill each day with jobs where
operating the trimmer or other hand-held power equipment is not
required.
• If you experience discomfort, redness and swelling of the fingers
followed by whitening and loss of feeling, consult your physician
before further exposing yourself to cold and vibration.
Repetitive Stress Injuries
It is believed that overusing the muscles and tendons of the fingers,
hands, arms and shoulders may cause soreness, swelling, numbness,
weakness and extreme pain in those areas. Certain repetitive hand
activities may put you at a high risk for developing a Repetitive Stress
Injury(RSI).AnextremeRSIconditionisCarpalTunnelSyndrome
(CTS), which could occur when your wrist swells and squeezes a vital
nerve that runs through the area. Some believe that prolonged expo-
sure to vibration may contribute to CTS. CTS can cause severe pain for
months or even years.
To reduce the risk of RSI/CTS, do the following:
• Avoid using your wrist in a bent, extended or twisted position.
Instead try to maintain a straight wrist position. Also, when grasping,
use your whole hand, not just the thumb and index finger.
• Take periodic breaks to minimize repetition and rest your hands.
• Reduce the speed and force with which you do the repetitivemove-
ment.
• Do exercises to strengthen the hand and arm muscles.
• Immediately stop using all power equipment and consult a doctor if
you feel tingling, numbness or pain in the fingers, hands, wrists or
arms. The sooner RSI/CTS is diagnosed, the more likely permanent
nerve and muscle damage can be prevented.

HEDGE CLIPPER
OPERATOR'SMANUAL 9
DESCRIPTION
The ECHO product you purchased has been factory
pre-assembled for your convenience.
After opening the carton, check for damage. Immedi-
atelynotifyyour retailer orECHODealerofdamaged
or missing parts. Use the contents list to check for
missing parts.
CONTENTS
__ 1 - Hedge Clipper Assembly
__ 1 - Operators Manual
__ 1 - Safety Manual
__ 1 - Warranty Statement
__ 1 - Warranty Registration Card
__ 1 - PlasticBag
__ - T-Wrench
__ -8mmx10mmOpenendWrench
__ -Bottle2.6oz.2-CycleOil
__ 1 - BladeCover
EMISSION CONTROL - Emissions Models
The emission control system for this engine is EM (Engine
Modification).
EmissionControlLabel (locatedonEngine) (EXAMPLE
ONLY,informationonlabelvariesbyFAMILY).
IMPORTANT ENGINE INFORMATION
ENGINEFAMILY:TEH021UB24RA
DISPLACEMENT: 21.2cc
THISENGINE MEETS U.S.EPA PHIAND1995 - 1999
CALIFORNIAEMISSIONREGULATIONSFORULGE
ENGINES.REFERTOOWNER’SMANUAL FOR
MAINTENANCESPECIFICATIONSANDADJUSTMENTS.
IMPORTANTThissparkignitionsystemcomplieswithCanadianICES-002.

10
14
18
12
15
8
6
16
11
5
7
17 HC-2000, 2400, 2410
2
1
HC-1500, 1600
3
4
6
7
8
9
10
11
12
13
14
15
16
10
13
19
20

HEDGE CLIPPER
OPERATOR'SMANUAL 11
1. SAFETYMANUAL- Read andunderstand thismanual before operation. Keepmanual in asafe locationof
safe operating techniques.
2. OPERATOR'SMANUAL- Readand understandthis manualbefore operation. Keepmanual ina safe
location for future reference, i.e., operation, maintenance, storage and specifications.
3. POWER HEAD - Factory Assembled to the gear housing assembly. Includes the Engine, Clutch, Fuel
System,Ignition System and RecoilStarter.
4. REARHANDLE-HC-1500,1600. ContainstheStopSwitch,ThrottleLockoutandThrottleTrigger.
5. LEFTHANDREARHANDLE-HC-2000,2400,2410. ContainstheStopSwitch,ThrottleLockoutand
ThrottleTrigger.
6. FRONTHANDLE/GUARD-
HC-1500,1600. Comfortable,texturedfinish provides anti-slip gripforfronthand. Guardprotectshandfrom
the blades. Warning decals are located on guard.
HC-2000,2400and HC-2410. Right Hand Handle,Rubberanti-slipgrip,guardprotectshand from theblades.
Warning decals are located on guard.
7. STOPSWITCH-
HC-1500. "TOGGLESWITCH"locatedontheleftsideoftherearhandle. MoveswitchUPtoRUN,DOWNtoSTOP.
HC-1600,HC-2000,2400,2410 "SLIDESWITCH"mountedontopofthelefthandrearhandle. MoveswitchFOR-
WARDtoRUN,BACKtoSTOP.
8. THROTTLETRIGGERLOCKOUT-ThislevermustbedepressedbeforeThrottleTriggercanbeactivated.
9. THROTTLETRIGGER-Springloadedtoreturntoidlewhenreleased. TriggerLockoutmustbedepressedfully
before Throttle Trigger will move. During acceleration, depress gradually for best operating technique.
10. BLADES- Double reciprocating blades mounted to a blade support bar. Models HC-1500, HC-1600 are double sided
blades, meaning they are capable of cutting on either side of the blade. All other models are single sided.
11. AIRCLEANER-Containsreplaceablefilterelement.
12. PRIMERBULB- Pumpingprimer bulbbeforestartingenginedrawsfresh fuel fromthefueltankpriming the carbure-
tor for starting. Pump primer bulb until fuel is visible and flows freely in the clear fuel tank return line. Pump bulb an
additional4or 5 times.
13. CHOKE - The choke control lever is located on the top of the choke case. Move to "COLD START" to close the
choke for Cold Starting. Move to "RUN" position to open choke.
14. RECOILSTARTERHANDLE-Pullhandleslowlyuntilrecoilstarterengages,thenquicklyandfirmly. DONOTpull
rope all the way out or allow the handle to snap back, damage to the starter will occur.
15. FUELTANK-Containsfuelandfuelfilter.
16. FUELTANKCAP-Coversandsealsfueltankopening.
17. SPARKPLUG-Providessparktoignitefuelmixture.
18. MUFFLER/SPARKARRESTOR-Themufflercontrolstheexhaustnoisewhilethesparkarrestorpreventshot,
glowing particles of carbon from leaving the muffler where they could possibly start a fire.
19. BLADE COVER - Used to cover blades during transportation or storage. Remove blade cover before using unit.
20. SAFETYVIDEO-(Notincludedwithunit)P/N99922202800Englishversiononlyisavailableatacostof$5.00from
ECHO, INC. or any authorized ECHO dealer. The video overviews safety precautions and proper operating tech-
niques and is supplemental to the Safety Manual. Read and understand the Safety Manual for complete information
on safe operation.

12
SPECIFICATIONS
LEDOME10051-CH E20051-CH E10061-CHE10002-CHE10042-CH E20042-CH E10142-CH E20142-CH
htgneLmm069 ).ni8.73( mm3311 ).ni6.44( mm099 ).ni0.93( mm0301 ).ni6.04( mm0821 ).ni4.05(
htdiWmm522 ).ni9.8( mm042 ).ni4.9( mm042 ).ni4.9( mm042 ).ni4.9( mm042 ).ni4.9(
thgieHmm091 ).ni5.7( mm002 ).ni9.7( mm032 ).ni1.9( mm012 ).ni3.8( mm012 ).ni3.8(
yrd,thgieWgk4.4 ).bl7.9( gk3.5 ).bl7.11( gk2.5 ).bl4.11( gk2.5 ).bl4.11( gk2.5 ).bl4.11(
enignEfoepyT enigneenilosag,rednilycelgnis,ekorts-owt,deloocriA
tnemecalpsiDcc2.12 ).ni.uc92.1( cc2.12 ).ni.uc92.1( cc2.12 ).ni.uc92.1( cc6.32 ).ni.uc44.1( cc6.32 ).ni.uc44.1(
eroBmm2.23 ).ni72.1( mm2.23 ).ni72.1( mm2.23 ).ni72.1( mm0.43 ).ni43.1( mm0.43 ).ni43.1(
ekortSmm0.62 ).ni20.1( mm0.62 ).ni20.1( mm0.62 ).ni20.1( mm0.62 ).ni20.1( mm0.62 ).ni20.1(
metsyStsuahxE relffuMrotserrAkrapS
roterubraC U1CamaZ
metsySnoitingI noitingiegrahcsidroticapaC,otengaMleehwylF
gulPkrapS ).ni620.0(mm56.0paG(A7-RMPB
leuF liodnaenilosag-leuFdexiM
oitaRliO/leuF lioenignedeloocriaekorts-owt,ecnamrofreP-iHOHCEgnisuoitaR1:05
enilosaG %01nahterom,lohoclalyhtemgniniatnocleufesutonoD.dedaelnUenatcO98 .EBTM%51rolohoclalyhte
liO lioenignedeloocriaekorts-owt,ecnamrofreP-iHOHCE
yticapaCknaTleuF.til3.0 )zo.lf1.01( .til5.0 )zo.lf0.71( .til5.0 )zo.lf0.71( .til5.0 )zo.lf0.71( .til5.0 )zo.lf0.71(
metsySretratS retratSlioceRcitamotuA
hctulC epyTlagufirtneC
oitaResaCraeG88.5:188.5:188.5:1E131.5:1 E29.3:1 E131.5:1 E29.3:1
elbuoD(rettuC )edalBgnitacorpiceR egdEelbuoDegdEelbuoDegdEelgniSegdEelgniSegdEelgniS
htgneLmm375 ).ni6.22( mm127 ).ni4.82( mm057 ).ni5.92( mm057 ).ni5.92( mm499 ).ni1.93(
hctiP ).ni4.1(mm53
thgieHmm12 ).ni38.0( mm12 ).ni38.0( mm42 ).ni49.0( mm42 ).ni49.0( mm42 ).ni49.0(
)MPR(deepSeldI 0003
)MPR(elttorhTnepOediW 000,21-000,11

HEDGE CLIPPER
OPERATOR'SMANUAL 13
ASSEMBLY HC MODELS ARE PRE-ASSEMBLED IN THE BOX.
Tools Required: None
Parts Required: None
PRE-OPERATION
FUEL
Fuel Requirements
Gasoline - Use 89 Octane [ ] (mid grade or higher) gasoline
known to be good quality. Gasoline may contain up to 15% MTBE
(methyltertiary-butyl ether). Gasohol containingmethyl (wood)
alcohol is NOT approved.
TwoStrokeOil-Atwo-strokeengineoilmeetingISO-L-EGD
(ISO/CD13738)andJ.A.S.O.FC Standards, must be used. Echo
brand Premium 50:1 oil meets these standards. Engine problems
due to inadequate lubrication caused by failure to use an ISO-L-
EGDandJ.A.S.O.FCcertifiedoil,suchasEchoPremium50:1Two-
strokeOil,willvoid the two-stroke engine warranty. (Emission
related parts only are covered for two years, regardless of two-
stroke oil used, per the statement listed in the EPA Phase I/
CaliforniaEmissionDefectWarrantyExplanation.)
IMPORTANT
EchoPremium2-StrokeOilmaybemixedat50:1ratiofor
application in all Echo engines sold in the past regardless of
ratio specified in those manuals.
Mixing Instructions
1. Fill an approved fuel container with half of the required amount
of gasoline.
2. Add 2-stroke oil to gasoline.
3. Close container and shake to mix oil with gasoline.
4. Addremaininggasolineandremix.
5. Install fuel container cap and wipe any spilled fuel from con-
tainer and surrounding area.
R+M
2

14
Handling Fuel
WARNING DANGER
FuelisVERYflammable.Useextremecarewhenmixing,storingor
handling or serious personal injury may result.
• Use an approved fuel container.
• DONOTsmokenearfuel.
• DONOTallowflamesorsparksnearfuel.
• Fuel tanks/cans may be under pressure. Always loosen fuel caps
slowly allowing pressure to equalize.
• NEVERrefuelaunitwhen the engine is HOT!
• NEVERrefuelaunitwiththeenginerunning.
• DONOT fill fueltanks indoors.ALWAYS fillfuel tanksoutdoors
over bare ground.
• Securely tighten fuel cap after refueling.
• Inspect for fuel leakage. If fuel leakage is found, do not start or
operate unit until leakage is repaired.
IMPORTANT
Spilled fuel is a leading cause of hydrocarbon emissions. Some
states may require the use of automatic fuel shut-off containers to
reduce fuel spillage. Contact your ECHO dealer for ordering
information.
After Refueling;
• Wipe any spilled fuel from the unit.
• Move at lease 3 m (10 ft.) from refueling location before starting the
engine.
After use;
• DO NOT store a unit with fuel in its tank. Leaks can occur. Return
unused fuel to an approved fuel storage container.
Storage - Fuel storage laws vary by locality. Contact your local
government for the laws affecting your area. As a precaution, store fuel
in an approved, air tight container. Store in a well ventilated, unoccu-
pied building, away from sparks and flames. Do not store fuel longer
than 30 days.
IMPORTANT
Stored fuel ages. Do not mix more fuel than you expect to use in
thirty (30) days, ninety (90) days when a fuel stabilizer is added.
IMPORTANT
Stored two-stroke fuel may separate. ALWAYS shake fuel
container thoroughly before each use.
3 m (10 ft.)
SM T WT F S
1234567
8 9 1011121314
15 16 17 18 19 20 21
22 23 24 25 26 27 28
29 30 31

HEDGE CLIPPER
OPERATOR'SMANUAL 15
EQUIPMENT CHECK
Before operation a complete check of the unit must be performed;
• Check unit for loose/missing nuts, bolts and screws. Tighten and/or
replace as needed.
• Inspect fuel lines, tank and area around carburetor for fuel leaks. DO
NOT operate unit if leaks are found.
• Never adjust blades when the engine is operating.
• Inspect hand guard for damage. Replace if damaged or missing.
• Check that the blade assembly is firmly attached and in safe operating
condition. Dull, loose or damaged blades should not be used.
4.5 m (15 ft.)
DETERMINE OPERATION AREA
• Before starting the unit, equip yourself and fellow workers in the 4.5 m
(15 ft.) safety zone with the required protective equipment and
clothing.
• Review the area to be trimmed. Look for hazards that could contribute
to unsafe conditions.
• Spectators, children and animals must be prevented from coming
nearerthan 4.5 m (15Ft.) whilethe HedgeClipper isin use.

16
4.5 m (15 ft.)
C
B
COLD
START
RUN
IDLE
H L
OPERATION
• Provide all users of this equipment with the Operator's Manual and
instructions for Safe Operation.
• Before starting the unit, equip yourself and any other person working
withinthe 4.5 m(15ft.) Safety Zonewith therequired Protective
Equipment and clothing.
• During operation, the complete unit, especially the gear box may
become very hot, too hot to touch. Avoid contact during and
immediatelyafteroperation.
• Do not operate this product indoors or in inadequately ventilated
areas.
STARTING COLD ENGINE
1. STOPSWITCH-START/RUN.
Move stop switch (A) away from the STOP position.
2. CHOKE-COLDSTART.
Movechoke(B)totheColdStart(CLOSED)position.
3. PRIMER-PUMPBULB.
Pumpprimerbulb (C) until fuel isvisible and flows freelyin the clear
fuel tank return line. Pump bulb an additional 4 or 5 times.
A
A

HEDGE CLIPPER
OPERATOR'SMANUAL 17
4. START-PULLROPE
Lay the hedge clipper on a flat clear area and pull the recoil starter
handle(D) until enginefires.
5. OPENCHOKE-RUN.
Move choke (B) to the RUN (OPEN) position. Restart engine if
necessary and allow unit to warm up at idle for several minutes.
WARNING DANGER
The blades should not move at idle. If blades move, readjust
carburetor according to "Carburetor Adjustment" instructions in
this manual or see your ECHO Dealer, otherwise serious personal
injurymayresult.
6. After engine warm up, gradually depress throttle trigger to increase
engine RPM to operating speed.
STARTING WARM ENGINE
The starting procedure is the same as Cold Start except DO NOT close
the choke.
WARNING DANGER
The blades should not move at idle. If blades move, readjust
carburetor according to "Carburetor Adjustment" instructions in
this manual or see your ECHO Dealer, otherwise serious personal
injurymayresult.
1. STOPSWITCH-START/RUN
Move stop switch (A) away from the STOP position.
2. START-PullRope
Lay the hedge clipper on a flat clear area and pull the recoil starter
handle (D) until the engine fires.
NOTE
If engine does not start after 5 pulls, use Cold Start Procedure.
B
COLD
START
RUN
IDLE
H L

18
STOPPING ENGINE
1. RELEASETHROTTLE. Allowenginetoidleforaminute.
2. STOP SWITCH - STOP. Move stop switch (A) to STOP position.
WARNING DANGER
If engine does not stop when stop switch is moved to STOP
position, close choke - COLD START position - to stall engine.
Have your ECHO dealer repair stop switch before using hedge
clipperagain.
MAINTENANCE
Your ECHO Hedge Clipper is designed to provide many hours of trouble free service. Regular scheduled maintenance will
help your Hedge Clipper achieve that goal. If you are unsure or are not equipped with the necessary tools, you may want
to take your unit to an ECHO Service Dealer for maintenance. To help you decide whether you want to DO-IT-YOUR-
SELF or have the ECHO Dealer do it, each maintenance task has been graded. If the task is not listed, see your ECHO
ServiceDealerforrepairs.
SKILL LEVEL
Level1= Easy to do. Most required tools come with unit.
Level2= Moderate difficulty. Somespecialized toolsmay berequired.
Level3= Experiencerequired.Specializedtoolsarerequired.ECHOrecommendsthe
unit be returned to your ECHO dealer for servicing.
ECHO offers REPOWERTM Maintenance Kits and Parts to make your maintenance job easier. Just below each task
heading are listed the various part numbers required for that task. See your ECHO dealer for these parts.

HEDGE CLIPPER
OPERATOR'SMANUAL 19
MAINTENANCE INTERVALS
metsyS/tnenopmoC ecnanetniaM erudecorP
erofeB esU yrevE leufeR
yliaD ro yrevE 4sruoH
3shtnoM 001ro sruoH 6shtnoM 003ro sruoH
ylraeY 006ro sruoH
retliFriAecalpeR/tcepsnI C/IC/I*R
reniartSleuFecalpeR/tcepsnI IR
eniLleuFecalpeR/tcepsnI I*IR
roterubraCecalpeR/tcepsnI C)1(R
metsySekohCecalpeR/tcepsnI I
metsySgnilooCnaelC/tcepsnI C/IC/I
rotserrAkrapSrelffuMecalpeR/naelC/tcepsnI C/IR
gnisuoHraeGesaerG )2(I
retratSlioceR epoR naelC/tcepsnI I*I
skaeLleuFriapeR/tcepsnI II *I
gulPkrapSnaelC C/I*R
metsySnoitingIecalpeR/naelC leehwylfdnaliocrofderiuqerecnanetniaMoN
stloB/stuN/swercSecalpeR/nethgiT/tcepsnI *I
NAELC=C,ECALPER=R,TCEPSNI=I foycneuqerfehtenimretedlliwecneirepxeruoydnaesulautcA.mumixameranwohsslavretniemiTTNATROPMI .ecnanetniamderiuqer .noitcepsnignirudraewroegamadfognidnifehtnodesaberaecalperotsnoitadnemmocerllA* sishtnom6yrevegninaelc,esuremusnoCroF.sruoh006retfaesulaicremmoCrofderiuqereblliwtnemecalpeR)1( .deriuqer OHCEfospmup2~1ylppA)2(
®
EBUL
MT
.sruoh01yreve

20
AIR FILTER
Level 1.
Tools required: 25or 50mm(1 or2in.) mediumbristlepaint brush
Parts required: 90008REPOWERTMAIR&FUELFILTERKIT
1. Close choke (Cold Start Position). This prevents dirt from entering
the carburetor throat when the air filter is removed. Brush accumu-
lateddirtfromthe air cleaner area.
2. Remove the air cleaner cover. Clean and inspect the element for
damage. If element is fuel soaked and very dirty, replace.
3. If element can be cleaned and reused, be certain it:
-still fits the cavity in the air cleaner cover.
-is installed with the original side out.
NOTE
Carburetor adjustment may be needed after air filter cleaning/
replacement.
FUEL FILTER
Level 1.
Tools required: 203-254mm (8-10in.)lengthofwirewithoneend
bent into a hook. Clean rag, funnel, and an approved fuel container
Parts required: 90008REPOWERTMAIR&FUELFILTERKIT
WARNING DANGER
FuelisVERYflammable.Useextremecarewhenmixing,storingor
handling.
1. Use a clean rag to remove loose dirt from around fuel cap and empty
fueltank.
2. Use the “fuel line hook” to pull the fuel line and filter from the tank.
3. Remove the filter from theline and install the newfilter.
