Echo Pro Attachment DPAS-2100 Series User manual

99922205734
© 08/2021 ECHO Incorporated
Operator’s
Manual
DPAS-2100
Pro Attachment
Series™
This product contains chemicals known to the State of California
to cause cancer, birth defects, or other reproductive harm. Cancer
and Reproductive Harm www.P65Warnings.ca.gov
Read and understand all provided literature before use.
Failure to do so could result in serious injury.

DPAS-2100
999222057342
© 08/2021 ECHO Incorporated
TABLE OF CONTENTS
TABLE OF CONTENTS
Introduction............................................................................................................3
Servicing Information..........................................................................................................3
Parts / Serial Number.................................................................................................3
Service.......................................................................................................................4
ECHO Consumer Product Support............................................................................4
Product Registration..................................................................................................4
Additional Literature...................................................................................................4
Packing List...............................................................................................................4
Safety.................................................................................................................................5
Manual Safety Symbols and Important Information...................................................5
InternationalSymbols.................................................................................................6
General Power Tool Safety Warnings........................................................................7
Enviromentally Battery Disposal..............................................................................13
Description.......................................................................................................................14
Assembly..............................................................................................................16
Unpack The Machine...............................................................................................16
Assemble The Shaft.................................................................................................17
Attach The Support Handle.....................................................................................18
Install The Battery....................................................................................................19
Remove The Battery................................................................................................19
Operation............................................................................................................20
Start The Machine...................................................................................................20
Stop The Machine....................................................................................................20
Adjust The Length Of The Cutting Line...................................................................21
Line Cut-off Knife.....................................................................................................21
Adjust The Cutting Diameter....................................................................................21
Operation Tips.........................................................................................................22
Cutting Tips.............................................................................................................22
Maintenance..............................................................................................................23
General Information.................................................................................................23
Clean The Machine..................................................................................................23
Nylon Line Replacement..........................................................................................24
Nylon Line Head Disassembly Instructions.............................................................25
Troubleshooting...............................................................................................................26
Storage...............................................................................................................28
Storage After Use....................................................................................................28
Specications.............................................................................................................29
Product Registration.........................................................................................................30
Warranty.............................................................................................................32

3
DPAS-2100
99922205734
© 08/2021 ECHO Incorporated
INTRODUCTION
SERVICING INFORMATION
INTRODUCTION
Specications, descriptions and illustrative material in this literature are as
accurate as known at the time of publication, but are subject to change without
notice. Illustrations may include optional equipment and accessories, and may
not include all standard equipment.
For additional literature, including safety manuals where applicable, or
questions regarding terms used in this manual, visit:
https://www.echo-usa.com/manuals
Genuine ECHO Parts and Assemblies
for your ECHO products are available
only from an Authorized ECHO Dealer.
When you do need to buy parts always
have the Model Number and Serial
Number of the unit with you. For future
reference write them in the space
provided below.
Model No. _______________ Serial No. _______________
Parts / Serial Number
Read and understand all provided
literature. Literature contains specications
and information for safety, operation,
maintenance, storage, and assembly specic
to this product. Scan QR codes for more
information.

DPAS-2100
999222057344
© 08/2021 ECHO Incorporated
SERVICING INFORMATION
Service of this product during the warranty period must be performed by an
Authorized ECHO Service Dealer. For the name and address of the Authorized
ECHO Service Dealer nearest you, ask your retailer or call: 1-800-432-ECHO
(3246). Dealer information is also available on our Web Site www.echo-usa.
com. When presenting your unit for Warranty service/repairs, proof of purchase
is required.
If you require assistance or have questions concerning the application,
operation, or maintenance of this product, call the ECHO Consumer Product
Support Department at 1-800-432-ECHO (3246) from 8:00 am to 5:00 pm
(Central Standard Time) Monday through Friday. Before calling, please know
the model and serial number of your unit.
the product registration sheet included in this manual. Registering your product
necessary to contact you.
Authorized ECHO Service Dealer, or by contacting ECHO Incorporated, 400
Oakwood Road, Lake Zurich, IL 60047, 1-800-432-ECHO (3246).
The ECHO product you purchased has been factory pre-assembled for
your convenience. Due to packaging restrictions, some assembly may be
necessary.
After opening the carton, check for damage. Immediately notify your retailer or
ECHO Dealer of damaged or missing parts. Use the contents list to check for
missing parts.
1 Power Head With Upper Drive Shaft Assembly
1 Lower Drive Shaft Trimmer Attachment
1 Support Handle Assembly
1 Operator's Manual
Service
ECHO Consumer Product Support
Product Registration
Additional Literature
PACKING LIST

5
DPAS-2100
99922205734
© 08/2021 ECHO Incorporated
SAFETY
SAFETY
Manual Safety Symbols and Important Information
Throughout this manual and on the product itself, you will nd safety alerts
and helpful, informational messages preceded by symbols or key words. The
following is an explanation of those symbols and key words and what they
mean to you.
The safety alert symbol accompanied by the word “DANGER”
calls attention to an act or condition which WILL lead to serious
personal injury or death if not avoided.
The safety alert symbol accompanied by the word “WARNING”
calls attention to an act or condition which CAN lead to serious
personal injury or death if not avoided.
The safety alert symbol accompanied by the word “CAUTION”
calls attention to an act or condition which might lead to minor or
moderate personal injury if not avoided.
The enclosed message provides information necessary for the
protection of the unit.
Note: This enclosed message provides tips for use, care and
maintenance of the unit.
CIRCLE AND SLASH SYMBOL
This symbol means the specic action shown is prohibited.
Ignoring these prohibitions can result in serious or fatal injury.

DPAS-2100
999222057346
© 08/2021 ECHO Incorporated
SAFETY
Symbol Description Symbol Description
Direct current Safety / Alert
Read and follow all
safety precautions
in the operator's
manual. Failure to
follow instructions
could result in
serious personal
injury.
Wear eye protection.
Wear safety
footwear.
Wear protective
gloves.
Wear head
protection.
Do not expose to rain
or in damp condition.
Thrown objects can
ricochet and result
in personal injury or
property damage.
Keep all bystanders
at least 50'/15m
away.
International Symbols
Some of the following symbols may be used on this product. Please study
them and learn their meaning. Proper interpretation of these symbols will allow
you to operate the product better and safer.
Note: Not all symbols will appear on your unit.

7
DPAS-2100
99922205734
© 08/2021 ECHO Incorporated
SAFETY
General Power Tool Safety Warnings
Read all safety warnings, instructions, illustrations and
specications provided with this power tool. Failure to follow
the warnings and instructions may result in electric shock re and/or
serious injury.
Save all warnings and instructions for future reference.
The term ″power tool″ in the warnings refers to your BATTERY-operated
(cordless) power tool.
Work Area Safety
• Keep work area clean and well lit. Cluttered or dark areas invite
accidents.
• Do not operate power tools in explosive atmospheres, such as in
the presence of ammable liquids, gases or dust. Power tools create
sparks which may ignite the dust or fumes.
• Keep children and bystanders away while operating a power tool.
Distractions can cause you to lose control.
Electrical Safety
• Power tool plugs must match the outlet. Never modify the plug in any
way. Do not use any adapter plugs with earthed (grounded) power
tools. Unmodied plugs and matching outlets will reduce risk of electric
shock.
• Avoid body contact with earthed or grounded surfaces, such as
pipes, radiators, ranges and refrigerators. There is an increased risk of
electric shock if your body is earthed or grounded.
• Do not expose power tools to rain or wet conditions. Water entering a
power tool will increase the risk of electric shock.
• Do not abuse the cord. Never use the cord for carrying, pulling or
unplugging the power tool. Keep cord away from heat, oil, sharp
edges or moving parts. Damaged or entangled cords increase the risk of
electric shock.
• When operating a power tool outdoors, use an extension cord
suitable for outdoor use. Use of a cord suitable for outdoor use reduces
the risk of electric shock.
• If operating a power tool in a damp location is unavoidable, use a
RESIDUAL CURRENT DEVICE (RCD) protected supply. Use of an RCD
reduces the risk of electric shock.
READ ALL INSTRUCTIONS BEFORE USING (THIS POWER TOOL)

DPAS-2100
999222057348
© 08/2021 ECHO Incorporated
SAFETY
Personal Safety
• Stay alert, watch what you are doing and use common sense when
operating a power tool. Do not use a power tool while you are tired
or under the inuence of drugs, alcohol or medication. A moment
of inattention while operating power tools may result in serious personal
injury.
• Use personal protective equipment. Always wear eye protection.
Protective equipment such as a dust mask, non-skid safety shoes, hard
hat or hearing protection used appropriately will reduce personal injuries.
• Prevent unintentional starting. Ensure the switch is in the off position
before connecting to power source and/or battery and when picking
up or carrying the tool. Carrying power tools with your nger on the
switch or energizing power tools that have the switch on invites accidents.
• Remove any adjusting key or wrench before turning the power tool
on. A wrench or a key left attached to a rotating part of the power tool may
result in personal injury.
• Do not over-reach. Keep proper footing and balance at all times. This
enables better control of the power tool in unexpected situations.
• Dress properly. Do not wear loose clothing or jewelry. Keep your hair,
clothing and gloves away from moving parts. Loose clothes, jewelry or
long hair can be caught in moving parts.
• If devices are provided for the connection of dust extraction and
collection facilities, ensure these are connected and properly used.
Use of dust collection can reduce dust related hazards.
• Do not let familiarity gained from frequent use of tools allow you
to become complacent and ignore tool safety principles. A careless
action can cause severe injury within a fraction of a second.
Power Tool Use and Care
• Do not force the power tool. Use the correct power tool for your
application. The correct power tool will do the job better and safer at the
rate for which it was designed.
• Do not use the power tool if the switch does not turn it on and off.
Any power tool that cannot be controlled with the switch is dangerous and
must be repaired.
• Disconnect the plug from the power source and/or remove the
battery, from the power tool before making any adjustments,
changing accessories, or storing power tools. Such preventive safety
measures reduce the risk of starting the power tool accidentally.
• Store idle power tools out of the reach of children and do not allow
persons unfamiliar with the power tool or these instructions to
operate the power tool. Power tools are dangerous in the hands of
untrained users.
• Maintain power tools and accessories. Check for misalignment or

9
DPAS-2100
99922205734
© 08/2021 ECHO Incorporated
SAFETY
• binding of moving parts, breakage of parts and any other condition
that may affect the power tool's operation. If damaged, have the
power tool repaired before use. Many accidents are caused by poorly
maintained power tools.
• Keep cutting tools sharp and clean. Properly maintained cutting tools
with sharp cutting edges are less likely to bind and are easier to control.
• Use the power tool and accessories in accordance with these
instructions, taking into account the working conditions and the
work to be performed. Use of the power tool for operations different from
those intended could result in a hazardous situation.
• Keep handles and grasping surfaces dry, clean and free from oil and
grease. Slippery handles and grasping surfaces do not allow for safe
handling and control of the tool in unexpected situations.
Battery Tool Use and Care
• Recharge only with ECHO eFORCE™ 56V battery series chargers.
A charger that is suitable for one type of battery may create a risk of re
when used with another battery.
• Use only with ECHO eFORCE™ 56V battery series. Use of any other
batteries may create a risk of injury and re.
• When battery is not in use, keep it away from other metal objects like
paper clips, coins, keys, nails, screws, or other small metal objects
that can make a connection from one terminal to another. Shorting the
battery terminals together may cause burns or re.
• Do not open or destroy the battery. Electrolytes contained within the
battery are corrosive and may cause damage to eyes or skin if released. It
may be toxic if swallowed.
• Under abusive conditions, liquid may be ejected from the battery;
avoid contact. If contact accidentally occurs, ush with water. If
liquid contacts eyes, additionally seek medical help. Liquid ejected
from the battery may cause irritation or burns.
• Exercise care in handling batteries to avoid shorting the battery with
conducting materials such as rings, bracelets, keys, etc. The battery
or conductor may overheat and cause burns if contact with said materials
is made.
• Do not use a battery or tool that is damaged or modied. Damaged
or modied batteries may exhibit unpredictable behavior resulting in re,
explosion or risk of injury.
• Do not expose a battery or tool to re or excessive temperature.
Exposure to re or temperature above 266 °F (130 °C) may cause
explosion.
• Follow all charging instructions and do not charge the battery or tool
outside the temperature range specied in the instructions. Charging
improperly or at temperatures outside the specied range may damage
the battery and increase the risk of re.

DPAS-2100
9992220573410
© 08/2021 ECHO Incorporated
SAFETY
Child Safety
Tragic accidents can occur if the operator is not aware of the presence of
children.
• Keep children out of the working area and under the watchful care of a
responsible adult.
• Do not allow children to operate this machine.
• Stay alert, and turn the machine off if a child or any other person enters
the working area.
• Use extreme care when approaching blind corners,doorways, shrubs,
trees, or other objects that may obscure your view of a child who may run
into the path of the machine.
Service
• Have your power tool serviced by a qualied repair person using
only identical replacement parts. This will ensure that the safety of the
power tool is maintained.
• Never service damaged batteries. Service of batteries should only be
performed by the manufacturer or authorized service providers.
Pro Attachment SeriesTM Safety Warnings
• Use only identical manufacturer’s replacement parts and accessories. Use
of any other parts may create a hazard or cause product damage.
• Always wear safety glasses with side shields marked to comply with ANSI
Z87.1. Everyday glasses have only impact resistant lenses. They are NOT
safety glasses. Following this rule will reduce the risk of eye injury. Use
face mask if operating in dusty work spaces.
• Avoid dangerous environment – Don’t expose power tools to damp or wet
conditions. Water entering a power tool will increase the risk of electric
shock.
• Don’t use in rain.
• Keep all bystanders, children, and pets at least 15 m. /50 ft. away.
• Dress properly – Do not wear loose clothing or jewelry. They can be
caught in moving parts. Use of rubber gloves and substantial footwear is
recommended when working outdoors. Wear protective hair covering to
contain long hair.
• Use the right machine. Do not use the machine for any job except that for
which it is intended.
• Avoid unintentional starting – Don’t carry the machine with nger on
switch. Be sure switch is off when battery is plugged in.
• Don’t force the machine – It will do the job better and with less likelihood
of a risk of injury at the rate for which it was designed.
• Don’t overreach – Keep proper footing and balance at all times.
