Echo DPPF-2100 User manual

X7508310400
© 8/23 ECHO Incorporated
Operator’s
Manual
DPPF-2100
Power Pruner®
Read and understand all provided literature before use. Failure
to do so could result in serious injury.
Cancer and Reproductive Harm
www.P65Warnings.ca.gov
Note: This product complies with CAN ICES-003(B) / NMB-003(B)

TABLE OF CONTENTS DPPF-2100
2 X7508310400
© 8/23 ECHO Incorporated
TABLE OF CONTENTS
Introduction................................................................................................................. 3
Servicing Information.................................................................................................. 3
Parts and Serial Number.................................................................................... 3
Service ............................................................................................................... 4
ECHO Consumer Product Support .................................................................... 4
Product Registration........................................................................................... 4
Additional Literature ........................................................................................... 4
Safety ......................................................................................................................... 5
For safe use of your product .............................................................................. 5
International Symbols......................................................................................... 6
Kickback............................................................................................................. 7
Handling the Product ......................................................................................... 8
Equipment ........................................................................................................ 14
General Safety Warnings and Instructions for the following ECHO tools: Curved
Shaft Edger, Straight Shaft Edger, Tiller Cultivator, or Pole Pruner, or DPAS unit
configured as a Curved Shaft Edger, Straight Shaft Edger, Tiller Cultivator, or
Pole Pruner. ..................................................................................................... 15
Description ............................................................................................................... 18
Contents................................................................................................................... 19
Assembly.................................................................................................................. 20
Cutting Attachment to Drive Shaft Installation.................................................. 20
Saw Chain Adjustment ..................................................................................... 21
Temperature Information .................................................................................. 22
Battery Charging .............................................................................................. 23
Battery Installation............................................................................................ 25
Battery Removal............................................................................................... 26
Operation.................................................................................................................. 27
Lubricating the Guide Bar and Saw Chain ....................................................... 27
Starting Unit ..................................................................................................... 28
Stopping Unit.................................................................................................... 28
Pruning Techniques.......................................................................................... 29
Maintenance............................................................................................................. 31
Skill Levels ....................................................................................................... 31
Maintenance Intervals ...................................................................................... 31
Maintenance and Care..................................................................................... 32
Lubrication........................................................................................................ 33
Guide Bar and Saw Chain Replacement ......................................................... 34
Guide Bar Cover Cleaning ............................................................................... 35
Filing Standard Saw Chain............................................................................... 36
Troubleshooting........................................................................................................ 39
Storage..................................................................................................................... 40
Storage ............................................................................................................ 40
Disposal ........................................................................................................... 41
Specifications ........................................................................................................... 42
Warranty................................................................................................................... 43
Product Registration................................................................................................. 44
Notes........................................................................................................................ 46

DPPF-2100 INTRODUCTION
X7508310400 3
© 8/23 ECHO Incorporated
INTRODUCTION
Specifications, descriptions, and illustrative material in this literature are as
accurate as possible. Specifications are subject to change without notice.
Illustrations might include optional equipment and accessories, and might
not include all standard equipment. Your equipment might appear slightly
different than pictured equipment.
Read and understand all provided literature.
Literature contains specifications and
information for safety, operation,
maintenance, storage, and assembly
specific to this product. Scan QR codes for
more information.
For additional literature, including safety manuals where applicable, or
questions regarding terms used in this manual, visit:
https://www.echo-usa.com/manuals
OR
https://www.shindaiwa-usa.com/manuals
SERVICING INFORMATION
Parts and Serial Number
Genuine ECHO parts and
assemblies for your ECHO products
are available only from an
Authorized ECHO Dealer. When
you do need to buy parts, always
have the model number and serial
number of the unit with you. For
future reference write them in the
space provided below.
Model No. _____________________ Serial No. ____________________

SERVICING INFORMATION DPPF-2100
4 X7508310400
© 8/23 ECHO Incorporated
Service
Service of this product during the warranty period must be performed by an
Authorized ECHO Service Dealer. For the name and address of the
Authorized ECHO Service Dealer nearest you, ask your retailer or call:
1-800-432-ECHO (3246). Dealer information is also available on our Web
Site www.echo-usa.com. When presenting your unit for Warranty service/
repairs, proof of purchase is required.
ECHO Consumer Product Support
If you require assistance or have questions concerning the application,
operation, or maintenance of this product, call the ECHO Consumer
Product Support Department at 1-800-432-ECHO (3246) from 8:00 a.m. to
5:00 p.m. (Central Standard Time) Monday through Friday. Before calling,
please know the model and serial number of your unit.
Product Registration
Register your ECHO equipment online at www.echo-usa.com or by filling
out the product registration sheet included in this manual. Registering your
product confirms warranty coverage and provides a direct link to ECHO if
we find it necessary to contact you.
Additional Literature
In addition to finding information online, information is available from your
Authorized ECHO Service Dealer, or by contacting ECHO Incorporated,
400 Oakwood Road, Lake Zurich, IL 60047, 1-800-432-ECHO (3246).

DPPF-2100 SAFETY
X7508310400 5
© 8/23 ECHO Incorporated
SAFETY
For safe use of your product
Be careful to read this section before using your product.
• The precautions described in this section contain important safety
information. Please observe them carefully.
• You must also read the precautions that appear in the body of the manual
itself.
Throughout this manual and on the product itself, you will find safety alerts
and helpful, informational messages preceded by symbols or key words.
The following is an explanation of those symbols and key words and what
they mean to you.
The safety alert symbol accompanied by the word “DANGER”
calls attention to an act or condition which WILL lead to serious
personal injury or death if not avoided.
The safety alert symbol accompanied by the word “WARNING”
calls attention to an act or condition which CAN lead to serious
personal injury or death if not avoided.
The safety alert symbol accompanied by the word “CAUTION”
calls attention to an act or condition which might lead to minor
or moderate personal injury if not avoided.
The enclosed message provides information necessary for the
protection of the unit.
Note: This enclosed message provides tips for use, care and
maintenance of the unit.
CIRCLE AND SLASH SYMBOL
This symbol means the specific action shown is prohibited.
Ignoring these prohibitions can result in serious or fatal injury.

SAFETY DPPF-2100
6 X7508310400
© 8/23 ECHO Incorporated
International Symbols
Note: Not all symbols will appear on your unit.
Read the Manuals
• Provide all users of this equipment with the Operator’s Manual and Safety
Manual for instructions on Safe Operation.
Clear the Work Area
• Spectators and fellow workers must be warned, and children and animals
prevented from coming nearer than 15 m (50 ft.) while the unit is in use.
Keep a Firm Grip
• Always hold throttle handle and support handle with thumbs and fingers
tightly encircling the handles.
Symbol Description Symbol Description
Warning, See
Operator’s
Manual
Direct Current
Wear Eye, Ear
and Head
Protection
Do not expose to
rain / water
Wear Hand and
Foot Protection
Do not operate
closer than 15 m
(50 ft.) from
electrical hazard.
Safety/Alert Chain Lubrication
Disconnect
battery before
maintenance
Correct chain
installation
direction

DPPF-2100 SAFETY
X7508310400 7
© 8/23 ECHO Incorporated
Keep a Solid Stance
• Maintain footing and balance at all times. Do not stand on slippery,
uneven or unstable surfaces. Do not work in odd positions or on ladders.
Do not over reach.
• Operate the Power Pruner® only from the ground or out of an approved
bucket lift.
• Always evaluate the branches to be pruned for hazards such as loose
dead branches which may fall and strike the operator or helpers. Remove
hazards before pruning.
• Plan retreat path from falling objects.
• Cut branches bounce when striking ground.
• Check that shoulder harness is adjusted for safe, comfortable operation.
• Turn the Power Pruner off when moving from tree to tree.
Kickback
Kickback can lead to dangerous loss of control of the Power
Pruner® and result in serious injury to the operator or any one
standing close by. Hold the Power Pruner firmly with both hands
with thumbs and fingers encircling the front and rear handles.
Be aware of the down and outward path the pruner will take after
the cut is made.
Kickback may occur when the moving
saw chain at the nose or tip of the
guide bar touches an object, or when
the wood closes in and pinches the
saw chain in the cut. In some cases
this may cause a lightning-fast
reverse action, kicking the guide bar
and saw chain up and back or down
and back towards the operator. Either
of these reactions may cause the
operator to lose control of the Power
Pruner which could result in serious
personal injury.
With a basic understanding of kickback, you can reduce or eliminate the
element of surprise which contributes to accidents.

SAFETY DPPF-2100
8 X7508310400
© 8/23 ECHO Incorporated
Avoid contact of the guide bar tip with any object while the saw chain is
moving.
Cut only wood. Avoid striking concrete, metal, wire, or other obstructions
which could cause kickback or damage to the saw chain.
If the saw chain does strike a foreign object, immediately stop the engine,
inspect and repair the Power Pruner if necessary.
Handling the Product
General Safety Warnings and Instructions
This section contains the prescribed general safety warnings and
instructions for battery-powered products contained in UL 2595 and for
handheld tools, transportable tools and lawn and garden machinery
contained in UL 62841-1. Additional important warnings and instructions are
provided in subsequent sections of this manual.
Important Safety Instructions
Read all safety warnings, instructions, illustrations, and
specifications provided with this power tool. Failure to follow all
instructions listed below may result in electric shock, fire,
serious injury and/or property damage.
Save all warnings and instructions for future reference.
The term "power tool" in the warnings refers to your mains-operated
(corded) power tool or battery-operated (cordless) power tool.
Work Area Safety
• Keep work area clean and well lit. Cluttered or dark areas invite
accidents.
• Do not operate power tools in explosive atmospheres, such as in the
presence of flammable liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
• Keep children and bystanders away while operating a power tool.
Distractions can cause you to lose control.

DPPF-2100 SAFETY
X7508310400 9
© 8/23 ECHO Incorporated
Electrical Safety
• Power tool plugs must match the outlet. Never modify the plug in any way.
Do not use any adapter plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets will reduce the risk of electric
shock.
• Avoid body contact with earthed or grounded surfaces such as pipes,
radiators, ranges and refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
• Do not expose power tools to rain or wet conditions. Water entering a
power tool will increase the risk of electric shock.
• Do not abuse the cord. Never use the cord for carrying, pulling or
unplugging the power tool. Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords increase the risk of electric
shock.
• When operating a power tool outdoors, use an extension cord suitable for
outdoor use. Use of a cord suitable for outdoor use reduces the risk of
electric shock.
• If operating a power tool in a damp location is unavoidable, use a ground
fault circuit interrupter (GFCI) protected supply. Use of a GFCI reduces
the risk of electric shock.
Personal Safety
• Stay alert, watch what you are doing and use common sense when
operating a power tool. Do not use a power tool while you are tired, ill, or
under the influence of drugs, alcohol or medication. A moment of
inattention while operating power tools may result in serious personal
injury.
• Use personal protective equipment. Always wear eye protection.
Protective equipment such as dust mask, non-skid safety shoes, hard
hat, or hearing protection used for appropriate conditions will reduce
personal injuries.
• Prevent unintentional starting. Ensure the switch is in the off-position
before connecting to power source and/or battery, picking up or carrying
the tool. Carrying power tools with your finger on the switch or energizing
power tools that have the switch on invites accidents.
• Disconnect the battery pack from the appliance before making any
adjustments, changing accessories, or storing appliance. Such preventive
safety measures reduce the risk of starting the appliance accidentally.
• Remove any adjusting key or wrench before turning the power tool on. A
wrench or a key left attached to a rotating part of the power tool may
result in personal injury.

SAFETY DPPF-2100
10 X7508310400
© 8/23 ECHO Incorporated
• Do not overreach. Keep proper footing and balance at all times. This
enables better control of the power tool in unexpected situations.
• Dress properly. Do not wear loose clothing or jewelry. Keep your hair,
clothing and gloves away from moving parts. Loose clothes, jewelry or
long hair can be caught in moving parts.
• If devices are provided for the connection of dust extraction and collection
facilities, ensure these are connected and properly used. Use of dust
collection can reduce dust-related hazards.
• Do not let familiarity gained from frequent use of tools allow you to
become complacent and ignore tool safety principles. A careless action
can cause severe injury within a fraction of a second.
Proper Clothing
Wear snug-fitting, durable clothing:
• Pants should have long legs, shirts should have long sleeves.
• DO NOT WEAR SHORTS.
• DO NOT WEAR TIES, SCARVES, JEWELRY, or clothing with loose or
hanging items that could become entangled in moving parts or
surrounding growth.
• Keep clothing buttoned or zipped, and keep shirt tails tucked in.
• Wear sturdy work shoes with nonskid rubber soles.
• Wear sturdy, no-slip, rubber work gloves to improve your grip on the
handles. Gloves also provide protection against cuts and scratches, cold
environments, and reduce the transmission of machine vibration to your
hands.
• DO NOT WEAR OPEN TOED SHOES.
• DO NOT OPERATE UNIT WITH BARE FEET.
Power Tool Use and Care
• Do not force the power tool. Use the correct power tool for your
application. The correct power tool will do the job better and safer at the
rate for which it was designed.
• Do not use the power tool if the switch does not turn it on and off. Any
power tool that cannot be controlled with the switch is dangerous and
must be repaired.

DPPF-2100 SAFETY
X7508310400 11
© 8/23 ECHO Incorporated
• Disconnect the plug from the power source and/or the battery from the
power tool before making any adjustments, changing accessories, or
storing power tools. Such preventive safety measures reduce the risk of
starting the power tool accidentally.
• Store idle power tools out of the reach of children and do not allow
persons unfamiliar with the power tool or these instructions to operate the
power tool. Power tools are dangerous in the hands of untrained users.
• Maintain power tools and accessories. Check for misalignment or binding
of moving parts, breakage of parts and any other condition that may affect
the power tool’s operation. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly maintained power tools.
• Keep cutting tools sharp and clean. Properly maintained cutting tools with
sharp cutting edges are less likely to bind and are easier to control.
• Use the power tool, accessories and tool bits etc. in accordance with
these instructions, taking into account the working conditions and the
work to be performed. Use of the power tool for operations different from
those intended could result in a hazardous situation.
• Keep handles and grasping surfaces dry, clean, and free from oil and
grease. Slippery handles and grasping surfaces do not allow for safe
handling and control of the tool in unexpected situations.
Battery Tool Use and Care
• Recharge batteries only with ECHO eFORCE®56V battery series
chargers. A charger that is suitable for one type of battery may create a
risk of fire when used with another battery.
• Use only with ECHO eFORCE®56V battery series. Use of any other
battery may create a risk of injury and fire.
• When battery is not in use, keep it away from other metal objects, like
paper clips, coins, keys, nails, screws or other small metal objects, that
can make a connection from one terminal to another. Shorting the battery
terminals together may cause burns or a fire.
• Under abusive conditions, liquid may be ejected from the battery; avoid
contact. If contact accidentally occurs, flush with water. If liquid contacts
eyes, additionally seek medical help. Liquid ejected from the battery may
cause irritation or burns.
• Do not open or destroy the battery. Electrolytes contained within the
battery are corrosive and may cause damage to eyes or skin if released.
It may be toxic if swallowed.

SAFETY DPPF-2100
12 X7508310400
© 8/23 ECHO Incorporated
• Exercise care in handling batteries to avoid shorting the battery with
conducting materials such as rings, bracelets, keys, etc. The battery or
conductor may overheat and cause burns if contact with said materials is
made.
• Do not use a battery or tool that is damaged or modified. Damaged or
modified batteries may exhibit unpredictable behavior resulting in fire,
explosion or risk of injury.
• Do not expose a battery or tool to fire or excessive temperature.
Exposure to fire or temperature above 130°C (265°F) may cause
explosion.
• Follow all charging instructions and do not charge the battery or tool
outside the temperature range specified in the instructions. Charging
improperly or at temperatures outside the specified range may damage
the battery and increase the risk of fire.
Service
• Do not modify or attempt to repair the appliance or the battery pack (as
applicable) except as indicated in the instructions for use and care.
• Have your power tool serviced by a qualified repair person using only
identical replacement parts. This will ensure that the safety of the power
tool is maintained.
• Never service damaged battery packs. Service of battery packs should
only be performed manufacturer or authorized service providers.
Environmentally Safe Battery Disposal
Recycle your ECHO ECHO eFORCE®56V battery FOR FREE at
Rechargeable Battery Recycling Corporation (RBRC) recycling locations.
Call 1-800-822-8837 or visit https://www.call2recycle.org for details.
The toxic and corrosive materials below are in the batteries used in this
machine: Lithium-Ion, a toxic material.
R
E
C
Y
C
L
E
1
.
8
0
0
.
8
2
2
.
8
8
3
7
R B R C
Li - ion
TM

DPPF-2100 SAFETY
X7508310400 13
© 8/23 ECHO Incorporated
Discard all toxic materials in a specified manner to prevent
contamination of the environment. Before discarding a
damaged or worn out Lithium-ion battery, contact your local
waste disposal agency, or the local Environmental Protection
Agency for information and specific instructions. Take the
batteries to a local recycling and/or disposal center, certified for
Lithium-ion disposal.
If the battery cracks or breaks, with or without leaks, do not
recharge it and do not use. Discard it and replace with a new
battery. DO NOT TRY TO REPAIR IT! To prevent injury and risk
of fire, explosion, or electric shock, and to avoid damage to
the environment:
• Cover the terminals of the battery with heavy-duty adhesive tape.
• DO NOT try to remove or destroy any of the battery components.
• DO NOT try to open the battery.
• If a leak develops, the released electrolytes are corrosive and toxic. DO
NOT get the solution in the eyes or on skin, and do not swallow it.
• DO NOT put these batteries in your regular household trash.
• DO NOT incinerate.
• DO NOT put them where they will become part of any waste landfill or
municipal solid waste stream.
• Take them to a certified recycling or disposal center.
FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions:
• This device may not cause harmful interference.
• This device must accept any interference received, including interference
that may cause undesired operation.

SAFETY DPPF-2100
14 X7508310400
© 8/23 ECHO Incorporated
Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to
operate equipment.
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy, and if not
installed and used in accordance with the instructions, may cause
harmful interference to radio or television reception. The reception
can be determined by turning the equipment off and on. The user is
encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Equipment
Use only ECHO attachments. Serious injury may result from the
use of a non-approved attachment combination. ECHO
Incorporated will not be responsible for the failure of cutting
devices, attachments or accessories which have not been
tested and approved by ECHO. Read and comply with all safety
instructions listed in this manual and safety manual.
◆Check unit for loose and missing nuts, bolts, and screws.
Tighten or replace as needed.
Guide Bar and Saw Chain
• Check that the cutting attachment, guide bar, and saw chain is firmly
attached and in safe operating condition.

DPPF-2100 SAFETY
X7508310400 15
© 8/23 ECHO Incorporated
• Use only one ECHO extension on the pruner.
• Do not hit rocks, stones, tree stumps, and other foreign objects with the
saw chain.
• Do not cut into the ground with the saw chain.
• If cutting attachment end strikes an obstruction, stop unit immediately
and inspect saw chain for damage.
• Do not operate with a dull, fractured, or discolored saw chain.
• Remove all foreign objects from work area.
Moving parts can amputate fingers or cause severe injuries.
Keep hands, clothing and loose objects away from all openings.
◆ALWAYS stop unit and make sure all moving parts have
come to a complete stop before removing obstructions,
clearing debris, or servicing unit.
◆DO NOT operate unit unless all guards and protective
covers are properly assembled to unit.
◆NEVER reach into any opening while unit is running.
Moving parts may not be visible through openings.
General Safety Warnings and Instructions for the
following ECHO tools: Curved Shaft Edger, Straight
Shaft Edger, Tiller Cultivator, or Pole Pruner, or
DPAS unit configured as a Curved Shaft Edger,
Straight Shaft Edger, Tiller Cultivator, or Pole
Pruner.
This section contains the prescribed general safety warnings and
instructions for handheld, motor-operated electric trimmers, lawn edgers,
cultivators, and pole pruners contained in UL 82. Additional important
warnings and instructions are provided in subsequent sections of this
manual.

SAFETY DPPF-2100
16 X7508310400
© 8/23 ECHO Incorporated
IMPORTANT SAFETY INSTRUCTIONS
When using electric trimmers, lawn edgers, cultivators, and
pole pruners basic safety precautions should always be
followed to reduce the risk of fire, electric shock, and personal
injury, including the following:
READ ALL INSTRUCTIONS.
1. Avoid Dangerous Environment - Don't use appliances in damp or wet
locations.
2. Don't Use in Rain.
3. Keep Children Away - All visitors should be kept at a distance from
work area.
4. Dress Properly - Do not wear loose clothing or jewelry. They can be
caught in moving parts. Use of rubber gloves and substantial footwear
is recommended when working outdoors. Wear protective hair covering
to contain long hair.
5. Use Safety Glasses - Always use face or dust mask if operation is
dusty.
6. Use Right Tool - Do not use tool for any job except that for which it is
intended.
7. Avoid Unintentional Starting - Don't carry tool with finger on switch. Be
sure switch is off when plugging in.
8. Don't grasp exposed cutting blades or cutting edges when picking up or
holding the tool.
9. Don't Force Tool - It will do the job better and with less likelihood of a
risk of injury at the rate for which it was designed.
10. Don't Overreach - Keep proper footing and balance at all times.
11. Stay Alert - Watch what you are doing. Use common sense. Do not
operate appliance when you are tired.
12. Store Idle Tools Indoors - When not in use, tools should be stored
indoors in dry, locked place out of reach of children with the battery
removed.
13. Maintain Tool with Care - Keep cutting edge sharp and clean for best
performance and to reduce the risk of injury. Follow instructions for
lubricating and changing accessories. Keep handles dry, clean, and
free from oil and grease.

DPPF-2100 SAFETY
X7508310400 17
© 8/23 ECHO Incorporated
14. Check Damaged Parts - Before further use of the appliance, a guard or
other part that is damaged should be carefully checked to determine
that it will operate properly and perform its intended function. Check for
alignment of moving parts, binding of moving parts, breakage of parts,
mounting, and any other condition that may affect its operation. A guard
or other part that is damaged should be properly repaired or replaced
by an authorized service center unless indicated elsewhere in this
manual.
15. Edger
• Keep guards in place and in working order.
• Keep metal blades sharp.
• Keep hands and feet away from cutting area
16. Cultivator
• Keep hands away from blades.
17. Pole Pruner
• Keep all parts of the body away from the saw chain. Do not remove cut
material or hold material to be cut when blades are moving. Make sure
the switch is off when clearing jammed material. Saw chain continues
to move after the switch is turned off. A moment of inattention while
operating the extended-reach pruner may result in serious personal
injury.
• Carry the extended-reach pruner by the handle with the saw chain
stopped. When transporting or storing the extended-reach pruner,
always fit the saw chain device cover. Proper handling of the extended-
reach pruner will reduce possible personal injury from the saw chain.
• Hold the extended-reach pruner by insulated gripping surfaces only,
because the saw chain may contact hidden wiring. A saw chain
contacting a "live" wire may make exposed metal parts of the
extended-reach pruner "live" and could give the operator an electric
shock.
• Do not use the extended-reach pruner in bad weather conditions,
especially when there is a risk of lightning. This decreases the risk of
being struck by lightning.
• To reduce the risk of electrocution, never use near any electrical power
lines. Contact with or use near power lines may cause serious injury or
electric shock resulting in death.
• Always use two hands when operating the extended-reach pruner.
Hold the extended-reach pruner with both hands to avoid loss of
control.
• Always use head protection when operating the extended-reach
pruner overhead. Falling debris can result in serious personal injury.

DESCRIPTION DPPF-2100
18 X7508310400
© 8/23 ECHO Incorporated
DESCRIPTION
Locate these safety decal(s) or etching(s) on your unit. Make sure they are
legible, and that you understand and follow the instructions. If any cannot be
read, replacements can be ordered from your ECHO dealer. Images shown
below are for example only. Those on your unit might appear slightly
different.
21
1
8
2
3
4
5
6
7
9
10
11
12
13
14
X5058310000
For use only with ECHO eFORCETM 56V
battery series. See operator’s manual
for list of compatible model numbers.
À utiliser uniquement avec la série de
batteries ECHO eFORCETM 56V. Voir le
manuel de l’opérateur pour la liste des
numéros de modèle compatibles.
Sólo para uso con la serie de baterías
ECHO eFORCETM 56V. Consulte el
manual del operador para verla lista de
números de modelos compatibles.

DPPF-2100 CONTENTS
X7508310400 19
© 8/23 ECHO Incorporated
CONTENTS
The ECHO product you purchased has been factory pre-assembled for your
convenience. Due to packaging restrictions, some assembly may be
necessary.
After opening the carton, check for damage. Immediately notify your retailer
or ECHO Dealer of damaged or missing parts. Use the contents list to check
for missing parts.
*Not all units include battery and charger.
1. POWER HEAD
2. THROTTLE HANDLE - FOR RIGHT HAND
3. SPEED SWITCH
4. LOCK OFF LEVER SWITCH
5. POWER SWITCH
6. STRAP HOOK
7. SUPPORT HANDLE - FOR LEFT HAND
8. CUTTING ATTACHMENT
9 AUTOMATIC OILER ASSEMBLY
10. GUIDE BAR
11. SAW CHAIN
12. CUTTING SHOE
13. SHOULDER HARNESS
14. GUIDE BAR COVER
1 Power Head and Drive Shaft Assembly
1 Cutting Attachment with Guide Bar and Saw Chain
1 Operator’s Manual
1 Shoulder Harness
1 Guide Bar Cover
1Battery*
1 Battery Charger*

ASSEMBLY DPPF-2100
20 X7508310400
© 8/23 ECHO Incorporated
ASSEMBLY
Cutting Attachment to Drive Shaft Installation
Parts required: Drive Shaft Assembly, Cutting Attachment.
Saw Chain is sharp! Always wear gloves when handling
assembly, otherwise serious personal injury may result.
1. Loosen screws (A) and remove
locator screw (B) on cutting
attachment.
2. Remove the vinyl cap from the
drive shaft.
3. Slide the cutting attachment
onto the shaft housing until the
hole in the neck of the cutting
attachment is aligned with the
hole (C) in the housing (it may
be necessary to rotate the saw
chain slightly to align the
internal pinion and drive shaft).
4. Insert locator screw (B) into
hole (C) and tighten to snug.
5. Tighten bolts (A), clamping the
cutting attachment onto the housing.
A
A
B
C
B
C
