Operator’s
Manual
RB-85W
Broadcast
Spreader

INTRODUCTION RB-85W
2 X7507840400
©02/22 ECHO Inc.
INTRODUCTION
Specifications, descriptions, and illustrative material in this literature are as
accurate as possible. Specifications are subject to change without notice.
Illustrations might include optional equipment and accessories, and might
not include all standard equipment. Your equipment might appear slightly
different than pictured equipment.
Read and understand all provided literature.
Literature contains specifications and
information for safety, operation,
maintenance, storage, and assembly
specific to this product. Scan QR codes for
more information.
For additional literature, including safety manuals where applicable, or
questions regarding terms used in this manual, visit:
https://www.echo-usa.com/manuals
OR
https://www.shindaiwa-usa.com/manuals

RB-85W SERVICING INFORMATION
X7507840400 3
©02/22 ECHO Inc.
SERVICING INFORMATION
Parts and Serial Number
Genuine ECHO parts and
assemblies for your ECHO products
are available only from an
Authorized ECHO Dealer. When
you do need to buy parts always
have the model number and serial
number of the unit with you. For
future reference write them in the
space provided below.
Model No. _____________________ Serial No. ____________________
Service
Service of this product during the warranty period must be performed by an
Authorized ECHO Service Dealer. For the name and address of the
Authorized ECHO Service Dealer nearest you, ask your retailer or call:
1-800-432-ECHO (3246). Dealer information is also available on our Web
Site www.echo-usa.com. When presenting your unit for Warranty service/
repairs, proof of purchase is required.
ECHO Consumer Product Support
If you require assistance or have questions concerning the application,
operation, or maintenance of this product, call the ECHO Consumer
Product Support Department at 1-800-432-ECHO (3246) from 8:00 a.m. to
5:00 p.m. (Central Standard Time) Monday through Friday. Before calling,
please know the model and serial number of your unit.
Product Registration
Register your ECHO equipment online at www.echo-usa.com or by filling
out the product registration sheet included in this manual. Registering your
product confirms warranty coverage and provides a direct link to ECHO if
we find it necessary to contact you.
Additional Literature
In addition to finding information online, information is available from your
Authorized ECHO Service Dealer, or by contacting ECHO Incorporated,
400 Oakwood Road, Lake Zurich, IL 60047, 1-800-432-ECHO (3246).

SAFETY RB-85W
4 X7507840400
©02/22 ECHO Inc.
SAFETY
Safety Information
Carefully read these instructions before use. Improper use or
failure to follow instructions can result in product failure or
injuries. For safe use of this product you must read and follow
all instructions before using.
Cancer and Reproductive Harm
www.P65Warnings.ca.gov
◆Do not allow anyone to operate the broadcast spreader
without proper instructions.
◆Do not permit children to operate the broadcast spreader.
◆Wear all personal protective equipment recommended by
chemical manufacturer.
◆Read and follow the chemical label instructions and
warnings for handling and applying the chemicals you plan
to spread – application settings provided are only a
guideline.

RB-85W DESCRIPTION
X7507840400 5
©02/22 ECHO Inc.
DESCRIPTION
1 Handles
2 Hopper
3 Wheels
4 Adjustable Deflectors
5 Gate Control Rod
6 Gate Control Lever
7 Gate Adjustment Limiter
4
5
3
1
2
4
6
7

CONTENTS RB-85W
6 X7507840400
©02/22 ECHO Inc.
CONTENTS
The product you purchased has been partially factory pre-assembled for
your convenience. Due to packaging restrictions, some assembly may be
necessary.
After opening the carton, check for damage. Immediately notify your retailer
or Dealer of damaged or missing parts. Use the contents list to check for
missing parts.
1 Hopper Assembly
2 Wheels
1 Upper Handle Assembly
1 Gate Control Rod
1 Control Rod Adapter
1Grate
1 Hopper Cover
1 6 mm Nut
1CotterPin
5 6 mm Flange Nuts
2 6 x 60 mm Bolts
1 6 x 50 mm Bolt
1 Metal Washer
1 Nylon Washer
1 Rear Deflector
1 Operator’s Manual
1 Warranty Statement

RB-85W ASSEMBLY
X7507840400 7
©02/22 ECHO Inc.
ASSEMBLY
Install Wheels and Handle
1. Install left wheel and
secure with washer (A)
cotter pin (B).
2. Install right wheel and
secure with 6 x 50 mm
bolt (C) and 6 mm flange
nut (D).
A
B
C
D

ASSEMBLY RB-85W
8 X7507840400
©02/22 ECHO Inc.
3. Install upper handle
assembly (E) into lower
handle bracket (F), and
secure with two 6 x 60 mm
bolts (G) and two 6 mm
flange nuts (H).
Install Gate Control Rod
1. Insert tab end of gate
control rod (C) into slotted
hole in gate control lever
(B). Turn rod clockwise
until it is parallel with
handle assembly.
E
H
G
F
C
B

RB-85W ASSEMBLY
X7507840400 9
©02/22 ECHO Inc.
2. Thread 6mm nut (C) onto
end of gate control rod to
a distance of 25.4 mm (1
in) from bottom of rod.
Insert threaded end of rod
into hole in control rod
adapter (D). Then thread
6 mm flange nut (E) onto
gate control rod. Assure
nuts remain spaced as
shown.
3. Attach control rod adapter
to gate linkage (F). Secure
with 6 mm flange nut (G)
and nylon washer (H).
Tighten nut until snug,
then loosen nut 1/4 turn to
allow hinge movement.
1.0 in.
(25 mm)
C
D
E
C
F
G
H

ASSEMBLY RB-85W
10 X7507840400
©02/22 ECHO Inc.
4. Push control rod adapter
(D) downward until gate is
fully closed.
5. Position gate control lever
fully forward, and tighten
control rod nut and flange
nut as shown.
D

RB-85W ASSEMBLY
X7507840400 11
©02/22 ECHO Inc.
Install Grate
1. Align notches in grate (A)
with tabs (B) in hopper.
Install grate into hopper.
Turn grate clockwise to
lock into place.
Rear Deflector
1. Install rear deflector (A) as
shown.
Check Tire Pressure
Tires should be inflated to 15 psi. Assure tire pressure does not
exceed 30 psi.
A
BB
B
A

OPERATION RB-85W
12 X7507840400
©02/22 ECHO Inc.
OPERATION
Application Instructions
TIP HAZARD. Unit can tip on uneven ground. Always fill hopper
on flat ground, and keep bystanders away. Otherwise personal
injury can result.
2. Adjust deflectors (C) to desired
angle for spreading range.
Note: With deflectors closed,
product will spread 1. 07 m
(3.5 ft). With deflectors
fully open, product will
spread 1.88 - 2.44 m (6-8
ft), depending on rate of
travel.
3. Pull gate control lever backward
to set gate to desired opening
size. Use gate adjustment limiter
(B) to restrict gate opening size.
4. Push gate control lever (A) fully
forward to close gate. Fill hopper
with product. Fill hopper in an
area that won’t be damaged by
spilled product.
C
C
C
C
C
B
A

RB-85W OPERATION
X7507840400 13
©02/22 ECHO Inc.
5. Start spreader in motion, and pull gate control lever back to begin the
flow of product.
6. Move gate control lever forward to close gate before turning or
stopping.
Sample Spread Pattern
Muestra del patrón de disribución
Modèle d’épandage type
SHUT OFF HERE
Apague aquí
Arrêt ici
SHUT OFF HERE
Apague aquí
Arrêt ici
START
Inicio
Mise en
marche
RESTART
Reinicie
Remise en
marche
RESTART
Reinicie
Remise en
marche
RESTART
Reinicie
Remise en
marche
RESTART
Reinicie
Remise en
marche
SHUT OFF HERE
Apague aquí
Arrêt ici
SHUT OFF HERE
Apague aquí
Arrêt ici

MAINTENANCE RB-85W
14 X7507840400
©02/22 ECHO Inc.
MAINTENANCE
Cleaning Spreader
Avoid spraying gear case directly, and do not use a pressure washer
on spreader.
1. Wash spreader with a
garden hose after each use.

RB-85W MAINTENANCE
X7507840400 15
©02/22 ECHO Inc.
Lubrication
Lubricate gear case and axle once per season.
1. Gear case and Axle: Clear
debris from grease fittings
(A). Apply 1-2 pumps of
lithium-based grease with
appropriate grease gun.
Clean excess grease from
grease fittings.
A
A
AA

SPECIFICATIONS RB-85W
16 X7507840400
©02/22 ECHO Inc.
SPECIFICATIONS
PRODUCT REGISTRATION
Thank you for choosing ECHO Power Equipment
Please go to http://www.echo-usa.com/Warranty/Register-Your-ECHO to
register your new product on-line. It's FAST and EASY! NOTE: your
information will never be sold or misused by ECHO, Incorporated.
Registering your purchase enables us to contact you in the unlikely event of
a service update or product recall, and verifies your ownership for warranty
consideration.
If you do not have access to the Internet, you can complete the form below
and mail to:
ECHO Incorporated, Product Registration, PO Box 1139,
Lake Zurich, IL 60047.
MODEL RB-85W
Length 1,194 mm (47 in.)
Width 654 mm (25.75 in.)
Height 952 mm (37.50 in.)
Weight 17.50 kg (38.50 lb.)
Capacity
Weight 38.50 kg (85 lb.)
Volume 43.9 L (1.55 ft3)
Loading Height 641 mm (25.25 in.)
Wheels and Tires
Tire Diameter 305 mm (12in.)
Tire Type Tubeless Pneumatic
Recommended Pressure 103.4 kPa (15 psi)

RB-85W PRODUCT REGISTRATION
X7507840400 17
©02/22 ECHO Inc.
ECHO Incorporated

NOTES RB-85W
18 X7507840400
©02/22 ECHO Inc.
NOTES

RB-85W NOTES
X7507840400 19
©02/22 ECHO Inc.

ECHO INCORPORATED
400 Oakwood Road
Lake Zurich, IL 60047
www.echo-usa.com
N31100001001 - N31100999999
