Echo Transportion Box ETB-120
ECHO-Motorgeräte Vertrieb Deutschland GmbH .Otto-Schott-Str. 7 .72555 Metzingen . Telefon [phone] . Telefax 0 71 23-96 83 258
http.//www.echo-motorgeraete.de . email: [e-mail] . Eingetragen im HRB Stuttgart 360542 . Geschäftsführer: Thomas Beck . St.Nr.: 89078/11652

Use for intended purpose
The ECHO Transportation Box ETB-120 is designed for mounting on all
C-Series tractors.
Any transport of people or animals is not allowed!
With the ETB-120, loads can be transported up to 120 kg.
Misuse, especially the slide of loose materials or similar is strictly prohibited.
Warranty
Echo Motorgeräte grants a warranty of 2 years for private usage, in
commercial use by 1 year.
Use the strut when you go with loaded carrier!
This greatly relieves the suspension of the box as well as the rear shot of the
tractor.
A go without mounted strut can cause severe damage and is excluded
from the warranty.
Mounted strut

Mounting
Check the completeness of the
delivery using the enclosed
packing list.
Place the base plate on a flat
surface, first mount the two
reinforcing plates. To do this, use
the lens head screws M8.
Allow all connections still loose!
Now place the back wall on the
base plate and fasten it with this
and the stiffening plates.
The side panels are mounted with
the screws M8x20 washer and nut
M8.
Let these glands also still loose!

The tailgate is bolted to the base
plate with two screws.
The two arms must be assembled
as shown.
To do this, use the shims.
The locking levers are screwed
from the inside of the arms. Mount
also the two spacer sleeves to
allow the freedom of movement of
the arms are maintained.

The holder to hold of the strut is
screwed on the slope coupling of the
tractor.
For mounting the carrier on the two
arms of the PGC Lift on the tractor is
inserted and secured with the
locking levers.
The strut is mounted as pictured and
prevents overloading of the rear
intake.
Use them every time you drive with
loaded ETB 120!
The transportation box can be
lowered at ground level for easy
loading and unloading.
