Eclipse Security ECL-IP2D50 User manual

ECL-IP2D50
User’s Manual
Version 1.3.3

i
Welcome
Thank you for purchasing our Network camera!
This user’s manual is designed to be a reference tool for your system.
Please read the following safeguard and warnings carefully before you use this series product!
Please keep this user’s manual well for future reference!

ii
Important Safeguards and Warnings
1．Electrical safety
All installation and operation here should conform to your local electrical safety codes.
The power shall conform to the requirement in the SELV (Safety Extra Low Voltage) and the Limited
power source is rated 12V DC or 24V AC in the IEC60950-1. (Refer to general introduction)
Please note: Do not connect two power supplying sources to the device at the same time; it may
result in device damage! The product must be grounded to reduce the risk of electronic shock.
We assume no liability or responsibility for all the fires or electrical shock caused by improper handling
or installation.
We are not liable for any problems caused by unauthorized modification or attempted repair.
2．Transportation security
Heavy stress, violent vibration or water splash are not allowed during transportation, storage and
installation.
3．Installation
Do not apply power to the camera before completing installation.
Please install the proper power cut-off device during the installation connection.
Always follow the instruction guide the manufacturer recommended.
4．Qualified engineers needed
All the examination and repair work should be done by the qualified service engineers.
We are not liable for any problems caused by unauthorized modifications or attempted repair.
5．Environment
This series network camera should be installed in a cool, dry place away from direct sunlight,
inflammable, explosive substances and etc.
Please keep it away from the electromagnetic radiation object and environment.
Please make sure the CCD (CMOS) component is out of the radiation of the laser beam device.
Otherwise it may result in CCD (CMOS) optical component damage.
Please keep the sound ventilation.
Do not allow the water and other liquid falling into the camera.
Thunder-proof device is recommended to be adopted to better prevent thunder.
The grounding studs of the product are recommended to be grounded to further enhance the reliability
of the camera.
6. Daily Maintenance
Please shut down the device and then unplug the power cable before you begin daily maintenance
work.

iii
Do not touch the CCD (CMOS) optic component. You can use the blower to clean the dust on the lens
surface.
Always use the dry soft cloth to clean the device. If there is too much dust, please use the water to
dilute the mild detergent first and then use it to clean the device. Finally use the dry cloth to clean the
device.
Please put the dustproof cap to protect the CCD (CMOS) component when you do not use the camera.
Dome enclosure is the optical component, do not touch the enclosure when you are installing the
device or clean the enclosure when you are doing maintenance work. Please use professional optical
clean method to clean the enclosure. Improper enclosure clean method (such as use cloth) may result
in poor IR effect of camera with IR function.
7. Accessories
Be sure to use all the accessories recommended by manufacturer.
Before installation, please open the package and check all the components are included.
Contact your local retailer ASAP if something is broken in your package.
Accessory Name
Amount
Network Camera Unit
1
Quick Start Guide
1
Installation Accessories Bag
1
CD
1
Warranty Card and Certificate
1

iv
Table of Contents
1General Introduction ..................................................................................................................1
1.1 Overview........................................................................................................................1
1.2 Features.........................................................................................................................1
1.3 Specifications................................................................................................................2
2Structure ....................................................................................................................................10
2.1 Components................................................................................................................10
2.2 Framework and Dimension.......................................................................................11
3Device Installation ....................................................................................................................14
3.1 Installation Steps for Metal Dome............................................................................14
3.2 Installation Steps for Plastic Dome..........................................................................15
4Quick Configuration Tool.........................................................................................................17
4.1 Overview......................................................................................................................17
4.2 Operation.....................................................................................................................17
5Web Operation..........................................................................................................................19
5.1 Network Connection...................................................................................................19
5.2 Login and Main Interface...........................................................................................19
6FAQ ............................................................................................................................................21
Appendix Toxic or Hazardous Materials or Elements ...............................................................22

1
1General Introduction
1.1 Overview
This series network camera integrates the traditional camera and network video technology. It adopts
video data collection, transmission together. It can connect to the network directly without any auxiliary
device.
This series network camera uses standard H.264 video compression technology, which maximally
guarantees the video quality.
It supports the IR night vision function. In the night environments, the device can use the IR light to
highlight the object which is suitable for the surveillance function in the low illumination environments.
The waterproof design conforms to the IP 66 level. It has the sound waterproof function suitable for
use in the outdoor environments.
It can be used alone or used in a network area. When it is used lonely, you can connect it to the
network and then use a network client-end. Due to its multiple functions and various uses, this series
network camera is widely used in many environments such office, bank, road monitor and etc.
1.2 Features
User
Management
Different user rights for each group, one user belongs to one group.
The user right shall not exceed the group right.
Storage
Function
Support central server backup function in accordance with your configuration
and setup in alarm or schedule setting
Support record via Web and the recorded file are storage in the client-end
PC.
Support network storage function such as FTP.
Network
Monitor
Network camera supports one-channel video data transmit to network
terminal and then decode. Delaying time is within 270ms (network bandwidth
support needed)
Max supports 20 connections.
Adopt the following video transmission protocol: HTTP, TCP, UDP,
MULTICAST, RTP/RTCP, RTSP and etc.
Support web access.
Network
Management
Realize network camera configuration and management via Ethernet.
Support device management via web or client-end.
Power
External power adapter DC 12V.
Some series support PoE.
Warning！
Do not connect these two power supplying sources to the device at the
same time; it may result in device damage!
Assistant
Function
Log function
Support system resource information and running status real-time display.
Day/Night mode auto switch.
Support picture parameter setup such as electronic shutter and gain setup.
Support motion detect.
Backlight compensation: screen auto split to realize backlight compensation
to adjust the bright.
Support video watermark function to avoid vicious video modification.
Built-in IR light. Support IR night vision.
The enclosure conforms to the IP 66 protection. Has the waterproof function.

2
1.3 Specifications
Please refer to the following sheet for network camera performance specification.
Model
Parameter
System
Main Processor
High performance DSP
OS
Embedded LINUX
System
Resources
Support real-time network, local record, and remote operation at the
same time.
User Interface
Remote operation interface such as WEB, DSS, PSS
System Status
Bit stream statistics, log, and software version.
Video Parameter
Image Sensor
1/4-inch CMOS
Pixel
1280(H)*720(V)
Day/night
Support day/night IR-CUT switch
Gain Control
Fixed/Auto
White Balance
Manual/Auto
BLC
Off/BLC/WDR (1-100 adjustable)/HLC(anti-flicker is outdoor and is
valid only when exposure mode is auto with range 1-100)
Exposure Mode
Manual/Auto
It ranges from 1/3 to 1/10000.
Video
Compression
Standard
H.264/H.264B/MJPEG
Video Frame
Rate
PAL:
Main stream (1280*720@25fps),
extra stream ( 704*576@25fps)
NTSC:
Main stream (1280*720@30fps),
extra stream ( 704*480@30fps)
Video Bit Rate
H.264H: 16Kbps-8192Kbps
MJPEG: adjustable and bit rate is adjustable.
Support customized setup.
Video Flip
Support mirror.
Support flip function.
Snapshot
Max 1f/s snapshot. File extension name is JPEG.
Privacy Mask
Supports max 4 privacy mask zones
Video Setup
Support parameter setup such as bright, contrast.
Video
Information
Channel title, time title, motion detect, tampering.
Lens
2.8mm, 3.6mm, 6mm, 8mm. Fixed focus.
Lens Interface
M12. Lens is the default accessories
Video
Motion Detect
396 (18*22) detection zones; sensitivity level ranges from 0 to 100;
area threshold ranges from 0 to 100.
Activation event: video storage, image snapshot, log, email function
and etc.
Record
Record Priority
Manual >Video detect>Schedule

3
Network
Wire Network
1-ch 10/100 Base-T Ethernet
Network Protocol
HTTP, TCP/IP, ARP,IGMP, ICMP, RTSP, RTP,UDP, RTCP, SMTP,
FTP, DHCP, DNS, DDNS, PPPOE, UPNP, NTP
Remote
Operation
Monitor, system setup, file download, log information, maintenance ,
upgrade and etc
IR light
IR light 20M.
General Parameter
Power
DC12V power and PoE.
DC12V
Power
Consumption
3W MAX
Working
Temperature
-30℃~+60℃
Working
Humidify
≤95%
Dimensions(mm)
Φ113.6×85.8
Φ93.4×80.5
Φ113.6×85.8
Φ93.4×80.5
Weight
0.27kg
0.35kg
0.27kg
0.35kg
Installation
Ceiling and wall mount
Model
Parameter
ECL-IP2D50
System
Main Processor
High performance DSP
OS
Embedded LINUX
System
Resources
Support real-time network, local record, and remote operation at the
same time.
User Interface
Remote operation interface such as WEB, DSS, PSS
System Status
Bit stream statistics, log, and software version.
Video Parameter
Image Sensor
1/3-inch CMOS
Pixel
2048(H)*1536(V)
Day/night
Support day/night mode switch
Gain Control
Fixed/Auto
White Balance
Manual/Auto
BLC
On/Off
Electronic
Shutter
Manual/Auto/Low noise/Low-motion blur
It ranges from 1/3 to 1/100000.
Video
Compression
Standard
H.264/H.264B/H.264H/MJPEG
Video Frame
Rate
PAL:
Main stream (1920*1080@25fps),
extra stream ( 704*576@25fps)
NTSC:
Main stream (1920*1080@30fps),
extra stream ( 704*480@30fps)
Video Bit Rate
H.264H: 16Kbps-8192Kbps
MJPEG: adjustable and bit rate is adjustable.
Support customized setup.
Video Flip
Support mirror.
Support flip function.
Snapshot
Max 1f/s snapshot. File extension name is JPEG.

4
Privacy Mask
Supports max 4 privacy mask zones
Video Setup
Support parameter setup such as bright, contrast.
Video
Information
Channel title, time title, motion detect, tampering.
Lens
2.8mm, 3.6mm, 6mm, 8mm. Fixed focus.
Lens Interface
M12. Lens is the default accessories
Video
Motion Detect
396 (18*22) detection zones; sensitivity level ranges from 0 to 100;
area threshold ranges from 0 to 100.
Activation event: video storage, image snapshot, log, email function
and etc.
Record
and
Backup
Record Priority
Manual >Video detect>Schedule
Storage
Management
Support NAS storage
Network
Wire Network
1-ch 10/100M Ethernet, RJ45 port
Network Protocol
HTTP，TCP，ARP，RTSP，RTP，UDP，RTCP，SMTP，FTP，DHCP，
DNS，DDNS，PPPOE，IPv4/v6，QoS，UPnP，NTP，HTTPS，Bonjour
Remote
Operation
Monitor, system setup, file download, log information, maintenance ,
upgrade and etc
Platform
Interface
Standard
Support ONVIF
General Parameter
IR light
IR light 20M.
Power
DC12V power and PoE.
DC 12V
Power
Consumption
4.8W MAX
Working
Temperature
-30℃~+60℃
Working
Humidify
≤95%
Dimensions(mm)
Φ113.6×85.8
Φ93.4×80.5
Φ113.6×85.8
Φ93.4×80.5
Weight
0.27kg
0.35kg
0.27kg
0.35kg
Installation
Ceiling and wall mount
Model
Parameter
System
Main Processor
High performance DSP
OS
Embedded LINUX
System
Resources
Support real-time network, local record, and remote operation at the
same time.
User Interface
Remote operation interface such as WEB, DSS, PSS
System Status
Bit stream statistics, log, and software version.
Video Paramete r
Image Sensor
1/3-inch CMOS
Pixel
1280(H)*960(V)
Day/night
Support day/night mode switch
Gain Control
Fixed/Auto

5
White Balance
Manual/Auto
BLC
On/Off
Electronic
Shutter
Manual/Auto/Low noise/Low motion blur
It ranges from 1/3 to 1/100000.
Video
Compression
Standard
H.264/H.264B/H.264H/MJPEG
Video Frame
Rate
PAL:
Main stream (1280*960@25fps),
extra stream ( 704*576@25fps)
NTSC:
Main stream (1280*960@30fps),
extra stream ( 704*480@30fps)
Video Bit Rate
H.264H: 16Kbps-8192Kbps
MJPEG: adjustable and bit rate is adjustable.
Support customized setup.
Video Flip
Support mirror.
Support flip function.
Snapshot
Max 1f/s snapshot. File extension name is JPEG.
Privacy Mask
Supports max 4 privacy mask zones
Video Setup
Support parameter setup such as bright, contrast.
Video
Information
Channel title, time title, motion detect, tampering.
Lens
2.8mm, 3.6mm, 6mm. Fixed focus.
Lens Interface
M12. Lens is the default accessories
Video
Motion Detect
396 (18*22) detection zones; sensitivity level ranges from 0 to 100;
area threshold ranges from 0 to 100.
Activation event: video storage, image snapshot, log, email function
and etc.
Record
and
Backup
Record Priority
Manual >Video detect>Schedule
Storage
Management
Support ONVIF
Network
Wire Network
1-ch 10/100 Base-T Ethernet
Network Protocol
HTTP，TCP，ARP，RTSP，RTP，UDP，RTCP，SMTP，FTP，DHCP，
DNS，DDNS，PPPOE，IPv4/v6，QoS，UPnP，NTP，HTTPS，Bonjour
Remote
Operation
Monitor, system setup, file download, log information, maintenance ,
upgrade and etc
Platform
Interface
Standard
Support ONVIF
General Parameter
IR light
IR light 20M.
Power
DC12V power and PoE.
DC 12V
Power
Consumption
4.8W MAX
Working
Temperature
-30℃~+60℃
Working
Humidify
≤95%
Dimensions(mm)
Φ113.6×85.8
Φ93.4×80.5
Φ113.6×85.8
Φ93.4×80.5
Weight
0.27kg
0.35kg
0.27kg
0.35kg

6
Installation
Ceiling and wall mount
Model
Parameter
System
Main Processor
High performance DSP
OS
Embedded LINUX
System
Resources
Support real-time network, local record, and remote operation at the
same time.
User Interface
Remote operation interface such as WEB, DSS, PSS
System Status
Bit stream statistics, log, and software version.
Video Parameter
Image Sensor
1/3-inch CMOS
Pixel
1280(H)*960(V)
2048(H)*1536(V)
Day/night
Support day/night mode switch
Gain Control
Fixed/Auto
White Balance
Manual/Auto
BLC
On/Off
Exposure Mode
Manual/Auto/Low noise/Low motion blur
It ranges from 1/3 to 1/100000.
Video
Compression
Standard
H.264/H.264H/MJPEG
Video Frame
Rate
PAL:
Main stream (1280*960@25fps)
extra stream 1 ( 704*576@25fps)
extra stream 2 ( 1280*720@8fps)
PAL:
Main stream (2048*1536@20fps)
extra stream 1 ( 704*576@20fps)
extra stream 2 ( 1280*720@1fps)
Main stream (1920*1080@25fps)
extra stream 1 ( 704*576@25fps)
extra stream 2
( 1280*720@11fps)
NTSC:
Main stream (1280*960@30fps)
extra stream 1 ( 704*480@30fps)
extra stream 2 ( 1280*720@1fps)
NTSC:
Main stream (2048*1536@20fps)
extra stream 1 ( 704*480@20fps)
extra stream 2 ( 1280*720@1fps)
Main stream (1920*1080@30fps)
extra stream 1 ( 704*480@30fps)
extra stream 2 ( 1280*720@1fps)
Note:
Extra stream 2’s actual frame depends on device max capacity set
which can be adjusted within its range.
Video Bit Rate
H.264H: 40Kbps-8192Kbps
MJPEG: 40Kbps-16384Kbps adjustable and bit rate is adjustable.
Support customized setup.
Video Flip
Support mirror.
Support flip function.
Snapshot
Max 1f/s snapshot. File extension name is JPEG.
Privacy Mask
Supports max 4 privacy mask zones
Video Setup
Support parameter setup such as bright, contrast.
Video
Information
Channel title, time title, motion detect, tampering, overlay.
Lens
2.8mm, 3.6mm, 6mm. Fixed focus.
Lens Interface
M12. Lens is the default accessories

7
Video
Motion Detect
396 (18*22) detection zones; sensitivity level ranges from 0 to 100;
area threshold ranges from 0 to 100.
Activation event: video storage, image snapshot, log, email function
and etc.
Record
Record Priority
Manual >Video detect>Schedule
Storage
Management
NAS storage
Network
Wire Network
1-ch 10/100 Base-T Ethernet
Network Protocol
HTTP, TCP/IP, ARP,IGMP, ICMP, RTSP, RTP,UDP, RTCP, SMTP,
FTP, DHCP, DNS, DDNS, PPPOE, UPNP, NTP, QoS, 802.1x
Remote
Operation
Monitor, system setup, file download, log information, maintenance ,
upgrade and etc
Protocol
PSIA, ONVIF
General Parameter
IR light
IR light 20M.
Power
DC12V power and PoE.
Note:
05 series does not support PoE.
Power
Consumption
DC 12V 3.1W MAX
DC 12V 3.6W MAX
Working
Temperature
-30℃~+60℃
Working
Humidify
≤95%
Dimensions(mm)
Φ113.6×85.8
Weight
0.27kg
Installation
Ceiling and wall mount
Model
Parameter
System
Main Processor
High performance DSP
OS
Embedded LINUX
System
Resources
Support real-time network, local record, and remote operation at the
same time.
User Interface
Remote operation interface such as WEB, DSS, PSS
System Status
Bit stream statistics, log, and software version.
Video Parameter
Image Sensor
1/3-inch CMOS
Pixel
1280(H)*960(V)
2048(H)*1536(V)
Day/night
Support day/night mode switch
Gain Control
Fixed/Auto
White Balance
Manual/Auto
BLC
On/Off
Exposure Mode
Manual/Auto/Low noise/Low motion blur
It ranges from 1/3 to 1/100000.
Video
Compression
Standard
H.264/H.264H/MJPEG

8
Video Frame
Rate
PAL:
Main stream (1280*960@25fps)
extra stream 1 ( 704*576@25fps)
extra stream 2 ( 1280*720@8fps)
PAL:
Main stream (2048*1536@20fps)
extra stream 1 ( 704*576@20fps)
extra stream 2 ( 1280*720@1fps)
Main stream (1920*1080@25fps)
extra stream 1 ( 704*576@25fps)
extra stream 2
( 1280*720@11fps)
NTSC:
Main stream (1280*960@30fps)
extra stream 1 ( 704*480@30fps)
extra stream 2 ( 1280*720@1fps)
NTSC:
Main stream (2048*1536@20fps)
extra stream 1 ( 704*480@20fps)
extra stream 2 ( 1280*720@1fps)
Main stream (1920*1080@30fps)
extra stream 1 ( 704*480@30fps)
extra stream 2 ( 1280*720@1fps)
Note:
Extra stream 2’s actual frame depends on device max capacity set
which can be adjusted within its range.
Video Bit Rate
H.264H: 40Kbps-8192Kbps
MJPEG: 40Kbps-16384Kbps adjustable and bit rate is adjustable.
Support customized setup.
Video Flip
Support mirror.
Support flip function.
Snapshot
Max 1f/s snapshot. File extension name is JPEG.
Privacy Mask
Supports max 4 privacy mask zones
Video Setup
Support parameter setup such as bright, contrast.
Video
Information
Channel title, time title, motion detect, tampering, overlay.
Lens
2.8mm, 3.6mm, 6mm. Fixed focus.
Lens Interface
M12. Lens is the default accessories
Video
Motion Detect
396 (18*22) detection zones; sensitivity level ranges from 0 to 100;
area threshold ranges from 0 to 100.
Activation event: video storage, image snapshot, log, email function
and etc.
Record
Record Priority
Manual >Video detect>Schedule
Storage
Management
NAS storage
Network
Wire Network
1-ch 10/100M Ethernet, RJ45 port
Network Protocol
HTTP, TCP/IP, ARP,IGMP, ICMP, RTSP, RTP,UDP, RTCP, SMTP,
FTP, DHCP, DNS, DDNS, PPPOE, UPNP, NTP, QoS, 802.1x
Remote
Operation
Monitor, system setup, file download, log information, maintenance ,
upgrade and etc
Protocol
PSIA, ONVIF
Gene ral Para mete r
IR light
IR light 20M.
Power
DC12V power and PoE.
Note:

9
05 series does not support PoE.
Power
Consumption
DC 12V 3.1W MAX
DC 12V 3.6W MAX
Working
Temperature
-30℃~+60℃
Working
Humidify
≤95%
Dimensions(mm)
Φ93.4×80.5
Weight
0.35kg
Installation
Ceiling and wall mount

10
2Structure
2.1 Components
You can refer to the following figures for product appearance information. See Figure 2-1 and Figure
2-2.
Figure 2-1 Metal Dome
Figure 2-2 Plastic Dome

11
Please refer to the following sheet for detailed information.
No.
Port
Name
Connector
Note
4
LAN
Network
port
Ethernet
To connect to standard
Ethernet.
Note:
Some devices do not
support PoE.
5
DC12V
DC 12V
power
To connect to DC12V power
supply.
2.2 Framework and Dimension
Please refer to the following two figures for dimension information. The unit is mm. See Figure 2-3 to
Figure 2-6.
Figure 2-3 Dimension of Metal Dome 1
Component
Component Name
Component 1
Device lens
Component 2
Dome body
Component 3
Dome enclosure

12
Figure 2-4 Dimension of Metal Dome 2
Figure 2-5 Dimension of Plastic Dome 1

13
Figure 2-6 Dimension of Plastic Dome 2

14
3Device Installation
Important
Before the installation, please make sure the installation environments can at least support 3x
weight of the camera.
3.1 Installation Steps for Metal Dome
Please follow the steps listed below to install the device. Please refer to Figure 3-1 to Figure 3-3 for
reference.
Step 1
Turn clockwise to remove the decoration ring from the snap joints.
Step 2
Please take the installation position map in the accessories bag, and then paste it on the ceiling or the
wall according to your monitor area requirements. Draw and then dig four expansion bolts holes in the
installation surface and then insert four expansion bolts in the holes. Secure these four bolts firmly.
Please draw the cable out from the cable exit when you install the device.
Step 3
Adjust the device installation pedestal to the proper position and then line up the four holes in the
device pedestal to the four plastic expansion bolt holes in the installation position. Put the four self-
tapping screws in the four plastic expansion bolts firmly. Loosen the decoration ring to adjust lens in
order to make lens toward designed monitoring area. User can use the M3X3 inner hex screw to
secure dome body.
Figure 3-1 Device installation illustration 1
Important

15
Please pay attention to the dome camera direction when you are installing. Please refer to the
following figure for detailed information. See Figure 3-2.
Figure 3-2 Device installation illustration 2
Figure 3-3 Device installation illustration 3
3.2 Installation Steps for Plastic Dome
Please follow the steps listed below to install the device. Please refer to Figure 3-4 for reference.
