Ecoflo Nalure Loo NL2 Instruction Manual

®
NL2
Installation & Maintenance Manual
▪Thank you for purchasing the NL2. Please read this manual carefully before installation.
▪ “Nature Loo” is a brand of Ecoflo Wastewater Management Pty Ltd.
▪Visit our website at ecoflo.com.au
IMNL-NL2.200423 © Ecoflo Wastewater Management Pty Ltd

© Ecoflo Wastewater Management Pty Ltd Page 2
Copyright © 2020 Ecoflo Wastewater Management Pty Ltd
Please call your local distributor or Ecoflo Wastewater Management for support if required.
Ecoflo Wastewater Management Pty Ltd
www.ecoflo.com.au
www.natureloo.com.au
Phone: [phone]
Phone: [phone]
Email: [email protected]
Proudly Designed and Assembled in Australia
by Ecoflo Wastewater Management
IMNL-NL2.200423

© Ecoflo Wastewater Management Pty Ltd Page 3
Table of Content
5
5
5
6
5
8
8
8
9
9
9
10
10
10
10
10
10
11
11
11
11
11
12
12
12
12
12
12
13
13
USING THE NL2
IMNL-NL2.200423

© Ecoflo Wastewater Management Pty Ltd Page 4
Please ensure that the package you received contains all items listed in the packing list document no: PSCM-002 that
comes with your NL2 package.
IMNL-NL2.200423
NL2 QTY /Unit
CHAMBER, PEDESTAL & SEAT
NL2 Pedestal 1
Compost Chamber with Lid & Breather 2
67mm VENT HOLE - Pedestal 1
25mm THREADED SPINWELD - Pedestal 1
HANDLE - fitted to Chamber 2
TOILET SEAT - Plastic. Fitted 1
Ecoflo 'How To Use' Sign 1
PLUMBING
25mmx1.2m Liquid Drain Hose - Purple 1
25mmx1"BSP Camlock Set 1
50mm Wallace Seal - greased & sealed 1
50mm x 600mm PVC DWV Pipe 1
50mm 90 Deg Bend 1
100mm Insect & Water Proof Vent Cowl 1
FASTENERS:
Mounting Blocks x2, Screws & Washers x4 x1 Set
Hose Clamp 21 - 38mm 1
Sign Screws 8Gx12.5mm 4
ELECTRONICS
FAN : 12v EcoFan in Housing 1
Transformer 240v-12v 1
CONSUMABLES
Spray Flask With Trigger- 750ml 1
Nature Flush Enzymes - 125ml 1
Microbes 2
Bulking Agent -Woodshavings (15L bag) 2
Toilet Roll 1
OTHER
Installation Manual(s) & EcoFlo pamphlet 1of ea

© Ecoflo Wastewater Management Pty Ltd Page 5
This section outlines the requirements and procedures to ensure trouble free installation. Please follow the
instructions exactly and contact Nature Loo for any installation questions.
Drain kit or excess fluid container if not purchased from Nature Loo.
The NL2 can be installed close to a wall with the vent pipe exiting directly through the rear wall (Figure 1) or
alternatively the vent pipe can be installed on the inside exiting up through the ceiling (Figure 2).
IMNL-NL2.200423

© Ecoflo Wastewater Management Pty Ltd Page 6
°
•
•
•
Due to the variety of possible configurations, the vent kit supplied with your NL2 only includes the essential
components. Additional DWV pipe and fittings may be required for a complete installation.
NL2 ventilation pipe break-out view Figure 3 next page...
IMNL-NL2.200423

© Ecoflo Wastewater Management Pty Ltd Page 7 IMNL-NL2.200423

© Ecoflo Wastewater Management Pty Ltd Page 8
•
•
•
•
If no 240v power socket is available, the fan can be connected to alternative power sources such as a solar
power system. Solar kits are available from Nature Loo. The fans are rated for voltages between 8 and 15 V
DC.
The turbo vent and associated fittings can be purchased from Nature Loo.
Your NL2 comes with an embossed logo and model number on the top of the unit. The serial number can be
located on the back of the unit. Further details such as Nature Loo contact details, design capacity, operating
condition, electrical requirement and basic notice and instructions are located in the front page of this manual.
IMNL-NL2.200423
The drainage system to be chosen depends entirely on the soil condition, ground water level, and local
regulation. Two drainage options for NL2 are recommended as below:
This is the normal method for disposal of excess liquid, but refer to council for permit for any
specific requirements. These instructions apply to installation of the drain kit items available from
Nature Loo.

© Ecoflo Wastewater Management Pty Ltd Page 9 IMNL-NL2.200423

© Ecoflo Wastewater Management Pty Ltd Page 10
•
•
USING THE NL2
NL2 is ready to be used!
The NL2 should be examined regularly to ensure correct operation. The key areas to be checked are listed
below:
NL2 is ready to be used again!
As a general rule, you should leave the material in the compost chamber as long as possible. The NL2 has
been designed for 2 people full time where the average monthly temperature is greater than 18° C in any
given month. Under these conditions the full chamber should only require a maximum of 60 days before it is
ready for emptying.
IMNL-NL2.200423

© Ecoflo Wastewater Management Pty Ltd Page 11
When ready for disposal the composted end product should not contain recognizable faecal material
and there should be no offensive odours immediately after removing the chamber lid.
If there is more than 2 people using the toilet or you are in a colder area then additional compost
chambers may be required. Additional compost chambers can be purchased from Nature Loo.
Nature Loo recommends wearing protective clothing whenever handling waste products.
Recommended protective clothing includes gloves, appropriate footwear, a face mask and ideally eye
protection.
Use mild detergents on your NL2. Never use scouring powder or other strong detergents that could
scratch the surface, or kill off your good bacteria. We recommend green friendly or septic safe products.
IMNL-NL2.200423

© Ecoflo Wastewater Management Pty Ltd Page 12 IMNL-NL2.200423

© Ecoflo Wastewater Management Pty Ltd Page 13
•
•
•
•
•
recommended by Nature Loo would void your warranty.
Any faulty fan during the warranty period should be returned to Nature Loo before replacement can be
provided.
IMNL-NL2.200423

© Ecoflo Wastewater Management Pty Ltd Page 14 IMNL-NL2.200423
