EcoSmart Fire Linear 130 User manual

WARNING
Improper installation, adjustment, alteration,
service, or maintenance can cause injury or
property damage. Read the installation and
maintenance instructions thoroughly before
installing or servicing this equipment.
DANGER
CARBON MONOXIDE HAZARD
This appliance can produce
carbon monoxide which has
no odor.
Using it in an enclosed space
can kill you.
Never use this appliance in
an enclosed space such as a
camper, tent, car or home.
WARNING
For outdoor use only
CAUTION
DO NOT DISCARD THIS MANUAL
•Importantoperatingandmaintenance
instructions included.
•Read,understand,andfollowthese
instructions for safe installation and operation.
DANGER
If you smell gas:
•Shutogastotheappliance.
•Extinguishanyopename.
•Ifodorcontinues,keepawayfromthe
appliance and immediately call your gas
supplierorredepartment.
WARNING
Do not store or use gasoline, or other
ammablevaporsandliquids,inthevicinity
of this or any other appliance.
An LP-cylinder not connected for use shall
not be stored in the vicinity of this or any
other appliance.
INSTALLATION,
OPERATION
AND MAINTENANCE
MANUAL
LONG GAS BURNER
ESF.2.B.G35 7.5lbs/16.5kg
MEDIUM GAS BURNER
ESF.1.B.G28 12.8lbs/5.8kg
ROUND GAS BURNER
ESF.1.B.G16 12.6lbs/5.7kg

ENGLISH
EDUCATE ALL USERS
Manuals can be found on our website or by contacting your local
distributor.
WHY REGISTER YOUR WARRANTY?
Registering your warranty achieves more than simply activating your
warranty - it provides our head oce with the information that we
require in order to communicate important safety and regulatory
information to you should the need arise.
This could include things like:
• Prompt notication in the unlikely event of a potential hazard,
• Reminders about regular safety steps and maintenance procedures,
• New model announcements or accessories that suit or enhance
your purchase.
It is important that we are able to communicate eectively with our
customers as part of our commitment to continual improvement,
consumer safety and property protection.
If you purchased your product through an external distributor, retailer
or agent. MAD Design USA does not have these details on le and
may have trouble sourcing them as systems and best practices vary
from business to business.
Please register your warranty today. You can do this online at
www.ecosmartre.com or by sending through your details as itemized
on page 21 via email to [email protected].
MAD Design USA
5875 Green Valley Circle, Suite 100
Culver City CA 90230
T + 1 [phone]
E [email protected]
LISTING AND CODE APPROVALS
A.ApplianceCertication
MODEL: ESF.1.B.G35, ESF.1.B.G28, ESF.1.B.G16
LABORATORY: Underwriters Laboratories, Inc. (UL)
TYPE: Decorative Gas-Fired Outdoor Fireplace
STANDARD: Outdoor Decorative Gas Appliances
ANSI Z21.97-2014
*CSA 2.41-2014
This appliance has been tested in accordance with ANSI Z21.97-2014
and CSA 2.41-2014 for Canada and has been listed by Underwriters
Laboratory (UL) for installation and operation as described in these
installation and operating instructions.
The installation must conform with local codes or, in the absence of
local codes, ANSI Z223.1 * NFPA 54 National fuel gas code – Natural
gas and propane installation code, CSA B149.1 – or propane storage
and handling code, CSA B149.2
The appliance, when installed, must be electrically grounded in
accordance with local codes or, in the absence of local codes, with
the National Electrical Code, ANSI/NFPA 70; or the Canadian Electrical
Code, CSA C22.1, if applicable.
B.BTUSpecications
Model
OriceSize Max Input BTU
LP NG LP NG
ESF.2.B.G35 #38 #17 65000 65000
ESF.1.B.G28 #43 #31 55331 51706
ESF.1.B.G16 #43 #31 55331 51706

© Copyright 2004 - 2019 EcoSmart Inc. All rights reserved. V0619
Contents
Markings
Important Safety Information
Clearances
Before You Start
Gas Hookup
Standard Equipment Received
Burner Assembly - Propane
Burner Assembly - Natural Gas
Installation - Natural Gas
Lighting and Operating
Troubleshooting
Service and Maintenance
Reference Materials
Warranty
3
3 - 4
5
6
7 - 8
9 - 10
11 - 12
13 - 14
15
16
17 - 18
19
20
21

ENGLISH
Markings
Listing Label Information/Location
Themodelinformationregardingyourspecicappliancecanbe
found on the rating plate attached to your burner via a metal chain.
Seethesampleratingplatebelowforlocationsofspecications.
PROP 65 WARNING
Cancer and Reproductive Harm
The use of this product, as well as by-products of the
combustion of propane, natural gas and/or ethanol, contain
chemicals known to the State of California to cause cancer
and/or other reproductive harm.
The Safe Drinking Water and Toxic Enforcement Act of 1986
referred to as Proposition 65, requires the State of California to
publish a list of chemicals known to cause cancer, birth defects or
reproductive harm. It also requires California business to warn the
public of potential exposures to these chemicals which result from
the products they use, make or distribute. This list, which must be
updated at least once a year, has grown to include approximately
900 chemicals since it was rst published in 1987.
The use of this product and/or the combustion of fuels, such as
propane, natural gas, and/or ethanol in this product can expose
you to harmful chemicals including formaldehyde, which are
known to the State of California to cause cancer, and harmful
chemicals including acetaldehyde, which are known to the State of
California to cause birth defects and/or other reproductive harm.
For more information go to www.P65Warnings.ca.gov/.
The Company encourages you to use its products and propane,
natural gas and/or ethanol safely. You must read and follow all
use, care and manufacturer instructions for all products
This burner is for installation within approved
models ONLY and is not to be installed into
custom designs.
Model: EcoSmart Fire GB Series
ANSI Z21.97-2014 and CSA 2.41-2014 for Canada.
Installation must conform with local codes or in the
absence of local codes, ANSI Z223.1 * NFPA 54
National Fuel Gas Code – Natural gas and propane
installation code, CSA B149.1 – or propane storage
and handling code CSA B149.2
Type of Gas: Natural Gas, Propane Gas
WARNING: Must Not Be Used For Cooking.
WARNING: For Outdoor Use Only. If stored
indoors, detach and leave cylinder outdoors.
MINIMUM CLEARANCES: Top: 6 Ft. [72”] (1829mm)
Sides: 2 Ft. [24”] (610mm) Bottom: [8”] (203mm)
Minimum clearance from sides and back of unit to
adjacent combustible construction below top of unit
is 8” (203mm) from sides and 8” (203mm) from back.
Minimum horizontal clearance from sides and back
of unit to adjacent vertical combustible construction
extending above top of unit is 24” (610mm) from
sides and 24” (610mm) from back.
MFG. DATE XX/XX
SERIAL # XXXX DATE DE FAB. XX/XX
WARNING
Improper installation, adjustment, alteration,
service or maintenance can cause injury or
property damage. Refer to the owner’s information
manual provided with this appliance. For assistance
or additional information consult a qualied
installer, service agency or the gas supplier.
DECORATIVE
OUTDOOR GAS-FIRED
BURNER
EcoSmart Inc
5875 Green Valley Circle
Suite 100, Culver City
CA 90230
42W4
Model
Orice Size Max Input BTU
LP NG LP NG
ESF.2.B.G35 #38 #17 65000 65000
ESF.1.B.G28 #43 #31 55331 51706
ESF.1.B.G16 #43 #31 55331 51706
WARNING!
If you do not follow these instructions exactly,
a re or explosion may result causing property
damage, personal injury, and/or loss of life.
A. This appliance must be lit manually. When lighting, follow
these instructions exactly.
B. Before lighting, smell around the appliance area for gas.
Be sure to smell next to the base of the appliance because
some gas is heavier than air and will settle on the oor.
WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electric switch. Do not use any phone in
your building.
• Immediately call your gas supplier from a neighbor’s
phone. Follow the gas supplier’s instructions.
• If you cannot reach your gas supplier, call the re department.
C. Use only your hand to turn the gas control knob or valve.
Never use tools . If the valve will not turn by hand, don’t
try to repair it. Call a qualied service technician. Force or
attempted repair may result in a re or explosion.
D. Do not use the appliance if any part has been underwater.
Immediately call a qualied service technician to inspect the
appliance and replace any part which has been underwater.
CAUTION: The gas pressure regulator provided with this
appliance must be used. This regulator is set for an outlet
pressure of 10.5 inches water column.
WARNING
Do not store or use gasoline or other ammable
vapors and liquids in the vicinity of this or any
other appliance. An LP-cylinder not connected
for use shall not be stored in the vicinity of this
or any other appliance.
LIGHTING INSTRUCTIONS
1. Depress sparker button and verify a spark is being produced
between the electrode tip and receiving probe.
2. Ensure control panel valve is in the “OFF” position and
slowly open valve on propane tank. If using natural gas or
whole-house LP, open ball valve. If not using a control valve,
skip this procedure until step 3.
3. Depress sparker button and continue holding button while
turning control valve to the on position. Release button once
ame is present.
TO TURN OFF GAS TO APPLIANCE
Turn the ON/OFF valve to “OFF” position at appliance for
a natural gas appliance For an LP appliance, turn the ON/
OFF valve to “OFF” at the appliance, then with a Type I or II
connection, turn the valve at the LP cylinder clockwise to the
“OFF” Position when the appliance is not in use.
FOR YOUR SAFETY,
READ BEFORE LIGHTING
BURNER
EcoSmart Inc
5875 Green Valley Circle
Suite 100, Culver City
CA 90230
Important Safety Information

© Copyright 2004 - 2019 EcoSmart Inc. All rights reserved. V0619
Important Safety Information
Congratulations on your purchase of this decorative gas
appliance. The appliance you have selected is designed to provide
safeoperation,reliabilityandeciency.
This manual contains instructions for the safe installation and
use of your new gas appliance. Before installing and using this
appliance, read the entire manual and follow the instructions and
warnings carefully.
This owner’s manual should be retained for future reference.
If you are the installer (and not the owner) please ensure that
this manual is given to the owner for them to learn about safe
operation of the appliance and for future reference.
This appliance is a Decorative Gas Appliance for OUTDOOR USE
ONLY and MUST NOT be used for cooking. Do not burn solid fuels
in this appliance.
This gas burner is for installation within approved models ONLY
and is not to be installed into custom designs.
The information contained in this owner’s manual, unless noted
otherwise, applies to all models and gas control systems.
Keep children away from the appliance . Never leave children
unsupervisedwhenthereisoperating.
In case of emergency, have on hand a multi purpose dry chemical
typereextinguisher(ABCinUSA).
WARNING
If the information in these instructions is not followed
exactly,areorexplosionmayresultcausingproperty
damage, personal injury, or loss of life.
WARNING
Improper installation, adjustment, alteration, service, or
maintenance can cause injury or property damage. Read the
installation and maintenance instructions thoroughly before
installing or servicing this equipment.
WARNING
It is imperative the burner be kept clean
WARNING
Do NOT use this appliance if any part of it has been underwater.
Immediatelycallaqualiedservicetechnicianinspectthe
appliance and replace any part of the control system and any
gas control which has been underwater.
Installation and service of this appliance should be
performed by qualied personnel. We recommend
NFI certied, factory-professionals, or technicians
supervised by an NFI certied professional.
1. EXPLOSION/FIRE HAZARD
i. Do not operate in an area with oxygen tanks in use or if
ammablevaporsarepresent.
ii. Never smoke while lighting the appliance.
2. LOCATING THE FIRE
i. Ensure there is enough ventilation for safe operation.
ii. Locate the appliance away from combustible materials by
observing the minimum clearance distances depicted in this
manual especially for items susceptible to movement.
iii. Locate the gas hose out of pathways where people may trip
over it or in areas where the hose may be subject to accidental
damage.
vi. Place the applianceonsolid,at,levelsurfaceandwhereitwill
not get excessively wet or submerged in water.
3. OPERATING THE FIRE
i. Do not use if damaged or malfunctioning.
ii. For decorative purposes only. Not suitable for continuous
operation. Do not use the
appliance to heat or boil water or as
a cooking appliance. Do not put wood, charcoal, paper or other
combustible objects in the Fire.
iii. MAD Design USA is not liable for any damage caused by using
the incorrect type of fuel.
vi. NEVERleaveareunattended.
4. HOT SURFACE HAZARD
i. Due to high surface temperatures, keep children, pets, clothing
and furniture away from the unit for up to 1 hour of use, as the
unit is hot while in operation, contact with the appliance may
cause skin burns.
5. USING ACCESSORIES
i. Use only authorised accessories with your appliance .
ii. Toreducetheriskofreorinjury,donotmodifythe appliance
in any way.
iii. The Burner has not not been tested with an unvented gas
logset.Toreducetheriskofreorinjury,donotinstallan
unvented gas log set into this appliance.
For decorative media you must:
- Ensure the decorative media does not interfere with the
burner parts.
- Conrmqualityandsuitabilitytoensurethemediawillnot
explode, emit carbon monoxide or fumes when exposed to
extreme temperature variations.
- Fire accessories must not be smaller than
1
/
2
in (12.7mm) diameter
so that the accessories cannot impede the burner parts.
iv. Do notusettingsorspareparts,otherthanthoseavailable
from or recommended by the manufacturer of this appliance.
If you have any questions regarding any of the above important
safety information please contact your retailer or MAD Design USA.
Please store these warnings in a safe place for future reference.

ENGLISH
Clearances
When planning an appliance installation, it’s necessary to determine
the following information rst:
Environmental Conditions
WARNING: Ensurethatyourreispositionedawayfromammable
materials and other sources of ignition (combustible materials,
gasolineandotherammablevaporsandliquids)atalltimes.Pay
verycloseattentiontopositioningthereawayfromitemsthatmay
move as a result of wind and drafts. For example trees/branches/
curtains/paper and the like.
The base of the burner within the model must never come into direct
contact with ammable materials.
Locating your appliance
Adequate and constant ventilation is important to keep the appliance
functioning properly and safely, including ventilation of the appliance
undersides. Setting the appliance without air circulation underneath
can cause heat build up and improper combustion. Do not remove
the feet or operate the appliance with missing feet.
1. Locate the appliance and the LP tank cover on hard, at surface
that extends the full length and width of the appliance. The
appliance and the LP tank cover can be placed on combustible
surface (such as wood deck) or on non-combustible material (such
as concrete). Ensure all clearances to the sides and clearances
above the appliance are observed at all times (see gures 1 and 2).
2. Maintain a minimum air space of ½” (12.5mm) between the ground
surface and the underside of the appliance sidewalls by adjusting
the articulating feet up or down as necessary.
3. Do not place the appliance over grass, articial turf, carpet or
any uneven surface, as this will block the airow underneath the
appliance. See gure 1.
4. Follow the same instructions above for the LP tank cover (if
purchased). See gure 1.
CORRECT
Min 0.5’’
(12.5mm)
INCORRECT
Min 0.5’’
CORRECT
(12.5mm)
INCORRECT
Figure 1
Position the appliance adjacent to the gas supply line or LP gas
supply cylinder.
DO NOT locate the appliance where it will get excessively wet or
submerged in water.
Minimum Clearances
Note:Measurementsaredistancesclosesttotheame
Side clearances to xed and stable furniture items that are not
susceptible to movement such as lounges or patio furniture must remain
a minimum of 24in (610mm) away from the ame at all times.
Overhead clearances to items that are susceptible to movement
(e.g. Curtains/Trees) must remain a minimum of:
- 78.7in (2000mm) away from the ame at all times.
Ceiling clearances must remain a minimum of:
- 72in (1,829mm) to overhang from top of burner.
Please note that:
Any furniture items or ttings directly above or beside the Burner
installation must be deemed suitable for heat tolerances by
their manufacturer e.g. electronic items including screens and
entertainment equipment, wallpaper, laminates, veneers, glues and
reconstituted materials.
MAD Design USA is not liable for any injuries or damages sustained
through any installation not in compliance with this manual.
Areextinguisherisstronglyrecommended.
WARNING
MAD Design USA disclaims any responsibility for, and the
warranty will be voided by, the following actions:
• Installation and use of any damaged components.
• Modication of the burner assembly or burner orice.
• Installation other than as instructed in this manual.
Anysuchactionmaycausearehazard
WARNING
Fire Risk
Provide adequate clearance:
• Around air openings
• For service access
Locate appliance away from trac areas
Clearance measurements are distances from the edge of the ame,
not from the centre.
Figure 2
72in MIN
(1,829mm)
24in MIN
(610mm)
24in MIN
(610mm)

© Copyright 2004 - 2019 EcoSmart Inc. All rights reserved. V0619
Before You Start
Tools and Supplies
Before beginning the installation, be sure that the following tools and
supplies are at hand:
• Gloves
• Safety Glasses
• Phillips screwdriver
• Non-corrosive leak-check solution
• Adjustable Wrenches
• 1 AAA battery
Initial Safety Inspections
Before assembling the appliance it is important to inspect the following
and determine if it is safe to proceed:
• Carefully remove all burner components from packaging.
• Check for damage. Do not use damaged components.
• The hose assembly must be replaced prior to the appliance being put
into operation if there is evidence of excessive abrasion or wear, or if
the hose is damaged. Do not use parts other than those specied by
the manufacturer.
• The burner must be replaced prior to the appliance being put into
operation if it is evident that the burner is damaged. Do not use parts
other than those specied by the manufacturer.
• Position the assembly in the desired location. This location must be
adjacent to the gas supply line. You must have easy access to the gas
valve control knob after it is installed and connected to the gas supply
because the ON/OFF gas valve is used to turn the burner on and o.
The location for the installation must be out of the pathways where
people may trip over it or in areas where the hose may be subject to
accidental damage.
In addition, for LP Gas Models:
• Be certain to mount or set the LP gas cylinder on a at stable
surface and restrain it to prevent it from tipping.
• Make sure the tank valve is turned completely o (clockwise).
• Ensure the tank valve has the proper external mating
threads (tank valve marked “USE WITH TYPE 1”).
• Inspect the hose shipped with the appliance for any
damage. Do not use if there is evidence of damage.
• Onceassembled,positionthehose out of pathways where people
might trip over it or in areas where the hose might be subject to
accidental damage.
WARNING
Asphyxiation Risk
• This gas appliance is for outdoor use in a well-ventilated space.
• This unit must not be installed inside an enclosed structure or
unvented appliance
CAUTION
Sharp Edges
Wear protective gloves and safety glasses during installation.
WARNING
Inspect appliance and components for damage. Damaged parts
may impair safe operation.
• Do NOT install damaged, incomplete, or substitute components.
Report damaged parts to your dealer.

ENGLISH
Gas Hookup
Fuel
Before making gas connections, ensure the appliance being installed is
compatible with the available gas type.
Gas Pressure
Proper input pressures are required for optimum performance. Gas line
sizing requirements need to be made following NFPA54.
WARNING
Fire Risk
Explosion Risk
Verify inlet pressures.
• High pressure may cause overre condition.
• Low pressure may cause explosion.
• Verify minimum pressures when other household gas
appliances are operating
Install regulator upstream of valve if line pressure is
greater than ½ PSI.
Pressure requirements for appliance are shown in table below. Minimum
pressures must be met when other household gas appliances are
operating.
Manifold Pressure Natural Gas Propane
Minimum Inlet Pressure 7 in w.c 11 in w.c
Maximum Inlet Pressure 10.5 in w.c 14 in w.c
The appliance must be disconnected from the gas supply piping
system during any pressures in excess of 1/2 psi (3.5 kPa).
The appliance must be isolated from the gas supply piping system
during any pressure testing of the gas supply piping system at test
pressures equal to or less than 1/2 psi (3.5 kPa).
Gas Connection
Note: Have the gas supply installed in accordance with local building
codes, if any. If not, follow ANSI 223.1. Installation should be done
by a qualied installer approved and/or licensed as required by the
locality.(In the Commonwealth of Massachusetts installation must be
performed by a licensed plumber or gas tter.
Note: A listed (and Commonwealth of Massachusetts approved)
3/8 in (9.5mm). T-handle manual shut-o valve and exible gas
connector are connected to the 3/8in (9.5mm) control valve inlet.
If substituting for these components, please consult local codes for
compliance.
Incoming gas line should be piped to the 3/8 in (9.5mm) connection on
the manual shuto valve.
WARNING
Fire Risk
Explosion Risk
• Gas build-up during line purge may ignite.
• Purge should be performed by qualied technician.
• Ensure adequate ventilation.
• Ensure there are no ignition sources such as sparks or
open ames.
CAUTION: A small amount of air will be in the gas supply lines. When
rst lighting appliance it will take a short time for air to purge from lines.
Subsequent lighting of the unit will not require such purging. Never allow
the ON/OFF valve to remain in the open position without pressing and
continuing to hold Ignitor button FIRST.
WARNING
CHECK FOR GAS LEAKS
Fire Risk
Explosion Risk
Asphyxiation Risk
• Check all ttings and connections.
• Do not use open ame.
• After the gas line installation is complete, all
connections must be tightened and checked for leaks
with a commercially available leak-check solution. Be
sure to rinse o all leak-check solution.
Fittings and connections may have loosened during
shipping and handling

© Copyright 2004 - 2019 EcoSmart Inc. All rights reserved. V0619
Gas Hookup
LP Gas Supply
• The pressure regulator and hose assembly supplied with LP models
must be used. Replacement pressure regulators and hose assemblies
must be those specied in this manual.
• The LP gas supply cylinder used with LP models must be constructed
and marked in accordance with the specications for LP gas cylinders
of the U.S. Department of Transportation (DOT). Specications for
LP-Gas Cylinders, or the Standard for Cylinders, Spheres and Tubes
for Transportation of Dangerous Goods and Commission, CAN/
CSA-B339, as applicable
• Cylinders must be stored outdoors in a well ventilated area out of the
reach of children. Disconnected cylinders must have threaded valve
plugs tightly installed and must not be stored in a building, garage or
any other enclosed area.
• Storage of this appliance indoors is permissible only if it has been
disconnected from its fuel supply (natural gas line or LP gas cylinder).
• The LP gas cylinder supply system must be arranged for vapor
withdrawal.
• The LP gas cylinder used must include a collar to protect the cylinder
valve.
• When an LP model is not in use, the LP gas must be turned o at the
supply cylinder.
• The specic size and capacity of the cylinder(s) to be used: 20 lb. or
hard plumbed to propane tank.
IMPROPER INSTALLATION, ADJUSTMENT, ALTERATION SERVICES,
OR MAINTENANCE CAN CAUSE INJURY OR PROPERTY DAMAGE.
REFER TO AND UNDERSTAND THIS MANUAL. FOR ASSISTANCE
OR ADDITIONAL INFORMATION CONSULT A QUALIFIED
INSTALLER, LICENSED TECHNICIAN OR THE GAS SUPPLIER.

ENGLISH
Standard Equipment Received
Please ensure that all items have been received. The burners include the minimum equipment required to operate the burner safely.
Burners
Included items
Long Gas Burner - ESF.2.B.G35 Medium Gas Burner - ESF.1.B.G28 Round Gas Burner - ESF.1.B.G16
Operations Manual
Flexible gas line (ships connected to burner)
LP Hose & Regulator (10’) Valve and Screws
(to connect to the control panel)
Sparker Box
4 x Nuts and Bolts
(for attaching linear
burner to Adapter Plate)
Control Knob and Key
Grounding Wire 36”
(ships connected to burner)
Control Panel
(does not ship with burner /
ships with surround unit)
WARNING
Improper installation, adjustment, alteration,
service, or maintenance can cause injury or
property damage. Read the installation and
maintenance instructions thoroughly before
installing or servicing this equipment.
DANGER
CARBON MONOXIDE HAZARD
This appliance can produce
carbon monoxide which has
no odor.
Using it in an enclosed space
can kill you.
Never use this appliance in
an enclosed space such as a
camper,tent, car or home.
WARNING
For outdoor use only
CAUTION
DO NOT DISCARD THIS MANUAL
•Importantoperatingandmaintenance
instructions included.
•Read,understand,andfollowthese
instructions for safe installation and operation.
DANGER
If you smell gas:
•Shutogastotheappliance.
•Extinguishanyopename.
•Ifodorcontinues,keepawayfromthe
appliance and immediately call your gas
supplierorredepartment.
WARNING
Do not store or use gasoline, or other
ammablevaporsandliquids,inthevicinity
of this or any other appliance.
An LP-cylinder not connected for use shall
not be stored in the vicinity of this or any
other appliance.
INSTALLATION,
OPERATION
AND MAINTENANCE
MANUAL
LONG GAS BURNER
ESF.1.B.G35 13.5lbs/6.13kg
MEDIUM GAS BURNER
ESF.1.B.G28 12.8lbs/5.8kg
ROUND GAS BURNER
ESF.1.B.G16 8.6lbs/3.9kg
G16 & G28 Burner
Orice #43 (LP - Ships Connected ). Orice #31 (NG).
G35 Burner
Orice #38 (LP - Ships Connected ). Orice #17 (NG)
4 x Control Panel Clips
(Fixing method 1: to secure
control panel in place, ships
with surround unit)
1x Allen Key
(Fixing method 2: to secure control
panel in place with pre-installed
screws, ships with surround unit)

© Copyright 2004 - 2019 EcoSmart Inc. All rights reserved. V0619
Standard Equipment Received
Valve and Screws
(to connect to the control panel)
Assembling the control panel
Conrm you have received all necessary parts as illustrated on page 9.
If clips have been provided as the xing method, refer to step A and
follow steps 1 to 6.
If pre-installed screws have been provided as the xing method, refer to
steps 1 to 6
A. Insert two clips into the top and bottom of the control panel. (Four
clips are supplied but only one or two will be needed in most cases).
1. Attach the valve to the back of the control panel using the provided
screws. Valve must be installed as shown in drawing (with outlet on
top and inlet on bottom).
2. Remove the sparker cover and plastic nut from the sparker box.
3. Place the sparker behind the control panel and insert sparker box
into control panel.
4. From the front of the control panel, secure the sparker by attaching
the plastic nut.
5. Insert AAA battery, ensuring the + direction of the battery is facing
outward when installed.
6. Screw on the sparker box cover to hold battery in place.
i. Cap assembly completed.
A.
3.
6. i.
1.
4. 5.
2.

ENGLISH
Burner Assembly - Propane
PROPANE
1. Unpack burner box. Remove all items and check against the items
listed on page 9 of the manual to ensure all parts needed are ready.
2. THE BURNER IS SHIPPED FOR PROPANE FUEL SOURCE. Verify that
you have the correct orice installed by checking it against the fuel orice
chart on page 1. The orice has the number stamped on the side. Once
conrmed, check that the attached exible gas line is tightly attached.
Ensure that the air shutter is open ¼” (6.4mm) on each side of the air shutter.
1/4”
(6.4)
3. Ensure ignitor wire is secured to bottom of Ignitor.
4. Ensure grounding wire is secured to bottom of burner.
5. Linear burners only: (this step is not required for round burners)
Place the tray on a large workbench or table. Attach the burner to the tray
using the four bolts and nuts provided. We recommend using the 3rd hole
from the outside of the long sides to securely fasten the burner to the tray.
Carefully place the burner/tray assembly above the surround near the
opening, without lowering it into the nal location. Position the burner/tray
assembly so that the gas input exible line (where the orice is located) is
pointing towards the control plate cutout location of the surround. Feed
the exible gas line, grounding wire and the ignitor wire through the burner
location opening rst then place lower the burner into its nal location.
6. Round burners only: (this step does not apply to linear burners)
Put the burner tray on the Surround Unit. Carefully place the burner on the
Surround Unit near the tray opening – without inserting the burner into the
nal location. Rotate the burner to make sure the gas input exible line
is pointing towards the gas control valve location of the surround. Feed
the exible line, grounding wire and the ignitor wires through the burner
location opening rst then lower the burner into its nal location.
7. Slide the black propane tank hose under the Surround Unit and out
through the control panel opening. The other end of the black propane
hose with the regulator will attach to the propane tank.
8. Pull all hoses and wires from inside the unit out through the control
plate cutout.
9. Ensure you have assembled the control panel, as outlined on page 10.
GAS OUTLET
(METAL FLEX LINE
TO BURNER)
10. Using two adjustable wrenches, attach the exible gas line to the
top valve tting (outlet). Do not overtighten.
11. Using two adjustable wrenches, attach the propane tank hose to the
bottom valve tting (input). Do not overtighten.

© Copyright 2004 - 2019 EcoSmart Inc. All rights reserved. V0619
Burner Assembly - Propane
12. Ensure propane tank is in the OFF position. Attach propane hose
and included regulator to propane tank.
13. Ensure the control knob (or “key”) is in the OFF position.
14. Use a leak detecting solution to check all connections before
operation.
15. Plug the Ignitor wire and grounding wire into the back side of the
sparker. These wires can be plugged into either port on the back side
of the sparker box.
16. Insert the fully assembled Control Panel into the side of the
Surround Unit, feeding the cables and wires back into the unit as
needed until the Control Panel is rmly in place.
As noted on page 10 ‘Assembling the Control Panel’:
FIGURE A: If clips have been provided asthexingmethod and
you nd the Control Panel is too loose, add an additional clip to the
side/s to tighten up the t. If it’s too tight, remove one of the clips until
the best t is achieved.
FIGURE B: Ifscrewshavebeenprovidedasthexingmethod,
tighten the 4 pre-installed screws with the included allen key until the
control panel is screwed in place. Tighten each one so the Control
Panel is set rmly in place and centered. Do not overtighten.
FIGURE A FIGURE B
17. Fill the burner area with the included black glass media. Use all black
glass charcoal provided for best eect. Keep clear of the sparker to
avoid accidental blockage. Spread the media evenly while ensuring the
burner is completely covered.
Adequate and constant ventilation is important to keep the appliance
functioning properly and safely, including ventilation of the appliance
undersides. Setting the appliance without air circulation underneath
can cause heat build up and improper combustion. Do not remove
the feet or operate the appliance with missing feet.
1. Locate the appliance and the LP tank cover on hard, at surface
that extends the full length and width of the appliance. The
appliance and the LP tank cover can be placed on combustible
surface (such as wood deck) or on non-combustible material (such
as concrete). Ensure all clearances to the sides and clearances
above the appliance are observed at all times (see gures 1 and 2).
2. Maintain a minimum air space of ½” (12.5mm) between the ground
surface and the underside of the appliance sidewalls by adjusting
the articulating feet up or down as necessary.
3. Do not place the appliance over grass, articial turf, carpet or
any uneven surface, as this will block the airow underneath the
appliance. See gure 1.
4. Follow the same instructions above for the LP tank cover (if
purchased). See gure 1.
CORRECT
Min 0.5’’
(12.5mm)
INCORRECT
Min 0.5’’
CORRECT
(12.5mm)
INCORRECT
Figure 1
WARNING
Do not burn without black glass charcoal on burner.

ENGLISH
Burner Assembly - Natural Gas
NATURAL GAS
VERY IMPORTANT: Connection of this product to Natural Gas must
be completed by a licensed gas plumber / installer only. Do not
attempt to install this product with Natural Gas without a licensed
installer present.
1. Unpack burner box. Remove all items and check against the items
listed on page 9 of the manual to ensure all parts needed are ready.
THIS BURNER IS SHIPPED FOR PROPANE FUEL SOURCE. TO
CONVERT IT FOR NATURAL GAS, THE ORIFICE NEEDS TO BE
REPLACED WITH THE INCLUDED ORIFICE MARKED #17 (G35) or
#31 (for G16 or G28).
2. REPLACING THE ORIFICE
a. Turn the burner over so that the exible hose is easily accessible.
Be careful not to bend the electrode tip.
b. Using two adjustable wrenches, remove the exible hose from
the burner orice.
c. G16 and G28 burners:Using an adjustable wrench, remove the
#43 orice from the gas inlet of the burner and insert #31 orice into
the gas inlet of the burner. Do not overtighten.
G35 burner: Using an adjustable wrench, remove the #38 orice
from the gas inlet of the burner and insert #17 orice into the gas
inlet of the burner. Do not overtighten.
#38/ #17
d. Re-attach the exible gas hose to the orice. Do not overtighten.
e. Adjust the air shutter to between 1/16” (1.6mm) open to
completely closed on each side of the air shutter.
f. Ensure ignitor wire is secured to the bottom of the ignitor.
1/16”
(1.5)
g. Ensure grounding wire is secured to bottom of burner
3. Linear burners only: (this step does not apply to round burners)
Place the tray on a large workbench or table. Attach the burner to
the tray using the four bolts and nuts provided. We recommend using
the 3rd hole from the outside of the long sides to securely fasten the
burner. Carefully place the burner/tray assembly above the surround
near the opening, without lowering it into the nal location. Position
the burner/tray assembly so that the gas input exible line (where the
orice is located) is pointing towards the control plate cutout location
of the surround.
Feed the exible gas line, grounding wire and the ignitor wire through
the burner location opening rst then lower the burner/tray assembly
into its nal location.
4. Round burners only: (this step does not apply to linear burners) Put
the burner tray on the Surround Unit. Carefully place the burner on the
Surround Unit near the opening, without inserting the burner into the
nal location. Rotate the burner to make sure the gas input exible line
is pointing towards the gas control valve location of the surround. Feed
the exible line, grounding wire and the ignitor wires through the burner
location opening rst then lower the burner into its nal location.
5. Pull all hoses and wires from inside the unit out through the control
plate cutout.
6. Route the natural gas line from below the Surround Unit out through
the control panel opening.
7. Ensure you have assembled the control panel, as outlined on page 10.
GAS OUTLET
(METAL FLEX LINE
TO BURNER)
8. Using two adjustable wrenches, attach the exible gas line to the
top valve tting (outlet). Do not overtighten.

© Copyright 2004 - 2019 EcoSmart Inc. All rights reserved. V0619
Burner Assembly - Natural Gas
9. Using two adjustable wrenches, attach the natural gas line to
the bottom valve tting (input). Do not overtighten. It is strongly
recommended to place a manual shuto valve in the natural gas line
before it reaches the valve on the control panel.
10. Ensure the control knob (or “key”) is in the OFF position.
11. Use a leak detecting solution to check all connections before
operation.
12. Plug the ignitor wire and grounding wire into the back side of
the sparker. These wires can be plugged into either port on the back
side of the sparker box.
13. Insert the fully assembled Control Panel into the side of the
Surround Unit, feeding the cables and wires back into the unit as
needed until the Control Panel is rmly in place.
As noted on page 10 ‘Assembling the Control Panel’:
FIGURE A: If clips have been provided asthexingmethod and
you nd the Control Panel is too loose, add an additional clip to the
side/s to tighten up the t. If it’s too tight, remove one of the clips until
the best t is achieved.
FIGURE B: Ifscrewshavebeenprovidedasthexingmethod,
tighten the 4 pre-installed screws with the included allen key until the
control panel is screwed in place. Tighten each one so the Control
Panel is set rmly in place and centered. Do not overtighten.
FIGURE A FIGURE B
14. Fill the burner area with the included black glass media. Use all black
glass charcoal provided for best eect. Keep clear of the sparker to
avoid accidental blockage. Spread the media evenly while ensuring the
burner is completely covered.
Adequate and constant ventilation is important to keep the appliance
functioning properly and safely, including ventilation of the appliance
undersides. Setting the appliance without air circulation underneath
can cause heat build up and improper combustion. Do not remove
the feet or operate the appliance with missing feet.
1. Locate the appliance and the LP tank cover on hard, at surface
that extends the full length and width of the appliance. The
appliance and the LP tank cover can be placed on combustible
surface (such as wood deck) or on non-combustible material (such
as concrete). Ensure all clearances to the sides and clearances
above the appliance are observed at all times (see gures 1 and 2).
2. Maintain a minimum air space of ½” (12.5mm) between the ground
surface and the underside of the appliance sidewalls by adjusting
the articulating feet up or down as necessary.
3. Do not place the appliance over grass, articial turf, carpet or
any uneven surface, as this will block the airow underneath the
appliance. See gure 1.
4. Follow the same instructions above for the LP tank cover (if
purchased). See gure 1.
CORRECT
Min 0.5’’
(12.5mm)
INCORRECT
Min 0.5’’
CORRECT
(12.5mm)
INCORRECT
Figure 1
WARNING
Do not burn without black glass charcoal on burner.

ENGLISH
Installation - Natural Gas
Natural Gas Supply Installation Guidelines
1. The gas supply line must have enough capacity to supply the burner
with its rated gas output.
2. The ame output may be too low if the gas line is too small.
3. Smooth walled pipe should be used as a supply line. Excessive
corrugated line will cause unwanted restriction and potential noise due
to gas ow.
4. Gas pressure at the unit should be within 5-7 in. WC to keep
restriction to a minimum.
5. Ensure that the length of the gas line and pipe diameter is properly
sized for the burner output (see Pipe Sizing Chart below). Add 1’ to 5’ to
the line length for every elbow or additional tting. If you have another
natural gas appliance sharing the same line, add the BTU output to
provide to provide the proper pipe size.
NaturalGasPipeSizingChart*
*Maximum delivery capacity of pipes in BTU/hour at dierent diameters and lengths for an initial pressure of 7-inch water
column. Note: 1 cubic feet per hour = 1000 BTU
As an example, to install a Brown Jordan FLO with a G35 burner (65,000 BTU) and located about 90 feet from the natural
gas supply line with 2 elbow ttings, you would need at least a ¾” pipe minimum.
Length of Pipe in Feet
SizeofPipeinInches(insidediameter)
½” ¾” 1”
10 108,000 230,000 387,000
20 75,000 160,000 280,000
30 61,000 129,000 224,000
40 52,000 110,000 196,000
50 46,000 98,000 177,000
60 42,000 89,000 159,000
70 38,000 82,000 149,000
80 36,000 46,000 140,000
90 33,000 71,000 133,000
100 32,000 68,000 125,000
125 28,000 60,000 117,000
150 25,000 54,000 105,000
175 23,000 50,000 93,000

© Copyright 2004 - 2019 EcoSmart Inc. All rights reserved. V0619
Lighting and Operating
To Extinguish
Turn control valve to “OFF” position or close ball valve. Close valve on
propane tank while not in use.
Initial break-in procedure: When you light the appliance, you may
notice that it produces heat which may have an odor. If you feel this
odor is excessive it may require an initial three to four hour continuous
burn on high.
WARNING
FIRE RISK – HIGH TEMPERATURES
Keep combustible household items away from appliance.
• Do NOT obstruct combustion and ventilation air.
• Do NOT place combustible items on top of or near appliance.
• Keep furniture, draperies away from appliance.
• Do NOT use, lantern fuel, kerosene, charcoal lighter
uid, bioethanol or similar liquids in this appliance.
• Combustible materials, ammable liquids, or vapors may ignite.
FOR YOUR SAFETY, READ BEFORE LIGHTING
WARNING! If you do not follow these instructions
exactly,areorexplosionmayresultcausingproperty
damage, personal injury, and/or loss of life.
A.This appliance can be lit electronically or with a match. When lighting,
follow these instructions exactly.
B.Before lighting, smell all around the appliance area for gas. Be sure
to smell next to the base of the appliance because some gas is heavier
than air and will settle on the oor.
WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electric switch, do not use any phone nearby.
• Immediately call your gas supplier from a neighbors phone. Follow gas
supplier’s instructions.
• If you cannot reach your gas supplier, call the re department.
C. Use only your hand to turn the gas control knob on propane tank (if
equipped), never use tools. If the valve won’t turn by hand, don’t try to
repair it, call a qualied service technician. Force or attempted repair
may result in a re or explosion.
D. Do not use the appliance if any part has been underwater.
Immediately call a qualied service technician to inspect the appliance
and replace any part which has been underwater.
E. The gas pressure regulator provided with this appliance must be used.
This regulator is set for an outlet pressure of 10.5in (267mm) water column.
Lighting Instructions
1. Depress sparker button and verify a spark is being produced
between the electrode tip and receiving probe.
2. Ensure control panel valve is in the “OFF” position and slowly open
valve on propane tank. If using natural gas or whole-house LP, open ball
valve. If not using a control valve, skip this procedure until step 3.
3. Depress sparker button and continue holding button while turning
knob to the “ON” position. Release button once ame is present.
WARNING: If the ame does not ignite within 5-10 seconds turn
the gas “OFF” and wait for 5 minutes before re-attempting to ignite.
Failure to follow this instruction may result in a volatile ignition due to
the build up of vapors.
1.
2.
3.

ENGLISH
Troubleshooting - General
Symptom Possible Causes Corrective Actions
1. Appliance won’t light
A. No LP in tank, or NG main not turned on. Check the LP (propane) tank. You may be out of
gas. Or check Natural Gas valve at main.
B. Plugged burner orice. Check the burner orice for stoppage. Remove
stoppage.
C. No spark igniting burner Refer to ignitor on section 7 below.
2. Low ames or
won’t stay lit A.
Manual shuto valve (on/o control knob)
open or not in- stalled between LP tank and
appliance.
Close LP tank and manual shuto valves. Open LP
tank valve rst, THEN the manual shuto valve.
3. Blue Flames
A.
This is a result of normal operation and
ames will begin to yellow as unit is allowed
to burn for 16-20 minutes.
No action required.
B. Improper air/fuel mixture related to air
shutter position.
Close air shutter. (for LP, leave ¼in [6.4mm] open,
Natural gas 1/16 in [1.6mm] open).
4. Metallic noise A.
Noise is caused by metal expanding and
contracting as it heats up and cools down,
similar to the sound produced by a furnace
or heating duct. This noise does not aect
the operation or longevity of the appliance.
No action required.
5.
Ignitor makes clicking
sound but no visible spark
is produced
A. Ignitor is improperly grounded. Check all wire connections at back of sparker box.
B. Ignition or ground wire not plugged in. Ensure ignitor wire and grounding wire are securely
attached to burner.
C. Ignitor tip set too far from grounding probe.
Check that tip of ignitor is within ¼ in (6.4mm)
of grounding probe. Gently bend Ignitor tip or
grounding probe by hand to achieve a smaller gap.
6. Ignitor does not spark or
make a ticking sound
A. Battery low, Not installed, Installed
incorrectly.
Ensure that a fresh AAA battery is installed Positive
(+) side facing outward toward the sparker cap.
B. Corrosion on battery contacts.
Check contact at the bottom of the battery cavity
for corrosion. Clean with a small piece of sandpaper
or a le.
C. Battery cap not screwed down completely.
If the cap cannot be screwed down tight enough,
the battery will not make a proper connection with
the sparker and it will not work. Be sure to use a
thin surface such as 20-22 gauge sheet metal to
mount sparker in.

© Copyright 2004 - 2019 EcoSmart Inc. All rights reserved. V0619
Troubleshooting - Loud Gas Flow
Excessive Rushing and Whistling noise
There are multiple causes for excess noise coming from the gas appliance.
The more gas (maximum control valve setting) the more likely you are to
hear excess noise. This is due to the larger volume of gas owing at a
higher velocity through the plumbing of the appliance. Gas owing noise
is inevitable so this is intended for excessively loud rushing or whistling.
1.Doyouhearawhistlingorrushingnoiseintheapplianceex-line?
The internal structure of the ex-line and the path the gas follows inside
of the ex-line can be the cause. When installing a ex-line, do your
best to avoid sharp bends and angles.
You may be able to remedy a noisy ex-line that is already installed by
carefully repositioning the line to remove sharp bends and angles.
Using commercially available appliance gas connectors (yellow
corrugated ex-lines from hardware stores) are not recommended for
gas re pits or replaces. These hoses are not intended for the higher
gas input rates of these appliances and produce large amounts of noise.
There are various sizes and lengths of whistle-free ex lines available.
The licensed plumber doing the installation can help recommend one.
2.Isthewhistlingcomingfromtheorice?
The orice is what controls the amount of gas that your appliance
is using. Sometimes the shape of an orice can produce a whistling
depending on the gas ow rate and gas pressure.
If repositioning the ex-lines in your appliance did not x the whistling
noise, disconnect the gas supply to the burner and remove the orice.
Blow through the orice to check for a whistle. If your orice whistles,
call our customer service at 1-888-590-3335 so we can ensure you
have the specic orice installed.
3. Ensure your air shutter is properly adjusted according to the
EcoSmart Gas Installation Manual.
A properly adjusted air shutter will give the brightest ame and quietest
performance.
For natural gas the air shutter should be between 1/16” to completely
closed.
For liquid propane, the air shutter should be open between 3/16”
and 1/4”.

ENGLISH
Service and maintenance
Although the frequency of appliance servicing and maintenance will
depend on use and the type of installation, a qualied service technician
should perform an appliance check-up annually.
Storage of an appliance indoors is permissible only if the cylinder is
disconnected and removed from the appliance.
Stainless steel will rust or corrode over time if contamination or
debris is not cleaned or removed immediately. When not in use, it is
recommended that you protect your replace from water damage or
corrosion with a protective cover.
WARNING
Risk of injury or property damage.
Before servicing:
• Turn o utilities to appliance
• Ensure appliance is completely cooled
Maintenance and Service Tasks
Likeallreandreplacesystems,it’simportanttorunthroughregularsafetychecks.Pleasetakethetimetofamiliariseyourself
(andanyotherusers)withthesafetyproceduresassociatedwithusingyourrepit.
Inspect Maintenance Tasks
Burner Assembly
1Remove decorative black glass charcoal and examine burner. Vacuum and wipe out as
needed. Use caution when cleaning these areas
2 Inspect for warping and corrosion. Repair as necessary
3Check the hose connecting the LP gas cylinder to ensure it is not damaged. Replace
as necessary.
4Verify air shutter area is clean
Burner Ignition and Operation
1 Verify all gas connections are tight and leak-free
2Clean burner top, inspect for plugged ports, corrosion, or deterioration. Replace
burner if necessary.
3Inspect for ame problems.
4Verify air shutter is clear of dust and debris and is in correct position for the gas type
being used.
5Inspect orice for soot, dirt, or corrosion
6 Verify manifold and inlet pressures. Adjust regulator as required.
Gas Hose with Regulator 1 The gas hose with regulator supplied with appliance must be used for LP installations.
The replacement must be those specied by the appliance manufacturer
WARNING
Annual inspection by qualied technician recommended.
Check:
• Obstructions of combustion and ventilation air.
• Condition of burner assembly
• Burner ignition and operation
• Burner air shutter adjustment
• Gas connections and ttings
Risk of:
• Fire
• Delayed ignition or explosion
• Exposure to combustion fumes
• Odors
