Siemens 7ME30 User manual

SITRANS F Ultrasonic Flowmeters
with PROFIBUS PA Interface
7ME30xx-xxxxx-1xxx
Instruction Manual (Supplement) C79000-B5676-C114-03
Note: This document is a supplement to the Instruction Manual C79000-B5676-C110 for the
PROFIBUS PA-version. Knowledge of this Instruction Manual is assumed, since this
supplement only describes the differences from the standard version.
Special notice must also be taken of the warnings specified for the standard version.

SIPART, SITRANS, SIMATIC
are Siemens registered trademarks.
All other product or system names are (registered) trademarks of their respective owners and must be treated
accordingly.
The reproduction, transmission or use of this document or its contents is not permitted without express written authority. Offenders will be liable
for damages.
All rights created by the granting of patents or registration of a design are reserved.
Technical data subject to change without notice

Instruction Manual
SITRANS F with PROFIBUS PA
C79000-B5676-C114-03
3
Contents
Page
1 Technical Description 4.................................................................
1.1 PROFIBUS 4............................................................................
1.1.1 General Information about PROFIBUS DP and PA 4..........................................
1.1.2 Properties of the PROFIBUS PA 5..........................................................
1.2 Function of the Device 6..................................................................
1.3 Scope of Functions 7.....................................................................
1.4 Technical Data 8.........................................................................
1.5 Order Data 8............................................................................
2 Installation 9...........................................................................
2.1 Electrical Connection 9...................................................................
3 Commissioning 10.......................................................................
4 Operation, Communication 11.............................................................
4.1 PROFIBUS Communication 11.............................................................
4.1.1 Cyclic Data Transmission 11................................................................
4.1.1.1 Input Data (from device to master) 12........................................................
4.1.1.2 Output Data (to the Device) 15..............................................................
4.1.1.3 Device Data Base File (GSD File) 15.........................................................
4.1.2 Acyclic Data Transmissio 16................................................................
4.1.3 Diagnosis 17.............................................................................
4.2 Local Operation and Display 20.............................................................
4.3 Locking Operation 27......................................................................
4.3.1 Local Write Protection 27...................................................................
4.3.2 General Write Protection 27................................................................
4.3.3 Locking Local Operation 28................................................................
5 Device Functions and Parameters 29......................................................
5.1 Display Function Group 29.................................................................
5.2 Diagnosis Function Group 29...............................................................
5.3 Measuring Functions Function Group 29.....................................................
5.3.1 Flow, Temperature, Sound Velocity, US Amplitude (menus 3.1 to 3.4) 29..........................
5.3.2 Totalizer (menu 3.5...3.7) 32................................................................
5.4 Device Outputs Function Group 32..........................................................
5.4.1 PROFIBUS (menu 4.1) 32..................................................................
5.4.2 Digital output 1 (menu 4.2) 33...............................................................
5.5 Identification Function Group 34.............................................................
5.6 Service Function Group 34.................................................................
5.6.1 Code (menu 6.1...6.2) 34...................................................................
5.6.2 Error Filter (menu 6.6.3) 35.................................................................
6 Maintenance 35..........................................................................
7 Certificates 36...........................................................................
7.1 EC Declaration of Conformity 36............................................................
7.2 EC Type Examination Certificate 37.........................................................
7.3 PNO Certificate 45........................................................................
8 Literature and Catalogs 46................................................................
9 Appendix: Device Data Base File (GSD File) 47.............................................
10 Index 50.................................................................................
11 Abbreviations 52.........................................................................

Instruction Manual
4SITRANS F with PROFIBUS PA
C79000-B5676-C114-03
1 Technical Description
1.1 PROFIBUS
The PROFIBUS (Process Field Bus) is an open communication system for automation engineering which
is being used in its thousands all over the world and which is specified in the European standard
EN 50170.
1.1.1 General Information about PROFIBUS DP and PA
The PROFIBUS PA is a variant of the PROFIBUS DP which is used widely in production engineering.
The PROFIBUS PA has special a transmission technique and therefore satisfies the requirements of
process automation/materials processing. This transmission technique is defined in the international
standard IEC 61158-2. The low transmission speed reduces the power loss and therefore enables an
intrinsically safe technology for use in areas where there is a high explosion risk. Line, star and tree
structures are possible as well as combinations of these. All kinds of field devices such as transducers,
actuators, analyzers, etc. can be connected to the PROFIBUS PA. The essential advantage in addition to
the saving of installation costs is the possibility of a more detailed diagnosis with an increase in the
availability of the plant components. In addition the automatic updating of plant documentation and plant
optimization during ongoing operation is supported.
Several PROFIBUS PA lines are linked to the fast PROFIBUS DP in an automatic system. The process
control system is also linked to this. Both bus systems use a uniform protocol layer. Thus the PROFIBUS
PA is a communication-compatible extension of the PROFIBUS DP into the field.
Master
(class 1)
Master
(class 2)
PROFIBUS DP
I
PROFIBUS PA
Slaves
(Field devices, decentral periphery, slave control
systems, network transition to PROFIBUS PA)
8x
Figure 1--1 Typical PROFIBUS automation system
Figure 1--1 shows a section of a typical PROFIBUS automation system. The control system consists of
two masters with shared tasks:
The Master class 1 takes care of the control and regulating tasks, Master class 2 allows operating and
monitoring functions. Measuring and actuating data are exchanged cyclically between Master class 1 and
the field devices. The status information signals of the field devices are transmitted parallel to these data
and evaluated in the class 1 master. No field device parameters are set or other device information read
during cyclic operation. The information necessary for establishing communication is available to the
control system from the stored, device-specific device data base files GSD.
One or more class 2 masters can access the field devices acyclically in addition to the cyclic mode. With
this communication type further information can be fetched from the devices or settings made in the
devices.

Instruction Manual
SITRANS F with PROFIBUS PA
C79000-B5676-C114-03
5
1.1.2 Properties of the PROFIBUS PA
The PROFIBUS PA (PA = Process Automation) enables di-directional communication between a bus
master and the field devices over a two-wire cable. At the same time the power is supplied to the two-wire
field devices through the same cables (current I in Figure 1--1).
Supplementary to the EN standard 50170, the PNO (PROFIBUS user organization) has defined the scope
of functions of the individual field device types in a so-called profile description. These profiles define the
minimum functional requirements and optional extensions. The device-internal “Device Management”
supplies all the necessary basic information for finding the profile parameters to the control system
configuration tools. In this way a parametering tool can operate all devices which conform to profile no
matter what their type and manufacturer.
The system must be implemented with one or more PROFIBUS PA lines depending on the automation job
and thus the number of field devices. A PROFIBUS PA line consists of the components illustrated in
Figure 1--2.
PLS, PC
FD
PROFIBUS PA
PROFIBUS DP
additional
line termination
T
FD
Control station Field
T
Coupler
Power
supply
FD = Field device
Figure 1--2 PROFIBUS PA architecture
The central process control system PLS or, in the case of low requirements, a PC, is responsible for the
control. As a rule the functions signal conversion DP-PA, bus feeding and bus termination are unified in the
“coupler” device. A DP/PA coupler or, in the case of higher requirements, a more powerful DP/PA link is
used depending on the number of PROFIBUS PA field devices to be operated in the automation system.
An additional terminating resistor must be fitted at the far end of the bus for transmission-technical
reasons. The theoretically possible line length (total of all line sections) is a maximum 1900 m (see
chapter 2.1) when using the recommended bus cable. However, the current requirements of the individual
users and voltage drop at the cable must also be taken into account in the planning. The individual field
devices FD can be connected almost anywhere in the bus system. See the “PNO Guide
PROFIBUS PA” /1/ for further information.
The DP/PA coupler or DP/PA Link is supplied by a power supply unit with safety extra-low voltage (SELV).
This power supply must have adequate reserves for bridging brief power failures.
The maximum number of devices that can be connected to a bus line depends on their current
consumption and the respective application conditions. When operating in an area where there is no risk of
explosion, the couplers/links can feed up to 400 mA into the bus.
When operating in explosion risk areas, the intrinsic safety is only guaranteed when the maximum power
fed into the bus does not exceed certain voltage and current values.
These are normally:
Current IS< 128 mA, voltage U0<15V

Instruction Manual
6SITRANS F with PROFIBUS PA
C79000-B5676-C114-03
!Warning
Only certified supply units (DP/PA couplers or DP/PA links) may be used to feed
the intrinsically safe PROFIBUS. See the EC Type Examination Certificate for
requirements.
The number of devices which can be connected to a bus line is given by the total of maximum current
consumptions of the connected devices (³10 mA per device is the standard). A current reserve should be
planned for safety, otherwise there is a risk that a defective device overloads the bus with its increased
current consumption and the power supply and communication with all unaffected users could collapse.
The power reserve quantity depends on the current increase in the event of an error specified by the
manufacturer.
The electronic current limiter installed additionally in the SITRANS F/PA ensures that the current does not
increase by more than 5 mA even when a device is defective.
Every device has its own address to distinguish between the connected process devices. The address
setting is described in the chapter 3 “Commissioning”.
See the System Description Field Technology /2/ for further information about components, setup
regulations and planning.
1.2 Function of the Device
ThePROFIBUSPAvariantoftheSITRANSFdiffersfromthe4to20mA/HARTversioninthebus
interface and the omission of the digital output 2. This means that the basic functions of the device
including the operation and display remain basically the same. Function blocks 1 to 6 take care of the
interface tasks to the bus.
μP
65321 4
Bus connection
+
Bus
controller
Figure 1--3 Block diagram of the bus link
1 The microprocessor interprets the bus command, initiates device-internal actions and provides
measured values, status and device data on the bus.
2 The device internal electronics are isolated from PROFIBUS PA by the potential isolator.
3 The bus interface contains the transmit and receive circuits for the bus system.
4 The electronic current limiter ensures that no illegally high current flows in the event of an error. This
avoids bus overloading, data communication with the other, unaffected users is maintained.
5 The reverse polarity protection enables the bus cables to be connected at any terminals and makes
installation errors almost impossible.
6 An EMC filter prevents malfunctions in the case of electromagnetic interference.

Instruction Manual
SITRANS F with PROFIBUS PA
C79000-B5676-C114-03
7
1.3 Scope of Functions
SITRANS F provides the following measured values and values derived from measured values using
PROFIBUS and local display.
·Flow (volume or mass flow)
·Sound velocity
·Temperature
·Ultrasonic amplitude
·Quantity (volume or mass) net, forward and reverse
An upper and lower limit can be specified for all measured values. An appropriate message is indicated in
the measured value status (see description 4.1.1.1) when a limit value is reached. Diagnostic messages
are also indicated in the event of malfunction or special states (see description below).
SITRANS F has a wide range of setting facilities, for example, measuring range scaling, definition of the
flow direction, residual flow suppression, attenuation of measured values etc. The settings are made on
the PROFIBUS or using the local keyboard with menu guidance.
The quantity values (volume and mass) are derived from the flow value by accumulation (volume or mass
forward from all positive flow values, volume or mass reverse from all negative flow values, volume or
mass net from all flow values with the correct sign) and also have setting facilities for the limit values but
no scaling.
The flow values can also be issued as a frequency or pulse sequence at “digital output 1”.
Status information on quality and compliance with limit values is provided with the measured values.
Further diagnosis data can be called up if there are device errors.
The following functions are implemented in addition to the standard device according to the PROFIBUS
device profile:
·User-specific scaling of all measured variables in the form of a linear representation
between any range of the measured variable (“measuring scale”) and the actual output
variable (“output scale”).
·A measuring range does not need to be set, the valid measuring range is only limited
by the respective sensor limits (see Table 5--1, page 30).
·Upper and lower warning limit for each measured variable to supplement the existing
alarm limits.
·Upper and lower warning and alarm limits for each totalizer, with selectable hysteresis
for the net totalizer.
The following functions on the standard device with 20 mA/HART interface are not available on the
PROFIBUS version as they can generally be replaced indirectly by the PROFIBUS functions.
·Analog output (4 to 20 mA)
·HART communication
·Digital output 2 (relay output)

Instruction Manual
8SITRANS F with PROFIBUS PA
C79000-B5676-C114-03
1.4 Technical Data
Device version Order number 7ME30xx-xxxxx-1xxx (Software version 2.00 onward)
Data According to operating manual of the 20 mA/HART version
(order number C79000-B5600-C110) with the following deviations:
Communication Layer 1+2 acc. to PROFIBUS PA, transmission technique acc. to
IEC 61158-2; Slave function
Layer 7 (protocol layer) according to PROFIBUS DP, Standard
EN 50 170 incl. DPV1
Device class B
Device profile 3.0
Device model Modular function device
Connections Up to 4 simultaneous C2 connections (Master class 2) are supported;
Automatic disconnection approx. 60 s after communication abort
Device address 126 in the as-delivered state
Power supply Separate power supply for basic unit
Permissible bus voltage 9 to 32 V; for devices in ignition protection type II 2G EEx dem[ia]
IIC T6 see table of the EC Type Examination Certificate
Current consumption of bus 10 mA
in case of error ≤14.5 mA (electronic current limiter)
Digital output 1 Only passive signals
Digital output 2 Omitted
Explosion protection II 2G EEx d IIC T6
II 2G EEx dem IIC T6
II 2G EEx dem[ia] IIC T6
See EC Type Examination Certificate for permissible maximum values
of voltage, current, power, inductance and capacitance
(see chapter 7)
1.5 Order Data
The former order procedure is still valid with the following deviations:
·For the PROFIBUS PA version the “0” must be replaced by a “1” at the 13th data position in the order
number.
·For the explosion protection, version II 2G EEx dem[ia] IIC T6 is available in place of version II 2G
EEx dem[ib] IIC T6, order code “G”.
7ME30xx --jjjjj-- jjjj
4to20mA/HART 0
PROFIBUS PA 1
Explosion protection
DWithout explosion protection A
DWith explosion protection:
-- II 2G EEx d IIC T6 (not for PG 13.5)
-- II 2G EEx dem IIC T6
-- II 2G EEx dem [ib] IIC T6 (only for 4--20 mA/HART,
not for 120--230 V, only passive pulse output)
-- II 2G EEx dem [ia] IIC T6 (only for PROFIBUS PA,
not for 120--230 V)
C
D
F
G

Instruction Manual
SITRANS F with PROFIBUS PA
C79000-B5676-C114-03
9
2 Installation
2.1 Electrical Connection
!Warning
·The pertinent regulations must be observed for electrical installation, in
explosion risk areas in particular:
- the rules and regulations governing the erection and operation of plants in
explosion risks areas (e.g. in Germany: Elex V, DIN VDE 0165)
- the EC Type Examination Certificate
- the power supplied from the coupler may not exceed the maximum values
specified in the EC Type Examination Certificate of the SITRANS F. The
device may no longer be connected to intrinsically safe circuits if these
values have been accidentally exceeded.
·Do not install the device under voltage. Danger of electric shock!
·The version for power supply UC 19 to 30 V may only be connected to SELV
or PELV circuits.
The following rules apply generally for laying the bus cable:
- Only use shielded, two-wire cables
- Only use the recommended cable types, e.g.:
in intrinsically safe circuits: Siemens 6XV1 830-5AH10 (color blue);
in circuits with enhanced safety or non-Ex applications:
Siemens 6XV1 830-5BH10 (color black)
- Lay cable separately from cable with voltages > 60 V
- Avoid laying near to large electrical installations
- The specifications only apply for properly executed installations.
Make the electrical connection as follows:
- The cables used for connecting must have the specified outside diameters.
- Compare the data on the rating plate with the local power supply.
- Release the catch on the cover of the terminal compartment by turning the 3 mm hexagon socket
screw.
- Unscrew the cover from the terminal compartment.
- Push the power cable and the bus cable through the cable gland up to the terminal block. Lay the cable
in a bend in front of the cable gland to prevent moisture getting into the terminal block.
- Make the connection as shown in Figure 2--1.
- Connect the PE cable of the power supply to the earth terminal in the terminal compartment. Use a
cable length so that the PE conductor is the last to come away when you pull the cable.
- Mount the cover for the power supply terminals in devices with ignition protection II 2G EEx dem[ia] IIC
T6.
- Tighten the cable gland and check strain relief.
- Screw the cover tightly to the housing, do not use a tool. The sealing ring must be clean and
undamaged.
- Mount the cover catch.

Instruction Manual
10 SITRANS F with PROFIBUS PA
C79000-B5676-C114-03
Earthconnectionforbuscableshield
Not used
Digital output 1
PROFIBUS PA
Power supply: L/N for AC 120 to 230 V
L+/L-- for UC 24 V
Earth terminal for PE
+-- L
L+
N
L--
34 5678 12
PROFI-
BUS PA
Figure 2--1 Electrical connection
A bus termination must be fitted at both ends of the bus for error-free communication (see Figure 1--2). At
the end nearest the control system this is already ensured by the bus termination contained in the coupler
or link. An additional termination must be fitted at the far end of the bus.
!Warning
Only approved bus terminations, branches, cables etc. may be used in intrinsically
safe circuits.
The specified immunity and radiated emission are only guaranteed if the bus shielding is fully effective.
This includes connecting the shields to the metal connections of the SITRANS F/PA but also laying the
shields to the terminal compartment, distributor, DP/PA coupler or DP/PA link.
A suitable potential equalizer must be provided to avoid potential differences between the individual plant
parts and thus the risk of malfunctioning. Refer to DIN VDE 0100 Part 410 and Part 540 for information on
dimensioning and design.
General information about PROFIBUS installation can be found in the PNO guide /1/.
3 Commissioning
Make sure the device addresses are set before operating two or more field devices on the bus. Every
address may only be assigned once so that there is no confusion. Basically an address range of 1 to 125
is possible; address 126 is set in the as-delivered state. Usually the lower addresses are assigned to the
masters in PROFIBUS systems. Therefore we recommend starting the address for the device at 30. The
addresses are set with the operation and monitoring module in menu item 4.1.1 or acyclically using
PROFIBUS.

Instruction Manual
SITRANS F with PROFIBUS PA
C79000-B5676-C114-03
11
4 Operation, Communication
4.1 PROFIBUS Communication
SITRANS F has a PROFIBUS PA connection corresponding with IEC 1158 (synchronous transmission).
The only possible baud rate is 31.25 kbits/s. The min TSDR (smallest station delay time, chapter 5.4.1,
Seite 32) at startup is 11 bit times and can subsequently be changed using the Set_Prm service. The bus
address has the value 126 as-delivered and can either be changed with the Set_Slave_Add DP service or
on the local keyboard (menu 4.1.1).
Communication uses the EN 50 170 standard (PROFIBUS DP and DP V1). The data transmission and
data formats will be described in the following sections.
The following DP services are supported as slave for a DP master class 1:
DData_Exchange
DRd_Inp
DRd_Outp
DSet_Prm
DChk_Cfg
DSlave_Diag
DSet_Slave_Add
DGlobal_Control
DGet_Cfg
The following DVP1 services are supported as slave for a master class 2:
DMSAC2_Initiate (indication and response)
DMSAC2_Abort (request, indication and response)
DMSAC2_Read (indication and response)
DMSAC2_Write (indication and response)
4.1.1 Cyclic Data Transmission
Cyclic data transmission is used to transmit input and output data between Master class 1 (control system
or PLC) and the slave (SITRANS F).
Up to seven different measured values (= modules) can be transmitted cyclically as input data in a
telegram with the Data_Exchange service. The following measured values are available in the order
specified:
1. Flow (volume or mass flow)
2. Sound velocity
3. Quantity (volume or mass) net
4. Temperature
5. Ultrasonic amplitude
6. Quantity (volume or mass) forward
7. Quantity (volume or mass) reverse
Output data are sent to the device together with the cyclic request telegram. The number and type of the
data actually transmitted can be defined with the configuration data (see GSD, chapter 4.1.1.3, page 15).

Instruction Manual
12 SITRANS F with PROFIBUS PA
C79000-B5676-C114-03
4.1.1.1 Input Data (from device to master)
Input data are user data (measured values) which are transmitted from the device to the master in the
following format:
Every measured value consists of 5 bytes which are composed of a floating point value corresponding with
IEEE -- 754 (4 bytes) and the appropriate measured value status (1 byte). First the measured value and
then the corresponding status is transmitted in the PROFIBUS telegram.
Byte Bit
No. 7 (MSB) 6543210(LSB)
1VZ E
27E 26E 25E 24E 23E 22E 21
2 E
20M 2-- 1 M 2-- 2 M 2-- 3 M 2-- 4 M 2-- 5 M 2-- 6 M 2-- 7
3 M
2-- 8 M 2-- 9 M 2-- 1 0 M 2-- 1 1 M 2-- 1 2 M 2-- 1 3 M 2-- 1 4 M 2-- 1 5
4 M
2-- 1 6 M 2-- 1 7 M 2-- 1 8 M 2-- 1 9 M 2-- 2 0 M 2-- 2 1 M 2-- 2 2 M 2-- 2 3
VZ: sign; 0 = positive, 1 = negative E: Exponent M: Mantissa
Table 4--1 Measured value format
Byte Bit
No. 7 (MSB) 6543210(LSB)
5Quality Substatus Limits
Table 4--2 Status byte format
The status bytes consist of 3 components:
DQuality (the maximum value bits 6 and 7): describes the basic quality of the
corresponding measured value
DSubstatus (bit 2 to 5): differentiates the quality of the
corresponding measured value
DLimits (the minimum bits 0 and 1): signal that limit values have been
exceeded
The components can use the following values with SITRANS F:
Bit Profile description Meaning
7 6
0 0 bad Measured value cannot be used
0 1 uncertain Measured value uncertain
1 0 good (not cascade) Measured value o.k.
Table 4--3 Quality

Instruction Manual
SITRANS F with PROFIBUS PA
C79000-B5676-C114-03
13
Bit (Profile) description Meaning
5432
0001configuration error Parameter error, i.e. upper and lower value for
measuring or output scale are identical
0011device failure RAM or EEPROM defective;
Diagnosis bit “Memory error” is also set and the
diagnosis message “RAM error” or “EEPROM error”
displayed locally.
0100sensor failure Measurement was not possible;
Diagnosis bit “Measurement failure” is also set and
the diagnosis message “Measuring path fault”
displayed locally.
0111out of service Corresponding function block is in “Out of service”
mode (see parameter MODE_BLK actual)
0000non-specific Measurement contains to many implausible
measured values, e.g. due to solids or gas bubbles in
the medium.
Diagnosis bit “Measurement failure” is also set and
the diagnosis message “Measuring path fault”
displayed locally.
0001last usable value Failsafe mode: the current measured value has been
replaced with the last good measured value
0010substitute set Failsafe mode: the current measured value has been
replaced with the agreed failsafe value
0011initial value Failsafe mode or state before the first measurement:
the current measured value has been replaced with
the start value
0100Sensor conversion
not accurate
Measured value is outside the sensor limits
(Table 5--1, Page 30)
0000ok Measured is value o.k. (normal state)
0001Update Event a parameter with the “static” memory attribute has
been changed locally or on the PROFIBUS
0010active advisory alarm Upper warning limit value has been exceeded or the
lower warning limit value has been undershot
0011active critical alarm Upper alarm limit value has been exceeded or the
lower alarm limit value has been undershot
Table 4--4 Substatus
Bit Profile description Meaning
1 0
0 0 ok The measured value is within the limit values (normal mode)
0 1 low limited The measured value has exceeded the upper limit value (alarm,
warning or sensor limit)
1 0 high limited The measured value has exceeded the upper limit value (alarm,
warning or sensor limit)
1 1 constant Measured value remains constant
Table 4--5 Limits
Limit bits can only be clearly evaluated in combination with the quality information.

Instruction Manual
14 SITRANS F with PROFIBUS PA
C79000-B5676-C114-03
The following combinations of the status byte values described above are possible in normal operation
(i.e. when the input value of the respective function block incl. status is not simulated):
Value Meaning Applies to
hex Quality Substatus Limit Flow Sound
velocity
Tem -
pera-
ture
Ultra-
sonic
ampl.
Net
quan-
tity
For-
ward
quan-
tity
re-
verse
quan-
tity
1F Bad out of service constant X X X X
0F Bad device failure constant X X X X
0C Bad device failure ok X X X
13 Bad sensor failure constant X
12 Bad sensor failure high limited X X X X X X
11 Bad sensor failure low limited X X X X X X
10 Bad sensor failure ok X X X X X X
07 Bad configuration error constant X X X X
52 Uncertain sensor conversion
not accurate
high limited X X X X X X X
51 Uncertain sensor conversion
not accurate
low limited X X X X X X X
4F Uncertain initial value constant X X X X
4B Uncertain substitute set constant X X X X
47 Uncertain last usable value constant X X X X
42 Uncertain non-specific high limited X X X X X X
41 Uncertain non-specific low limited X X X X X X
40 Uncertain non-specific ok X X X X X X
8E Good active critical
alarm
high limited X X X X X X X
8D Good active critical
alarm
low limited X X X X X X X
8A Good active advisory
alarm
high limited X X X X X X X
89 Good active advisory
alarm
low limited X X X X X X X
84 Good active update
event
ok X X X X X X X
80 Good ok ok X X X X X X X
Table 4--6 Valid status byte combinations
The status conditions in Table 4--5 have decreasing priority from top to bottom. If several status conditions
are fulfilled, the current status with the highest priority will be signaled.

Instruction Manual
SITRANS F with PROFIBUS PA
C79000-B5676-C114-03
15
4.1.1.2 Output Data (to the Device)
The output data consist of one byte each per resettable totalizer (net, forward and reverse) of which only
the two respective least significant bits are evaluated. All other bits are not evaluated but should be set to
0. This value represents the SET_TOT parameter of the totalizer function block defined in the PROFIBUS
PA profile.
Bit Profile description Meaning
1 0
0 0 cancel Totalizer is running
0 1 reset Totalizer is stopped and reset to 0
1 0 preset Totalizer is stopped and reset to a preset value (PRESET_TOT
parameter, only acyclic access)
Table 4--7 Totalizer mode SET_TOT
The transferred value is effective until it is changed, i.e. after the value 1 (reset totalizer) is sent, for
example, the totalizer will remain on the value 0 until the SET_TOT parameter is changed again.
Each SET_TOT value affects the corresponding totalizer independently of the others. The quantities are
also cumulated independently of each other, i.e. the net quantity does not have to be equal to the sum of
the quantity forwards and quantity reverse especially if a totalizer has been reset or was preset.
4.1.1.3 Device Data Base File (GSD File)
The device data base file (GSD file) is used to configure the format and order of the cyclical data. The
standard GSD for ultrasonic flow transducers described in profile 3.0 and which does not support
manufacturer-specific expansions can be used alternatively to the device-specific GSD (“siem8091.gsd”,
see appendix 9). The “IDENT_NUMBER_SELECTOR acyclic parameter must be set to select the GSD
(0 = profile GSD, 1 = manufacturer-specific GSD = factory setting).
All permitted identifiers are listed in the GSD for each measured value (= module). They can be combined
freely with the limitation that only one identifier can be used per module and the order of the identifiers
must coincide with the order of the modules.
The identifier formats “short” (identifier byte) and “long” (extended identifier) are accepted for the flow,
sound velocity, temperature and ultrasonic amplitude. The “long” and “resettable quantity ... long” are
accepted for the totalizer modules. The identifiers are checked independently of each other, i.e.
combinations with different formats are permitted when several measured values are queried. At least one
measured value must be queried, i.e. the number of the identifier must be at least 1 and may be
maximum 7.
The order of the measured values in the cyclical telegram defined in the GSD is set and cannot be
changed (see also chapter 4.1.1, page 11).
For the configuration data this means that the first identifier always represents the flow, the second the
sound velocity, ... , the last the quantity reverse. If you want to omit a measured value, set “Free Place” as
the identifier.

Instruction Manual
16 SITRANS F with PROFIBUS PA
C79000-B5676-C114-03
Example:
The measured values sound velocity, temperature and ultrasonic amplitude are to be transmitted. The
following identifier combination should set:
1. Free Place (for flow)
2. short Identifier or long Identifier (for sound velocity)
3. Free Place (for net quantity)
4. short Identifier or long Identifier (for temperature)
5. short Identifier or long Identifier (for ultrasonic amplitude)
An identifier is not required for the forward quantity and reverse quantity as the ultrasonic amplitude is the
lastvaluetobetransmitted.
Output data can only be transmitted and therefore the totalizer reset if the corresponding “extended
Identifier” (long) is used. The first byte of the output data always refers to the first resettable totalizer.
If, for example, the “Resettable quantity forw. (long)” and “Resettable quantity rev. (long)” identifiers for the
forward and reverse quantity are set but the “Resettable quantity net (long)” identifier is not set for the net
quantity, i.e. the net quantity totalizer is the only one which cannot be reset, the first byte of the output data
will refer to the totalizer for the quantity forward.
4.1.2 Acyclic Data Transmission
The acyclic data transmission is mainly used for remote control of devices, i.e. for transmitting parameters
during commissioning, maintenance, batch processes or for displaying further variables which do not take
part in the acyclic input and output data transmission.
Acyclic accesses can be carried out by Master class 1 (C1 connection) or Master class 2 (C2 connection).
Sitrans F supports up to 4 simultaneous C2 connections.
The approximately 400 parameters including address (slot and index), format, range of values, start value
and attributes are compiled in an object list “Obj8091.rtf” which is available on request.
We recommend using the SIMATIC PDM software package and a PC (compatible with industry standard)
or a programming unit with the following minimum specifications should preferably be used for acyclic
operation:
Hardware:
D80486 processor or higher
DAt least 32 MB RAM
DHard drive with at least 70 MB free space
DMonitor: VGA standard or MS Windows compatible
DKeyboard and mouse (optional)
DCD-ROM drive
DCP5411 A2, CP5511 or CP5611 interface
Software:
DWindows 95 or Windows NT
DSIMATIC PDM V5.01 or higher (SIMATIC STEP 7 OEM included)
Integrated Help functions support use of SIMATIC PDM.

Instruction Manual
SITRANS F with PROFIBUS PA
C79000-B5676-C114-03
17
4.1.3 Diagnosis
The diagnostic data can be requested with the Slave_Diag service. If extended diagnostic messages exist,
this is displayed with the Diag_Flag of the Data_Exchange service. If the master then calls the Slave_Diag
service, the user diagnostic data are supplied in the following form:
Byte
No.
Profile description Value Meaning
1Header 8 (dec.) (Fixed) length of the diagnostic data
(number of bytes)
2254 (dec.) (Fixed)
3 1 (Fixed)
40or1 Displays changes in diagnostic data
(see below)
5Byte 1 (see
below)
Diagnostic information
6DIAGNOSIS Byte 2 -- -- -- (not supported)
7
D
I
A
G
N
O
S
I
S
Byte 3 -- -- -- (Reserved)
8Byte 4 (see
below)
More diagnosis data is available
Table 4--8 Format of complete diagnostic data
The total length of the external diagnostic data is always 8 bytes including the header.
The Diag_Flag is always set when the last 4 bytes of the diagnostic data (corresponds with the
DIAGNOSIS parameter) have changed since the last message therefore also, for example, when the
diagnostic messages disappear again so that the master register each change in the diagnostic data.
If a diagnostic message is active, the corresponding bit is set or reset.
The following bits in the external diagnostic data are supported by SITRANS F all other bits always remain
reset:
Bit no. Description Meaning
0Error appears At least one bit in the subsequent 4 bytes (DIAGNOSIS) has
been set
1Error disappears At least one bit in the subsequent 4 bytes (DIAGNOSIS) has
been set
2 ... 7 reserved -- -- --
Table 4--9 Format of byte 4 diagnostic data
The “Error appears” message has priority over the “Error disappears”, i.e. if a diagnostic bit is set and
another reset at the same time, “Error appears” will be displayed.

Instruction Manual
18 SITRANS F with PROFIBUS PA
C79000-B5676-C114-03
The DIAGNOSIS part contains device diagnostic messages and has the following structure
(bit 0 = LSB, bit 7 = MSB):
Bit no. Description Meaning Causes (= local message)
0DIA_HW_ELECTR Hardware failure of the
electronic
“Temperature measurement
error”
“SSC error”
Error in communication with
internal peripherals
“Communications module not
addressable”
“Measuring module not
addressable”
4DIA_MEM_CHKSUM Memory error “EEPROM error”
“RAM error”
5DIA_MEASUREMENT Measurement failure “Unreliable flow value”
“Measuring path error” (affects
flow, sound velocity and
ultrasonic amplitude)
This diagnostic message
also appears when the
measuring tube is empty!
Flow outside sensor limits
(not a local message)
Table 4--10 Format of byte 5 diagnostic data (= DIAGNOSIS Byte 1)
Byte 8 (= DIAGNOSIS byte 4):
Bit no. Description Meaning Causes
0 ... 6 reserved -- -- --
7EXTENSION_AVAILABLE More diagnosis information is
available
More diagnosis information is
available
(here: see DIAGNOSIS byte 1
for local messages)
Table 4--11 Format of byte 8 diagnostic data (= DIAGNOSIS Byte 4)
The bits in DIAGNOSIS take over the function of a collective message in most cases which can then be
broken down in more detail using the local messages.
The EXTENSION_AVAILABLE bit indicates that there is further diagnostic information, essentially details
on the DIAGNOSIS message. This information is displayed locally. The messages related to measured
values are also transmitted with the measured values in the status byte (substatus).

Instruction Manual
SITRANS F with PROFIBUS PA
C79000-B5676-C114-03
19
Examples of telegrams with diagnostic data (Ext_Diag_Data):
Output state: all diagnostic bits are reset. When the “Temperature measurement error” (byte 5, bit 0 set)
and “Unreliable flow value” (byte 5, bit 5 set) events occur, the following diagnostic data will result:
Diagnostic byte no. 1 2 3 4 5 6 7 8
Value (hex) 08 FE 01 01 21 00 00 80
Meaning
seeTable4--8
Header DIAGNOSIS
Output state: all diagnostic bits are reset. When the “EEPROM error” (byte 5, bit 4 set) and “Flow outside
sensor limits” (byte 5, bit 5 set) events occur, the following diagnostic data will result:
Diagnostic byte no. 1 2 3 4 5 6 7 8
Value (hex) 08 FE 01 01 30 00 00 80
Meaning
seeTable4--8
Header see above DIAGNOSIS
Output state: at least one diagnostic bit is set. As soon as all diagnostic messages are removed the
following diagnostic data result:
Diagnostic byte no. 1 2 3 4 5 6 7 8
Value (hex) 08 FE 01 02 00 00 00 00
Meaning
seeTable4--8
Header see above DIAGNOSIS

Instruction Manual
20 SITRANS F with PROFIBUS PA
C79000-B5676-C114-03
4.2 Local Operation and Display
The menu structure for local operation is mostly repeated in the SIMATIC PDM PC user interface. It is
based on the block structure which is a mandatory setting from the PROFIBUS PA profile. Substantial
differences from the menu structure of the device with HART communication therefore cannot be avoided.
The complete menu structure is therefore given in the following table:
Menu
code
Device function,
parameter
Description Factory setting
() = display only
Options for settings
1. Display
1.1 Multi-Display Display of two measured
values simultaneously
(actual measured
value line 1)
(actual measured
value line 2)
Menu 1.9.2
Menu 1.9.3
1.2 Flow Flow value (actual meas. value)
1.3 Totalizer Flow from the start of
measurement (volume of
mass, dependent on
menu 3.1.1)
(
actual count
)
1.3.1 Total. forw. Forward flow only
(
a
c
t
u
a
l
c
o
u
n
t
)
1.3.2 Total. rev. Reverse flow only
1.3.3 Total. net Difference of forward and
reverse flows
1.3.4 Set (all) Set totalizer to zero or start
(volume totalizer and sum of
errors)
Start Start
Stop+Reset
1.4 Sound velocity Velocity of sound in measured
substance
(actual meas. value)
1.5 Temperature Temperature of measuring
tube
(actual meas. value)
1.6 US Amplitude Relative ultrasonic amplitude
of the received ultrasonic
signals (reference: water)
(actual meas. value)
1.7 Flow velocity Flow velocity in measuring
tube
(actual meas. value)
1.8 Frequency Calculated frequency value
for flow
(actual meas. value)
1.9 Parameters Set parameter for local
display
1.9.1 Language Operating language english english, deutsch, français,
italiano, español, nederlands
1.9.2 Line 1 Determination of the
measured value to be
displayed for the multi-display
Flow Flow, Total. net, Temperature,
Flow Velocity, Sound
Velocity, US Amplitude,
Frequency
1.9.3 Line 2 Determination of the
measured value to be
displayed for the multi-display
Total. net. Flow, Total. net, Temperature,
Flow Velocity, Sound
Velocity, US Amplitude,
Frequency
1.9.4 Display Flow Select the display of the flow
value
Display in %: related to output
scale (full scale minus start
value, menu 3.1.8)
Physical Unit Physical. Unit, %,
Bar Diagram in %
