MagCore Plus II User manual

MagCore® Plus II
Troubleshooting guide
Ver. 2020.1230
www.rbcbioscience.com

RBC Bioscience Corp.
TEL : [phone]
FAX : [phone]
3F., No.132, Ln. 235, Baoqiao Rd., Xindian Dist.,
New Taipei City 23145, TAIWAN.
http : //www.rbcbioscience.com

1
MagCore® Plus II
Warning:
Always check packaging when receiving a new unit!
Let us know immediately if indicators are not in the initial condition (showing
that machine was tilted during transportation).
Perform the following and send us the result:
1. Take a picture of indicators.
2. Keep the machine switched off. Push X-axis inside and close the door.
3. Turn the machine on. It will run automatic initialization, let it run and when
machine stops making noise and nothing moves inside, go to Maintenance
and run piston test.
Notice:
If the problem you are experiencing is not covered by this guide, let us know:
fill in the Instrument malfunction form and send it to us along with the
instrument's serial number!
To see RBC training videos click or copy in your browser the link below:
MagCore Plus II Training Files
(https://drive.google.com/drive/folders/1ORi-jZ3MWz0-2S4b4-8wEud7sLbADD0-)

2www.rbcbioscience.com
CONTENTS
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Specification. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
━ Operating Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
━ Operating Environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
━ Applications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
PCB Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
PLC Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Unpacking Plus ll . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
━ Removing Packaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
━ Activating All the Menu Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
━ X-Axis Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
━ Y-Axis calibration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Pistons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
━ Noise during Pipetting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
━ Cleaning Pistons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
━ V-Axis Immobilization. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Detaching Housing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
━ Tools List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
━ Procedure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Non-Responsive HMI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
━ Replacing HMI Frame. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
━ Replacing Touch Panel Screen Pad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
━ Calibrating HMI Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
━ Adjusting HMI Screen Position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
━ Replacing Touch Panel Sliding Component. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
━ Door Touching the Cartridge Rack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
━ Door Movement Issue . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
━ Door Switch Malfunction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Axis Misplacement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Axis Directions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
━ Y-Axis Manual Adjustment (Complicated Procedure!) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
X-Axis. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
━ X-Home Sensor Failure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Checking encoder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
Checking Signal Propagation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
41

3
MagCore® Plus II
Bending Cartridges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
━ Cartridge Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
━ Lifted Cartridges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
━ Cartridges alignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
━ M-axis Tolerance Misalignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Rails (X-Axis Inspection) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
━ Noise during the Rack Movement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
━ Rusting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
━ Rack Immobilization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Motors: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
━ Motor Test. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Directions to Run the Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52
Directions to Stop the Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
52
━ Jog Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Sensors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53
Encoders. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
Cleaning Encoder Disc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
54
RD Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
━ Activating RD Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
━ I/O . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
━ Heating Test. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Software Update . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
━ PLC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
━ HMI. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
━ Program. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Error Alarm Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .71
Common Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .76

4www.rbcbioscience.com
Handle the power cord carefully.
Hold the plug when unplugging the cord.
Keep the set free from moisture,
liquid, and dust.
Unplug the power cord if the system
will not be used again in a long time.
Do not obstruct the ventilation space.
Do not let foreign objects in the set.
Do not let insecticides, benzene, and
thinner come in contact with the set.
Do not ever disassemble or modify
the set in any way.
Avoid high temperatures.
Leave space for sufficient heat dissipation during installation.
CAUTIONS
Risk Of Electric Shock
Do Not Open
Safety Precautions
Before Use
WARNINGS and CAUTIONS stated below are intended to protect the individual from injuries
and avoid damage to machines.
CAUTION:
To reduce the risk of electric shock, do not remove the cover. Refer to qualified
service technician for inner part servicing.
CAUTION:
1. Handle The Power Supply Cord Carefully
Do not damage or twist the power supply cord. Damaged or twisted cord may
cause electric shock or error when used. When you remove it from the outlet, be
sure to remove by holding the plug and not by pulling the cord.
2. Do Not Place Anything Inside
Do not place metal objects inside the MagCore®System and wipe away all spilled
liquid to minimize the risk of system error and electric shock.
NOTE ON USE:
1. Read Instructions – All the safety and operating instructions should be read before
operating the instrument.
2. Keep the Instructions – Keep the safety and operating instruction manual for future
reference.
3. Cautions and Warnings – All warning signs should be attached on the product and
shown in the user's manual.
4. Follow Instructions – All operating and use instructions should be followed.
5. Cleaning – Unplug the product before cleaning. Use only 75% of EtOH to clean the
surface of instrument.
6. Attachments – Do not attach anything on the instrument.
7. Liquid and Moisture – Do not use this product near water and avoid moist areas -
bath tub, wash bowl, kitchen sink, laundry, swimming pool or in a moist basement.
8. Proper Installation – Do not place this product on an unstable cart, stand, tripod,
bracket, or table. The product may fall and caues serious injury to a child or adult, and
serious damage to the product. Use only with a cart, stand, tripod, bracket, or table
recommended by the manufacturer, or sold with the product. Any mounting of the
product should follow the manufacturer's instructions, and should use a mounting
tool recommended by the manufacturer.
9. Ventilation – Slots and openings in the cabinet are designed for ventilation, which
is required for safe operation and minimizing the chance of overheating. The product
should be placed on a hard surface to ensure proper ventilation. This product should
not be placed in a built-in installation such as a bookcase or rack unless proper
ventilation is ensured or instructed by the manufacturer.
10. Power Sources – This product should be operated only from the type of power
source indicated on the label. If you are not sure of the type of power supply at your
lab, consult the seller or local power company. For products intended to operate from
battery or other sources, refer to the operating instructions.
11. Grounding or Polarization – This product may be equipped with a polarized
alternating-current plug. This plug will fit into the power outlet in one way only. This is
a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the
plug. If the plug should still fail to fit, contact your electrician to replace your obsolete
outlet. Do not defeat the safety purpose of the polarized plug.
12. Power-Cord Protection – Power-supply cords should be routed so that they are
not likely to be walked on or pinched by items placed near or against them. Pay extra
attention to the plugs, convenience receptacles, and the connecting point where the
cord extends out of the product.
13. Lightning – Unplug the product if it will not be used again for a long period or in the
case of a heavy storm. This will prevent damage to the product due to lightning and
power surges.
14. Overloading – Do not overload wall outlets, extension cords, or integral convenience
receptacles as this can result in a risk of fire or electric shock.
15. Object and Liquid Entry – Never push objects of any kind into this product as they
may touch dangerous voltage points or short-out parts that could result in a fire or
electric shock. Never spill liquid of any kind on the product.
16. Servicing – Do not attempt to repair this product by yourself. Refer all servicing to
qualified service technician.
17. Damage Requiring Service – Unplug this product from the wall outlet and refer
servicing to qualified service technician under the following conditions:
a) When the power-supply cord or plug is damaged,
b) If liquid has been spilled, or objects have fallen into the product,
c) If the product has been exposed to rain or water,
d) If the product does not operate normally following the operating instructions.
Adjust only controls covered by the operating instructions as an improper adjustment
of other controls may result in damage and will often require extensive work by a
qualified technician to restore the product to its normal operation,
e) If the product has been dropped or damaged in any way, and
f)When the product exhibits a distinct change in performance
– this indicates a need for service.
18. Replacement Parts – When replacement is required, be sure the service technician
uses replacement parts specified by the manufacturer or those with similar features
as the original part. Unauthorized substitutes may result in fire, electric shock, or other
hazards.
19. Safety Check – Upon completion of any shipment, storage, installation or
maintenance service to this product, ask the service technician perform safety checks
to confirm that the products is in proper operating condition.
20. Heat – The product should be placed away from heat sources such as radiators, heat
registers, stoves, or other products that produce heat.
21. Moving Product - The machine requires two people lifting from both sides at the
bottom edge. Do not attempt to lift by bending forward. Bend your hips and knees to
squat down, keep the machine close to your body, and straighten your legs to lift.
General Warning. Follow the instruction for operation, be
aware of electrical hazard caused by inappropriate operation.
1. Power Supply
2. Barcode Scanner
Warning: Biological Hazard
Warning: High Temperature
Read the instruction carefully and keep for future reference.
This product is confirmed with European Union conformity
assessment regulations regarding health and safety or
environmental protection.
Waning: Electricity
SAFETY INSTRUCTIONS

5
MagCore® Plus II
Model Plus II
System Method Cellulose Coated Magnetic Beads
System Components 1. Pipetting Unit: Dispensing, transferring, X -Y two axis movements.
2. Electric Control: PLC module and Arm-based main board embedded in.
3. UV Light: Power 8W, life duration 11,000 hrs .
4. Heating Block: RT-90° C .
5. Display Screen: 7 inches colored touch panel .
6. Accessories: T - Rack, Cartridge Rack s, barcode scanner
Power Supply Voltage: AC 100V~240V; Frequency: 50/60Hz ; Max. 4.5AMax, 450W
Dimension W523 x D602 x H605 (mm) / W20.59x D23.7 x H23.81 (inches)
Net Weight 70kg / 154.35lbs
Specification
━ Operating Parameters
━ Operating Environment
━ Applications
Applications: Whole Blood DNA (200μl/400μl/1,200μl), Viral Nucleic Acid (DNA/RNA 200μl/400μl/1,200μl), FFPE Genomic DNA,
FFPE Total RNA, Forensic DNA, Plasma and Circulating Cell-Free DNA (1,200μl/4,000μl), Tissue Genomic DNA, Plant Genomic
DNA, Bacterial DNA, Whole Blood Total RNA, Cultured Cells Total RNA, Tissue Total RNA, Plant Total RNA.
Processing Capacity 1-16 samples per batch
Processing Time 30-90 minutes (depends on sample type and method)
Sample Volume 200 μl /400 μl /1,200 μl / 4ml
Elution Volume 30μl /40μl /60μl /100μl /150μl /200 μl
Yield Average 6μg Genomic DNA from
200μl human whole blood
Purity DNA : O.D A260/280 ratio 1.8 ± 0.1
RNA : O.D A260/280 ratio 2.0 ± 0.2
Pipetting Accuracy 500μl ≤ 4%
Humidity Allowed During Operation: 30%-75%
Pressure Allowed During Operation: 700hPa-1060hPa
Temperatures Allowed During Transportation / Storage Packaging 10°C- 40°C
Temperatures Allowed During Operation 15°C-35°C
Pollution Degree Level 2

6www.rbcbioscience.com
PCB Configuration

7
MagCore® Plus II
PLC Configuration
I/O IN I/O OUT
X0 Y Motor Encoder Signal(A) Y0 Y Motor Drive(A)
X1 Y Motor Encoder Signal(B) Yl Y Motor Drive(B)
X2 Y Home Sensor Signal Y2 V Motor Drive(A)
X3 Y3 V Motor Drive(B)
X4 V Motor Encoder Signal A Y4 X Motor Drive(A)
X5 V Motor Encoder Signal B Y5 X Motor Drive(B)
X6 V Home Sensor Signal Y6
X7 UP Sensor Signal Y7
X8 Y8
X9 Y9
X10 X Motor Encoder Signal(A) Y10 M DC Motor JOG
X11 X Motor Encoder Signal(B) Y11 UV Lamp Switch-Relay
X12 X Home Sensor Signal Y12 RS232 Switch
X13 Down Sensor Signal
X14
X15
X16
X17 Door Sensor

8www.rbcbioscience.com
Accessories
1. T-Rack X 1
2. Cartridge Rack X 1
3. Power Cable X 2 (Europe standard and U.S.A standard)
4. Grease X 1
5. 3mm O-Rings X 16
6. 5mm O-Rings X 16
7. Empty Cartridge X 10
8. Sample Tube /Elution Tube X 20
9. PipetteTip X 20
10. Waste Box X 1
11. Barcode Scanner X 1
1234 5
7
6
8 9
10 11

9
MagCore® Plus II
Unpacking Plus ll
━ Removing Packaging
Remove all the screws on the button of the wooden case (a total of 14 screws). Then
take off the cover.
Open the Front Door
For Restricted Personnel Use
Installation
AB
C D
Accessory Box
Cushioning Material
Remove cushioning material
and take out accessory box.
Remove the brackets and cable ties then
pull out the touch panel.
Remove the two brackets
191106
1
1Close the front door. 1
Switch onthe power, the machine will initialize automatically.
2
Move the rack module outward manually,
then cut off and remove the two cable ties
2
2
Accessory Box
Romove cushioning material
Take out accessory box
Pull out the touch panel and tighten screw
after touch panel is erected.
3

10 www.rbcbioscience.com
Open the Front Door
For Restricted Personnel Use
Installation
AB C
D
Accessory Box
Cushioning Material
Remove cushioning material
and take out accessory box.
Remove the brackets and cable ties then
pull out the touch panel.
Remove the two brackets
191106
11
Close the front door.
1
Switch onthe power, the machine will initialize automatically.
2
Move the rack module outward manually,
then cut off and remove the two cable ties
2
2
Accessory Box
Romove cushioning material
Take out accessory box
Pull out the touch panel and tighten screw
after touch panel is erected.
3
Open the Front Door
For Restricted Personnel Use
Installation
AB
C
D
Accessory Box
Cushioning Material
Remove cushioning material
and take out accessory box.
Remove the brackets and cable ties then
pull out the touch panel.
Remove the two brackets
191106
1
1
Close the front door.
1
Switch onthe power, the machine will initialize automatically.
2
Move the rack module outward manually,
then cut off and remove the two cable ties
2
2
Accessory Box
Romove cushioning material
Take out accessory box
Pull out the touch panel and tighten screw
after touch panel is erected.
3

11
MagCore® Plus II
━ Activating All the Menu Buttons
Calibration
If some buttons of the Maintenance menu remain inactive after installation, switch off
the machine, close the door, turn the machine on and let it run automatic initialization.
After it stops making noise check if those buttons are activated.
This issue happens when PLC is new and it does not have the initial position values
written in. When machine initializes the values are being written into PLC. You will have
to do this once and they will stay in the memory.
Tap "Maintenance" → next page → "Advanced" (Password-1688).
Go to page "Teach position" and follow the steps below to calibrate.
Select
Replace O-RingSterilization
PistonEject Tip
Back
07/13/2020 09:25:32
Motor Test
Clean Needles
Advanced
Back
7 8 9
000
4 5 6
1 2 3
password
3OHDVHHQWHU\RXUSDVVZRUG
WRHQWHUWKHDGYDQFHGIXQFWLRQ
07/13/2020 09:25:32
Clear Enter
Administrator
Back
Load Speed Default
Motor JOG Test
IO Check
Resetting
RD Use
07/13/2020 09:25:32
Teach Position

12 www.rbcbioscience.com
Maintenance-Teaching Position
Back
7 8 9
000
4 5 6
1 2 3
07/13/2020 09:25:32
Clear Enter
0 0
0 0
0 0
TIP4 Position
X Axis Motor Y Axis Motor
Encode
Input Pulse Input Pulse
Upload
Encoder Value
Download
Encoder Value
TIP3 Position
Encode
━ X-Axis Calibration
1. Put the Tips (200 μ l) at the W4 in the positions 1 and 16 on the T-rack.
2. Run W4 piston test and observe the distance between real position and correct
position.
3. X position:
1 mm = 92 Pulse;
Direction: Inward (X axis moves inward, pistons will be outward) → minus;
Outward → plus.
For example: if you want to make the X axis position (T-rack) 1 mm inward, the original
value is 10000, 10000 – 92 = 9908, enter 9908.
Adjust the Input Pulse → tap "Enter" → tap "Upload Encoder Value" → tap "Execute",
repeat until the position is correct.
;$[LV3RVLWLRQ8SGDWH
ExecuteCancel
07/13/2020 09:25:32
Maintenance-Position Update

13
MagCore® Plus II
Maintenance-Teaching Position
Back
7 8 9
000
4 5 6
1 2 3
07/13/2020 09:25:32
Clear Enter
0 0
0 0
0 0
TIP4 Position
X Axis Motor Y Axis Motor
Encode
Input Pulse Input Pulse
Upload
Encoder Value
Download
Encoder Value
TIP3 Position
Encode
Maintenance-Teaching Position
Back
7 8 9
000
4 5 6
1 2 3
07/13/2020 09:25:32
Clear Enter
0 0
0 0
0 0
TIP4 Position
X Axis Motor Y Axis Motor
Encode
Input Pulse Input Pulse
Upload
Encoder Value
Download
Encoder Value
TIP3 Position
Encode
Maintenance-Teaching Position
Back
7 8 9
000
4 5 6
1 2 3
07/13/2020 09:25:32
Clea
rE
nter
31053 12399 12399
10966 10966
11695 11695
12540 12540
31053
PERFORATE
V Axis Motor
Encode
Upload
Encoder Value
Upload
V_200 Position
Load
Define
10ul POS
100ul POS
55ul POS
45ul POS
Input Pulse
Maintenance-Teaching Position
Back
7 8 9
000
4 5 6
1 2 3
07/13/2020 09:25:32
Clea
rE
nter
31053 12399 12399
10966 10966
11695 11695
12540 12540
31053
PERFORATE
V Axis Motor
Encode
Upload
Encoder Value
Upload
V_200 Position
Load
Define
10ul POS
100ul POS
55ul POS
45ul POS
Input Pulse
Maintenance-Teaching Position
Back
7 8 9
000
4 5 6
1 2 3
07/13/2020 09:25:32
Clea
rE
nter
31053 12399 12399
10966 10966
11695 11695
12540 12540
31053
PERFORATE
V Axis Motor
Encode
Upload
Encoder Value
Upload
V_200 Position
Load
Define
10ul POS
100ul POS
55ul POS
45ul POS
Input Pulse
━ Y-Axis calibration
1. Put the Pipette Tips (1200 μ l) at the W3 at in the positions 1 and 16 on the T-rack.
2. Do W3 piston test and observe the distance between real position and correct
position.
3. Y position,
1 mm = 672 Pulse,
Direction: Upward → minus
Downward → plus
For example: if you want to make the Y position 0.5 mm downward, the original
value is 30000, 30000 + (672 x 0.5) = 30336, enter 30336.
Adjust the Input Pulse → tap "Enter" → tap "Upload Encoder Value" → tap "Execute,
repeat until the position is correct.
V-axis values are preset; they have to be rewritten to PLC only if a PLC unit was
replaced.
To see V value, press an arrow down in Teach position, you will see the screen for V-axis
motor. "Load default values" (1) and press "Execute", then "Upload V_200 Position" (2)
and press "Execute" and then "Upload Encoder Value" (3) and press "Execute":
1
2
3
<$[LV3RVLWLRQ8SGDWH
ExecuteCancel
07/13/2020 09:25:32
Maintenance-Position Update

14 www.rbcbioscience.com
Pistons
━ Noise during Pipetting
━ Cleaning Pistons
If you hear noise during pipetting, this means the grease on the pistons wore off.
Lubricate the rods inside the pistons.
If lubricating the piston does not help, replace the piston (you can send us pistons for
maintenance or install new ones).
1. Take out cartridge rack, move V axis to the lowest position manually or by JOG
mode.
2. Unscrew the screws on the metal sheet, and then detach the metal sheet.

15
MagCore® Plus II
3. There is a hole on the metal rod, fix the metal rod with a hex key, then unscrew the
upper screw.
4. Move the V axis to highest position manually or by JOG mode.

16 www.rbcbioscience.com
5. Take the piston out, you can pull out the metal rod and clean the inner side with a
cotton swab, but do not screw the cap and nut, and do not disassemble the piston,
or the tensile strength might be altered and lose accuracy.
6. Follow the reversed steps to install pistons, push the metal sheet inward gently and
fasten the screws, then do all axis initialization after the installation is finished.
Cap
Nut

17
MagCore® Plus II
If instrument is showing Error14 (V Position Over Pulse) and it is impossible to run jog
test for V-axis or move it manually, this indicates that the X-rings inside the pistons
have worn off.
Do not try to exchange X-rings – opening the piston will change its tensile strength
and pipetting will lose accuracy.
Replace the piston (you can send pistons for maintenance or install new ones).
━ V-Axis Immobilization

18 www.rbcbioscience.com
Detaching Housing
━ Tools List
━ Procedure
1. Hex wrench, 3 mm and 4 mm 2. Philips screwdriver
1. Turn off the power and unplug the power cable.
2. Unscrew the 8 screws marked with red circles, loosen the 2 screws marked with
green circles (no need to take out the 2 screws), then disassemble the back cover.
