Edge-Core ECS4100-26TX User manual

– 1 –
Quick Start Guide
1. Unpack the Switch and Check Contents
ECS4100-26TX
ECS4100-26TX-ME
ECS4100-28T
ECS4100-52T
Rack Mounting Kit—two brackets and eight screws
Four adhesive foot pads
Power Cord—either Japan, US, Continental Europe
or UK
Console Cable—RJ-45 to DB-9
Documentation—Quick Start Guide (this document)
and Safety and Regulatory Information
Note: The ECS4100 series switches are for indoor use only.
Note: For Safety and Regulatory information, refer to the
Safety and Regulatory Information document included with
the switch.
Note: Other documentation, including the Installation
Guide, Web Management Guide, and CLI Reference Guide,
can be obtained from www.edge-core.com.
2. Mount the Switch
Attach the brackets to the switch.
Use the screws and cage nuts supplied with the rack to
secure the switch in the rack.
2
1
1
2
Caution: Installing the switch in a rack requires two
people. One person should position the switch in the rack,
while the other secures it using the rack screws.
Note: The switch can also be installed on a desktop or shelf
using the included adhesive rubber foot pads.
3. Ground the Switch
Ensure the rack on which the switch is to be mounted is
properly grounded and in compliance with ETSI ETS 300 253.
Verify that there is a good electrical connection to the
grounding point on the rack (no paint or isolating surface
treatment).
Attach a lug (not provided) to a #12 AWG (PoE switch) or #18
AWG (non-PoE switch) minimum grounding wire (not
provided), and connect it to the grounding point on the
switch using 3.5 mm screw with washer. Then connect the
other end of the wire to rack ground.
Caution : The earth connection must not be removed
unless all supply connections have been disconnected.
Caution: The device must be installed in a restricted-access
location. It should have a separate protective earthing
terminal on the chassis that must be permanently
connected to earth to adequately ground the chassis and
protect the operator from electrical hazards.
4. Connect Power
a. Connect AC Power
Plug the AC power cord into the socket on the rear of the
switch.
Connect the other end of the power cord to an AC power
source. Verify that the external AC power requirements for
the switch can be met as listed below:
ECS4100-26TX: AC 100-240 V, 50/60 Hz, 1 A
ECS4100-28T: AC 100-240 V, 50/60 Hz, 1 A
ECS4100-52T: AC 100-240 V, 50/60 Hz,1 A
Note: For International use, you may need to change the AC
line cord. You must use a line cord set that has been
approved for the socket type in your country.
1
2
1
2
1
1
2
E012017-AP-R02
150200001586A www.edge-core.com
26-Port L2+ 10G Ethernet Switch (ECS4100-26TX/ECS4100-26TX-ME)
52-Port L2+ Gigabit Ethernet Switch (ECS4100-52T)
28-Port L2+ Gigabit Ethernet Switch (ECS4100-28T)

Quick Start Guide
– 2 –
b. Connect DC power to ECS4100-26TX-ME
Note: Before wiring the DC plug or connecting power to the
switch, ensure that power to the feed lines is turned off at
the supply circuit breaker or disconnected from the power
bus.
The ECS4100-26TX-ME switch supports the option of
connecting an external 36 to 60 VDC power source to its DC
terminal block.
Connect the 36 VDC power feed wire to the DC plug “+” pin.
Connect the ground/return wire to the DC plug “-” pin.
5. Verify Switch Operation
Verify basic switch operation by checking the system LEDs.
When operating normally, the Power and Diag LEDs should
be on green.
6. Perform Initial Configuration
Connect a PC to the switch console port using the included
console cable.
Configure the PC’s serial port: 115200 bps, 8 characters, no
parity, one stop bit, 8 data bits, and no flow control.
Log in to the CLI using default settings: Username “admin”
and password “admin.”
Note: For further information on switch configuration, refer
to the Web Management Guide and CLI Reference Guide.
2
1
3
1
2
3
1
3
12
1
2
3
7. Connect Network Cables
For RJ-45 ports, connect 100-ohm Category 5, 5e or better
twisted-pair cable.
For the SFP/SFP+ slots, first install SFP/SFP+ transceivers and
then connect fiber optic cabling to the transceiver ports. The
following transceivers are supported:
◆1000BASE-SX (ET4201-SX)
◆1000BASE-LX (ET4201-LX)
◆1000BASE-ZX (ET4201-ZX)
◆1000BASE-LHX (ET4201-LHX)
◆10GBASE-SR (ET5402-SR)
◆10GBASE-LR (ET5402-LR)
◆10GBASE-ER (ET5402-ER)
As connections are made, check the port status LEDs to be
sure the links are valid. Press the Mode button to change
from Ethernet to PoE status:
◆On/Blinking Green — Port has a valid link. Blinking
indicates network activity.
◆On Amber — Port is supplying PoE power.
2
1
1
2
3

Quick Start Guide
– 3 –
Hardware Specifications
Switch Chassis
Size (W x D x H) ECS4100-26TX/ECS4100-26TX-ME/
ECS4100-28T/ECS4100-52T: 44 x 22 x 4.4 cm
(17.32 x 8.66 x 1.73 in. )
Weight ECS4100-26TX: 2.2 kg (4.85 lb)
ECS4100-26TX-ME: 2.36 kg (5.20 lb)
ECS4100-28T: 2.2 kg (4.85 lb)
ECS4100-52T: 2.5 kg (5.5 lb)
Temperature Operating: 0 ° C to 50 ° C (32 ° F to 122 ° F)
Operating: 0 ° C to 45 ° C (32 ° F to 113 ° F,
ECS4100-52T only)
Storage: -40 ° C to 70 ° C (-40 ° F to 158 ° F)
Humidity Operating: 10% to 90% (non-condensing)
Power Specification
AC Input Power ECS4100-26TX: AC 100-240 V, 50/60 Hz, 1 A
ECS4100-28T: AC 100-240 V, 50/60 Hz, 1 A
ECS4100-52T: AC 100-240 V, 50/60 Hz, 1 A
AC-DC Power
Adapter
(ECS4100-26TX-
ME)
Input: AC 100-240 V, 50/60 Hz, 1 A
Output: 36-60 VDC, 2 A
Total Power
Consumption
ECS4100-26TX: 20 W
ECS4100-26TX-ME: 20 W
ECS4100-28T: 20 W
ECS4100-52T: 40 W
Regulatory Compliances
Emissions CE Mark
◆EN 55022, Class A
FCC Class A
BSMI Certificate
Immunity IEC 61000-3-3, 61000-4-2/3/4/5/6/11
Safety UL/CUL(UL60950-1, CSA60950-1)
UL 60950-1, 2nd Edition, 2014-10-14
CAN/CSA C22.2 No. 60950-1-07, 2nd Edition,
2014-10
IEC 60950-1:2005 (2nd Edition); Am 1:2009+
Am 2:2013
EN60950-1:2006+A11:2009+A1:2010+A12:2011
+A2:2013
CB (IEC/EN 60950-1)
BSMI CNS14336-1
