Edge-Core ECS4110-28T User manual

– 1 –
Quick Start Guide
L2 Gigabit Ethernet Switch
ECS4110-28T
The ECS4110-28T is a high-performance enterprise Layer 2 switch that provides 24
10/100/1000BASE-T RJ-45 ports and four Small Form Factor Pluggable (SFP) Gigabit
slots that support 1000BASE-SX, 1000BASE-LX, 1000BASE-LH, 100BASE-FX
and1000BASE-T transceivers.
N OTE : For detailed switch installation information, refer to the Installation Guide,
which is on the Documentation CD included with the switch.
N OTE : For Safety and Regulatory information, refer to the Safety and Regulatory
Information document included with the switch.
The switch is designed to be installed in a standard 19-inch equipment rack.
However, you can also install the switch on any flat surface, such as a desktop.
Follow the steps in this guide to install the switch in your network.
1. Unpack the Switch Unpack the switch and check the package contents.
◆ECS4110-28T L2 Gigabit Ethernet Switch
◆Bracket Mounting Kit containing two brackets and eight screws for attaching
the brackets to the switch
◆Four adhesive foot pads
◆Power cord—either US, Continental Europe or UK
◆Console cable (RJ-45 to DB-9)
◆Quick Start Guide (this document)
◆Regulatory and Safety Information
◆Documentation CD — includes Installation Guide and Management Guide
E032013-KS-R02
150200000586A
www.edge-core.com

Quick Start Guide
– 2 –
2. Install the Switch The switch can be mounted in a standard 19-inch rack or on a desktop or shelf.
Rack Mounting —Following your rack plan, mark the holes in the rack where the
switch will be installed. One person should lift the switch into the rack so that it is
aligned with the marked holes. A second person should secure the switch in the
rack, using four rack-mounting screws (not provided).
Desktop or Shelf Mounting —Attach the four adhesive feet to the bottom of the
switch, then set the device on a desktop, shelf, or other flat surface.
Attach the brackets to the switch,
then use the rack mounting screws
supplied with the rack to secure the
switch in the rack.
Attach the four adhesive rubber foot
pads to the recessed areas on the
bottom of the switch.

Quick Start Guide
– 3 –
3. Connect Power To supply AC power to the ECS4110-28T switch, first verify that the external AC
power supply can provide 100 to 240 VAC, 50-60 Hz and 0.90 A.
To connect AC power, plug the power cord into a grounded, 3-pin, AC power source
and then into the AC socket on the rear of the switch.
Caution: Use the AC power cord supplied with the switch. For international users
that may need to change the AC power cord, you must use a cord set that has been
approved for the socket type in your country.
4. Verify Switch
Operation
Verify basic switch operation by checking the system LEDs.
When operating normally, the PWR and DIAG LEDs should be on green.
Plug the AC power cord into the
socket on the rear of the switch.
System Status LEDs

Quick Start Guide
– 4 –
5. Make Initial
Configuration
Changes
At this point you may need to make a few basic switch configuration changes
before connecting to the network. It is suggested to connect to the switch console
port to perform this task.
The serial port’s configuration requirements are as follows: 115200 bps, 8
characters, no parity, one stop bit, 8 data bits, and no flow control.
You can log in to the command-line interface (CLI) using default settings: User
name “admin” with password “admin.”
For information on initial switch configuration, refer to the Management Guide,
which is on the Documentation CD included with the switch.
6. Connect Network
Cables
Connect network cables to port interfaces:
◆For the RJ-45 ports, use 100-ohm Category 5, 5e or better cable for 1000BASE-T
connections, or Category 5 or better for 100BASE-TX connections.
Console Port
Connect Category 5 or better cables
with RJ-45 plugs to the RJ-45 ports.

Quick Start Guide
– 5 –
◆For the SFP slots, first install SFP transceivers and then connect cabling to the
transceiver ports.
The SFP slots support the following transceiver types: 1000BASE-SX, 1000BASE-LX,
1000BASE-LH, 100BASE-FX, and 1000BASE-T.
As connections are made, check the port status LEDs to be sure the links are valid.
N OTE : For further switch configuration information, refer to the Management
Guide,which is on the Documentation CD included with the switch.
For fiber transceivers connect 62.5/
125 or 50/125 multimode or 9/125
single-mode fiber with LC connectors.

Quick Start Guide
– 6 –
Hardware Specifications
Item Specification
Chassis Specifications
SIze (W x D x H) 44.0 x 28.0 x 4.4 cm (17.32 x 11.00 x 1.73 in)
Weight 2.70 kg (5.95 lbs)
Temperature Operating: 0° C to 50° C (32° F to 122° F)
Storage: -40° C to 70° C (-40° F to 158° F)
Humidity Operating: 10% to 90% (non-condensing)
Power Specifications
AC Input AC 100-240 V, 50-60 Hz 0.90 A
Power Consumption 30 W Maximum
Maximum Current 0.90 A @ 100 VAC or 0.60 A @ 200 VAC
Regulatory Compliances
Emissions CE Mark
◆EN 55024
◆EN 55022, Class A
◆EN 61000-3-2
◆EN 61000-3-3
FCC Class A
VCCI Class A
RoHS DIrective 2002/95/ec of the European Parliament and of the
Council, WEEE Directive 2002/96/EC
Immunity IEC 61000-4-2/3/4/5/6/8/11
Safety UL/CUL (UL60950, CSA 22.2.No 60950)
EN 60950-1:2006+A11:2009+A1:2010+A12:2011 / IEC 60950-1:2005;
Am1:2009; CSA22.2 No. 60950-1-07 2nd; UL 60950-1 2nd
Certification Body (CB, IECEE)
