Edge Lighting Controller Dial with Power Supply Quick start guide

1
Operating CDP
Selecting Modes
O N
1 2 3 4 5 6 7
COLOR MODE
O N
1 2 3 4 5 6 7
Configure your CDP by setting the DIP switches on the front:
NOTE: The DIP switches must
remain accessible after installation.
When making changes in the DIP
switch settings, disconnect and
reconnect the power supply to
activate new settings.
CHASE MODE
Advanced Operation for Color Mode
1- Turn the light on 3- Set Color2- Activate configuration mode
2 SEC
4- Save color saving
TAP TAP
Advanced Operation for Chase Mode
1- Turn the light on 3- Set show speed2- Activate configuration mode
2 SEC
4- Save color setting
TAP TAP
1- Turn the light on 2- Change brightness 3- Turn the light off
BRIGHTNESS
TAP TAP
CDP
Operational Guide for Controller Dial with Power Supply
904-CDP-02
1718 W. Fullerton Ave
Chicago, IL 60614
Tel: [phone]
Fax: [phone]
www.edgelighting.com
[email protected]
© 2016 Edge Lighting. All Rights Reserved.

1- Turn the light on 3- Set Color2- Activate configuration mode
2 SEC
5- Set White
4- Activate White
6- Save settings
Advanced Operation for RGBW
TAP TAP
TAP
7- Dim
BRIGHTNESS
2
