EdgeStar WAC Series Reference manual

EdgeStar, 8606 Wall St, Suite 1800, Austin, TX 78754
support.edgestarr.com
*Warranty service should be performed by an authorized service representative only.
Document Type: Service Bulletin
Step 1: Remove Front Panel
1.1 Disconnect unit from power supply.
1.2 Remove 2 (two) Phillips head screws that attach front panel to cabinet. The screws are located on the lower
left and right sides of the front panel as noted in the following images.
While rare, excessive vibration during shipment may cause the ribbon cable that connects the front control
panel to the control board to become disconnected. This can result in a unit that will not power on and/or may
appear to power on but will not perform all functions correctly. To remedy this issue, the ribbon cable
connection must be checked and re-connected if loose or disconnected.
Koldfront Window / Through The Wall Air Conditioner Ribbon Cable Connection
Please refer to the below instructions.
Models Covered: WAC and WTC Series Air Conditioners
Page 1 of 2
1.3 Gently release / remove panel far enough to
reveal ribbon cable that connects the control
panel to the control box within the interior
cabinet.

EdgeStar, 8606 Wall St, Suite 1800, Austin, TX 78754
support.edgestarr.com
*Warranty service should be performed by an authorized service representative only.
Step 2: Inspect the ribbon cable connection
2.1 If ribbon cable is fully disconnected as shown in the image below, simply re-connect rmly.
2.2 If upon initial inspection it appears that the ribbon cable is properly connected, it is still recommended that
you disconnect and reconnect in order to verify a rm connection.
Step 3: Test Unit
3.1 Place front panel in correct positioning to re-attach to cabinet.
3.2 Plug unit into properly rated power source.
3.3 Power on unit using control panel or remote control (depending on model).
3.4 Test to verify problem has been resolved and that all functions are working properly.
Step 4: Secure Panel to Cabinet Frame to complete repair
4.1 Unplug unit from power source.
4.2 Re-attach 2 (two) Phillips head screws to secure front panel to cabinet.
4.3 Plug unit back into power source - repair completed.
If you problem has not been resolved, please contact EdgeStar Support for additional assistance.
Page 2 of 2
Document Type: Service Bulletin
Models Covered: WAC and WTC Series Air Conditioners
It is important to always check the status of the LCDI plug when troubleshooting an air
conditioning appliance that will not power on.
- Check the LCDI plug to see if it has been tripped and needs to be reset.
- The LCDI plug can be tested for proper function by pressing the TEST button.
- Locate and press the RESET button on the plug. If the RESET button fails to function, the
power cord must be replaced.
Note: LCDI stands for ‘Leakage Current Detection and Interruption’ and is designed to detect damage to your appliance and home electrical system.
NOTE ON LCDI PLUGS
Disconnected Connected
