EdgeStar Koldfront PDW60EB User manual

Dishwasher
Owner’s Manual
For more information on other great EdgeStar products on the web, go to http://www.edgestar.com
PDW60EB, PDW60EW

IMPORTANT SAFETY INFORMATION
Read all instructions carefully prior to use. For your safety, the information
detailed in this manual should be followed. Improper use and/or handling
can cause serious damage to the appliance and/or to the user including
but not limited to fire, explosion, and/or electric shock, resulting in
personal injury, or death.
Use this appliance only for its intended purpose as described in this
Owner′s Manual.
WATER HEATER SAFETY PRECAUTION
Hydrogen gas is flammable!
Under certain conditions, hydrogen gas may be produced in a water
heater that has not been used for more than two weeks. To prevent the
possibility of damage and/or injury, turn on all hot water faucets and allow
them to run for several minutes. Do this before using any electrical
appliance connected to the hot water system. This simple procedure will
release any built-up hydrogen gas. Since hydrogen gas is flammable, do
not smoke, use an open flame or use any appliance during this process.
PROPER INSTALLATION AND MAINTENANCE
When installing and servicing your dishwasher, refer to the following:
This dishwasher should be properly installed and placed in a location in
accordance with the Installation Instructions prior to operation.
Connect the dishwasher to a grounded permanent electrical system.
Check with a qualified electrician or service representative if you are in
doubt whether the appliance is properly grounded.
Improper electrical connection poses a risk of electric shock.
Do not attempt to repair or replace any part of your dishwasher unless it
is specifically recommended in this manual.
All other service maintenance should be completed by a qualified
technician.
To minimize the possibility of electric shock, disconnect this appliance
from the power supply before attempting any maintenance.
Turning the dishwasher OFF does not disconnect the appliance from
the power supply.
Dispose of discarded appliances, including any shipping and packaging
materials, properly.

EdgeStar Dishwasher ii
PRECAUTIONS FOR OPERATION
When using your dishwasher, follow basic precaution, including the
following:
Use this appliance only for its intended purpose as described in this
Owner’s Manual.
This appliance is not intended for use by children.
Do not allow children to play with, on, or inside this or any appliance.
Close supervision is necessary if this appliance is used near children.
Use caution when opening or closing the door to avoid injury.
Use only powder, tabs, liquid detergents, or rinse agents recommended
for use in a dishwasher and keep them out of the reach of children.
Using a detergent that is not specifically designed for dishwashers may
have an undesired result such as excessive suds.
To avoid damage to the door seal, place sharp items strategically.
Load sharp knives handle-side up to reduce the risk of injury.
Do not wash plastic unless it is marked as dishwasher safe. For plastic
items not marked as dishwasher safe, refer to the manufacturer’s
recommendations.
Do not operate your dishwasher unless everything enclosed is securely
in place.
Do not tamper with controls.
Do not rough-handle, sit, or stand on the door or dish rack of the
dishwasher.
Do not discard the dishwasher without removing the door.
Do not store or use combustible materials such as gasoline or other
flammable vapors and liquids in the vicinity of this or any other
appliance.
Contents washed in anti-bacterial mode (if available) may be hot to the
touch. Use care before handling.
If your dishwasher is connected to a wall switch, ensure tthe switch is
ON prior to use.
Do not wash non-dishware items such as furnace filters, paint brushes,
etc. in your dishwasher. Discoloration, staining, and/or other damage to
dishwasher may result.
If you choose to turn the switch OFF between wash cycles on
dishwashers with electronic controls, allow 5 - 10 seconds after turning
the switch ON before touching the START/RESET button. This allows
the control system to reboot.
PLEASE SAVE THESE INSTRUCTIONS

iii
Table of Contents
IMPORTANT SAFETY INFORMATION ..............................................................................I
PRECAUTIONS FOR OPERATION ....................................................................................II
INTRODUCTION .............................................................................................................1
PARTS IDENTIFICATION .................................................................................................2
FRONT VIEW...................................................................................................................... 2
BACK VIEW........................................................................................................................2
ACCESSORIES .....................................................................................................................2
PREPARING THE DISHWASHER FOR USE ........................................................................3
UNPACKING THE DISHWASHER .............................................................................................. 3
INSTALLATION REQUIREMENTS.....................................................................................3
CLEARANCE REQUIREMENTS ................................................................................................. 3
WATER REQUIREMENTS....................................................................................................... 3
Water Pressure.......................................................................................................... 3
Water Temperature ..................................................................................................3
ELECTRICAL REQUIREMENTS.................................................................................................. 3
CONNECTING THE HOSES TO THE DISHWASHER............................................................4
DISCONNECTING YOUR DISHWASHER ......................................................................................5
OPERATING INSTRUCTIONS...........................................................................................6
CHECKLIST BEFORE USING YOUR DISHWASHER.......................................................................... 6
CONTROL PANEL FUNCTIONS ................................................................................................6
Error Codes................................................................................................................6
WASH CYCLES CHART ..........................................................................................................7
PROPERLY LOADING THE DISHWASHER.................................................................................... 8
Cutlery Basket ........................................................................................................... 9
ONLY USE PROPER DETERGENT .............................................................................................9
USE JET-DRY RINSE AGENT................................................................................................. 11
STARTING THE WASH CYCLE ...............................................................................................12
CHANGING THE CYCLE .......................................................................................................12
Forget to Add a Dish?.............................................................................................. 13
AT THE END OF THE WASH CYCLE ........................................................................................13
MAINTENANCE............................................................................................................14
FILTER SYSTEM ................................................................................................................. 14
CLEANING THE DISHWASHER ......................................................................................15
CLEANING THE DOOR ........................................................................................................ 15
CLEANING THE SPRAY ARMS ...............................................................................................15
PROTECT AGAINST FREEZING ......................................................................................15
GUIDE TO KEEPING THE DISHWASHER IN TOP SHAPE..................................................16
TROUBLESHOOTING ....................................................................................................17
TROUBLESHOOTING CONTINUED ..........................................................................................18
SPECIFICATIONS ..........................................................................................................19
EDGESTAR LIMITED WARRANTY..................................................................................20

1
Introduction
Thank you for purchasing this EdgeStar dishwasher. We are glad you chose us.
We believe that your purchase of this product opens a relationship between you
and EdgeStar. We will provide the customer support needed to nurture that
relationship.
This manual contains important information regarding the proper installation, use
and maintenance of your dishwasher. Following this manual will ensure that your
product will work at its peak performance and efficiency.
Please save the original product packaging in case you need to safely transport
your dishwasher.
For Your Records:
Please write down the model number and serial number
below for future reference. You can locate your model
number on the tub wall just inside the door. Both numbers are
needed to obtain warranty service. You may also want to
staple your receipt to this manual as it is the proof of your
purchase, and is also needed for service under your
warranty.
Model Number:
Serial Number:
Date of Purchase:
To better serve you, please do the following before contacting customer service:
If you received a damaged product, immediately contact the dealer that
sold you the product.
Read and follow this instruction manual carefully to help you install, use
and maintain your portable air conditioner.
Read the troubleshooting section of this manual as it will help you
diagnose and solve common issues.
Visit us on the web at http://www.edgestar.com for product guides,
additional troubleshooting resources and up-to-date information. If you
need service, our friendly customer service representatives are available
via email at serv[email protected] or by telephone at 1 (866) 319-
5473.

EdgeStar Dishwasher 2
Parts Identification
Front View
Back View
Accessories
Filter System
Detergent Dispenser
Cup Shelf
Rinse Aid Dispenser
Spray Arm
Drain Port
Inlet Port
Cutlery Basket

3
Preparing the Dishwasher for Use
Unpacking the Dishwasher
Use at least two people to move and install the dishwasher to prevent back and
other types of injuries. Carefully remove the packaging materials. Remove any
shipping tape and glue from your dishwasher before using. Do not use sharp
instruments, rubbing alcohol, flammable fluids, or abrasive cleaners to remove
tape or glue. These products can damage the surface of your dishwasher. Check
to make sure the parts necessary for installation are included. If any parts are
missing, please contact our customer service. Put the dishwasher on a level and
flat surface that is able to support the entire weight of the dishwasher fully
loaded.
Installation Requirements
The dishwasher has been designed for a countertop installation. Please follow
the instructions for clearance, water and electrical requirements.
Clearance Requirements
The minimum height clearance required to install your dishwasher on a counter
top surface with overhead cupboards is 45cm (17.7”).
Water Requirements
Make sure the water supply/faucet connection is within reach of the inlet and
drain hose assembly (i.e., 58 cm / 22.8”). If your sink has a spray wand, it is
recommended that the hose be disconnected and the hole plugged.
Water Pressure
For best results, incoming water pressure should be between 15 and 20 pounds
per square inch (psi).
Water Temperature
For best results, the water temperature must be at least 55ºC (130ºF). To prevent
damage to the dishwasher, the temperature of the incoming water supply should
not exceed 65ºC (149ºF).
Electrical Requirements
Read all safety precautions listed at the beginning of this manual. It is
recommended that you use receptacles that cannot be turned off by a switch or
pull chain.
Make sure there is an electrical supply (outlet) within reach of the electrical
power supply cord (195 cm / 6.3 ft).
The dishwasher is equipped with a power supply cord having a 3-prong
grounding plug. To minimize possible shock hazard, the cord must be plugged
into a mating 3-pronged and grounding-type wall receptacle providing 110-120V,
60Hz, grounded in accordance with the National Electrical Code and local codes
and ordinances. If a mating wall receptacle is not available, it is the personal
responsibility of the customer to have a properly grounded, 3-prong wall
receptacle installed by a certified electrician. Use a circuit that is rated for 10
amps.
WARNING: Do not use an extension cord or an adapter plug with this appliance.
WARNING! Do not, under any
circumstances, cut or remove
the third (ground) prong from
the power cord.
WARNING: A hose that
attaches to a spray wand can
burst if it is installed on the
same water line as the
dishwasher.

EdgeStar Dishwasher 4
Connecting the Dishwasher
Your dishwasher comes equipped with a Faucet Adapter, Quick Connect, Drain
Hose and Inlet Hose. The faucet adapter must be installed on the faucet before
you can connect the dishwasher. This adapter is included inside your
dishwasher.
The faucet adapter is compatible with faucets inclusive of either male (outside) or
female (inside) threaded faucet connections.
1. Screw the faucet adapter onto (or into) the faucet tap. Check for leaks (use
Teflon or plumbers tape to eliminate any leaks if necessary).
2. Connect the six-sided connection of the drain hose to the drain port
connection on the back of the dishwasher cabinet. To avoid damage to
threads, do not over-tighten.
3. Connect the star-shaped connection of the inlet hose to the inlet port on the
back of the dishwasher cabinet. Do not over-tighten.
4. Connect the circular connection of the drain hose onto the longer (bottom)
male connection on the quick connect.
5. Connect the circular connection of the inlet hose onto the shorter (top) male
connection on the quick connect.
6. Attach the Quick Connect assembly onto the faucet adapter, by pulling down
the outer locking collar on the Quick Connect, while pushing the quick
connect assembly upward onto the faucet adapter.
7. Release the locking collar when the quick-connect assembly snaps onto the
faucet adapter. Verify the connection is secure.
8. Slowly open the hot water line and check for any sign of water leaks at all
connections. If leaks are located, immediately close the water supply and
repair the hose connections.
Pressure Relief Valve
Faucet Adapter
Locking Collar
Quick Connect assembly

5
If your existing faucet adapter is not compatible with the “quick connect” hose
assembly supplied, then the following procedures should be followed:
• Connect the faucet adapter (included with dishwasher) to your faucet.
• If your faucet is inclusive of a ‘female’ type (threaded) connection, both rubber
washers must be installed inside the faucet adapter.
• If your faucet is inclusive of a ‘male’ type (threaded) connection, use only the
standard rubber washer (0.2”/5mm thick) supplied within the adapter. Remove
the second rubber washer.
For Best Results:
Your dishwasher cleans by spraying a mixture of clean hot water and detergent
(under pressure) against the soiled surfaces of dishes. The water is pumped
through a rotating spray arm, drained through a filter (removing food and soiled
particles) and pumped back through the spray arm. Soiled water is pumped out
and replaced with clean water at the end of each cycle (the number of times this
is repeated depends on the wash cycle chosen).
NOTE:
Hard water conditions will adversely affect the washing performance of your
dishwasher. Hard water conditions will also contribute to ‘lime’ (white film
substance) deposits and/or ‘scaling’ on the stainless steel surface of the
dishwasher tub and heater element, located in the sump underneath the
removable filter screen. To assist in minimizing these conditions, it is
recommended to periodically operate/rinse the inside of the dishwasher (empty)
using 1 cup of white vinegar at least once a week.
Disconnecting your Dishwasher
1. Close the hot water supply at the faucet.
2. Disconnect the power supply cord.
3. Remember to release the water pressure inside the inlet hose.
4. The inlet hose is pressured when the water supply line is opened, even if
closed immediately.
5. To release pressure: press and hold the red pressure relief button on the
quick-connect assembly until the flow of water stops.
6. Disconnect the quick-connect hose assembly by pulling down on the outer
locking collar, thus releasing it from the faucet adapter.
Failure to relieve water pressure before disconnecting the Quick
Connect assembly from the Faucet Adapter may result in backpressure
overspray.
The inlet water temperature can be EXTREMELY HOT!
Backpressure overspray could cause SEVERE BURNS and/or
SCALDING!
Do NOT let children disconnect the dishwasher. Close supervision of
children is always important around appliances.

EdgeStar Dishwasher 6
Operating Instructions
To get the best performance from your dishwasher, read all operating
instructions.
Checklist Before using your Dishwasher
The following things should be checked before using the dishwasher.
1. The dishwasher is level
2. The hot water faucet is opened
3. There are no leaks at the drain and inlet ports.
4. The unit’s power plug is connected to a grounded outlet
5. The power is switched on
6. There are no kinks in the drain and inlet hoses
7. All packing and printed materials are removed from the dishwasher
Control Panel Functions
1. Power Button: Press to turn the unit On/Off.
2. Program Selector Dial: Rotate the knob to select wash cycle
a. Wash cycle descriptions listed on next page
3. Start/Pause Button: Press to START or PAUSE the unit
Error Codes
E1 –Long water inlet time –Faucet may not be opened or water
pressure is too low.
E4 –Overflow –dishwasher may be leaking.

7
Wash Cycles Chart
NOTE:NOTE:
Turning On the ApplianceTurning On the Appliance
Starting a washcycle...
Draw out the basket(see thesection entitled Loading the Dishwasher ).
Pour in the detergent (seethe section entitled Salt, Detergent andRinse Aid ).
Insert the pluginto the socket.The power supplyis 120V/60 Hz
Make sure that the watersupply is turnedon to full pressure.
Rotate the knob to select wash program you need
Heavy->Normal->Light->Glass->Speed->Soak
Then press the Start/Reset button, the dishwasher begins tostart.
When you press the Start/Reset button to pause during washing;
the dishwasher will stop;the dishwasher go on washing unless you
press the Start/Reset button .
Means: need tofill rinse intothe Rinse-Aid Dispenser.
( )
*AHAM DW-1-2005 : This program is the test cycle, the rinse-aid dispenser
setting is recommended to Position 6.
NOTE:NOTE:
Detergent
pre/main
Cycle Selection
Information
Program Running
time(min) Energy
(Kwh)
Water
(l)
Description
of Cycle
Rinse
Aid
For normally soiled loads,
such as pots, plates,glasses
and lightly soiled pans.
standard daily cycle.
For lightly soiled loads,such
as plates,glasses,bowls and
lightly soiled pans.
For the heaviest soiled loads,
such as pots,pans,casserole
dishes and dishes that have
been sitting with dried food
on them for a while.
A shorter wash for lightly
soiled loads that do not
need drying.
For lightly soiled loads,
such as glasses, crystal and
fine china.
15 g.
85
75
100
45
70
0.361
0.311
0.424
0.233
0.274
12
12
14.5
12
9.7
Pre-wash
Pre-wash
Wash (55 )
Rinse
Rinse (65 )
Drying
Pre-wash
Pre-wash (50 )
Wash (50 )
Rinse
Rinse (60 )
Drying
Pre-wash
Wash(50 )
Rinse
Rinse(60 )
Drying
/
10 2.5
0.01
Pre-wash
Pre-wash
Pre-wash(50 )
Wash (50 )
Rinse
Rinse(55 )
Heavy
Pre-wash
Pre-wash(50 )
Wash (55 )
Wash (50 )
Rinse
Rinse (65 )
Drying
Glass
Speed
15 g.
To rinse dishes that you
plan to washlater that day.
Light
Soak
18g
18g
18g
(*AHAM DW-1-2005 )
Normal

EdgeStar Dishwasher 8
Properly Loading the Dishwasher
A properly loaded dishwasher is key for optimal performance. Overfilling
the dishwasher can reduce the dishwasher’s efficiency. Furthermore
improper placement of items can hinder the performance of the unit.
This unit is optimized for holding 6 place settings including:
Cutlery basket
6 Large Plates and
Serving Bowl
Dessert Plates
4 Saucers and 6
6-Glasses
placed below
cup shelf5-
Serving
Bowl/Plate
6-Bowls
1-Saucer Cup
Position the dishes and cookware so they are secure during the wash
cycle. Dishes and cutlery that shift in the wash cycle may hinder the spray
arms from proper motion, resulting in an undesired result. Be sure to
secure dishes and utensils so items cannot be moved by sprayed water.
6 Cups
2 Serving bowls
6 Glasses
6 Saucers
6 Fruit bowls
1 Oval platter
6 Dinner plates
6 Bread and butter plates
1 Cutlery basket

9
Cutlery Basket
Silverware should be placed in the cutlery basket with handles directed
toward the bottom. If the rack has side baskets, spoons should be loaded
individually into the appropriate slots. Knives and other sharp utensils
should be placed in the basket with handles up. Longer utensils should be
placed in the horizontal position on the cup shelf instead of in the basket.
WARNING: Do not let any item extend through bottom of cutlery basket. This
may prevent the spray arm from spinning.
For personal safety and a highest quality wash, securely place all
silverware in the basket:
Be sure the similar pieces of silverware do not nest together.
Place most silverware with handles-down.
Place knives and other potentially dangerous utensils handles-up.
Only Use Proper Detergent
Use only detergent specifically made for use in dishwashers. Keep your
detergent fresh and dry. Do not put powder detergent into the dispenser
until you are ready to wash dishes.
The amount of detergent to use depends on whether your water is hard or
soft. With hard water, you need extra detergent to alleviate the deposits
that are left by the excessive minerals. Less detergent is needed for soft
water.
To identify whether your water is hard or soft, contact your water
department. A water softener is recommended for water that contains
twelve or more grains. Without it, lime can build up in the water valve,
which could stick while open and cause flooding. Too much detergent
with soft water can cause a permanent cloudiness of glassware, called
etching.
For heavily soiled loads, use the HEAVY WASH Cycle, fill one or both of
the interior cups, depending on the hardness of your water, and also fill
the open cup on the dispenser lid.
Use the information in the table below as a guideline to determine the
amount of automatic dishwasher detergent to place in the dispenser:
Number of Grains
Detergent Cups to Fill
Less than 4
15 cup
4 to 8
25 cup
8 to 12
15 and 25 cups
Greater than 12
15, 25 cups and the open cup

EdgeStar Dishwasher 10
To open the wash cover:
Press the button and the cover will flip back revealing the detergent
dispensing cups. See below:
NOTE: DO NOT USE HAND DISH DETERGENT
Using a detergent that is not specifically designed for dishwashers will
cause the dishwasher to fill with suds. During operation, these suds will
spill out of the dishwasher vents.
Since so many detergent containers look similar, store the dishwasher
detergent in a separate space from all other cleaners. Show anyone who
may use the dishwasher where the correct detergent is stored.
While there may be no lasting damage to the dishwasher by using
dishwashing detergent that is not formulated to work with dishwashers,
your dishes may not get fully clean.

11
Use Jet-Dry Rinse Agent
Jet-Dry rinse agent removes spots and prevents new film build-up on
your dishes, glasses, flatware, cookware and plastic.
Filling the Dispenser
The rinse agent dispenser holds 3.5 oz. of rinse agent. Under normal
conditions, this will last approximately one month. Try to keep it full, but
do not overfill.
1.Make sure the dishwasher door is fully open.
2.Turn the dispenser knob to the left and lift it out.
3.Add rinse agent until the indicator window looks full.
4.Clean up any spilled rinse agent with a damp cloth.
5.Replace the dispenser knob.
Rinse Aid Setting
The amount of rinse agent released into the final wash can be adjusted.
The factory setting is at the midpoint. If there are rings of calcium
(hard water) spots on dishes, try a higher setting.
To adjust the setting
Remove the dispenser knob; then turn the adjuster counterclockwise
to increase the amount of rinse agent.
Only use branded rinse aid for the dishwasher. Never
fill the rinse aid dispenser with any other substances
such as liquid detergent.

EdgeStar Dishwasher 12
Starting the Wash Cycle
Once the dishwasher is fully loaded follow these procedures to start the
wash cycle:
Ensure that the unit is connected to the power supply.
Ensure that the water supply is turned on to full pressure .
Pour in the detergent
Press the ON/OFF switch to power the dishwasher on.
Rotate the knob to the desired cycle. The wash cycle will be
changed as following direction:
Heavy -> Normal -> Light -> Glass -> Speed -> Soak
Press the START/PAUSE button, the dishwasher begins to start.
NOTE:
When the START/PAUSE button is pressed during a wash cycle the cycle
is suspended and the program light will stop blinking. Unless the
START/PAUSE button is pressed to continue the cycle, an indicator beep
will be heard every minute.
Changing the Cycle
You can modify the washing cycle, but only when the dishwasher has
been running for a short time. Otherwise, detergent may have been
release, and the appliance may have already drained water. If this is the
case, the detergent dispenser must be refilled.
Opening the door during the wash cycle may result in injury from
scalding hot water.
Pressing the START/PAUSE button for three seconds or more will put the
machine in a stand-by state. At this point the cycle setting can be
changed.
NOTE:
If the door is opened during the wash cycle, the machine will be paused.
When the door is closed, the machine will restart in 10 seconds.

13
Forget to Add a Dish?
A dish can be added any time before the detergent cup opens.
1. Press the START/PAUSE button.
2. Open the door slightly to stop the washing.
3. You can open the door after the spray arms stop spinning.
4. Add remaining dishes.
5. Close the door.
6. Press the START/PAUSE button.
The dishwasher will restart after 10 seconds.
At the End of the Wash Cycle
When the selected wash cycle has finished, the buzzer of the dishwasher
will sound for 8 seconds. Turn off the dishwasher using the ON/OFF
button, shut off the water supply and open the door. Wait a few minutes
before unloading the dishwasher to avoid handling the dishes and
utensils while they are still hot.
Removing the Dishes
1. Switch off the dishwasher by pressing the ON/OFF button.
2. Turn off the water tap!
3. Open the door carefully. Leave the door ajar and wait a few
minutes before removing the dishes. This will allow the dishes
to cool and assist in the drying process.
4. Unload the dishwasher. It is normal for the dishwasher to be
wet inside.
WARNING: It is dangerous to open the door when
washing as the hot water may scald you.

EdgeStar Dishwasher 14
Maintenance
Filter System
The filter system consists of a coarse filter, a flat (Main filter) And a micro filter
(Fine filter).
1. Main filter:
Food and soil particles trapped by this filter are pulverized by a special jet on the
spray arm and washed down to drain.
2. Fine filter:
This filter holds soil and food residue in the cylindrical base and prevents the soil
from being redeposited on the dishes during wash cycle.
3. Coarse filter
Larger items, such as pieces of bone or glass, that could block the drain are
trapped in the coarse filter. To remove the items caught by the filter, gently
squeeze the tap on the top of this filter and lift out.
The filter efficiently removes food particles from the wash water, allowing it to be
re-cycled during the cycle.
For best performance and results, the filter assembly must be cleaned regularly.
For this reason, it is a good idea to remove the larger food particles trapped in
the filter after each wash cycle by rinsing the filter assembly under running water.
Use a soft cleaning brush to clean the coarse filter and the fine filter. Reassemble
the filter parts as shown in the following diagram and reinsert the entire assembly
in the dishwasher, positioning it in its seat and pressing downward.
To remove the filter assembly, grab the handle of the fine filter, rotate it counter-
clockwise, then pull upward.
Important
Never run the dishwasher without the filters in place.
Improper replacement of the filter or damaged filters may reduce the
performance level of the dishwasher and/or damage dishes and
utensils.
Clean the entire filter system at least once a week
Inspect the filters after each wash and remove any food remnants and
clean under running water.

15
Cleaning the Dishwasher
The control panel can be cleaned by using a lightly dampened cloth. Dry
thoroughly with a soft towel.
Never use sharp objects, scouring pads or harsh cleaners on any part of the
dishwasher.
Cleaning the Door
To clean the edge around the door, you should use only a soft warm damp cloth.
To prevent water into the door lock or electrical components, do not use a liquid
spray or cleaner of any kind.
WARNING: abrasive agents or some paper towels may scratch
or leave spots on the stainless steel surface
Cleaning the Spray Arms
The spray arms can be removed for periodic cleaning of the nozzles to prevent
possible clogging. Wash the spray arms under running water and carefully
reinstall them making sure that the movement is in no way impeded.
Protect Against Freezing
Please take frost protection measures on the dishwasher in winter. Each time
after washing cycles, please take the following steps:
1. Turn off the dishwasher
2. Turn off the water supply and disconnect the water inlet hose from the back of
the unit.
3. Drain the water from the inlet hose and inlet port. (Use a pan to catch the
water)
4. Reconnect the water inlet hose to the inlet port.
5. Remove the filter system and use a sponge to absorb the water that is in the
sump area.

EdgeStar Dishwasher 16
Guide to Keeping the Dishwasher in Top Shape
After Every Wash
Turn off the water supply to the appliance and leave the door slightly open so
that moisture and odors are not trapped inside.
When Cleaning
Never use abrasive solvents when cleaning. Only use a dampened soft cloth with
warm water. To remove spots or stains from the interior surface you may use a
cloth dampened with water and a little white vinegar
Cleaning the Door Seals
Food that remains trapped in the seals may cause odors to form. Periodic
cleaning with a damp sponge will prevent this from occurring.
Clean the Filters Regularly
Cleaning the filters regularly will prevent clogs and odors from occurring.
Preparation for storage
It is recommended that you run a wash cycle with the dishwasher empty.
Disconnect the unit from power. Remove any water remaining in the sump area
with a terry cloth or absorbent sponge. Turn off the water supply and leave the
door of the appliance slightly open. This will help the door seals to last longer and
prevent odors from forming inside the dishwasher.
If the Dishwasher Must be Moved
If the dishwasher must be moved, try to keep it in the upright position. Do not
ship the unit on its side or upside down.
Do not use Some Items That Are Not Suitable for Dishwasher Use:
Cutlery with wooden, horn, china, or mother of pearl handles
Plastic items that are not heat resistant
Older cutlery with glued parts that are not heat resistant
Bonded cutlery items or dishes
Pewter or copper items
Crystal glass
Steel items subject to rusting
Wooden platters
Items made from synthetic fibers
Silver and aluminum parts have a tendency to discolor during washing
Glazed patterns may fade if machine washed
Some types of glasses can become dull after a large number of washes
