EdgeStar IP200 Series Manual

“Ice shovel” installation for IP200* series
NOTE: This instruction guide assumes a) the ice shovel piece is already removed from
your ice maker and b) the “water bucket” piece and hinges for the ice shovel are currently
properly installed. See fig. 1 for an image of the ideal condition of the ice maker prior to
beginning this installation.
Fig. 1:
In order to properly complete this installation, you need 1 plastic ice shovel part, 2 metal
pins, and a pair of needle nose pliers.
Step 1:
Partially insert 1 pin into one side of the ice shovel, as shown in fig. 2.
Fig. 2:

Step 2:
Position the ice shovel piece about the hinges as shown in fig. 3a, then carefully push the
pin further in, making sure to insert the pin through the hole in the hinge (it is often
easiest to use a pair of needle nose pliers for this step). See fig. 3b.
Fig. 3a:
Fig. 3b:

NOTE: At this point, your ice maker should look something like fig. 4.
Fig. 4:
Step 3:
Repeat Step 2 for the other side of the ice shovel. See fig. 5:
Fig. 5:

Your installation should now be complete. The ice maker should look like fig. 6.
Fig. 6:
Here is a closer view of the hinge of an ice maker after installing a new ice shovel- fig. 7.
Fig. 7:
