EdgeStar Wine Cooler TWR215ESS User manual

Table of Contents
Table of Contents 1
Welcome Message and Thank You 1
Important Safeguards 2
1. Specifications 3
2. Parts and Features 4
3. Operation 4
4. Troubleshooting 7
5. Limited Warranty 9
Welcome and Thank You
Welcome and thank you for purchasing this EdgeStar® wine cooler. Once you
complete our easy unit set up by following this manual, it will provide you and
your family years of great service.
If you are reading this owner’s manual, you’ve probably already unpacked the
unit. Note that you should save the packaging in case you need to safely
transport this wine cooler in the future.
In order to assemble this wine cooler, carefully
unpack all parts. The only assembly required is that
of the handle(s). In order to install a handle, you
need a Phillips head screwdriver, the handle(s), and
the two installation screws.
•Open the door of the wine cooler.
•Locate the two screw holes on the inside of
the door (they may be partially obscured by
the door liner gasket.
•Insert the screws into the holes. They should
now poke out of the front of the door.
•Line up the holes in the handle with the
screws and give each screw about 2-4 full
turns into the handle.
•Now screw the screws in all the way, and
your handle is installed!
After you get the handle(s) installed, make sure that your wine cooler is fully
unpacked, and position it into your preferred location (remember, for the best
conditions for your wine, choose a spot in a cool (room temperature) area,
away from direct sunlight leaving about 2-4 inches around all sides,
specifically the back for adequate ventilation. Make sure the unit is set on a
sturdy surface that can support its weight.
Note: that you can screw in and out the legs to level the unit. You may also
want to clean the interior with a solution of mild soap and water and a damp
cloth. Then plug the unit in, set the temperature, and fill it with wine.
1

At what temperatures should you set the wine cooler? Experts differ in
opinion, but we recommend low to mid 50’s (F) for whites and mid 60’s (F) for
reds. Enjoy! IMPORTANT SAFEGUARDS
When using an electrical appliance, basic precautions should always be
followed, including the following:
BEFORE USE, PLEASE READ AND FOLLOW ALL INSTRUCTIONS FOR
THIS WINE COOLER
•Do not use if the power supply cord is damaged. If damaged, it must be
replaced by the manufacturer or a similarly qualified technician.
•This wine cooler is not intended for use by young children or infirm
persons without supervision.
•Ensure the cooler is unplugged before cleaning or if not in use.
•To clean the cooler use only mild detergents or glass cleaning
products. Never use harsh detergents or solvents.
•It is not recommended to use this wine cooler with an extension cord or
power strip. Please ensure that the appliance is plugged directly into an
electrical outlet.
•When positioning the wine cooler, ensure that there is at least a 2”
clearance on each side with 4” directly behind the cooler. This will
ensure adequate ventilation of heat from the back of the cooler.
•This cooler is designed to store wine bottles. If food is placed inside,
ensure that there is sufficient airflow between items. Also note that the
temperature range for this cooler is optimized for wine and beverage
storage. Perishable food items may require a different storage
environment.
•Do not place hot food or drinks into the wine cooler before they cool
down to room temperature.
•Please close the cooler door immediately after putting in or taking out
wine in order to prevent inside temperature from dramatically changing.
•Avoid subjecting the cooler to external heat sources or direct sunlight.
•For a stable installation, make sure the cooler is placed on a flat, level,
and solid surface.
•Make sure that the surface on which the wine cooler is placed is strong
enough to hold the wine cooler once it is fully loaded with wine bottles.
•Do not place any other appliances on top of the wine cooler.
•The wine cooler is an electrical appliance. To avoid injury or death from
electrical shock, do not operate the wine cooler with wet hands, while
standing on a wet surface, or while standing in water.
•Do not use outdoors or in wet /moist conditions.
•Do not turn the cooler upside down, on its side, or 45° or more off level.
•Never pull the power cord to disconnect it from the outlet. Grasp the
plug and pull it from the outlet.
•Never lift or carry the wine cooler by the power cord.
•Keep the power cord away from heated surfaces.
•This wine cooler is designed for household, non-commercial use only.
•Do not plug this cooler into the power socket before set up is completed.
2

•An empty cooler can be dangerous for children. If disposing of the
cooler remove gaskets, latches, lids and the entire door from your
unused appliance, or take other action to ensure that children cannot
become trapped inside.
•If your model of wine cooler is equipped with a lock, take care to keep
the keys away from children.
•Do not cut or remove the third prong (the grounding prong) from the
power cord.
•The cord should be secured behind the unit and should not be left
exposed or dangling.
•Do not move this cooler without emptying it of its contents and securing
the door in a closed position.
1. Specifications
Model TWR210EBL
Voltage/frequency 115V/60Hz
Power 140 W (77)
Rated Current 2.0 A (77)
Net Weight 46.297LB
Protection Type I
Climate Type SN • N
Model TWR215ESS
Voltage/frequency 115V/60Hz
Power 140 W (77)
Rated Current 2.0 A (77)
Net Weight 46.297LB
Protection Type I
Climate Type SN • N
Model TWR320EBL
Voltage/frequency 115V/60Hz
Power 210 W (77)
Rated Current 3.0 A (77)
Net Weight 69.887LB
Protection Type I
Climate Type SN • N
Model TWR325ESS
Voltage/frequency 115V/60Hz
Power 210 W (77)
Rated Current 3.0 A (77)
Net Weight 69.887LB
Protection Type I
Climate Type SN • N
3

2. Parts and Features
1. LIGHT 2. FAN GRATE 3. SHELF 4. FOOT
5. HINGE 6.TEMPERATURE DISPLAY
7. TEMPERATURE CONTROLS
8. DOOR FRAME 9.DOOR GLASS 10.HANDLE
Note: The above diagram is for reference only- your specific model of wine
cooler will likely differ slightly from the diagram above (in light placement,
bottle capacity, etc,) but its operation will be essentially the same.
3. Operation
The Temperature Control
Your wine cooler uses a digital control to adjust the thermostat-
Adjust the temperature using the up and down arrows located on the wine
cooler.
Interior Light
Your wine cooler is equipped with an interior light with an on/off switch. Turn
the light on or off by pressing the switch.
Leveling Legs
Your wine cooler is shipped with leveling legs installed. To adjust these
leveling legs, carefully lean the cooler to one side (make sure the cooler is
empty and the door is secured) and unscrew the leveling legs to make them
longer. Screw them in tighter to make them shorter.
Note: This cooler is not designed to operate with the leveling legs removed.
4

Bottle Capacity
Bottle capacity listed for your wine cooler is an estimated maximum capacity
based on standard 750 mL wine bottles. For any other size bottles, capacity
will vary.
Racks
Please note that the racks for your cooler have a top and a bottom. If you are
having trouble fitting the stated number of bottles in the cooler (provided you
have standard wine bottles), try flipping over one or more racks.
Also note that your wine cooler (depending upon the model) may have more
“slots” for racks than the number of racks provided with the unit. Additional
racks may be purchased from your retailer.
Door Lock (not standard on all models)
Some models of wine cooler have a factory installed lock with keys. The lock
is inset to the door. To lock your cooler, insert the key into the lock and turn
the key until the metal tab is fully extended.
To unlock your cooler, insert the key into the lock and turn until the metal tab
is fully retracted back into the door.
Caution: Make sure to keep the key in a safe place and out of reach of
children- to prevent child entrapment.
Cleaning the Cooler
•Unplug your cooler. Remove all items from it (wine bottles, shelves,
etc.)
•Clean the inside surfaces with a mild cleaner. We suggest you use
either warm water alone, or a baking soda solution (try mixing 2
tablespoons of baking soda into a quart of water.)
•Clean the wire shelves/trays (if you have them) with a mild detergent
solution.
•Clean the wooden shelves/trays (if you have them) with a soft cloth and
wood cleaner.
•Wash the outside of the cooler with a mild detergent solution.
•Dry any wet parts with a soft cloth.
Caution: make sure to minimize the exposure of water to any electronic or
control parts.
Extended Periods of Disuse
Your cooler can operate safely for three weeks or longer without any
adjustments. However, if the cooler is to be left alone for several months, you
should unplug it and clean it according to the instructions above. Pay special
attention to drying the interior.
Now set the unit aside somewhere out of the reach of children. You may want
to crack the door slightly to prevent mold growth or odour.
Transporting the Cooler
The ideal packaging for you cooler is its original packaging. If possible, keep
this packaging handy and repack the cooler as it was initially packed if you
need to transport it.
If you do not have the original packaging:
5

•Make sure the cooler is turned off and unplugged.
•Remove all items.
•Remove shelves and any other loose items within the cooler.
•Shut the door and tape it closed.
•Transport the cooler in a secure, upright position along with its shelves.
•Protect the outside of the cooler with Styrofoam, cardboard, a blanket,
etc.
Energy Efficiency Tips
Locate your cooler in the coolest area of the room.
Locate your cooler away from direct sunlight or any heat-producing sources,
as this will force the cooler to work even harder, making it less likely to cool
your wine properly.
Let any hot foods or drinks cool before placing them inside the cooler.
5. Troubleshooting
Your EdgeStar wine cooler is a thermoelectric refrigeration unit that uses
“green” thermoelectric cooling to store your wine under ideal conditions.
What are the benefits of thermoelectric cooling?
•Low energy usage
•No vibration
•Cools with little noise- the only noise produced is by the fans used to
dissipate heat.
What are some of its limitations?
•Cooling takes longer than with equivalent compressor-based units- you
must allow 24 hours or more for the unit to reach its lowest temperature
•Fans run constantly
•Units are more sensitive to ambient temperature, sunlight conditions,
and potentially loading conditions- they may not cool to their theoretical
minimum temperature under adverse conditions
6

Symptoms Possible causes Solutions
The wine
cooler does
not turn on.
There is a power
failure.
The cooler is not
plugged in.
A house fuse has
blown or the circuit
breaker is tripped.
Ensure the cooler is
plugged in and the
power outlet has power.
Replace the broken fuse
in your fuse box or reset
the breaker.
The wine
cooler will not
reach the
desired
temperature
The cooler is placed
too close to a heat
source.
The cooler does not
have sufficient
ventilation.
Keep the cooler away
from sunshine or other
heat sources.
Make sure the wine
cooler has several
inches of ventilation on
the sides and back.
Close the door tightly
and do not open the door
too frequently or for a
long period of time.
The door is opened
too frequently or for a
long period of time.
The environment is
humid.
The ambient
temperature is too
low.
The door is being
opened too
frequently.
Frost is
forming in the
wine cooler
Though the unit uses an
“auto-defrost” system,
under certain conditions,
manual defrosting may
be required. If frost
builds up, you can try
running the cooler on a
warmer temperature
setting, minimizing the
number of times you
open the door, or
unplugging the unit to
allow the frost to melt.
7

Symptoms Possible causes Solutions
The cooler
turns on and
off frequently.
The room
temperature is higher
than the
recommended
ambient temperature
(77°F).
The door is being
opened often.
The door is not
completely closed.
The door gasket is
not sealing properly.
The cooler does not
have the suggested
ventilation.
Run the cooler in the
appropriate ambient
temperature.
Minimize the number of
times the door is
opened.
Make sure the door is
completely closed.
Make sure the door
gasket is properly
sealing.
Make sure the cooler
has at least 2” on the
sides and 4” in the back
for clearance.
The cooler
makes too
much noise.
If the noise is from
the fan, it may be
normal operating
noise.
The fan makes normal
fan noises when
operating- this is normal.
The unit is not level.
Make sure the cooler is
on a level surface.
Popping or crackling
noises are coming
from the unit.
Some popping or
crackling noises are
normal. They are caused
by expansion and
contraction of the inside
walls due to temperature
changes.
Your cooler is not
level. Make sure the cooler is on a level surface.
The door gasket is
dirty. Clean the door gasket.
The door will
not shut
properly.
Make sure the door
gasket is properly
sealing.
The door gasket is
malformed.
The shelves are
incorrectly installed. Correctly install the shelves.
8

6. Limited Warranty
This EdgeStar product is warranted to be free from defective workmanship
and materials for the first year following the date of original purchase.
Replacement parts will be supplied free of charge for the first year following
the date of original purchase. Labor will be performed free of charge for the
first 90 days following the date of original purchase.
WHAT IS COVERED:
This warranty applies to the original purchaser only, and only covers defects
in workmanship experienced during operation of the product under normal
service, maintenance, and usage conditions. This warranty applies to the
purchase and use of this product in residential settings within the United
States of America.
WHAT IS NOT COVERED:
The following limitations apply to the coverage of this warranty:
Optional accessories, attachments, and appearance items are excluded from
warranty coverage, as is shipping damage, and any damage caused by
improper voltage or any other misuse, including abnormal service, handling,
or usage.
This warranty does not cover normal wear and tear on parts or replacement of
parts designed to be replaced, e.g. filters, etc.
This warranty does not cover service trips to deliver, pick-up, repair, or install
the product, or to instruct in proper usage of the product.
Damages or operating problems resulting from abuse, operation outside
environmental specifications, uses contrary to instructions provided in the
owner’s manual, accidents, vermin, fire, flood, improper installation,
unauthorized service, acts of God, unauthorized installation or modification, or
commercial use are excluded from warranty coverage.
This warranty does not cover labor incurred 91 days or more after the date of
original purchase.
This warranty does not cover use of EdgeStar products in commercial
settings.
DESCRIPTION OF WARRANTY SERVICE:
All defective product components covered by this warranty will be repaired or
replaced, at EdgeStar’s option, free of charge on a mail-in basis to EdgeStar’s
authorized repair facility during the first 90 days from the date of original
purchase.
All defective product components covered by this warranty will be repaired or
replaced, at EdgeStar’s option, on a mail-in basis to EdgeStar’s authorized
repair facility during the time period beginning on the 91st day from the date of
original purchase and ending one year from the date of original purchase.
During this time period, parts will be supplied free of charge, but labor charges
will apply.
All replacement parts and units will be new, remanufacturered, or refurbished.
All products and components replaced by EdgeStar under warranty service
become the property of EdgeStar.
9

OBTAINING WARRANTY SERVICE:
Contact EdgeStar for troubleshooting assistance and warranty service
authorization at 1-866-319-5473. Please have your order receipt available to
confirm the date of purchase.
Once an EdgeStar authorized representative has confirmed that your product
is eligible for warranty service, the product must be returned to an EdgeStar
authorized repair facility.
The purchaser is solely responsible for prepaying all shipping related costs to
and from the repair facility.
EdgeStar is not responsible for damage resulting from shipper mishandling or
improper packaging.
Do not return defective product to the place of purchase.
THIS WARRANTY IS IN LIEU OF ANY OTHER WARRANTY, EXPRESS OR
IMPLIED, INCLUDING WITHOUT LIMITATION, ANY WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. TO
THE EXTENT ANY IMPLIED WARRANTY IS REQUIRED BY LAW, IT IS
LIMITED IN DURATION TO THE EXPRESS WARRANTY PERIOD ABOVE.
NEITHER THE MANUFACTURER NOR ITS DISTRIBUTORS SHALL BE
LIABLE FOR ANY INCIDENTAL, CONSEQUENTIAL, INDIRECT, SPECIAL,
OR PUNITIVE DAMAGES OF ANY NATURE, INCLUDING WITHOUT
LIMITATION, LOST REVENUES OR PROFITS, OR ANY OTHER DAMAGE
WHETHER BASED IN CONTRACT, TORT, OR OTHERWISE. SOME
STATES DO NOT ALLOW THE EXCLUSION OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES, SO THE ABOVE EXCLUSION MAY NOT
APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL
RIGHTS. YOU MAY HAVE OTHER RIGHTS THAT VARY FROM STATE TO
STATE.
10
