Edimax IC-3005 Series User manual

1

2
ErPAnnouncement
Product: Internet Camera (IP Camera)
Purpose: 24 hour surveillance and transfer of footage for safety and health
reasons as intented use.
Detailed description:
- Health purposes: Users can pass through the Internet (from anywhere)
to control the product (IP Camera). It's intended to watch and listen to
people who need to be cared for at home and automatically sends
e-mails and phone alerts to warn observers and ask for their attention.
The product also provides a record function to retain all images and
voice information for the sake of reference.
- Safety purposes: Users can initiate a “motion detect” function to
record and send e-mails to notify them when doors or windows are
opened –potentially by unwarranted persons.
- General purposes: Record/monitor environment footage and sound
and store them onto a hard disk as a record.
As we cannot predict when events of this nature may occur, we need for the
product to remain active and alert at all times. If the product had to go into
“standby/off” mode, it would impact the effectiveness of recording and warning
functions resulting in users not getting the information they need.
Based on the ErP official journal of European Union
Directives 2009/125/CE of the European parliament and of the council of
21 October 2009 Article 15 sector 5 part (a) and (b) as below:
“Implementing measures shall have no significant negative impact on the
functionality of the product, from the perspective of the user.”
“Health, safety and environment shall not be adversely affected.”
We announce that the product need not comply with the (EC) No 1275
Standby and on/off mode function of Implementing Measurement.
We will keep up to the newest Implementing Measurements in the future
and make the necessary changes if it's related to this product.

3
Copyrightby Edimax Technology Co, LTD. all rights reserved. No part of this
publication may be reproduced, transmitted, transcribed, stored in a retrieval
system, or translated into any language or computer language, in any form or
by any means, electronic, mechanical, magnetic, optical, chemical, manual or
otherwise, without the prior written permission of this Company.
This company makes no representations or warranties, either expressed or
implied, with respect to the contents hereof and specifically disclaims any
warranties, merchantability or fitness for any particular purpose. Any software
described in this manual is sold or licensed "as is". Should the programs prove
defective following their purchase, the buyer (and not this company, its
distributor, or its dealer) assumes the entire cost of all necessary servicing,
repair, and any incidental or consequential damages resulting from any defect
in the software. Further, this company reserves the right to revise this
publication and to make changes from time to time in the contents hereof
without obligation to notify any person of such revision or changes.
The product you have purchased and the setup screen may appear slightly
different from those shown in this QIG. For more detailed information about
this product, please refer to the User's Manual on the CD-ROM. The software
and specifications could be subjected to change without notice. Please visit
our web site www.edimax.com for updates.All rights reserved including all
brand and product names mentioned in this manual are trademarks and/or
registered trademarks of their respective holders.
Linux Open Source Code
Certain Edimax products include software code developed by third
parties, including software code subject to the GNU General Public
License ("GPL") or GNU Lesser General Public License ("LGPL").
Please see the GNU (www.gnu.org) and LPGL
(www.gnu.org) Websites to view the terms of each license.
The GPL Code and LGPL Code used in Edimax products are distributed
without any warranty and are subject to the copyrights of their authors.

5
1. Product Information
Congratulations on buying this Edimax IP Camera! You've chosen
well. This IP camera is ideal for all kinds of video surveillance from
home and office safety to child and pet monitoring purposes. This
Edimax IP camera is tailor made to stream live video over your
network, so you can view its footage from anywhere on your local
computers. Better yet, you can view its video via the Internet! The
Edimax IC-3005 series features extremely high picture quality
matched by a high frame rate video streaming because of advanced
video compression. To get the best video quality, select MPEG4 or
MJPEG, depending on your network settings.
Before enjoying your new IP camera, please check the package
contents. If anything is missing, return this package to your dealer to
claim the missing contents.
2. Check your package contents
1 x IP Camera
1 x Power Adapter
1 x Mounting Kit
1 x Category 5 Ethernet Cable
1 x Quick Installation Guide
1 x CD (Including Manual/Utility/Multi-Language QIG)
3. System Requirement
CPU: Intel Pentium 4 2.4 GHz above or Intel Dual-Core
2.0GHz
VGA Card Resolution: 1024 x 768 or above
A CD-ROM Drive
Hard Disk:At least 128MB (256MB recommended) of
available space
OS: Windows 2000/XP/Vista/7

6
4. Hardware Installation
4.1 LED and Focusing
There are two LEDs indicating the camera's status and networking

7
4.2 Camera Ports
Name
Description
Tripod
Connector
Connects to standard tripod / camera wall holder
Power
Connector
Connects to 5V DC power adapter
Reset to
Default /
*WPS
(IC-3005Wn
only)
Press and hold this button for more than 5 seconds
to reset the camera settings to factory default.
Press the WPS button (click) on the IP Cam and
click on the Access Point that you want to
wirelessly connect it to.
Ethernet
Connector
Connects to your local area network with Ethernet
cable
Tripod Connector
Reset to Default
Power Jack
LAN Port

8
4. Hardware Installation
1. Unpack your Edimax IP Camera from its packaging and ensure
that all the items listed in Chapter 1 are there.
2. Connect the Edimax IP Camera to your network by attaching a
network cable from your switch or router to the LAN port on the
IP Camera.
3. Connect the power adapter to the IP Camera and plug the
adapter into a power outlet. When the IP Camera is ready, the
Blue LED will light up.
Note: It is highly recommended to use only the power adapter
shipped with the IP Camera. Do NOT use any other power adapter
and avoid possible damage to your new device.

9
5. Software Installation
The Installation Wizard will guide you through this simple process.
Below we tell you how to get it started up. The following example is
for Windows Vista. The procedure is similar for Windows
2000/XP/7.
1. Insert the Edimax CD into your CD-ROM drive. It should start
up automatically. If it doesn't, click on “Autorun.exe” in the
“Autorun” folder on the CD.
2. The Install Wizard will give you four options to choose from.
Here you can select program you wish to install. The following
installation steps are a demonstration of installing the
'Administrator Utility & Camera Viewer‟. Click on 'setup utility'.

10
3. The 'Install Wizard' should take you here. Click on „Next‟ to
continue your installation.
4. Click on 'Next' to move to the next step. If you wish to install
the program to an alternate location, click on „Browse‟ and
select a location.

11
5. Click „Next‟ to move on to the next step or make your
selections here.

12
6. Click on „Install‟ to install the program.

13
7. Click „Finish‟ to confirm the software installation.
8. If you have Windows Defender or other 3rd party firewall
software, you may see the following or a similar message,
Please click „Unblock‟ to allow your Edimax IP camera Utility
to pass through the firewall. Not doing so may cause the IP
camera utility to not function optimally.

14
9. A new folder named „Internet Camera‟ under „All Programs‟ will
be created. Click on 'IP Cam Admin Utility' to connect to the IP
camera and use the camera's functions directly.

15
10. After installation, the system will automatically run the
„Administrator Utility‟. On the first page, the cameras found in
your network will be listed. Select the one you wish to
configure and click on the „Configure Camera‟ icon.

16
11. You will be prompted to insert your user name and password.
The default user name is „admin‟ (unchangeable), and the
default password is „1234‟ (changeable). Click „OK‟ to
continue.
12. The program will automatically detect the IP address status of
your network and suggest a free IP address for the IP Camera
using DHCP. You can accept the suggested address or enter
the values manually. If you enter the values manually, ensure
that the „Subnet Mask‟ is the same for both the camera and the
PC. Since the IP Camera works through the network (TCP/IP
Protocol) the IP address setting must be correct for you to
access the IP camera. Click „OK‟ to apply your configuration.

17
6. WEB Management Interface
You can use your WEB browser (Internet Explorer 5.5 or above) to
connect to the IP camera. Type the IP address (see 5.12) in the
address bar of your web browser. Bookmark the address for ease of
future use. You‟ll be prompted to insert a user name and password:
User name: admin / Password: 1234
Once you're logged on, you will see the following message appear
at the top of Internet Explorer. Click on the message, and click
„Install ActiveX Control…‟

18
When you see this message, click ‟Install‟. ActiveX control will be
installed, allowing you to access the IP camera.
You should now be able to see the images and hear the sounds
captured by the Edimax IP camera. For advanced functions, please
refer to instructions in the user manual (also on CD-ROM).

19
R&TTE Compliance Statement
This equipment complies with all the requirements of DIRECTIVE
1999/5/EC OF THE EUROPEAN PARLIAMENTAND THE
COUNCIL of March 9, 1999 on radio equipment and
telecommunication terminal Equipment and the mutual recognition
of their conformity (R&TTE)
The R&TTE Directive repeals and replaces in the directive
98/13/EEC (Telecommunications Terminal Equipment and Satellite

20
