Edimax IC-1520DPg User manual

www.edimax.com EDIMAX TECHNOLOGY CO., LTD.
Digital Pan/Tilt/Zoom to expand the viewing area
The IC-1520DPg is a compact 1.3 megapixels network camera with digital pan-tilt-
zoom to enhance your viewing and monitoring experience. Built-in a wide angle lens,
the IC-1520DPg has a panorama of 128°in horizontal and 99°in vertical. You can
use a smaller viewing window to move around like a magnifier. With a preset path,
the IC-1520DPg will cruise along the path. The IC-1520DPg breaks the viewing area
limit and provides the flexibility to meet your needs.
Fast Center Zoom-in
When something catches your attention, you can zoom-in to see the details and
record at the same time. You won't miss a tiny thing. The IC-1520DPg brings you
the benefit of both the panoramic view and the detail view.
Motion Detection and Snapshots the Triggered Event by E-mail and FTP
The IC-1520DPg is a powerful surveillance system. When the motion detection
mode is on, the IC-1520DPg will snapshot the triggered event and send it by email
or to a FTP server. You don't have to look at the monitor all the time. The IC-
1520DPg can guard the surveillance area automatically.
Supports DDNS & UPnP
The IC-1520DPg can stream the live video to a local network and Internet. With
DDNS features, you can assign a domain name to the IC-1520DPg. To view the
video from Internet because you only need to type the domain name (like
www.edimax.com) in the browser address bar in stead of the IP address. UPnP
allows Window XP/Vista users access the IC-1520DPg by clicking the icon on the
screen system tray without knowing the IP address.
DigitalPan/Tilt
WirelessNetworkCamera IC – 1520DPg
European Headquarters
Edimax Technology Europe B.V.
TEL: [phone]
FAX: [phone]
[email protected]
United Kingdom Office
Edimax Technology (UK) Ltd.
TEL: [phone]
FAX: [phone]
[email protected]
Germany Office
Edimax Technology Europe BV
TEL : [phone]
FAX : [phone]
e-mail : [email protected]
U.S.A. Office
Edimax Computer Company
TEL: [phone]
FAX: [phone]
[email protected]
Headquarters
Edimax Technology Co., LTD.
TEL: [phone]
FAX: [phone]
[email protected]
Poland Office
Edimax Technology Poland SP. Z o.o.
TEL: [phone]
FAX: [phone]
[email protected]
Romania Office
Edimax Technology Romania
TEL: [phone]
FAX: [phone]
[email protected]
Russia Office
Edimax Technology Russia
TEL: [phone]
FAX: [phone]
[email protected]
Latin America Office
Edimax Latin America Inc.
TEL: [phone]
FAX: [phone]
[email protected]
China Office
Beijing Edimax Science &
Technology Co., Ltd.
TEL: [phone]
FAX: [phone]
[email protected]

www.edimax.com EDIMAX TECHNOLOGY CO., LTD.
INTERFACE MANAGEMENT POWER ADAPTER
1 Ethernet ( RJ-45) Port
1 Power Jack
1 Reset Button
1 External Detachable Antenna
Provides Admin Utility, Camera
Viewer & Web browser management
Firmware upgradeable
DC 12V, 0.4A
LED HARDWARE HUMIDITY
LAN
WLAN
Power
1.3M Pixels CMOS Sensor
Manual Focus, F= 2.0
2 MB Flash
16 MB SDRAM
FOV
Horizontal: 128 degrees
Vertical: 99 degrees
10-90%
(Non-condensing)
FUNCTIONS DIMENSION & TEMPERATURE CERTIFICATIONS
View multiple cameras simultaneously - Up to 4
cameras within the local network or anywhere in
the world via the Internet
Supports one administrator account and four user
accounts
Sending snapshot to email and ftp server on a
predetermined schedule
Provides manual focus lens
Supports login free
Supports motion-detection by sending the snapshot
of events to email and ftp server
Records video clips manually or on a predetermined
schedule
Supports video playback
Recording format – Video (AVI)
Snapshot format – Picture (JPEG)
114 X 79 X 50 mm
0~45 ℃CE, FCC
SYSTEM REQUIREMENTS
Windows 98/ME/2000/XP/2003/Vista
Internet Explorer 6.x and above
xDSL broadband router
NETWORK SETUP DIAGRAM AND RELATED PRODUCTS
An example of how the IC-1520DPg can be setup:
• Connect the IC-1520DPg to PC by Ethernet (RJ45) LAN port.
• Install the Admin Utility into your PC and set up the IC-1520DPg IP subnet as same as Broadband Router’s.
• Configure IC-1520DPg with Broadband Router via wireless connection.
• All computers in the local network can now view the IC-1520DPg.
• To view the IC-1520DPg via the Internet, open the http and video ports in the router. Then, you can watch live video
from anywhere in the world.
FEATURES AND TECHNICAL SPECIFICATIONS
