Edimax ES-5800G V2 User manual

8-Port Gigabit Desktop Switch
Description
The ES-5800G V2 is a 10/100/1000 Mbps Ethernet Desktop unmanaged switch designed to enhance network
performance in a compact form factor, and with outstanding performance and high efficiency. The switch uses
store and forward packet-switching technology which offers reliable data transfer. This switch is ideal for
network connectivity for the SOHO environment.
The ES-5800G V2 with plastic housing offers a cost-effective Gigabit Ethernet solution for users to easily extend
home networks and to fulfill their online gaming, multimedia transferring and streaming needs. The plug-and-
play design allows users to easily connect network devices such as PCs, network storages and print servers to the
home network without manual configuration involved.
IEEE Energy Efficient Ethernet (EEE) compliance saves power
The Switch ES-5800G V2 offers environmental efficiency with Fast Ethernet speeds critical for next-generation
network applications. To comply with the IEEE802.3az standard, the Switch ES-5800G V2 provides power saving
functions to reduce energy consumption to help business save cost.
•Inactive link detection
The power usage adjustment feature automatically reduces power usage when any shut down network device or
inactive link is detected. That is, power consumption of the switch can be adjusted according to the link status or
the number of active network devices when possible.
•Cable length detection
The devices equipped with this green feature can automatically detect the length of connected Ethernet cables
and adjust power usage accordingly. The shorter the cable length, the less power it consumes.
Supports High-Speed Networking and Jumbo Frames
The ES-5800G V2 is an excellent solution to expand your Gigabit network. With Gigabit speed, the ES-5800G V2
gives high flexibility and high bandwidth connectivity to servers, workstations and other attached devices. It
enables you to save time when transferring large files. In addition, it also supports Jumbo Frames 9K to improve
network utilization in large files transfer.
Supports Auto-Negotiation
Every port of the ES-5800G V2 can automatically distinguish the connected network devices are running at
10Mbps, 100Mbps and 1000Mbps for Half/Full-Duplex mode . The ES-5800G V2 can adjust the speed and mode
accordingly.
Easy to Use
The ES-5800G V2 is plug-and-play and supports all kind of network protocols to make installation and network
management easy and fast. LED indicators provide a quick and easy way to read port and switch information.
ES-5800G V2
Copyright © 2012 Edimax Technology Co. Ltd. All rights reserved. Maximum performance, actual data rates, and coverage will vary depending on network
conditions and environmental factors. Product specifications and design are subject to change without notice.
www.edimax.com
9K Jumbo frameimproves
performanceof large data transfers
Reduce power
use by over 70%

www.edimax.com
Copyright © 2012 Edimax Technology Co. Ltd. All rights reserved. Maximum performance, actual data rates, and coverage will vary depending on network
conditions and environmental factors. Product specifications and design are subject to change without notice.
8-Port Gigabit Desktop Switch
ES-5800G V2
Features
•Complies with IEEE802.3, IEEE802.3u and IEEE802.3ab standards
•Supports auto MDI/MDI-X crossover detecting and auto correction
•Supports full and half duplex for 10/100Mbps, and full duplex for 1000Mbps
•Wire-speed packet filtering and forwarding rate
•Store-and-forward architecture filters fragment & CRC error packets
•Supports jumbo frames up to 9K bytes
•Supports IEEE802.3az energy efficient Ethernet function
Network Setup Diagram and Related Products
An example to setup ES-5800G V2:
•Connect the ES-5800G V2 to your Router or cable/xDSL modem.
•Connect Print Server, NAS , Smart TV, Laptop, Media Player, Game Console and IP Camera to ES-5800G V2.
Specifications
Standards
Features
Filtering / Forwarding Rates
•IEEE 802.3 10BASE-T
•IEEE 802.3u 100BASE-TX
•IEEE 802.3ab 1000BASE-T
•IEEE 802.3x Flow Control
•IEEE 802.3az Energy Efficient
Ethernet
•8 RJ-45 Ports
•MAC Address: 8K
•Buffer Memory: 128K
•Jumbo Frame: 9K
•Transmission Method: Store and Forward
•1000Mbps Port –1,488,000pps
•100Mbps Port –148,800pps
•10Mbps Port –14,880pps
Transmission Media
LED Indicators
Power Requirement
•10BASE-T Cat. 3, 4, 5 UTP/STP
•100BASE-TX Cat. 5 UTP/STP
•1000BASE-T Cat. 5E UTP/STP
•Per Port: Link/Act
•Per Unit: Power
•DC 5V 1A
Power Consumption
Dimensions
Weight
•3 Watts (Max)
•137 ×76 ×25.5 mm (L x W x H)
•148g
Temperature
Humidity
Certifications
•Operating: 0 to 40℃
•Storage: -20 to 70℃
•Operating: 10 to 90% RH (Non-condensing)
•Storage: 5 to 90% RH (Non-condensing)
•CE
•FCC Class B
Power Saving
