EDS FL - 50 User manual

EDS - INFORMAZIONI TECNICHE
1
Flame Detector
UV + IR
Explosion Proof
Execution
FL - 50
TECNICAL
INSTALLATION
MANUAL
SAFETY
INSTRUCTIONS
EDS - V. Ca' Nova Zampieri 6 - 37057 S. G. Lupatoto - VERONA - Tel. [phone] - Fax [phone] - Email: [email protected] - Web: www.eds.eu
Date: 20-11-2019
File: FL50_ist_11_2019

EDS - INFORMAZIONI TECNICHE
2
FL-50 QUICK INSTALLATION
The FL-50 detector is supplied with the following initial setting:
- IR sensitivity: maximum
- UV sensitivity: maximum
- UV + IR time delay: 5 seconds
- Optics heating (if present): set for nominal 24 Vdc power supply
- Alarm relay: normally de-energized (JP1 jumper in position 2-3)
- Fault relay: normally de-energized (JP2 jumper in position 2-3)
If you already have an FL-50 detector installation experience, follow the steps below.
If you don't have this experience read the whole manual.
1 - Remove the detector from the packaging
2 - Release the bracket from the detector by unscrewing the GH ring (fig.8)
3 - After choosing the correct position to obtain the best protection of the area, fix the bracket to the wall or
ceiling using 4 expansion caps. Connect a 4 mm2 minimum cable to the earth screw (fig.8)
4 - Disassemble the cover of the detector by unscrewing the 4 hexagonal head screws and slowly remove
the electronic optical assembly
5 - Install an ATEX certified cable gland on the corresponding inlet on the base of the appliance.
Respect the 1/2 "NPT - 1/2" GK - M20x1.5 threads. We recommend to use the cable gland EDS type PSC-
12-EMI for maximum protection against electromagnetic interference
6 - Introduce a shielded cable according to local standard with section appropriate to the distance (1.5mm2
up to 500m)
7 - After making the conductors, make the connections as shown in fig.6.
8 - Make the adjustments for the sensitivity, delay of intervention, setting of the relays (fig.2-3-90-10 and
chap.10) and setting of the optics heating system power supply (if existing).
Otherwise, use the initial factory settings
9 - Reinstall the cover with the electronic optical assembly in the base and tighten the 4 hexagonal head
screws. Tightening torque 3 Nm.
10 - Install the appliance on the bracket and, using the GH ring (fig.8), orient the appliance so that its viewing
angle covers the area to be protected
11 - Connect the appliance cable to the control panel
12 - Give power to the appliance and perform a Test run as indicated in chap. 12
NOTE
These instructions are for all FL-50 UV + IR models.
FL-50 IR can be supplied with 1 UV sensor + 1-2-3 IR sensors.
Depending on the model, you will have to use the adjustments according to the installed sensor.
The models and sensors installed are the following:
- FL50-1-1-X-X-X-X-X-X ......... sensor installed UV + IR1
- FL50-1-2-X-X-X-X-X-X ......... sensor installed UV + IR1 + IR2
- FL50-1-3-X-X-X-X-X-X ......... sensor installed UV + IR1 + IR2 + IR3
For example, if you use the FL50-1-1-X-X-X-X-X-X model, you must make the adjustments indicated in these
instructions on the IR1 sensor.

EDS - INFORMAZIONI TECNICHE
3
1- INTRODUCTION
1.1 - This technical manual indicates the instructions for the installation, calibration and start-up of the FL-50 flame detector.
Its installation is extremely simple and takes just a few minutes to complete the operation.
For best results, we recommend reading the instructions below completely and scrupulously complying with what is
indicated.
2- WARNINGS
2.1 - The FL-50 detector is explosion-proof, therefore the installation and maintenance of the detector must be carried out
by competent and qualified personnel. It is the user's responsibility to maintain the FL-50 detector under normal operating
conditions.
3- REFERENCE STANDARDS
4- SAFETY INSTRUCTION
4.1 - These instructions are addressed to qualified personnel in accordance with the national laws including the relative
standards and, where applicable, in accordance with EN60079-17 (verification and maintenance of electrical systems
locatedinroomswhereexplosiveatmospheresmayformandwhichspecifiesthequalificationofthepersonnelassignedto
thesechecks and maintenance.)
4.2 - The FL-50 detector can be installed in areas with danger of explosion: Zone 1 - Zone 2 - Zone 21 - Zone 22.
It must not be installed in a hazardous area classified as Zone 0.
4.3 - The technical data indicated on the container must be respected
4.4 - Changes to the product are not permitted
4.5 - The FL-50 detector must be installed only if it is completely intact
4.6 - Only EDS spare parts must be used
4.7-Ordinaryandextraordinarymaintenanceoperationsmustbecarriedoutonlybyqualifiedpersonnelwiththeapproval
of "expert"personnel
4.8-Thenationalsafetyandaccidentpreventionregulationsandtheinstructionsindicated with the warning triangle in this
technicalmanualmustbestrictlyobserved
FLAME DETECTOR
FL-50
EN60079-17
EN60529
EN50130-4:1995/A2:2003
DirettivaATEX2014/34/UE
EN60079-0(2012)+A11(2013)
EN 60079-1(2014)
EN60079-31(2014)
EN60079-28(2015)

EDS - INFORMAZIONI TECNICHE
4
4.9 - The detector is equipped with ATEX marking
CE 0722 II 2GD Ex db op is IIC T6 Gb
Ex tb IIIC T85 ° C Db
therefore the appliance can be installed in environments with an explosion hazard (gas and dust) zones: 1 - 2 - 21 - 22
5- VALIDITY
5.1-Theseinstructionsarevalidfor the FL-50 flamedetector, when used inareas with potentially explosive atmospheres
according to the ATEX 2014/34 / UE directive
6- OPERATION
6.1 - The FL-50 flame detector is able to detect a flame produced by a fire within its field of vision within a few seconds.
The FL-50 detector reacts with great sensitivity to the emission of infrared IR and ultraviolet UV radiation emitted by a
source of adequate power in its field of vision. However, the emission of IR or UV radiation alone is not sufficient to cause
the alarm. It is in fact necessary that the emission includes both radiations, such as those produced by the flame.
FL-50 is also equipped with special and sophisticated algorithms that analyze the spectrum, the frequency, the intensity and
the duration of the radiation. Only when signals are present that fall within the calibration parameters, the alarm is generated.
This makes the detector highly immune to false alarms.
7- PRECAUTIONS BEFORE INSTALLATION
7.1 -All installation and maintenance operations must be carried out when the device is not live
7.2 - When the cover is opened, great care must be taken not to damage the O-ring type gasket
7.3 - To avoid damaging the cover-bottom coupling, carefully clean the surfaces before coupling them
8- IMPORTANT INSTALLATION RULES
8.1 - Prevent the detector from being exposed to direct sunlight.
The sun is a powerful source of IR and UV radiation.
If this source is modulated by some elements, such as curtains moved by the wind in front of a window, it can cause false alarms.
Therefore outdoor installation must be carried out after careful examination of the environmental conditions and possibly using the
lowest sensitivity levels and the longest intervention delay. The use of the FL50-PSLsunshade is recommended.
8.2 - The positioning of the FL-50 detector must be carried out so as to allow future maintenance operations in an easy and
accessible way.
8.3 - The installation must be so that the detector is not subjected to vibrations and possible shocks.
8.4 - If the FL-50 detector is installed in dirty and dusty places, a periodic verification of the detector operation and a frequent
cleaning of the optical windows is required (chap.13)
8.5 - Prevent the angle of vision of the detector from being obscured by obstacles (shelves, packages, pallets, etc.)
8.6 - Avoid large detector temperature changes.

EDS - INFORMAZIONI TECNICHE
5
The detector must not be installed near heat or cooling sources. The generation of ice or moisture inside or outside the
detector can compromise its functionality. In the presence of such problems, it is useful to use the version of FL-50
equipped with an automatic temperature control system (see detector code). This system keeps the optical windows at
a suitable temperature to obtain regular functionality.
8.7 - Prevent the detector from having a direct view of IR and UV sources that could be modulated by certain environmental
conditions. The presence in the viewing angle of electric arcs produced by welding machines, industrial lighting systems,
gamma rays, etc. can sometimes disrupt the detector's operations. Keep in mind that, to generate an alarm, these
perturbations must persist for a time longer than the time delay programmed on the detector.
Therefore, if the disturbing source acts for a shorter time, no alarm will be generated.
9- INSTALLATION
9.1 - The appliance must be installed on the ceiling or on the wall.
In general, the ceiling position is recommended for the monitoring of materials laid on the floor. In this case, to prevent
the smoke from a hatching fire from obscuring and therefore reducing its sensitivity, we recommend installing the detector
at 1-1.5m from the ceiling.
By loosening the GH ring (fig.8) of the brackets it is possible to orient the appliance in various directions.
9.2 - If several detectors are used in the same environment, avoid having two detectors pointed towards each other.
9.3 - The installation height is in relation to the area to be controlled, bearing in mind that the viewing angle of the detector
is 100 ° C and that its maximum flame detection distance (with a target generated by a flame reference from petrol with
a height of 20 cm within a 33x33x5 cm tray) is 50 m. The graph in fig.4 indicates the protected area as a function of
distance and sensitivity. The sensitivity of the detector is dependent on the flame generated by various liquids and
combustible gases.
In the table of fig. 1 the detection distances according to the flame generated by various elements are listed.
9.4 - To install the cables, 1 or 2 threaded holes 1/2 "NPT - 1/2" GK - M20x1.5 are provided.
The product is supplied without cable gland . It must be the customer's responsibility to use ATEX certified cable
glands in accordance with current plant regulations EN60079-0; EN60079-1; 60079-31 - IP65 protection degree.
We recommend to use the cable gland EDS type PSC-12-EMI for maximum protection against electromagnetic
interference.
9.5 - Open the front cover by loosening the 4 hexagonal head screws and access the terminal board.
Connect the terminals with a fire-resistant multipolar shielded cable according to local standard with adequate insulation
and mechanical resistance (eg. FG7) according to the diagram in fig. 6.
The section of the 2 power supply wires must be at least 1,5 mmq for 500m distance.
The conductors for the other signals (relays, analogue output, etc.) may have a lower section.
Ifyou use the EDS PSC-12-EMI cable gland, the shields ofthe cable must beinstalled as shown in the following figure.
SHIELDCABLE INTERNAL CONDUCTORS

EDS - INFORMAZIONI TECNICHE
6
9.6 - Indication of the terminals - fig. 6 and 8
[V+ V-] - they must be connected to the power supply (+) 11 - 30Vdc
[COM/NC/NA] - are the voltage-free terminals for theAlarm relay. The detector is supplied with normally de-energized
relays. Using the jumper JP1 (fig.10) the condition can be changed (see chap. 10.1)
[COMF/NCF/NAF] - terminals without voltage of the Fault relay. Supplied normally not energized. Using the jumper JP2
(fig.10) the condition can be modified (see chap. 10.1) The Fault signal is generated if the normal internal operations or the
automatic or manual Test of the detector fail (if these options are present - see coding of the detector)
[OUT] - analog output 0-5V - at stepped voltage levels
[0 V ] - error, Fault or defect in the power supply
1 V - regular operation
2 V - UV only alarm (service level - immediate)
3 V - IR only alarm (service level - immediate)
4 V - pre-alarm (service level - immediate)
5 V - alarm (delayed)
Note - Levels 2 and 3V are available as a service function only for installers to check if there are sources of false alarms
in the environment, so that these sources can be obscured / eliminated or the sensitivity level can be lowered to avoid
possible false alarms. Levels 2 and 3V must not be used by control equipment as they do not indicate an alarm.Also the
4 V (pre-alarm) is not an alarm level and should not be used by the control equipment.
[MTEST] - terminal to carry out the Manual Test (if present in the model). It must be connected with a cable to an external
push-button (on or near to the control panel) connected between this terminal and the power supply negative
[AM+ AM-] - (if present in the model) - 4-20mA stepped analog output - at current levels
0 mA - error, Fault or defect in the power supply
4 mA - regular operation
8 mA - UV only alarm (service level - immediate)
12 mA - IR only alarm (service level - immediate)
16 mA - pre-alarm (service level - immediate)
20 mA - alarm (delayed)
Note - The 8 and 12 mA levels are available as a service function only for installers to check if there are sources of false
alarms in the environment, so that these sources can be obscured / eliminated or the sensitivity level can be lowered to
avoid possible false alarms. The 8 and 12 mA levels should not be used by the control equipment as they do not indicate
an alarm. Even the 16 mA (pre-alarm) is not an alarm level and should not be used by the control equipment.
[R-/R+/T-/T] - (if present in the model) - RS485 output - for 2 or 4-wire connection

EDS - INFORMAZIONI TECNICHE
7
10 - SETTINGS
FL-50 can be configured for specific environmental needs (Ta = -20 / + 55 ° C) through a suitable selection of sensitivity
and time delay for the IR and UV sections. Therefore, after careful examination of the environmental characteristics, the
installer has the possibility of setting the detector to obtain the best performance.
10.1 - Setting the relays
Alarm Relay. Supplied normally de-energized. The JP1 jumper (see fig.9) allows, depending on the position, operation
with relay normally energized or not energized. Therefore:
position 1-2 normally excited
position 2-3 normally not excited‘
Fault Relay. Supplied normally de-energized. The JP2 jumper (see fig.9) allows, depending on the position, operation
with relay normally energized or not energized. Therefore:
position 1-2 normally excited
position 2-3 normally not excited
After selection use the correct NC - NA position of the relays.
10.2 - Sensitivity adjustment
The FL-50 detector has two independent adjustment possibilities for the IR and UV section:
IR - 4 sensitivity levels using the Dip_Switch S3 (high - medium / high - medium / low - low) - fig. 9 and tab.fig.2
UV - 4 sensitivity levels using the Dip_Switch S2 (high - medium / high - medium / low - low) - fig. 10 and tab. fig.3
10.3 - Delay of intervention
FL-50 has 4 delay levels for the activation of the alarm relay, which can be selected with the S2 Dip-Switch (fig.10 - fig.3)
• 5 seconds
• 10 seconds
• 20 seconds
• 30 seconds
If the radiation source acts continuously, raising both IR and UV detectors, an alarm signal is generated for a longer time
than the programmed one.
The times indicated above can vary up to 5-30% depending on the programmed sensitivity.
10.4 - Alarm Memory
The alarm memory can be activated via the S2 Dip-Switch (fig. 10 - fig.3). In the event of an alarm the detector remains
in alarm until the power supply is interrupted for at least 5 seconds.
10.5 - Setting the optics heating system (if present in the model)

EDS - INFORMAZIONI TECNICHE
8
FL-50 is supplied with the heating system set for the 24Vdc power supply. If the detector is powered at 12Vdc, the
heating system must be set for 12Vdc using the Dip-Switch S1 (fig.10).
The table in fig.4 indicates the settings for the 12 and 24Vdc voltages.
The automatic heating system intervenes if the room temperature drops below 5 ° C.Above 5 ° C the system is deactivated.
11 - VERIFICATION OF OPERATION
After installation, after the configuration operations and after completely closing the box, it is possible to power the detector
and proceed to check the operation.
11.1 - If false alarms are generated, it must be checked whether disturbing elements exist in the area controlled by the
detector. If necessary, change the sensitivity and time delay settings to compensate for these anomalies.
11.2 - LED indications
When the detector switches on, the White, Red and Yellow LEDs flash three times.
White LED
- flashing every 10 seconds - indicates normal operation
- steady light - when both the IR and UV sections are both activated due to the presence of a flame, a pre-alarm indication
is immediately generated by permanent switching on of the white LED (walk test / preallarm).
Red LED
- steady light - when the detector detects the IR + UV radiation of the flame for a time longer than the programmed time
delay on the detector, the red LED lights up to indicate the alarm condition
Yellow LED
- steady light - indicates the Fault condition during manual or automatic Test
11.3 - If possible, perform a function test as described in point 12.1.
12 - MANUAL AND AUTOMATIC TEST (if present in the model)
The FL-50 detector can be equipped as an option with a Manual and Automatic Test system for checking the operation
of the IR and UV sensors and cleaning the optical windows. The Test consists in activating 1 IR source and 1 UV source
insidethe FL-50 . Activation is activated periodically automatically by the internal electronics or by pressing on a remote
buttoninstalledoutsidethepotentially explosive areaor insidethe explosivezoneprovided itisin explosion-proofexecution
withcharacteristicssuitable for installation in thisarea, connected as indicated intheinstruction manual.
12.1 - Manual Test
Warning! - This test, if successful, causes a true Alarm signal (Alarm output relay is energized and the analogue output
goes to 5V (or 20mA ).
Before performing this Test it is necessary to consider the consequences derived from the detector alarm.
Thereforeitis advisable to block the peripherals(sirens,extinguishing systems, etc.) connected to the detectoralarmrelay
toavoid damage. To allow manualtesting,theMTEST terminal must beconnectedtoan external Normally OpenNOpush-
button (NA). The push-button poles must be connected to the MTEST terminal and the other pole to the detector power
supplynegative. To execute the Manual Test,press the button for about1 second. The detector performs aseries of checks

EDS - INFORMAZIONI TECNICHE
9
and performs the activation of IR and UV signals to simulate the flame for a duration of about 120 seconds.
After this time the detector must go to Alarm and the analogue output (OUT) must indicate 5V (or 20mA).
Ifthe Test has a negativeresult the Fault relay is de-energized(if normally energized) and theanalogue output (OUT) will
indicate 0 V.
12.2 - Automatic Test
The FL50 detector periodically performs an Automatic Test every 24 hours.
If the Automatic Test is successful, no output signal is generated.
If the Test has a negative result no Alarm signal is generated but a Fault signal is generated.
This signal remains active until the cause of the Fault is eliminated
During the Test the detector generates an IR signal and a UV signal that simulate the flame to verify the correct response
of the sensors and associated electronics.
The test lasts about 120 seconds.
During the Automatic Test, the Alarm output relay and the analogue output remain blocked.
13 - FUNCTIONAL TESTING WITH TEST LAMP
For operational testing in the field of flame detectors EDS with infrared sensors IR and ultraviolet UV, we recommend the use
of the FLT-20 Portable Test Lamp. This instrument is suited for testing flame detectors installed in explosion-proof environments
with risk of explosion. In these environments, the flame detectors can not be tested with the use of flames or similar devices.
FLT-20 is explosion-proof Ex-d IIC T6 ATEX certified and therefore can be used in potentially explosive environments classified
as Zone 1 - 2 - 20 -21 - 22.
It should be remembered that in environments with danger of explosion it is absolutely not necessary to carry
out a functional test by lighting a flame.
14 - MAINTENANCE
14.1 - The detector's optical windows must be periodically cleaned to ensure regular operation. The frequency of this
operation must depend on the environmental characteristics. Use an antistatic cloth or a damp cloth to remove the dust.
Use a cloth dampened with slightly soapy water to remove any deposits.
fig.1
ECNATSIDNOITCETED-05LF
ENOIZALEVIRIDAZNATSID-05LF
emalFfoepyT
ammaiFidopiT
]m[ecnatsiDnoitceteD
]m[enoizaleviridaznatsiD
enilosaG
anizneB 05
enahtpE-N
onatpE-N 05
enesoreK
enesoreK 53-03
lhooclAlyhtE
ocilitElooclA 62-22
lonahtE
olonatE 62-22
lonahteM
olonateM 62-22
enahteM
onateM 81-51
)mc09erifemulp(repaP
)mc09otteg(atraC 81-51
)2mc0001tegrat(n
egordyH
oilgasreb(onegordI
)2mc0001
81-51

EDS - INFORMAZIONI TECNICHE
10
fig. 2
PUTESROSNESVU-YROMEM-YALEDEMIT-05LF
TES2SHCTIWSPID
ROSNESVUYTIVITISNES RI+VUYALEDEMIT
)dnoces( YROMEM
12 SUTATS34 SUTATS56SUTATS
NONOMUMIXAMNONO03NOFFONO
NOFFO
MUIDEM
OT
MUMIXAM
NOFF
O02FFOFFOFFO
FFONO
MUIDEM
OT
MUMINIM
FFONO01
FFOFFOMUMINIMFFOFFO5
fig. 3
Fig. 4
Fig. 2 shows how the Dip Swtitch S3 must be set to adjust the sensitivity of the IR sensors
Fig. 3 indicates how the Dip Swtitch S2 must be set to adjust the sensitivity of the UV sensor, the alarm time delay of the
IR + UV section (the delay is the same for both) and the alarm memory (activated or not activated) )
Note - Intervention time delays are related to both the UV and IR sections simultaneously.
In addition, the times indicated above may vary by an increase of 5-30% depending on the programmed sensitivity.
PUTESROSNES-RI-05LF
TES3SHCTIWSPID
YTIVITISNES
1RI2RI3RI
1234 5 6 SUTATS
NONONONONONOMUMIXAM
FFONOFFONOFFONOMUMIXAMOTMUIDEM
NOFFONOFFONOFFOMUMINIMOTMUIDEM
FFOFFOFFOFFOFFOFFOMUMI
NIM
1S-WODNIWLACITPOGNITAEHPUTES
HCTIWSPID
1S 8-17-26-35-4
ccV21
)V51-21( NOFFONONO
ccV42
)V03-42( FFONOFFONO

EDS - INFORMAZIONI TECNICHE
11
fig.5
DETECTION DISTANCE GRAPHICS
25
50
75
100%
sensibilità
50[m] 40 30 20 10
distance [m] sensitivity
[degree]
DS1987A
25
33
40
50
010
20
35
45
60
50
60
50
45
35
20
10
4040
distanza [m] [gradi]
10 20 30 40 50[m]

EDS - INFORMAZIONI TECNICHE
12
Fig. 6
WIRING DIAGRAM
FAULT RELAY
1
R-
V-
AMP -
SHIELD
COMF
CONNECT TO V-
1
ALARM RELAY
2
ANALOG OUT 0-5V
R+ RS485 OUT
COMA
AMP +
NAF
MTEST
2
POWER SUPPLY
P
3
DS1814H
RS485 modul
FAULT RELAY
T-
P
NAA
NCF
T+
3
12/24 Vdc
external button for manual Test
V+
R load 50-300 ohm
EARTH TERMINAL
NCA
ANALOG OUT 4-20mA
ALARM RELAY
JP2
JP1
VERONA (ITALY)
EDS srl
NOTE - the indications of the relays is relate to the initial setting of the relays in the normally unexcited configuration
for the Alarmrelay and not energized for the Fault relay (JP1 jumpers in position 2-3 and JP2 in position 2-3 see chapter
10.1 and fig.9 ).

EDS - INFORMAZIONI TECNICHE
13
fig.7
FL50 - VIEW OF THE TERMINAL BOARD
FL50 - TERMINAL BOARD VIEW
4-20mA module RS-485 module
analog terminal board and Mtest
power and relays terminal board

EDS - INFORMAZIONI TECNICHE
14
Fig. 8
protection elements of the optical windows opticalwindows
FL50 VISTE ESTERNE
FL-50 EXTERNAL VIEW
elementi di protezione delle ottiche
vite di terra
ground screw
finestre ottiche
coperchio con guarnizione OR
cover with O-Ring insulating
gasket
ghiera di fissaggio GH
ring nut GH
supporto orientabile
adjustable support

EDS - INFORMAZIONI TECNICHE
15
FL-50 INTERNAL VIEW - VISTA INTERNA
fig. 10 - dip switch S2
S2
S1
fig. 9 - dip switch S3 - jumper JP1 - JP2
JP2 JP1S3
1 2 3 1 2 3

EDS - INFORMAZIONI TECNICHE
16
TECHNICAL INFORMATION
3 IR + UV
Flame Detector FL-50
APPLICATIONS
• refineries and Oil&Gas installations
• compressor stations
• petroleum products storage (gasoline, paint
thinner etc.).
• paint warehouses
• paper products storehouses
• timber warehouses and silos
• chemical laboratories
• flammable gases tanks and storehouses
TECHNICAL ADVANTAGES
• easy installation
• speed of intervention
• infrequent and inexpensive maintenance
• high immunity to false alarms
• versions with combination of UV and IR
sensors
• optional remote automatic and manual test
• heated optical windows option
• analog, digital and relay outputs
• explosion-proof ATEX certified
The flame detector FL-50 is capable of detecting within a few
seconds a flame produced by a fire within his field of vision. It
finds particular application in the areas where it is presumed
that a fire may develop quickly, such as in storage of oil
products, paints, plastics, alcohols, etc.
The operating principle is based on the detection of infrared
radiation (IR) and ultraviolet light emitted by a flame (UV).
The detector, depending on version, can be equipped with the
following sensors:
• 3 IR infrared sensors with different spectral windows
• 1 UV ultraviolet sensor
The use of this multi-sensor technology and a microprocessor
controlled circuitry and software with specific algorithms, make
the detector very efficient and at the same time highly immune
to false alarms products generally from natural disturbances or
generated in the environment, such as lights , flashes produced
by machines welding, hot objects, etc.
The detector is equipped with a special internal circuit for
automatic periodic test or manual remote test.This test verifies
also the cleaning and the efficiency of the optical windows.
An automatic temperature control of the optical windows
(optional) allows the use of the detector even at very low
temperatures.
The enclosure of the device is made of aluminum alloy in Ex-
d ATEX certified and has remarkable qualities of robustness
and practicality installation.
A special bracket with ball joint, allows the perfect optical
orientation of the device.
FL50 with inox sunshield
ATEX
CERTIFIED

EDS - INFORMAZIONI TECNICHE
17
Electrical data
• nominal power supply: 12 - 24Vdc (11Vdc minimum - 30Vdc maximum)
• consumption: 180 mA max.
• protection against polarity reversal
Performance
• class detectors: X (maximum flame detection distance: 50 m target flame 33x33 cm - height 5 cm)
• optical viewing angle: 100 degrees
• IR spectral response: 0.8 - 4.8 microns (depending on the models)
• UV spectral response: 185 - 260nm
• room temperature: -20 + 55 ° C
• relative humidity: 0 - 90% RH non-condensing
• automatic temperature control system
• internal sensitivity adjustment on 4 levels for IR and 4 levels for UV
• regulation of intervention delay: 4-8-15-30 sec.
• microprocessor controlled electronics
• Internal automatic periodic operation test
• terminals for remote operation test
• immunity to electromagnetic disturbances: according to EN50130-4 standards
Outputs
• alarm output relay: 1 A / 24 Vdc
• fault output relay: 1 A / 24 Vdc
• analogue output: 0-5V
• analogue output: 4-20mA (optional)
• RS485 serial port (optional)
Mechanical data
• container: in light aluminum alloy
• execution: explosion-proof CE 0722 II 2GD Ex db op is IIC T6 Gb
Ex tb IIIC T85 ° C Db
•certification: ATEX - CESI 11ATEX019X
•IP65 protection (EN60529)
• cable exit: hole M20x1.5 (optional threads on request 1/2 "NPT - 1/2" GK)
• application areas: zone 1 - zone 2 - zone 21 - zone 22
• container dimensions with bracket: 130x185 mm
• weight: 3 Kg
TECHNICAL DATA
FL50-X-X-X-X-X-X-X-X
0 - witout UV sensor
1 - with UV sensor
0 - without IR sensor
1 - with 1 IR sensor
2 - with 2 IR sensor
3 - with 3 IR sensor
0 - standard output(Alarm relay + Fault relay + analog output 0-5V
1 - standard output + analog output 4-20mA
2 - standard output+ analog output 4/20mA + RS485 serial port
0 - without automatic and manual Test
1 - with automatic and manual Test
0 - without painting
1 - with painting
0 - AL alloy
1 - INOX AISI 304
2 - INOX AISI 316L
1 - 1 cable outlet M20x1,5
2 - 2 cable outlet M20x1,5
0 - without automatic optical windows heating
1 - with automatic optical windows heating
optional threads on request: 1/2" NPT - 1/2"GK
enclosure
Optional Elements
FL50-PSL - stainless steel sunshield
PSC-12-EMI - cable gland 1/2" - ATEX - EMI
FL-50 AVAILABLE MODELS

EDS - INFORMAZIONI TECNICHE
18
EDS srl
V. Cà Nova Zampieri 6
37057 - San Giovanni Lupatoto
Verona - Italy
tel: [phone] fax: [phone]
email: [email protected] web: www.eds.eu
68.0 80.0
126.0
187.5
130.0
FLANGIA
FLANGE
Ø5.0
FL-50 - OVERALL DIMENSIONS
