INSTRUCTION
MANUAL
otto
Keep for future reference.
To reduce the risk of serious injury or death, read this owner’s
manual prior to using this stroller.
Suitable from children 0 to 20 kg.
Independently safety tested for compliance to the Australian and
New Zealand standard AS/NZS 2088:2013.

WARNINGS
• ALWAYS APPLY THE BRAKES WHEN THE STROLLER IS
STATIONARY.
• DO NOT LEAVE CHILDREN UNATTENDED.
• SECURE THE CHILD IN THE HARNESS AT ALL TIMES.
• DO NOT CARRY EXTRA CHILDREN OR BAGS ON THIS
STROLLER.
• MAKE SURE CHILDREN ARE CLEAR OF ANY MOVING
PARTS IF YOU ADJUST THIS STROLLER.
• THE MAXIMUM WEIGHT OF THE CHILD USING THIS
STROLLER IS NOT TO EXCEED 20KG.
• THE MAXIMUM LOAD OF THE BASKET IS 2KG.
• THE MAXIMUM LOAD ON OF THE CANOPY POCKET IS
1KG.
• USE THE STRAP TO STOP THE STROLLER ROLLING AWAY.
• DO NOT USE ANY ACCESSORIES OTHER THAN THOSE
APPROVED FOR USE WITH THIS STROLLER BY EDWARDS
& CO.
• IT IS UNSAFE TO USE ACCESSORIES NOT APPROVED FOR
USE WITH THIS STROLLER.
• Do not place heavy weights on the handle of the stroller as it will
impact the stability of the frame.
• The stroller is not intended to be a substitute baby cot or bed. It is
only designed to enable safe transportation of children.
• Always take your child out of the stroller when on stairs.
WARNINGS!: TO AVOID
INJURY OR DEATH:
ALWAYS FOLLOW THE MANUFACTURERS INSTRUCTIONS.
READ ALL INSTRUCTIONS CAREFULLY BEFORE ASSEMBLY
AND USE OF THIS STROLLER.
THE CORRECT USE AND MAINTENANCE OF THIS PRODUCT
IS ESSENTIAL.

• Use the safety strap located on the handle at all times.
• It is unsafe to use accessories other than those supplied by
Edwards & Co.
• Keep away from fire and extreme heat. Do not store in
areas that may get particularly hot in summer like roof
space or beside shed walls.
• This stroller is designed for use on flat and gentle sloping
surfaces. Take care on higher sloping or uneven surfaces as
there is a risk of the stroller tipping over.
• There is a risk of fingers being jammed in moving parts
when folding or unfolding the stroller. Take care of fingers
and NEVER let children fold or unfold the stroller.
• This product is designed for walking only. Never run or jog
with this stroller.
• Salt water or excessive moisture may cause corrosion on
the fastenings and moving parts of this stroller. Store your
stroller in a sheltered dry place and avoid beach use where
possible. Corrosion caused by environmental factors is not
covered by the manufacturer warranty.
WARNING! USE THE HARNESS AT
ALL TIMES.
GENERAL WARNINGS (cont.)
Harness
• To avoid serious injury, always use the safety harness when
your child is in the stroller. Always adjust the straps to suit
the size of your child’s body and to fit it firmly. A loose
restraint or harness is DANGEROUS.
• Never leave a harness connected when not fitted to a child
in the stroller. The harness can form loops which may be a
strangulation hazard.
WARNINGS!: TO AVOID
INJURY OR DEATH:

STROLLER COMPONENTS
The product should come with the following:
Main components
• Stroller frame with fabric seat
• Four wheels (two front and two rear)
• Sun conopy
• Storage basket
folding trigger
fold lock
brake
rear wheel
front wheel
sun canopy
buckle

Rear wheels: Installation
Locate the metal rod on the wheel. Insert the rod into the rear wheel
housing located on the axle. The wheel has successfully installed
when you hear a CLICK!
IMPORTANT Once installed, pull the wheel to confirm a proper
connection.
Rear wheels: Removal
Press the button located under each wheel axle and pull the wheel
outwards as pictured.
ASSEMBLY: Wheel installation and removal

Front wheels: Installation
Insert the wheel rod into the front wheel housing until you hear a
CLICK!
IMPORTANT Once installed, pull the wheel to confirm a proper
connection.
Front wheels: Removal
Push the button on the side of the wheel housing and pull downwards
as pictured.
ASSEMBLY: Wheel installation and removal

Unfolding:
1. Stand the stroller upright.
2. Lift the fold lock located on the left hand side of the frame away
from the catch clip.
3. Pull the handle of the stroller upwards.
4. The stroller will unfold and CLICK! into place.
ASSEMBLY: Unfolding the stroller

FOLDING THE STROLLER
Folding:
1. Apply the brakes.
2. Adjust the seat recline to an upright position.
3. On the handlebar, slide the folding trigger to the right and
simultaneously rotate the tubing downwards towards the floor.
4. Push the handlebar downwards towards the floor, then rotate the
handlebar over the seat in an anti-clockwise circle.
5. Once collapsed, ensure the the fold lock engages. This prevents
the stroller from unfolding.

CARRYING THE STROLLER
The stroller can be carried using the in-built handle as pictured.

SEAT RECLINE
To adjust the recline, press the button on the strap toggle at the rear
of the seat and raise or lower the seat to the desired position.
FOOT REST
To raise or lower the leg rest, press the two buttons on both sides of
the leg rest hinge.

USING THE BUCKLE
Locking the buckle
1. Insert each tongue into the buckle until you hear a CLICK!
2. Repeat for each tongue x 4.
Unlocking the buckle
1. Press the button at the centre of the buckle.
SHOULDER STRAP HEIGHT
There are three height slot positions for the shoulder straps. As your
child grows, you will need to move the straps according to your child’s
height. The correct height is where the straps are about level with
your child’s shoulders. The picture on the next page demonstrates
the correct installation.
To adjust the shoulder strap height insert the stops
through harness slots and turn to ensure they are flat.

WARNING! Never leave a harness
connected when not fitted to a child in the stroller. The
harness can form loops which may be a strangulation
hazard.
TIGHTENING & LOOSENING STRAPS
To tighten and loosen the harness, pull the straps through the toggle
on the shoulder strap and/or the crotch strap as pictured.
The straps should be firm but not too tight around your child. You
should be able to fit two fingers in between the harness and your
child.

PARKING BRAKE & SWIVEL LOCK
Parking brake:
To engage the brake, depress the rear of the red brake pedal
downwards. Give the stroller a small jiggle to ensure it engages.
This brake locks both rear wheels.
To release the brake, press the front of the brake pedal downwards.
Front wheel swivel lock:
The swivel lock is located on the front wheel housing.
To lock the swivel, depress the slider downwards.
To free the wheel, lift the slider upwards.
Engaging the brake Releasing the brake

CARING & MAINTENANCE
Important information
• We recommend storing your stroller indoors to avoid corrosion.
• We recommend regular inspection and maintenance of locking
devices and security of essential components.
• Regularly check all parts for wear and tear. Lubricate if tight
with a silicone based product. Do not use spray petroleum
lubricants such as ‘CRC’.
• To clean the lining and/or sun canopy, we recommend sponging
with warm soapy water and a small amount of mild detergent
(such as dishwashing liquid).
• NEVER tumble dry.
• NEVER machine wash.
• NEVER clean with abrasive, ammonia-based, bleach-based or
spirit-based cleaners.
• If the wheels become damaged or worn, discontinue use and
replace.
• Avoid sun exposure for long periods to prevent fading and
damage to the fabric.
• Salt water is extremely damaging to the moving parts of this
stroller. Even salty atmospheric conditions can enter into the
mechanisms of the product. If you use the product near salt
water, please refer to our Servicing Guide found on our website
for proper maintenance. Corrosion is not covered under our
warranty.
• NEVER wring any fabrics.
• Dry thoroughly before storage.
• Store in a well-ventilated area, away from direct sunlight which
could damage or fade your car seat.
• Store in a safe place when it is not being used. Avoid placing
heavy objects on top of it.
• NEVER allow the seat to come into contact with corrosive
substances such as battery acid or petroleum products.

WARRANTY
All Edwards & Co products are guaranteed for two years from the
date of purchase against defects in material and workmanship.
If we determine that the product has a manufacturing fault, we will
repair or replace it free of charge to you. The decision to repair
or replace is solely at the discretion of Edwards & Co. Proof of
purchase must be provided.
The warranty is “return to base” and not a free in-home service. This
means the customer is responsible for any inwards freight charge to
return the product to an Edwards & Co representative for warranty
or service.
Our warranty excludes claims resulting from misuse, abnormal use,
overloading, general wear and tear, child outgrowing the product,
not following instructions, transportation damage (including airline
or freight damage), poorly maintained product, dropped goods,
negligence, second-hand product, modified product, colour fading,
over inflation, mould, damage to handle foam in use or fabric
cuts and tears. Our warranty also does not cover tyre punctures
or corrosion to frames or fasteners as a result of atmospheric or
environmental conditions.
Any replacement will not give the right for the warranty period to be
extended.
Edwards & Co does not cover warranty if the product has been
purchased second hand or from an unauthorised reseller.
For the complete terms and conditions of our warranty, please visit
our website - edwardsandcobaby.com/warranty
