Page 1 of 4 DATA SHEET E85001-0279
Not to be used for installation purposes. Issue 1
EDWARDS®Catalog uIntelligent Initiating
12-18-17
LIFE SAFETY & INCIDENT MANAGEMENT
SIGA-278
Overview
The SIGA-270 and SIGA-278 series Manual Pull Stations are part
of EDWARDS’s Signature Series system. The SIGA-270 Fire Alarm
Manual Pull Stations feature our very familiar teardrop shape. They
are made from die-cast zinc and finished with red epoxy powder-
coat paint complemented by aluminum colored stripes and mark-
ings. With positive pull-lever operation, one pull on the station
handle breaks the glass rod and turns in a positive alarm, ensuring
protection plus fool-proof operation. Presignal models (SIGA-270P)
are equipped with a general alarm (GA) keyswitch for applications
where two stage operation is required. The up-front highly visible
glass rod discourages tampering, but is not required for proper
operation.
EDWARDS’s double action single stage SIGA-278 station is a
contemporary style manual station made from durable red colored
lexan. To initiate an alarm, first lift the upper door marked “LIFT
THEN PULL HANDLE”, then pull the alarm handle.
Standard Features
Note: Some features described here may not be supported by all control sys-
tems. Check your control panel’s Installation and Operation Guide for details.
• Traditional familiar appearance
SIGA-270 models feature our familiar teardrop design with
simple positive pull action and sturdy die-cast metal body.
• One stage (GA), two stage (pre-signal), and double action
models
SIGA-270 models are available for one or two stage alarm
systems. The single stage double action SIGA-278 features a
rugged Lexan housing with keyed reset mechanism.
• Break glass operation
An up-front visible glass rod on the SIGA-270 discourages
tampering.
• Intelligent device with integral microprocessor
All decisions are made at the station allowing lower com-
munication speed while substantially improving control panel
response time. Less sensitive to line noise and loop wiring
properties; twisted or shielded wire is not required.
• ADA Compliant
Meets ADA requirements for manual pull stations.
• Electronic Addressing with Non-volatile memory
Permanently stores programmable address, serial number,
type of device, and job number. Automatically updates historic
information including hours of operation, last maintenance
date, number of alarms and troubles, and time and date of last
alarm.
• Automatic device mapping
Each station transmits wiring information to the loop control-
ler regarding its location with respect to other devices on the
circuit.
• Diagnostic LEDs
Status LEDs; flashing GREEN shows normal polling; flashing
RED shows alarm state.
• Designed for high ambient temperature operation
Install in ambient temperatures up to 120 °F (49 °C).
Manual Pull
Stations
SIGA-270, SIGA-270P,
SIGA-278
MEA
Patented
SIGA-270 SERIES
7150-1657:
0129 S2318

Page 2 of 4 DATA SHEET E85001-0279
Not to be used for installation purposes. Issue 1
Figure 4. Single Stage Systems
Figure 5. Two Stage Systems
Application
The operating characteristics of the fire alarm stations are deter-
mined by their sub-type code or “Personality Code”. NORMALLY-
OPEN ALARM - LATCHING (Pesonality Code 1) is assigned by the
factory; no user configuration is required. The device is configured
for Class B IDC operation. An ALARM signal is sent to the loop
controller when the station’s pull lever is operated. The alarm con-
dition is latched at the station.
Compatibility
Signature Series manual stations are compatible only with ED-
WARDS’s Signature Loop Controller.
Warnings & Cautions
This device will not operate without electrical power. As fires fre-
quently cause power interruption, we suggest you discuss further
safeguards with your local fire protection specialist.
Testing & Maintenance
To test (or reset) the station simply open the station and operate
the exposed switch. The SIGA-270 series are opened with a tool;
the SIGA-278 requires the key which is supplied with that station.
The station’s automatic self-diagnosis identifies when it is defec-
tive and causes a trouble message. The user-friendly maintenance
program shows the current state of each Signature series device
and other pertinent messages. Single devices may be deactivated
temporarily, from the control panel. Availability of maintenance
features is dependent on the fire alarm system used.
Scheduled maintenance (Regular or Selected) for proper system
operation should be planned to meet the requirements of the
Authority Having Jurisdiction (AHJ). Refer to current NFPA 72 and
ULC CAN/ULC 536 standards.
Wiring Notes
1 Refer to Signature Loop Controller manual for maximum
wire distance.
2. All wiring is power limited and supervised.
Typical Wiring
The fire alarm station’s terminal block accepts #18 AWG (0.75mm2)
to #12 AWG (2.5mm2) wire sizes. See Signature Loop Controller
catalog sheet for detailed wiring requirement specifications.

Page 3 of 4 DATA SHEET E85001-0279
Not to be used for installation purposes. Issue 1
Figure 2. SIGA-270, SIGC-270F, SIGC-270B installation
Figure 3. SIGA-270P, SIGC-270PB installation
Installation
Single-stage Signature Series fire alarm manual pull stations mount to North American 2½ inch (64 mm) deep 1-gang boxes.
Two stage presignal (270P) models require 1½ inch (38 mm) deep 4-inch square boxes with 1-gang, ½-inch raised covers. Openings
must be angular. Rounded openings are not acceptable. Recommended box: Steel City Model 52-C-13; in Canada, use Iberville Model CI-
52-C-49-1/2.
All models include terminals are suited for #12 to #18 AWG (2.5 mm2to 0.75 mm2) wire size. EDWARDS recommends that these fire
alarm stations be installed according to latest recognized edition of national and local fire alarm codes.
Electronic Addressing:The loop controller electronically addresses each manual station, saving valuable time during system com-
missioning. Setting complicated switches or dials is not required. Each station has its own unique serial number stored in its on-board
memory. The loop controller identifies each device on the loop and assigns a “soft” address to each serial number. If desired, the stations
can be addressed using the SIGA-PRO Signature Program/Service Tool.
Figure 1. SIGA-278 installation
LIFT
NORMAL
Cover Release
Screw
Compatible
Electrical Box
with ½-inch
raised covers
Glass Rod
Release Lever
Toggle
Switch
Back
Plate
Do not use
boxes with
rounded
openings.

Page 4 of 4 DATA SHEET E85001-0279
Not to be used for installation purposes. Issue 1
12-18-17
LIFE SAFETY & INCIDENT MANAGEMENT
Contact us...
Email: edwards.fi[email protected]
Web: edwards-fire.com
1016 Corporate Park Drive
Mebane, NC 27302
EDWARDS is a registered mark in the
United States and other countries.
© 2018 United Technologies Corporation.
All rights reserved.
Specifications
Ordering Information
Catalog Number
SIGA-270, SIGC-
270F, SIGC-270B
SIGA-270P,
SIGC-270PB SIGA-278
Description Single Action
- One Stage
Single Action -Two
Stage (Presignal)
Double Action
- One Stage
Addressing
Requirements
Uses 1 Module
Address
Uses 2 Module
Addresses
Uses 1 Module
Address
Operating Current Standby = 250µA
Activated = 400µA
Standby = 396µA
Activated = 680µA
Standby = 250µA
Activated = 400µA
Construction & Finish Diecast Zinc - Red Epoxy
with aluminum markings
Lexan - Red with
white markings
Type Code Factory Set
Operating Voltage 15.2 to 19.95 Vdc (19 Vdc nominal)
Storage and Operating
Environment
Operating Temperature: 32ºF to 120ºF (0ºC to 49ºC)
Storage Temperature: -4ºF to 140ºF (-20ºC to 60ºC) Humidity: 0 to 93%
RH
LED Operation On-board Green LED - Flashes when polled
On-board Red LED - Flashes w hen in alarm
Compatibility Use With: Signature Loop Controller
Agency Listings UL, ULC (note 1), MEA, CSFM, FM
Note: SIGC-270F, SIGC-270B and SIGC-270PB are ULC listed only. Suffix “F” indicates French markings.
Suffix “B” indicates English/French biling ual markings.
Catalog
Number Description
Ship Wt.
lbs (kg)
SIGA-270 One Stage Fire Alarm Station, English Markings - UL/ULC Listed
1 (0.5)
SIGC-270F One Stage Fire Alarm Station, French Markings - ULC Listed
SIGC-270B One Stage Fire Alarm Station, French/English Markings - ULC Listed
SIGA-270P Two Stage (Presignal) Fire Alarm Station, English Markings - UL/ULC
Listed
SIGC-
270PB
Two Stage (Presignal) Fire Alarm Station, French/English Markings
- ULC Listed
SIGA-278 Double Action (One Stage) Fire Alarm Station, English Markings
- UL/ULC Listed
Accessories
32997 GA Key w/Tag - for pre-signal station (CANADA ONLY)
0.1 (.05)
276-K2 GA Key - for pre-signal station (USA ONLY)
276-K1 Station Reset Key, Supplied with all Key Reset Stations
27165 12 Glass Rods - for SIGA-270 series (CANADA ONLY)
270-GLR 20 Glass Rods - for SIGA-270 series (USA ONLY)
276-GLR 20 Glass Rods - for SIGA-278 series
276B-RSB Surface Mount Box, Red - for SIGA pull stations 1 (0.6)
