Efco SA 9500 Assembly instructions

EFCO it‘s an EMAK S.p.A. trademark
42011 Bagnolo in Piano (RE) Italy
COMET USA, INC. • www.efcopower.com
EN OPERATOR’S INSTRUCTION MANUAL
FR MANUEL D’UTILISATION ET D’ENTRETIEN
ES MANUAL DE INSTRUCCIONES

English 5
Français 20
Español 36

1
3
2
11
10
9
12
13
14
7
8
15
4
5
6
16
17
18
19
20
D
C
A
B
1
2

OK
1
3 4
6
8
12
5
11
7
9
A
B
1
2
3
4
RCJ6Y
0,5 mm
0,020”
13
15
17 18
19
14 16
4321 5

1
2
3
4
RCJ6Y
0,5 mm
0,020”
13
15
17 18
19
14 16
4321 5

5
en
GB
F
D
E
NL
P
GR
TR
CZ
SK
RUS
UK
PL
H
LV
EST
LT
RO
INTRODUCTION
To correctly use the blower and prevent
accidents, do not start work without having first
carefully read this manual. You will find
explanations concerning the operation of the
various parts plus instructions for necessary
checks and relative maintenance.
Note: Illustrations and specifications in this
manual may vary according to Country
requirements and are subject to change
without notice by the manufacturer.
THE OPERATOR’S MANUAL
Your operator’s manual is for your protection.
READ IT. Keep it in a safe place for reference.
Know what you are doing before you begin
assembly of the unit. Proper preparation and
upkeep go hand-in-hand with satisfactory
performance of the saw and safety.
Contact your dealer or the distributor for your
area if you do not understand any of the
instructions in this manual.
In addition to the operating instructions, this
manual contain paragraphs that require your
special attention.
Such paragraphs are marked with the symbols
described below:
Warning: where there is a risk of an accident or
personal injury or serious damage to property.
Caution: where there is a risk of damaging the
machine or its individual components.
WARNING - To ensure safe and correct
operation of the blower, this operator's
manual should always be kept with or near
the machine. Do not lend or rent your blower
without the operator's instruction manual.
WARNING: Allow only persons who
understand this manual to operate your
blower.
CONTENTS
1. UNDERSTANDING SAFETY LABELS __ 5
2. BLOWER COMPONENTS ___________ 5
3. SAFETY RULES ___________________ 6
4. ASSEMBLY_______________________ 8
5. STARTING - USE __________________ 9
6. STOPPING THE ENGINE ____________ 13
7. MAINTENANCE___________________ 14
8. STORAGE________________________ 17
9. TECHNICAL DATA _________________ 18
10. TROUBLE SHOOTING CHART _______ 19
1. UNDERSTANDING SAFETY LABELS
(Fig.19)
1. Your manual contains special messages to
bring attention to potential safety concerns,
machine damage as well as helpful operating
and servicing information. PLEASE READ ALL
THE INFORMATION CAREFULLY TO AVOID
INJURY AND MACHINE DAMAGE.
2. Wear eye, hearing and head protection when
operating this equipment.
3. WARNING! The blower may throw objects at
high velocity that can ricochet and hit the
operator. This may cause serious eye damage.
4. The blower operator must make sure that no
bystanders or animals come nearer than 35
feet (10 metres). Whenever several operators
are working in the same work area, they
should maintain a safe distance of at least 35
feet (10 metres) from one another.
5. Noise pressure level measured at 30 feet (10
metres) distance according to ANSI
B175.2-1996
2. BLOWER COMPONENTS (Fig. 1)
1. Frame
2. Air lter
3. Spark plug
4. Starter handle
5. Engine cowling
6. Fuel tank
7. Harness
8. Cushion
9. Elbow tube
10. Flexible tube
11. Control handle
12. 13. 14. Blower tubes
15. Vibration mounts
16. Combination wench
17. M5x65 screws (no.2)
18. M6 nuts (no.2)
19. 90 mm dia. hose clamps (no.2)
20. Antistatic cable

6
en
GB
F
D
E
NL
P
GR
TR
CZ
SK
RUS
UK
PL
H
LV
EST
LT
RO
3. SAFETY RULES
State and Local Requirements
The engine is NOT equipped with a Spark Arrester
System complying with the requirements of SAE
Recommended Practice J335 and California Codes
4442 and 4443. All national forest land and land
managed by the states of California, Maine,
Washington, Idaho, Minnesota, New Jersey and
Oregon require internal combustion engines to
be equipped with a spark arrester screen by
law. Other states and federal agencies are
enacting similar regulations.
Operating this engine in a state or locale where
such regulations apply, could result in a violation
of the law.
Note: When using a blower for logging
purposes, refer to Code of Federal
Regulations, Parts 1910 and 1928.
WARNING: The ignition system of your
unit produces an electromagnetic
field of a very low intensity. This field may
interfere with some pacemakers. To reduce
the risk of serious or fatal injury, persons with
pacemaker should consult their physician
and the pacemaker manufacturer before
operating this tool.
WARNING: Muffler surfaces are very hot
during and after operation of the blower,
keep all body parts away from the muffler.
Serious burns may occur if contact is made
with the muffler.
WARNING: Exposure to vibrations
through prolonged use of gasoline
powered hand tools could cause blood
vessel or nerve damage in the fingers, hands,
and wrists of people prone to circulation
disorders or abnormal swellings. Prolonged
use in cold weather has been linked to blood
vessel damage in otherwise healthy people. If
symptoms occur such as numbness, pain, loss
of strength, change in skin color or texture, or
loss of feeling in the fingers, hands, or wrists,
discontinue the use of this tool and seek
medical attention.
WARNING: The engine exhaust from this
product contains chemicals known to
the State of California to cause cancer, birth
defects or other reproductive harm. Operate
your blower outdoors only in a well ventilated
area.
Basic Safety Precautions
• Read this manual carefully until you
completely understand and can follow all
safety rules, precautions, and operating
instructions before attempting to use the
unit.
• Restrict the use of your blower to adult users
who understand and can follow safety rules,
precautions, and operating instructions
found in this manual. Minors should never be
allowed to use a blower.
• Do not handle or operate a blower when you
are fatigued, ill, or upset, or if you have taken
alcohol, drugs, or medication. You must be in
good physical condition and mentally alert.
Blower work is strenuous. If you have any
condition that might be aggravated by
strenuous work, check with your doctor
before operating a blower. Be more cautious
before rest periods and towards the end of
your shift.
• Keep children, bystanders, and animals a
minimum of 35 feet (10 meters) away from
the work area. Do not allow other people or
animals to be near the blower when starting
or operating the blower.
• While working with the blower, always use
safety protective approved clothing. The use
of protective clothing does not eliminate
injury risks, but reduces the injury effects in
case of accident. Consult your trusted
supplier to choose equipment in compliance
with legislation. The clothing must be proper
and not an obstacle.Wear adherent protective
clothing. Protective jackets and dungarees
are ideal. Do not wear clothes, scarves, ties
or bracelets that get stuck in wood or twigs.
Tie up and protect long hair (example with
foulards, cap, helmets, etc.). Wear safety
boots having skid-proof sole and anti-
piercing insert. Wear protective goggles or
face screens. Use protections against
noises: for example noise reduction ear
guards or earplugs. The use of protections
for the ear is very important, because the
perception of danger audio signals
(screaming, alarms, etc.) is limited. Always

7
en
GB
F
D
E
NL
P
GR
TR
CZ
SK
RUS
UK
PL
H
LV
EST
LT
RO
remove your hearing protection as soon as
the engine stop. Wear gloves that permit
the maximum absorption of vibrations.
WARNING – Wear face mask when
operating the blower in dusty
environments.
• Only loan your blower to expert users who
are completely familiar with blower opera-
tion and correct use. Give other users the
manual with operating instructions, which
they have to read before using the blower.
• Check the blower each day to ensure that
each device, whether for safety or otherwise,
is functional.
• Never use a damaged, modified, or impro-
perly repaired or assembled blower. Do not
remove, damage or deactivate any of the
safety devices.
• Carefully plan your blowing operation in
advance. Do not start blowing until you have
a clear work area, secure footing.
• All blower service, other than the operations
shown in the present manual, have to be
performed by competent personnel.
• It is unadvisable to hitch tools or applications
to the P.t.o. that are not specified by the
manufacturer.

WARNING - The blower may throw objects
at high velocity that can ricochet and hit the
operator. This may cause serious eye damage.
Always wear eye protection.
Fuel Handling
WARNING: Gasoline is an extremely
flammable fuel. Use extreme caution
when handling gasoline or fuel mix. Do not
smoke or bring any fire or flame near the fuel
or the blower.
·To reduce the risk of fire and burn injury,
handle fuel with care. It is highly flammable.
· Mix and store fuel in a container approved for
gasoline.
· Mix fuel outdoors where there are no sparks or
flames.
· Select bare ground, stop engine, and allow to
cool before refueling.
· Loosen fuel cap slowly to release pressure and
to keep fuel from escaping around the cap.
· Tighten fuel cap securely after refueling. Unit
vibration can cause an improperly tightened
fuel cap to loosen or come off and spill
quantities of fuel.
· Wipe spilled fuel from the unit. Move 10 feet
(3 m) away from refueling site before starting
engine.
· Never attempt to burn off spilled fuel under
any circumstances.
· Do not smoke while handling fuel or while
operating the blower.
· Store fuel in a cool, dry, well ventilated place.
· Never place the blower in a combustible area
such as dry leaves, straw, paper, etc.
· Store the unit and fuel in an area where fuel
vapors cannot reach sparks or open flames
from water heaters, electric motors or switches,
furnaces, etc.
· Never take the cap off the tank when the
engine is running.
· Never use fuel for cleaning operations.
· Take care not to get fuel on your clothing.
Operation and Safety
WARNING: Use a firm grip with thumbs
and fingers encircling the blower handles.
• Keep all parts of your body away from the
blower when the engine is running.
• Always carry the blower with the engine
stopped. When transporting in a vehicle
properly secure your blower to prevent
turnover, fuel spillage and damage to the
blower.
• Before you start the engine, make sure the
blower is not directed to people.
• Shut off the engine before setting down the
blower. Do not leave the engine running
unattended.
• Only use the blower in well-ventilated places,
do not operate the blower in explosive or
flammable atmospheres or in closed
environments.

8
en
GB
F
D
E
NL
P
GR
TR
CZ
SK
RUS
UK
PL
H
LV
EST
LT
RO
WARNING: Beware of carbon monoxide
poisoning.
• Do not operate blower from a ladder, in a tree
or on a root top. Always work from a firm-
footed and safe position.
• Do not work near electric cables.
• Keep the handle dry, clean, and free of oil or
fuel mixture.
• Stand with your weight evenly balanced on
both feet.
• Do not overreach. You could be drawn or
thrown off balance and lose control of the
blower.
Precautions to Reduce Vibration Risk
· The blower is provided with anti-vibration (AV)
system; never alter or modify it.
· Wear gloves and keep your hands warm.
· Maintain a firm grip at all times, but do not
squeeze the handles with constant, excessive
pressures, take frequent breaks. All the above
mentioned precautions do not guarantee that
you will not sustain whitefinger disease or
carpal tunnel syndrome. Therefore, continual
and regular users should monitor closely the
condition of their hands and fingers. If any of
the above symptoms appear, seek medical
advice immediately.
Maintenance Precaution
WARNING: Never operate a blower that is
damaged, improperly adjusted, or is not
completely and securely assembled.
WARNING: All blower service, other
than items in the Operator's Manual
maintenance instructions, have to be
performed by competent blower service
personnel. (If improper tools are used to
remove the flywheel or clutch, or if an
improper tool is used to hold the flywheel in
order to remove the clutch, structural damage
to the flywheel could occur which could
subsequently cause the flywheel to burst and
serious injury could result.)
WARNING:
Never modify your blower in any way.
Keep the handles dry, clean, and free of oil or
fuel mixture.
WARNING: Use only accessories and
replacement parts recommended.
• Never attempt to service the blower while
the engine is running.
• Never use fuel for cleaning operations.
• Keep the blower in a dry place, off the ground
and the tanks empty.
• If your blower is no longer usable, dispose of
it properly without damaging the
environment by handing it in to your local
Dealer who will arrange for its correct
disposal.
• Replace immediately any safety device when
damaged or broken.
WARNING: The muffler and other parts
of the engine (e.g. fins of the cylinder,
spark plug) become hot during operation
and remain hot for a while after stopping the
engine.
To reduce risk of burns do not touch the
muffler and other parts while they are hot.
4. ASSEMBLY
Assembling the tubes/handgrip
WARNING – When fitting the tube and
nozzle, the engine must be off and the switch
in the STOP position.
To assemble the blower read the following
instructions.
Machine components
Refer to Fig.3:
1. Insert the elbow tube into the fan casing.
2. Secure the elbow with the two screws and
two nuts supplied using the hex wrench
incorporated in the spark plug wrench
(supplied).
Refer to Fig.2:
1. Fit the hose clamps on the two ends of the
exible tube (10, Fig.1), without tightening
them.
2. Fit the exible tube onto the elbow tube (9,
Fig.1) and onto the blower tube (12, Fig.1)
taking care to ensure that the cone (A, Fig.2)
is positioned towards the blower tube; now
tighten the two hose clamps using the

9
en
GB
F
D
E
NL
P
GR
TR
CZ
SK
RUS
UK
PL
H
LV
EST
LT
RO
supplied wrench.
3. Fit the control handle (11, Fig.1) on the
blower tube (12, Fig.1) after fully undoing
the screw located under the locking lever
(Fig.5) using the supplied hex wrench.
Refer to Fig.4:
1. With the locking lever in its lowered
position (locked), tighten the screw
suciently to secure the control handle to
the blower tube but without tightening it
fully. Do not tighten the screw with the
lever in the open position.
2. Wind the antistatic cable around the blower
tube in a spiral (B, Fig.2) and insert it into the
hole in the blower tube; connect the end of
the antistatic cable Bto the terminal in the
control handle (as shown in circle C, Fig.2).
3. Couple the blower tubes (13-14, Fig.1)
by means of the bayonet tting (see the
bayonet tting in the enlarged view in circle
D, Fig.2).
Adjusting the control handle
Correct positioning of the control handle
is extremely important in order to work
comfortably with the blower. To adjust the
control handle position:
1. Raise the locking lever (1, Fig.5).
2. Find the most comfortable working position
by sliding the control handle and adjusting
its angle.
3. When you nd the preferred position, lock
the control handle by lowering the locking
lever.
Adjusting the harness and quick release
WARNING - The harness must be
adjusted with the engine stopped.
Before using the blower it is extremely
important to ensure the weight of the machine
is correctly balanced on your shoulders. This is
done by adjusting the length of the shoulder
straps until the machine is perfectly in contact
with your back and shoulders.
Note that correct balancing of the machine
is especially important when working on
gradients. To tighten the shoulder straps pull as
shown in Fig.7.
To loosen the shoulder straps lift the buckle
with the movement shown in Fig.8.
In the presence of danger, release the
machine from your shoulders by proceeding
as follows:
1. Use one hand to press the quick release tabs
on the right-hand shoulder strap (shown in
the box in Fig.6) as shown in Fig.9.
2. Accompany the machine by bending your
upper body slightly to the left: the blower
will slide o your shoulders.
5. STARTING
FUELING
This product is powered by a 2-cycle engine and
requires pre-mixing gasoline and 2-cycle oil.
Pre-mix unleaded gasoline and 2-cycle engine oil
in a clean container approved for gasoline.
RECOMMENDED FUEL: THIS ENGINE IS
CERTIFIED TO OPERATE ON UNLEADED GASOLINE
INTENDED FOR AUTOMOTIVE USE WITH AN
OCTANE RATING OF 89 ([R + M] / 2) OR HIGHER.
Mix 2-cycle engine oil with gasoline according to
the instructions on the package.
We strongly recommend the use of 2% (1:50)
Efco two cycle engine oil, which is specifically
formulated for all air-cooled two-stroke engines.
The correct oil / fuel proportions shown in the
table are suitable when using an equivalent high-
quality engine oil (JASO specification FD or ISO
specification L-EGD).
CAUTION: DO NOT USE AUTOMOTIVE OIL
OR 2-CYCLE OUTBOARD OIL.
GASOLINE OIL
2% - 50:1
ℓ ℓ (cm3)
1
5
10
15
20
25
0,02
0,10
0,20
0,30
0,40
0,50
(20)
(100)
(200)
(300)
(400)
(500)

10
en
GB
F
D
E
NL
P
GR
TR
CZ
SK
RUS
UK
PL
H
LV
EST
LT
RO
CAUTION:
- Match your fuel purchases to your
consumption; don’t buy more than you
will use in one or two months;
- Store gasoline in a tightly-closed
container in a cool, dry place.
CAUTION - For the mixture, never use a
fuel with an ethanol percentage higher
than 10%; gasohol (mixture of gasoline and
ethanol) up to 10% ethanol or E10 fuel are
acceptable.
When using an Oxygenated Gasoline a good
practice of Fuel Management is necessary.
Gasoline Oxygenated with alcohol readily takes/
up water when it is present; the water may be
condensed out of humid air or be a contaminant
in the fuel system, including tank.
The use of Oxygenated Gasoline may cause the
occurrence of vapor-lock easier.
NOTE - Prepare only the quantity of mixture
required for immediate use; do not leave fuel in
the tank or a container for a long time. Were
commend the use of the additive if the mixture is
to be stored for 12 months.
Alkylate gasoline
CAUTIONS – Alkylate fuels have different
density than normal fuel. Therefore
engines, set with normal fuel, need different H
jet regulation to avoid critical issues. For this
operation it’s necessary turned at a Licensed
Service Dealer.
FILLING THE TANK
Stir the mixture well before refuelling.
If you are using a petrol can to prepare the
mixture, make sure the container is clean
and mix for at least a minute to ensure the
oil is properly dissolved in the petrol. The oil
percentages are shown in the tables below.
WARNING: Follow safety instruction for
fuel handling. Always shut off engine
before fuelling. Never add fuel to a machine
with a running or hot engine. Move at least 3
m from refuelling site before starting engine.
DO NOT SMOKE!
1. Clean surface around fuel cap to prevent
contamination.
2. Loosen fuel cap slowly.
3. Carefully pour fuel mixture into the tank.
Avoid spillage.
4. Prior to replacing the fuel cap, clean and
inspect the gasket.
5. Immediately replace fuel cap and hand
tighten. Wipe up any fuel spillage.
NOTE: It is normal for smoke to be emitted
from a new engine during and after first use.
WARNING: Check for fuel leaks, if any
are found, correct before use. Contact a
Servicing Dealer if necessary.
USE
Preparation for Working
1. Operate the blower only at reasonable hours,
i.e. not early in the morning or late at night
when people might be disturbed. Comply
with times listed in local ordinances.
2. Operate the blower at the lowest possible
throttle setting to do the job.
3. Check the condition of the blower before
operation, especially the muffler, air intake
and air filter.
4. Under dusty conditions, slightly spray the
work area with a hose or use a mister
attachment when water is available.
5. Watch out for children, pets, open windows
or cars, and blow debris safely away.
6. Use the full nozzle extension so the air
stream can work close to the ground.
7. After using the blower, clean up and dispose
of debris in trash receptacles.
What do leaf blowers do?
You can use a leaf blower to:
• Remove and gather leaves. To remove
rubbish or grass cuttings from roads,
footpaths, parks, parking lots, outhouses and
sports grounds, etc.
• Remove grass clippings
• Dislodge or break up matted grass
• Clean parking lots
• Clean farm and construction equipment
• Clean arenas and amusement parks
• Remove light or fluffy snow

11
en
GB
F
D
E
NL
P
GR
TR
CZ
SK
RUS
UK
PL
H
LV
EST
LT
RO
• Dry off pavement and outdoor areas
• To remove rubbish from corners, round
connections, and between paving stones,
etc.
Operating courtesy
• Follow local rules and ordinances about
when to use leaf blowers. Do not use very
early in the morning or very late in the day.
• Check wind direction and intensity. Never
point the nozzle or blow debris toward
people, pets, cars or houses.
• Do not blow debris toward open windows or
doors.
• Always be considerate of people passing by
and of property.
• Do not leave the blower running when
unattended.
• Do not use a blower to spread or mist
fertilizers,chemicalsor other toxic substances,
fuel, unless it is designed for these purposes
and in an appropriate area.
• Use the lowest possible throttle speed to do
the job.
• Avoid using more than one machine at a
time, especially in neighborhoods or around
buildings where sound can be intensified.
Reducing dust
• Pay attention to what you are moving.
• Practice moving grass clippings or a paper
cup without moving dust.
• Wet dusty areas down first before using a
blower.
• Never use a leaf blower to move excessively
dusty materials.
• A leaf blower should NOT be used to clean
up:
— Large amounts of gravel or gravel dust
— Construction dirt
— Plaster dust
— Cement and concrete dust
— Dry garden topsoil
WARNING!– Dust with silica in its
composition may contain crystalline
silica. Silica is a basic component of sand,
quartz, brick, clay, granite and numerous
other materials and rock, including masonry
and concrete products. Repeated and / or
substantial inhalation of airborne crystalline
silica can cause serious or fatal respiratory
disease, including silicosis. In addition, the
state of California and some other authorities
have listed respirable crystalline silica as
a substance known to cause cancer. When
encountering such materials, always follow
the respiratory precautions mentioned above.
WARNING!– Breathing asbestos dust
is dangerous and can cause severe or
fatal injury, respiratory illness or cancer.
The use and disposal of asbestos containing
products have been strictly regulated by
OSHA and the Environmental Protection
Agency. Do not blow or disturb asbestos or
asbestos containing product, such as asbestos
insulation. If you have any reason to believe
that you might be disturbing asbestos,
immediately contact your employer or local
OSHA representative.
If the substance being blown is a commercial
substance, review the material safety data sheet
for that substance or consult the material
manufacturer.
TO BLOW AWAY DEBRIS ON THE GROUND
WARNING! - When fitting the blower tube
and nozzle, the engine must be switched
off and the stop switch must be in the stop
position (2, Fig.13).
1. Adjust the harness so that the machine is easy
to carry (Fig. 7 - 8).
2.
The speed of the air jet is regulated by means of the
throttle (1, Fig. 13).
Select the speed which is best suited for the
application. Once the setting is identified, the
throttle limiter (4, Fig.13) can be used to
maintain and retrieve it accurately.
Full throttle is obtained when the limiter (4) is
pushed fully up.
Blowing
WARNING – Constantly check the area
in which you are working: never direct
the air jet towards people or animals.The
blower can propel small objects at very high
speed. Stop the engine immediately if you are
approached.

12
en
GB
F
D
E
NL
P
GR
TR
CZ
SK
RUS
UK
PL
H
LV
EST
LT
RO
WARNING! – Never remove the cowl when
the engine is running. The fan rotor could
cause serious bodily injury, especially to the
hands.
Before you begin blowing, put on the required
safety equipment.
WARNING! - When working with the
blower, wear the required protecting
equipment:
1. Hearing protection.
2. Eye protection.
3. Face mask in dusty environments.
WARNING! - Be careful, particularly if
left hand operation is applied. Avoid any
direct body contact with the exhaust outlet
area.
WARNING! - Never start the blower if the
inspection cover is not closed, is damaged
or cannot be closed.
WARNING! - Do not operate the blower
while standing on a ladder or a stand.
WARNING - Don’t walk backward while
operating the machine.
WARNING - Never attempt to blow hot or
burning substances or combustible fluids.
Start the blower as described on page 12. Work
according to the following instructions:
1. Never blow air toward fixed objects such as
walls, large rocks, automobiles and fences.
2. When working inside corners, blow from the
corner and inward toward the center of the
work area. Otherwise, debris can fly up in
your face and cause eye injury.
3. Never point the blower nozzle at delicate
plants.
Work Area Precautions
• Never allow children to operate your blower.
Only allow others to use this blower who
have read this Operator's Manual or received
adequate instructions for the safe and proper
use of this blower.
• Do not work near electrical wires or buildings.
• Work only when visibility and light are
adequate for you to see clearly.
• Donot work from a ladder,this is extremely
dangerous. Leave this operation for
professionals.
• Stop the engine before setting the blower
down.
• Be particularly cautious and alert while
wearing hearing protection because such
equipment may restrict your ability to hear
sounds indicating danger (calls, signals,
warnings, etc).
• Be extremely cautious when working on
slopes or uneven ground.
STARTING THE ENGINE
STARTUP PROCEDURE
Blower controls – Control handle (Fig.13)
· To accelerate press throttle trigger (1)
together with safety lever (3).
· To start the engine switch (2) must be set to
“1”.
· If you want to work with the engine at xed
speed, press safety lever (3) and move lever
(4) towards the “+” mark until obtaining the
required engine rpm. To disable the xed
speed setting, return the lever to the “-”
position.
· To stop the engine, set switch (2) to “0”.
Starting
Before starting the engine:
· Place the machine on an area of at ground.
· Check that the switch (2, Fig.13) is not in
position“0” (o).
· Make sure that there is no one near the
machine and/or in front of the blower tube.
Starting a cold engine (engine stopped for
more than 30 minutes)
· Press the primer bulb (A, Fig.12) fully down,
slowly, 10 times.
· Lower the choke lever (B, Fig.12) until you
hear a click.
· Check that the switch (2, Fig.13) is in position
“1”(on).
· Place your left hand on the engine cowling
and your left foot on the frame to keep the
machine steady.
· Use your right hand to pull the handle (4,
Fig.1) until you encounter slight resistance.
Without releasing the rope, pull with a short
sharp gesture. Pulling with insucient force

13
en
GB
F
D
E
NL
P
GR
TR
CZ
SK
RUS
UK
PL
H
LV
EST
LT
RO
at this point may result in ooding of the
engine.
· When you hear the engine re for the rst
time raise the choke lever (B, Fig.12) toward
its vertical position until it clicks into place
(Fig.11).
· Pull the handle once again to start the
engine. Keep the engine at idle speed for at
least one minute before accelerating to full
revs.
Starting with a warm engine
· Press the primer bulb (A, Fig.12) fully down,
slowly, 10 times.
· Raise the choke lever (B, Fig.12) until you
hear a click.
· Check that the switch (2, Fig.13) is in position
“1”(on).
· Place your left hand on the engine cowling
and your left foot on the frame to keep the
machine steady.
· Use your right hand to pull the handle (4,
Fig.1) until you encounter slight resistance.
Without releasing the rope, pull with a short
sharp gesture. Pulling with insucient force
at this point may result in ooding of the
engine.
· Keep the engine at idling speed for at least
one minute before accelerating to full revs.
Procedure in the case of a ooded engine
· Remove the spark plug (3, Fig.1) using the
supplied wrench, then clean it and dry it.
· Check that the choke lever B is in its
horizontal position as shown in Fig.11.
· Pull the starter handle (4, Fig.1) at least 20
times.
· Fit the spark plug; bring the xed throttle
lever to the max revs position (4, Fig.13).
· Start the engine.
If the engine fails to start, proceed as follows:
· Remove the spark plug using the supplied
wrench, then clean it and dry it.
· Turn the engine upside down with the spark
plug bore facing downward.
· Pull the starter handle (4, Fig.1) at least 20
times and check whether fuel drips from the
spark plug bore.
· Dry the surfaces around the spark plug bore.
· Ret the spark plug and repeat the
operations with the throttle lever (1, Fig.13)
in the max speed position and the choke
lever (B) in its horizontal position as shown in
Fig.11.
CAUTION:
- Never wrap the starter cord around your
hand.
- When pulling the starter rope, do not use
the full extent of the rope as this can cause
the rope to break.
- Do not let starter rope snap back. Hold the
starter handle (4, Fig.1) and let the rope
rewind slowly.
BREAKING-IN THE ENGINE
The engine reaches the maximum power after
5÷8 hours of activity.
During this period of breaking-in do not use the
engine at wide open throttle without load, to
avoid excessive functioning stress.
WARNING! - During the breaking-in
period do not vary the carburetion to obtain
a presumed power increment; the engine
can be damaged.
NOTE: It is normal for smoke to be emitted
from a new engine during and after first use.
6. STOPPING THE ENGINE
Set the throttle lever to idle position (1, Fig. 13)
and wait a few seconds to let the engine cool o.
Turn o the engine, pushing the ON/OFF switch
(2, Fig. 13).

14
en
GB
F
D
E
NL
P
GR
TR
CZ
SK
RUS
UK
PL
H
LV
EST
LT
RO
MAINTENANCE CHART
Please note that the following maintenance intervals apply for normal
operating conditions only. If your daily work requires longer than normal
or harsh cutting conditions are present the suggested intervals should
be shortened accordingly.
Before Each Use
After Each
Refueling Stop
Weehly
If Damaged or
Faulty
As Required
Complete Machine Inspect (Leaks, Cracks, and Wear) X X
Controls (Ignition Switch, Choke
Lever, Throttle Trigger, Trigger
Interlock)
Check Operation
X X
Fuel Tank and Oil Tank Inspect (Leaks, Cracks, and Wear) X X
Fuel Filter Inspect and Clean X
Replace Filter Element XEvery 6
Months
All Accessible Screws and Nuts
(not Adjusting Screws)
Inspect - Retighten X
Air Filter Clean X
Replace XEvery 6
Months
Cylinder Fins and Starter System
Vents
Clean
X
Starter Rope Inspect (Damage, and Wear) X
Replace X
Carburetor Check Idle
X X
Spark Plug Check Electrode Gap X
Replace XEvery 6
Months
Vibration Mounts Inspect (Damage and Wear) X
7. MAINTENANCE

15
en
GB
F
D
E
NL
P
GR
TR
CZ
SK
RUS
UK
PL
H
LV
EST
LT
RO
WARNING! – Always wear protective
gloves during maintenance operations. Do not
carry out maintenance with the engine hot.
Never carry out maintenance operations with
the engine running.
- Non-correct maintenance and removal of
safety devices could cause serious injuries.
- Do not use fuel mixture for cleaning
operations.
- Do not attempt to carry out operations
or repairs that are not part of the normal
maintenance. See the authorised dealer.
AIR FILTER
The eciency of the air intake lter on any
engine is of critical importance so it must be
checked and cleaned regularly. To clean the air
lter, refer to Fig.17 and proceed as follows:
· Unscrew the two knobs to remove the cover
in order to gain access to the lter (as shown
in Fig.17).
· Remove the lter and clean it by knocking it
against a hard surface; then use compressed
air and blow from the side of the metal mesh
and between the pleats, proceeding in a
lengthwise direction.
· Ret the lter and close the cover, tightening
the two knobs.
CAUTION – Using the blower without the
air lter or with a very dirty air lter can damage
the engine and will invalidate the warranty.
Change the lter when it can no longer be
cleaned eciently.
FUEL FILTER (Fig. 18)
We recommend changing the fuel lter in the
fuel tank at least once a year. This operation
must be carried out by an Authorized Service
Centre:
· Empty the fuel tank.
· Extract the lter and disconnect it from the
fuel hose.
· Fit a new lter in the fuel hose.
· Re-insert the lter in the fuel tank.
CAUTION – Failure to replace the fuel lter
when it is dirty will result in impaired operation
of the engine.
ENGINE
Clean cylinder ns with a brush or compressed
air periodically. Dangerous overheating of engine
may occur due to impurities on the cylinder.
SPARK PLUG
Clean spark plug and check electrode distance
periodically (Fig. 16). Use Champion RCJ6Y or of
other brand with the same thermal grade.
FAN CASING
Following prolonged use of the blower a large
amount of dust may be deposited on the fan casing
(behind the cushion). This obstructs the air ow
(reduced volume) and can result in damage to
the fan and/or overheating of the engine. For this
reason, be sure to clean the fan casing regularly.
Clean the slots in the fan casing: they play an
important role in relation to engine cooling.
CARBURETOR
The carburettor is factory adjusted to standard
settings that comply with emissions regulations.
WARNING:
- Do not change the carburettor settings
by tightening or loosening the regulator
screws; this operation must be performed
by qualied personnel at an Authorized
Service Centre.
- Incorrect adjustment of the carburettor
can cause serious damage to the engine.
- Furthermore, do not tamper with or
remove the red protective caps on the
carburettor regulator screws.
In the case of problems (engine dies when
idling, irregular engine speed or failure to reach
maximum power) seek the assistance of an
Authorized Service Centre.
WARNING: Weather conditions and
altitude may aect carburation.

16
en
GB
F
D
E
NL
P
GR
TR
CZ
SK
RUS
UK
PL
H
LV
EST
LT
RO
MUFFLER
WARNING – This muffler incorporates
a catalytic converter, needed in order
to ensure the engine complies with current
emissions standards. Never attempt to modify or
remove the catalytic converter: in doing so, you
will be breaking the law.
WARNING – Mufflers with catalytic
converters become very hot during
operation, and retain heat for a long time
after the engine has been stopped. This is the
case even with the engine idling. Contact can
burn the skin. Always remember the potential
fire risk!
CAUTION – If the muffler is damaged, it
must be replaced. If the muffler frequently
becomes blocked, this could be an indication
that the efficiency of the catalytic converter is
limited.
WARNING – Do not use the blower if
the muffler is damaged or missing, or
has been altered in any way. Operating the
machine with an improperly maintained
muffler will increase the risk of fire and
hearing loss.
EXTRA MAINTANANCE ADVISABLE
It is advisable to inspect the machine by a
specialized technician at an authorized service
network at the end of season, if used intensively,
and every two years if with normal use.
WARNING! – Any maintenance operations
not specifically dealt with in this manual
must be carried out by an authorised service
centre. To ensure that your blower continues
to function correctly, use only ORIGINAL
REPLACEMENT PARTS.
Any unauthorized changes and/or
use of non-original replacement parts
may result in serious injury or death to the
operator or third parties.
TRANSPORTION
Only transport the blower with the engine
switched off.
WARNING - When transporting the
machine on a vehicle, ensure that it is
firmly and securely fastened using straps or
belts. The machine must be transported in the
horizontal position, also ensuring compliance
with applicable transport regulations for such
machines.

17
en
GB
F
D
E
NL
P
GR
TR
CZ
SK
RUS
UK
PL
H
LV
EST
LT
RO
8. STORAGE
WARNING: Stop engine and allow to cool,
and secure the unit before storing or
transporting in a vehicle. Store unit and fuel in
an area where fuel vapors cannot reach sparks
or open flames from water heaters, electric
motors or switches, furnaces, etc. Store unit
with all guards in place. Position so that any
sharp object cannot accidentally cause injury
to passersby. Store the unit out of reach of
children and other unauthorized persons.
1. Drain and clean the fuel tank in a well
ventilated area.
2. Drain all fuel from tank into a container
approved for gasoline. Run engine until it
stops. This will remove all fuel-oil mix which
could become stale and leave varnish and
gum in the fuel system.
3. Cleaan all foreign material from the saw. Keep
away from corrosive agents such as garden
chemicals and de-icing salts.
4. Abide by all Federal and local regulations for
the safe storage and handling of gasoline.
Excess fuel should be used in other 2-cycle
engine powered equipment.
CAUTION: It is important to prevent gum
deposits from forming in essential fuel
system parts such as the carburetor, fuel filter,
fuel hose, or fuel tank during storage. Alcohol
blended fuels (called gasohol or E10 or using
ethanol, methanol) can attract moisture
which leads to fuel mixture separation and
formation of acids during storage. Acidic gas
can damage the engine.
ENVIRONMENTAL PROTECTION
Environmental protection should be a priority of
considerable importance when using the
machine, for the benefit of both social cohesion
and the environment in which we live.
- Try not to cause any disturbance to the
surrounding area.
- Scrupulously comply with local regulations
and provisions for the disposal of oils, petrol,
batteries, filters, deteriorated parts or any
elements which have a strong impact on the
environment. This waste must not be disposed
of as normal waste, it must be separated and
taken to specified waste disposal centres
where the material will be recycled.
Demolition and disposal
When the machine reaches the end of its service
life, do not dispose of it into the environment;
instead take it to a waste disposal centre.
Most materials used in the manufacture of the
machine are recyclable; all metals (steel,
aluminium, brass) can be delivered to a normal
recycling station. For information contact your
local waste recycling service. Waste disposal must
be carried out with respect for the environment,
avoiding soil, air and water pollution.
In all cases, applicable local legislation must
be complied with.

18
en
GB
F
D
E
NL
P
GR
TR
CZ
SK
RUS
UK
PL
H
LV
EST
LT
RO
9. TECHNICAL DATA
Displacement 4.7 cu.in. (77.0 cm3)
Engine 2 stroke
Power 5.0 HP (3.6 KW)
Fuel tank capacity 0.6 US gal. (2.3 ℓ)
Primer carburetor Yes
Antivibration system Yes
Weight 24.7 lb (11.2 kg)
Blower air flow (ANSI B 175.2-2012) 807 cfm (1370 m3/h)
Maximum air speed (ANSI B 175.2-2012) 170 mph (76 m/s)
Pressure level ANSI B 175.2-1996 79 dB (A)
