Efco TR 1551 Assembly instructions

en
OPERATOR’S INSTRUCTION MANUAL
MANUEL D’UTILISATION ET D’ENTRETIEN
MANUAL DE INSTRUCCIONES
fr
es
TR 1551 (3.06 cu.in)

en
2
To correctly use the earth auger and prevent accidents, do not start work without having
first carefully read this manual. You will find explanations concerning the operation of
the various parts plus instructions for necessary checks and relative maintenance.
Note: Illustrations and specifications in this manual may vary according
to Country requirements and are subject to change without notice by the
manufacturer.
THE OPERATOR’S MANUAL
Your operator’s manual is for your protection. READ IT. Keep it in a safe place for
reference. Know what you are doing before you begin assembly of the unit. Proper
preparation and upkeep go hand-in-hand with satisfactory performance of the earth
auger and safety.
Contact your dealer or the distributor for your area if you do not understand any of the
instructions in this manual.
In addition to the operating instructions, this manual contains paragraphs that require
your special attention.
Such paragraphs are marked with the symbols described below:
Warning: where there is a risk of an accident or personal injury or serious damage to
property.
Caution: where there is a risk of damaging the machine or its individual components.
WARNING - To ensure safe and correct operation of the
earth auger this operator's manual should always be
kept with or near the machine. Do not lend or rent your
earth auger without the operator's instruction manual.
WARNING: Allow only persons who understand this manual to
operate your earth auger.
INTRODUCTION



en
3
PRODUCT IDENTIFICATION
Earth Auger Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
SAFETY
Understanding Safety Labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
State and Local Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
SAFETY RULES
Basic Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Fuel Handling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Operation and Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Precautions to Reduce Vibration Risk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Maintenance Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
ASSEMBLY
Fitting bits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Optional carth augers accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
OPERATION
Fueling. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Preparation for Working . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Starting the Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Breaking-in the Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Stopping the Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Working Techniques . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
MAINTENANCE
Maintenance Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Carburetor Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Fuel Filter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Air Filter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Cooling System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Spark Plug. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Muffler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Gear Housing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Bit Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
TROUBLESHOOTING
Using Troubleshooting Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
STORAGE
Storing Earth Auger. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
TECHNICAL DATA
TR 1551 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
TABLE OF CONTENTS

en
4
PRODUCT IDENTIFICATION
1 - Starter Handle
2 - On/Off Switch
3 - Throttle Trigger
4 - Grease Cap
5 - Bit Stop Pin
6 - Bar
7 - Fuel Tap
8 - Muffler Guard
9 - Fuel Tank Cap
10 - Purge Bulb
11 - Idle Speed Screw
12 - Air Filter Cover
13 - Half Throttle Lock
14 - Throttle Trigger Lockout
15 - Spark Plug
16 - Choke Lever
17 - Bit
18 - Boring Tip
19 - Combination Wrench
Earth Auger Components

en
5
SAFETY
- This symbol indicates Warning, and
Caution.
- Your manual contains special
messages to bring attention to
potential safety concerns, machine
damage as well as helpful operating
and servicing information. PLEASE
READ ALL THE INFORMATION
CAREFULLY TO AVOID INJURY
AND MACHINE DAMAGE.
- Wear eye, hearing and head
protection when operating this
equipment.
- Wear non-slip, heavy-duty
protective gloves when handling
earth auger and bit.
- Wear safety strong shoes or boots
having skid-proof sole and anti-
piercing insert.
State and Local Requirements
This engine is NOT equipped with a Spark Arrester System complying with the requirements of SAE
Recommended Practice J335 and California Codes 4442 and 4443. All national forest land and land
managed by the states of California, Maine, Washington, Idaho, Minnesota, New Jersey and
Oregon require internal combustion engines to be equipped with a spark arrester screen by law.
Other states and federal agencies are enacting similar regulations.
Operating this engine in a state or locale where such regulations apply, could result in a violation of the
law.
Note: When using this machine for logging purposes, refer to Code of Federal Regulations, Parts
1910 and 1928.
WARNING: The ignition system of your unit produces an electromagnetic field of a very
low intensity. This field may interfere with some pacemakers. To reduce the risk of serious
or fatal injury, persons with pacemaker should consult their physician and the pacemaker
manufacturer before operating this tool.
WARNING: Muffler surfaces are very hot during and after operation of the earth auger,
keep all body parts away from the muffler. Serious burns may occur if contact is made
with the muffler.
Understanding Safety Labels

en
6
SAFETY
WARNING: Exposure to vibrations through prolonged use of gasoline powered hand tools
could cause blood vessel or nerve damage in the fingers, hands, and wrists of people
prone to circulation disorders or abnormal swellings. Prolonged use in cold weather has
been linked to blood vessel damage in otherwise healthy people. If symptoms occur such
as numbness, pain, loss of strength, change in skin color or texture, or loss of feeling in the
fingers, hands, or wrists, discontinue the use of this tool and seek medical attention.
WARNING: The engine exhaust from this product contains chemicals known to
the State of California to cause cancer, birth defects or other reproductive harm.
Operate your earth auger outdoors only in a well ventilated area.



en
7
1
SAFETY RULES
Basic Safety Precautions
• Read this manual carefully until you completely understand and
can follow all safety rules, precautions, and operating instructions
before attempting to use the unit.
• Restrict the use of your earth auger to adult users who understand
and can follow safety rules, precautions, and operating instructions
found in this manual. Minors should never be allowed to use a
earth auger.
• Do not handle or operate a earth auger when you are fatigued,
ill, or upset, or if you have taken alcohol, drugs, or medication.
You must be in good physical condition and mentally alert. Earth
auger work is strenuous. If you have any condition that might be
aggravated by strenuous work, check with your doctor before
operating a earth auger (Fig. 1). Be more cautious before rest
periods and towards the end of your shift.
• Keep children, bystanders, and animals a minimum of 50 feet (15
meters) away from the work area. Do not allow other people or
animals to be near the earth auger when starting or operating the
earth auger (Fig. 2).
• While working with the earth auger, always use safety protective
approved clothing. The use of protective clothing does
not eliminate injury risks, but reduces the injury effects in
case of accident. Consult your trusted supplier to choose
equipment in compliance with legislation. The clothing must be
proper and not an obstacle. Wear adherent anti-cut clothing.
Protective jackets (Fig.3) and dungarees (Fig.3) are ideal.
Do not wear clothes, scarves, ties or bracelets that can stuck in
to twigs. Tie up and protect long hair (example with foulards, cap,
helmets, etc.). Safety shoes or boots having skid-proof sole
and anti-piercing insert (Fig.4). Wear protective helmet (Fig.5)
in places where there can be falling objects. Wear protective
goggles or face screens. Use protections against noises:
for example noise reduction ear guards (Fig.5) or earplugs.
The use of protections for the ear requests much more attention
and caution, because the perception of danger audio signals
(screaming, alarms, etc.) is limited. Wear gloves (Fig.6, page 8).
• Only loan your earth auger to expert users who are completely
familiar with earth auger operation and correct use. Give other
users the manual with operating instructions, which they have to
read before using the earth auger.
• Check the earth auger each day to ensure that each device,
whether for safety or otherwise, is functional.
• Never use a damaged, modified, or improperly repaired or
assembled earth auger. Do not remove, damage or deactivate any
of the safety devices. Always replace bit immediately if it becomes
damaged, broken or is otherwise removed.
• Carefully plan your working operation in advance. Do not start
cutting until you have a clear work area, secure footing.
• All earth auger service, other than the operations shown in the
present manual, have to be performed by competent personnel.
• The earth auger must only be used for making bores in soil. It
is forbidden to cut other types of material. Do not use the earth
auger as a lever to lift, move or break objects, nor lock it on fixed
supports. It is forbidden to apply tools or applications that are not
the ones indicated by the manufacturer onto the earth auger’s
power take-off.
• It is unadvisable to hitch tools or applications to the P.t.o. that are
not specified by the manufacturer.
2
3
4
5

en
8
SAFETY RULES
Fuel Handling
WARNING: Gasoline is an extremely flammable fuel.
Use extreme caution when handling gasoline or fuel
mix. Do not smoke or bring any fire or flame near the
fuel or the earth auger (Fig.7).
•To reduce the risk of fire and burn injury, handle fuel with
care. It is highly flammable.
• Mix and store fuel in a container approved for gasoline (Fig.8).
• Mix fuel outdoors where there are no sparks or flames.
• Selectbareground,stopengine,andallowtocoolbeforerefueling.
• Loosen fuel cap slowly to release pressure and to keep fuel
from escaping around the cap.
• Tighten fuel cap securely after refueling. Unit vibration can
cause an improperly tightened fuel cap to loosen or come off
and spill quantities of fuel.
• Wipe spilled fuel from the unit. Move 10 feet (3 m) away from
refueling site before starting engine (Fig.9).
• Never attempt to burn off spilled fuel under any circumstances.
• Do not smoke while handling fuel or while operating the earth
auger.
• Store fuel in a cool, dry, well ventilated place.
• Never place the earth auger in a combustible area such as dry
leaves, straw, paper, etc.
• Store the unit and fuel in an area where fuel vapors cannot
reach sparks or open flames from water heaters, electric
motors or switches, furnaces, etc.
• Never take the cap off the tank when the engine is running.
• Never use fuel for cleaning operations.
• Take care not to get fuel on your clothing. If you get fuel on
your clothing substitute them immediately.
Operation and Safety
WARNING: Always hold the earth auger with both
hands when the engine is running. Use a firm grip
with thumbs and fingers encircling the earth auger
handles (Fig.10).
• Keep all parts of your body away from the earth auger when
the engine is running.
• Always carry the earth auger with the engine stopped the
bit to the rear, and the muffler away from your body. When
transporting in a vehicle, properly secure your earth auger to
prevent turnover, fuel spillage and damage to the earth auger.
• Do not operate a earth auger with one hand! Serious injury
to the operator, helpers, bystanders, or any combination of
these persons may result from one-handed operation.
An earth auger is intended for two-handed use.
• Before you start the engine, make sure the earth auger is not
contacting any object.
• Shut off the engine before setting down the earth auger.
Do not leave the engine running unattended.
• Only use the earth auger in well-ventilated places, do not
operate the earth auger in explosive or flammable atmospheres
or in closed environments (Fig.11). Beware of carbon monoxide
poisoning.
6
7
8
9
10

en
9
SAFETY RULES
• Do not operate earth auger from a ladder. Always cut from a
firm-footed and safe position.
• Do not work near electric cables.
WARNING – Contact with electrical cables or wires
can cause serious injury or death as a result of
electrical shock (Fig.12). This unit is not insulated.
• Keep the handles dry, clean, and free of oil or fuel mixture.
• When the earth auger is running, grip the left handle firmly
with your left hand and the right handle with your right hand
(Fig.10).
• Never raise the earth auger above shoulder height.
WARNING – Striking a hard object in the earth
with the turning auger and the resulting slowing or
stopping of the auger creates reactive forces. The
transfer of rotational (reactive) forces can cause the
auger powerhead and handles to rotate suddenly in
a counterclockwise direction and can result in loss of
control or cause the handle frame to hit the operator
or throw him to the ground, resulting in serious
injury.
WARNING – Thrown objects may ricochet and strike
the operator. Therefore, to reduce the risk of injury
to your eyes never operate an earth auger unless
wearing goggles or properly fitted protective glasses
with adequate top and side protection complying with
ANSI Z 87.1 (or your applicable national standard.
11
12

en
10
SAFETY RULES
Precautions to Reduce Vibration Risk
• Wear gloves and keep your hands warm.
• Keep the bit sharp and the earth auger, well maintained. A dull bit will increase cutting time, will increase
the vibrations transmitted to your hands.
• Maintain a firm grip at all times, but do not squeeze the handles with constant, excessive pressures,
take frequent breaks. All the above mentioned precautions do not guarantee that you will not sustain
whitefinger disease or carpal tunnel syndrome. Therefore, continual and regular users should monitor
closely the condition of their hands and fingers. If any of the above symptoms appear, seek medical
advice immediately.
Maintenance Precaution
WARNING: Never operate a earth auger that is damaged, improperly adjusted, or is not
completely and securely assembled.
WARNING: Be sure that the bit stops moving when the throttle control trigger is released. If
the bit moves at idle speed, the carburetor may need adjusting, see Operation-Carburetor
Adjusting Section. If the bit moves at idle speed after adjustment has been made, contact a
Servicing Dealer for adjustment and discontinue use until the repair is made.
WARNING: All earth auger service, other than items in the Operator's Manual maintenance
instructions, have to be performed by competent earth auger service personnel. (If improper
tools are used to remove the flywheel or clutch, or if an improper tool is used to hold the
flywheel in order to remove the clutch, structural damage to the flywheel could occur which
could subsequently cause the flywheel to burst and serious injury could result.)
• Never modify your earth auger in any way.
• Keep the handles dry, clean, and free of oil or fuel mixture.
WARNING: Use only accessories and replacement parts recommended.
• Never touch the bit or attempt to service the earth auger while the engine is running.
• Never use fuel for cleaning operations.
• Keep the earth auger in a dry place, off the ground with the tanks empty.
• If your earth auger is no longer usable, dispose of it properly without damaging the environment by
handing it in to your local Dealer who will arrange for its correct disposal.
• Replace immediately any safety device when damaged or broken.
WARNING: The muffler and other parts of the engine (e.g. fins of the cylinder, spark
plug) become hot during operation and remain hot for a while after stopping the engine.
To reduce risk of burns do not touch the muffler and other parts while they are hot.
WARNING – To reduce the risk of injury from a turning drilling tool or from reactive forces,
the throttle trigger must move freely and return immediately to the idle position when it is
released. Regular maintenance is important in this respect. Check the condition and the
tightness of the drilling tool.

en
11
ASSEMBLY
Lubricant for reduction gearbox (Fig.13)
WARNING! - The earth auger is supplied with TAMOIL
TAMLITH GREASE 2 (150 g) grease in the reduction
gearbox.
Remove the screw (A) under the reduction gearbox and check for the
presence of grease.
Fitting bits (Fig.14-15)
Fit the reduction shaft (B) into the seat on the bit (D) and secure it
using the appropriate gudgeon pin (C).
WARNING! - Do not change the ratio of the reduction
gearbox. The characteristics of the machine could
change and unforeseen reactions could occur.
Optional earth augers accessories
Augers (Fig.16)
Equipped with tip and flute made of special steel to ensure top
performance and excellent resistance to wear.
Description Part number
Single flute auger ø 3" x 39.3" 375100028A
Single flute auger ø 4" x 39.3" 375100029A
Single flute auger ø 6" x 39.3" 375100030A
Single flute auger ø 8" x 39.3" 375100031A
Extensions (Fig.16)
To obtain greater drilling depth.
Description Part number
12" extension 375100101
Ice augers (Fig.17)
For drilling through ice.
Description Part number
Ice augers 375100110
13
15
16
17
14

en
12
OPERATION
20
19
18
Fueling (Do Not Smoke!) (Fig.20)
This product is powered by a 2-cycle engine and requires pre-
mixing gasoline and 2-cycle oil. Pre-mix unleaded gasoline and 2-
cycle engine oil in a clean container approved for gasoline (Fig.18).
RECOMMENDED FUEL: THIS ENGINE IS CERTIFIED TO
OPERATE ON UNLEADED GASOLINE INTENDED FOR
AUTOMOTIVE USE WITH AN OCTANE RATING OF 89 ([R+M]/2)
OR HIGHER (Fig.19).
Mix 2-Cycle Engine Oil with gasoline according to the instructions
on the package.
We strongly recommend the use of 2% (1:50) Efco Two Cycle
Engine Oil, which is specifically formulated for all Efco air-cooled
two-stroke engines.
The correct oil / fuel proportions shown in the table below
are suitable when using the Efco Two Cycle Engine Oil or an
equivalent high-quality engine oil (JASO specification FD or ISO
specification L-EGD).
When oil specifications are NOT equivalent or unknown use 4%
(1:25) oil / fuel mixing ratio.
CAUTION: DO NOT USE AUTOMOTIVE OIL OR
2-CYCLE OUTBOARD OIL.
CAUTION: Never use a fuel with an alcohol percentage
higher than 10%; gasohol up to 10% alcohol or E10
fuel are acceptable.
When using an Oxygenated Gasoline a good practice of Fuel
Management is necessary.
Gasoline Oxygenated with alcohol readily takes/up water when it
is present; the water may be condensed out of humid air or be a
contaminant in the fuel system, including tank.
CAUTION:
- Match your fuel purchases to your consumption;
don’t buy more than you will use in one or two
months;
- Store gasoline in a tightly-closed container in a
cool, dry place.
The use of Oxygenated Gasoline may cause the occurrence of
vapor-lock easier.
NOTE: 2-Cycle Engine Oil contains a fuel stabilizer and will stay
fresh up to 30 days. DO NOT mix quantities larger than usable
in a 30 day period. A 2-cycle oil containing a fuel stabilizer is
recommended.
Fuel Mixture 2-Cycle Engine Oil (25:1) 4%
Gasoline Oil
1 Gallon (US) . . . . . . . . . . . . . . . . . . . . . . . . . . 5.2 oz.
1 Liter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40 cc (40 ml)
High Quality 2-Cycle Engine Oil (50:1) 2%
Gasoline Oil
1 Gallon (US) . . . . . . . . . . . . . . . . . . . . . . . . . . 2.6 oz.
1 Liter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 cc (20 ml)

en
13
OPERATION
21
24
23
22
Filling the Tank (Fig.22)
WARNING: Follow safety instruction for fuel handling.
Always shut off engine before fueling. Never add fuel
to a machine with a running or hot engine. Move at
least 10 feet (3m) from refueling site before starting
engine (Fig.21). DO NOT SMOKE!
1. Clean surface around fuel cap to prevent contamination.
2. Loosen fuel cap slowly.
3. Carefully pour fuel mixture into the tank. Avoid spillage.
4. Prior to replacing the fuel cap, clean and inspect the gasket.
5. Immediately replace fuel cap and hand tighten. Wipe up any
fuel spillage.
NOTE: It is normal for smoke to be emitted from a new engine
during and after first use.
WARNING: Check for fuel leaks, if any are found,
correct before use. Contact a Servicing Dealer if
necessary.
Preparation for Working
Proper Grip on Handles.
1. Wear non-slip gloves for maximum grip and protection.
WARNING: Hold the earth auger firmly with both hands.
Always keep your LEFT HAND on the left handlebar
and your RIGHT HAND on the throttle handle as shown
in Fig.23. Never use a cross-handed grip. Left-handers
should follow these instructions too.
2. Maintain a proper grip (B, Fig.24) on the earth auger whenever
the engine is running. The fingers should encircle the bar and
the thumb is wrapped under the bar.
Working Conditions
Striking something hard in the earth, such as a rock or gravel,
may cause the drilling tool to slow down suddenly or stop. In
such a situation, some or all of the rotational force (reactive force)
is transferred to the powerhead and handle frame of the earth
auger which can cause the auger powerhead and handles to
rotate suddenly in a counterclockwise direction.
WARNING – Work carefully in rock ground or where
other solid objects may be present. Keep throttle
feed pressure to a minimum. If you feel or hear the
drilling tool strike a solid object, release the throttle
trigger immediately and remove the object before
drilling is continued. When drilling in heavy clay soil,
bore about 1/3 way and remove the auger from the
hole. Clean off auger then continue in slow steps
frequently clearing drill.

en
14
OPERATION
WARNING – You should hold your earth auger firmly to
control sudden jolts and reactive forces. Be prepared
to release the throttle completely if the forces become
too great. If reactive forces are not controlled, rotation
of the handles may result in severe jerking and loss of
control and may cause the handle frame to strike you
or throw you to the ground.
WARNING – To reduce the risk of electrocution and
damage to property, always be alert for underground
pipes and cables and for overhead wires. Before drilling,
obtain the necessary plans and permits. Contact your
local utility company or your locator service, such as
“Miss Utility” or “One Call”, for information as to cable
and pipes locations. Where necessary, confirm actual
locations by use of devices such as cable detectors
and/or by carefully dug trenches. Stay clear of overhead
electrical wires when backing the drilling tool out of the
hole. If any portion of the machine strikes a wire, it will
cause electrical shock or death.
Work Area Precautions
• Never allow children to operate your earth auger. Only allow
others to use this earth auger who have read this Operator's
Manual or received adequate instructions for the safe and
proper use of this earth auger.
• Keep everyone - helpers, bystanders, children, and animals a
safe distance from the working area (Fig.25).
• Always work with both feet on solid ground to prevent being
pulled off balance.
• Do not work above chest height.
• Do not work near electrical wires or buildings. Leave this
operation for professionals.
• Work only when visibility and light are adequate for you to see
clearly.
• Do not work from a ladder, this is extremely dangerous.
• Stop the engine if the bit strikes a foreign object. Inspect the
bit and repair parts as necessary.
• Stop the engine before setting the earth auger down.
• Be particularly cautious and alert while wearing hearing
protection because such equipment may restrict your ability to
hear sounds indicating danger (calls, signals, warnings, etc).
• Be extremely cautious when working on slopes or uneven
ground.
WARNING – To reduce the risk of falling, be careful when
carrying or operating the machine in slippery conditions
when the ground is wet, icy or snow covered. Special
care must also be taken on embankments and slopes.
Starting The Engine
• Place the earth auger on level ground and ensure that no
objects or obstructions are in immediate vicinity which could
come in contact with the bit. Hold the right handle firmly with
the left hand and put your right foot onto the base of the left
handle, see Fig.26.
• Don’t press on the unit or the auger with your foot.
• Make sure that the throttle lever works properly.
25
26

en
15
OPERATION
• Open the fuel tap (A, Fig.27).
• Fill the carburetor by pushing primer bulb a couple of times (C,
Fig.27).
• Put the ON/OFF switch (B, Fig.28) in the "I" position.
• Put the choke lever (F, Fig.29) in the CLOSE position.
• Pull throttle lever (D, Fig.29) and lock it in the half-throttle
position by pressing button (E), then release lever (D).
• Grip the handle on the throttle side, lean the bar against
your body and pull the starter rope until it meets resistance
(Fig.31). Pull the starter rope hard a few times and when the
engine begins to turn, bring the choke lever (F, Fig.30) back to
the original position «OPEN». Repeat the procedure until the
engine starts. Once the engine is running, press the throttle (D,
Fig.29) to release it from the half-throttle position and let the
engine idle.
• When pulling the starter rope, do not use the full extent of the
rope as this can cause the rope to break. Do not let starter rope
snap back. Hold the handle and let the rope rewind slowly.
• When the engine starts at starting-throttle, engine speed will
be fast enough for the clutch to engage and move the cutting
tool.
WARNING: Do not cut material with the choke/fast
idle lever at the FULL CHOKE position. Do not
operate your earth auger with the starting throttle
lock engaged. Cutting with the starting throttle lock
engaged does not permit the operator proper control
of the earth auger speed.
NOTE - STARTING WARM ENGINE:
Follow above starting instructions, but do not use the OPEN
(Fig.30) Choke position for start up again. To set fast idle for
warm engine starting, pull choke out completely and push
back in to the original CLOSE (Fig.30) Position.
WARNING: Weather conditions and altitude may
affect carburetion. Do not allow bystanders close to
the earth auger while adjusting the carburetor.
WARNING: Never attempt to start the earth auger
when the bit is in a cut or kerf.
Breaking-in the Engine
The engine reaches the maximum power after 5-8 hours of activity.
During this period of breaking-in do not make the machine function
idly at full throttle, to avoid excessive functioning stress.
CAUTION! – During the breaking-in period do not
vary the carburetion to obtain a presumed power
increment; the engine can be damaged.
29
28
31
27
30

en
16
Difficult Starting (or starting a flooded engine)
The engine may be flooded with too much fuel if it has not started
after 10 pulls. Flooded engines can be cleared of excess fuel
by following the warm engine starting procedure listed below.
Ensure the ON/STOP switch is in the ON position. Starting could
require pulling the starter rope handle many times depending on
how badly the unit is flooded. If engine fails to start refer to the
TROUBLESHOOTING TABLE (page 23).
Engine is Flooded
If you did not move the choke lever to warm start, quickly
enough after the engine began to fire, the combustion chamber
is flooded.
• Set the on/off swich to STOP.
• Engage a suitable tool in the spark plug boot (Fig.32).
• Pry off the spark plug boot.
• Unscrew and dry off the spark plug.
• Open the throttle wide.
• Pull the starter rope several times to clear the combustion
chamber.
• Refit the spark plug and connect the spark plug boot, press it
down firmly.
• Set the on/off swich to I, the starting position.
• Set the choke lever to warm start – even if engine is cold.
• Now start the engine.
Stopping The Engine
Release the throttle trigger (D, Fig.33) and let the engine return
to idle.
To stop the engine, move the on/off switch (B) to the “ STOP ”
position. Do not put the earth auger on the ground when the bit
is still moving.
In the event that the “ STOP ” position of the switch will not
function, pull the choke lever in CLOSE position (refer to Fig.30)
to stop the engine.
Pre-operation checking
WARNING: THE EARTH AUGER SHOULD NEVER
MOVE AT IDLE. Turn the idle speed screw “T”
counterclockwise to reduce the idle RPM and stop
the bit, or contact a Servicing Dealer for adjustment
and discontinue use until the repair is made.
Serious personal injury may result from the bit
moving at idle.
32
OPERATION
33

en
17
OPERATION
Working Techniques
General Working Instructions
WARNING: Do not work during periods of high wind
or heavy precipitation.
WARNING: Never work, when visibility is poor or in
very high temperatures.
WARNING: Long-term exposure to noise can result
in permanent hearing impairment. So always use
approved hearing protection.
WARNING: Faulty bits can increase the risk of
accidents.
WARNING - If correctly used, the earth auger is
a quick, easy to handle and efficient tool; if used
improperly or without the due precautions it could
become a dangerous tool. THE MACHINE CAN
CAUSE SERIOUS INJURY. For pleasant and safe
work, always strictly comply with the safety rules
that follow and throughout this manual.
• The gear housing gets hot when the machine has been in
use (Fig.34). To avoid burning yourself do not touch the gear
housing.
• Check the working attachment. Never use bits that are dull,
cracked or damaged.
• Check that the machine is in perfect working order. Check that
all nuts and screws are tight.
WARNING: The complete clutch cover and gear
housing must be fitted before the machine is started,
otherwise the clutch may come loose and cause
personal injury.
WARNING: If you encounter a situation where you are
uncertain how to proceed you should ask an expert.
Contact your dealer or your service workshop.
Avoid all usage which you consider to be beyond
your capability.
• When the engine is switched off, keep your hands and
feet away from the cutting attachment until it has stopped
completely.
• Check the working area for foreign objects such as electricity
cables, insects and animals, etc, or other objects that could
damage the bit, such as metal items.
34

en
18
OPERATION
• If any foreign object is hit or if high vibrations occur stop the
machine immediately. Disconnect the HT lead from the spark
plug. Check that the machine is not damaged. Repair any
damage.
• If anything jams in the bits while you are working, switch off the
engine and wait until it has stopped completely before cleaning
the bits. Disconnect the HT lead from the spark plug.
• Always wear heavy-duty gloves when repairing the cutting
attachment. This is extremely sharp and can easily cause cuts.
• Release the throttle trigger as soon as the cut is completed,
allowing the engine to idle. If you run the earth auger at
full throttle without a cutting load, unnecessary wear or
damage can occur to the bit and engine.
Local rugulations
Observe all country-specific and local regulations and ordinances
regarding soil working.
Preparations
Before starting work, scare away small animals so that they
cannot be injured.
Working techniques
WARNING! - Do not use damaged or excessively
worn bits. If the bit gets jammed, turn off engine
before removing the obstruction.
The auger becomes trapped in the drill hole, turn off the engine
immediately and remove as described in the chapter entitled
“Removing a trapped auger”.
WARNING – To reduce the risk of injury, never touch
a rotating drilling tool or drilling spindle with your
hand or any part of your body. It continues to rotate
for a short period after the throttle lever is released.
Always shut off the engine before putting the machine
down or transporting it over a long distance.
When taking the drilling tool out of the hole, lift the
machine vertically so that the tool comes out straight
without canting. Cover and clearly mark boreholes,
to prevent anyone from stepping in a hole.
Working with shaft extension (optional special accessory, Fig.35)
Do not fit the shaft extension until the full length of the auger is in
the hole.
WARNING – Starting hole with the shaft extension
fitted increases the risk of personal injury because
the unit is then at chest height and cannot be kept
properly under control.
For the same reason the shaft extension must be
removed before the auger is pulled out of the hole.
Removing a trapped auger
If the auger jams in the drill hole, shut off the engine immediately.
Move on/off switch in direction of STOP (B, Fig.36).
Transportation
When you walk with your earth auger, turn off the engine. Grip the
front handle and keep the bits behind you.
35
36

en
19
MAINTENANCE
Maintenance Chart
Please note that the following maintenance intervals apply for normal operating conditions only. If
your daily work requires longer than normal or harsh cutting conditions are present the suggested
intervals should be shortened accordingly.
Before Each
Use
After Each
Refueling Stop
After Finishing
Daily Work
Weekly
Monthly
If Damaged or
Faulty
As Required
Complete Machine Inspect (Leaks, Cracks, and Wear) XX
Clean X
Controls (Ignition Switch, Choke Lever, Throttle
Trigger, Trigger Interlock) Check Operation XX
Fuel Tank Inspect (Leaks, Cracks, and Wear) XX
Clean X
Grease Cap Inspect (Leaks, Cracks, and Wear) XX
Clean X
Fuel Filter Inspect X
Clean, Replace Filter Element XEvery 6
Months
Bit Inspect (Damage, Sharpness, and Wear) XX
Sharpen XX
Clutch Drum Inspect (Damage, and Wear) X
Replace X
All Accessible Screws and Nuts (Not Adjusting
Screws)
Inspect X
Retighten X
Air Filter Clean XX
Replace XEvery 6
Months
Cylinder Fins Clean X
Starter System Vents Clean X
Starter Rope Inspect (Damage and Wear) X
Replace X
Carburetor Check ldle (Chain must not rotate at ldle) XX
Spark Plug Check Electrode Gap X
Replace XEvery 6
Months

en
20
37
40
39
38
MAINTENANCE
Carburetor Adjustment
Before adjusting the carburetor, clean the starter cover vents as
shown in Illustration Fig.37, and air filter as shown in Illustration
Fig.38, refer to Operation-Starting Unit and Maintenance-Air
Filter Sections for details. Allow the engine to warm up prior to
carburetor adjustment.
This engine is designed and manufactured in order to comply with
EPA (Environmental Protection Agency) Phase 1 regulations.
The carburetor is factory set and should not require adjusting.
The carburetor will permit only limited adjustment of the “L” (Low
Jet) and “H” (High Jet) needles (Fig. 39). Any adjustment should
be done by a Servicing Dealer.
Under no circumstances should the “L” (Low Jet) and “H” (High
Jet) needles be forced outside the range of adjustment.
WARNING: Serious damage can occur to the engine
if improper adjustments are made to the “L” and “H”
needles. Do not force the “L” and “H” needles outside
the adjustment range in such case the engine will not
run in compliance with emissions regulations.
Idle Speed Adjustment
• If the engine starts, runs, and accelerates but will not idle; turn
the idle speed screw “T” clockwise to increase idle speed
(Fig.39).
• If the earth auger turns at idle, turn the idle speed screw
“T” counterclockwise to reduce the idle RPM and stop the
bit movement. If the bit still moves at idle speed, contact a
Servicing Dealer for adjustment and discontinue use until the
repair is made.
WARNING: Don’t tamper with the carburetor.
WARNING: With the engine idling (2600 rpm), the
bit should not move. We recommend that you have
the dealer or an authorised mechanic carry out any
carburetor adjustments.
WARNING: Weather conditions and altitude may
affect carburation.
WARNING: Do not allow anyone to stay close to the
earth auger while working or while adjusting the
carburetor.
Fuel Filter
Check the fuel filter (B, Fig.40) periodically. Replace it if
contaminated or damaged.
