Efergy ELITE User manual

*All values shown in this manual are only examples. Actual figures will vary depending on your consumption.

CT SensorTransmitter
10 / 15 / 20s
ELECTRICITY MONITORING
TRANSMITTER

2. Plug the C T sensors’
jacks into the transmitter
1. O pen and place one
CT sensor around each
mains cable
Do not touch below this level
1. Pull the clasp to open the CT sensor
2. Place the CT sensor around the cable
3. Push the clasp to close securely

Wireless energy
monitor link button
Hold for 2 seconds
history
backward
forward
mode/set

INSTANT MODE
MONITOR SETUP
15 16
Push the mode/set button to change information being displayed from kW to cost
(displayed in $).
Cost and Emission Per Day or Hour Energy Now
The lower part of the screen shows Shows the instant power in kW.
the estimated cost and carbon
emissions per day or hour.
Push the History button to access daily, weekly and monthly stored data. Use the backward
and forward arrow buttons to scroll between dates and compare consumption data.
Press the mode/set button to change the information display from kWh to costs and CO2
emissions.
Historical consumption
information for days,
weeks and months in
kWh, $ and KgCO2
Average information for
days, weeks and months
in kWh, $ and KgCO2
HISTORY MODE

FA S
1817
If I remove the batteries will I lose the information on the display?
The display has an internal memory, so if you need to change or remove the batteries the
information stored on it will not be lost.
How do I reset the display (clear the stored data and start again)?
Press and hold the mode/set and History buttons simultaneously for 2 seconds.
How far does the device transmit?
The transmitter work up to around 230ft/ 40m within the home. The 433MHz range is well
suited for in-home use. This can cover 3 floors and is also ideal for buildings where electricity
meters are situated outside.
I have dashes (- - - -) showing on the display. What does this mean?
Move the display closer to the transmitter and press the link button. If the dashes remain
on the display this would indicate that the transmitter and receiver are not communicating.
Please contact efergy customer services to help solve the problem, at [e-mail]
The backlight appears to work sometimes and then not others. Is it broken?
No. The backlight is on a timer to save battery life. The display should work at darker periods
during the day when any buttons are pressed. The LED backlight will be activated from 18:00
hours - 6:00 hours.
TECHNICAL INFORMATION
Model Name
Model Number
Frequency
Transmission Time
Transmission Range
Working voltage range
Measuring Current
Carbon Ratio
Elite true power meter
Elite-TPM-NA 1.0
433.5MHz
10, 15 or 20 seconds
230ft - 328ft/ 40m - 70m
110V - 600V
50mA-200A (MAX)
0.50kg.CO2/ kWh
