eFOLDi Tyre Inflator User manual

Tyre Inflator
User Manual
Packing List
1x Inflator
1x Air Tube
1x Presta Valve
Convertor
1x Ball Inflation
Needle
1x USB Charging Cable
1x Storage Bag
Details
UNIT ‘U’ Button - Button + Button LED Screen POWER Button
+
-
U
Short Press Choose Unit Reduce Pressure Increase Pressure Start/Stop Inflating
Long Press Turn On/Off Light Quick Reduce Quick Increase Turn On/Off
About Buttons
About Inflation Reference Pressure Time from Empty (Minutes) Frequency from Empty
Car
Road Bike
Mountain Bike
Motorcycle
Basketball
*No extrusion during testing
2.3 –2.5 BAR
100-120 PSI
30-50 PSI
30-50 PSI
7-9 PSI
8-12
2-3
2-3
2-3
0.5-1
2-3 (205 55R17)
8-12 (700x23C) *
12-18 (26x1.95) *
8-12
30-40
LED Light
Vent Port
Air Tube Storage
USB Charging
Port
Charging Indicator
Steps for Inflation
1. Connect one end of the air tube to the inflator, connect the other end to the tyre valve
(for presta valve please install the valve convertor first).
2. Long press the POWER button until the LED screen lights up. The LED will show the current set pressure.
3. Press the UNIT button to choose the pressure unit between PSI, BAR, KPA and kgf/cm².
4. Use the ‘+’ button and ‘-’ button to set the target pressure. The inflator will remember the pressure you set previously.
5. Press the POWER button to start inflating. Pressing it again can pause or continue.
The inflator will stop automatically when it reaches the target pressure.
Using the Torch - Long press the UNIT button to turn On/Off the LED light.
About Charging
1. For first time use or after a long time of no use please charge the inflator before using.
2. The charging indicator will turn red during charging and the indicator light will turn red and green alternately
when charging is complete.
3. Usually the inflator should be charged every two months even when it will not be used.
If you do not charge the inflator for a long time the battery will be over-discharged and the battery may become damaged.

Tyre Inflator
ATTENTION
1. It’s normal that the inflator becomes hot after working more than 1 min.
Please do not touch the hot part of the air tube!
2. The inflator is noisy when in operation –make sure that small children and pets are kept away.
3. Please check the inflator before use. If you find any issue do not use it.
4. If you notice any abnormal sounds or excessive temperatures during the inflation, please stop it immediately.
5. Please ensure the smooth flow of air during the inflation.
6. The compressor in the inflator may produce electric sparks at work. Please keep it away from flammable and explosive
objects.
7. Do not leave the working area in case of accident.
8. After extended use, the inflator and air tube will become hot. Please take a break before using it again.
9. Please try to avoid dirt, soaking and excessive shocks.
10. Harsh chemicals, cleaning agents, detergents and other chemicals are not to be used for cleaning.
11. Do not store the inflator in a cold, hot or humid place.
12. Children are forbidden to use the inflator. Please keep it away from children.
13. Don't inflate the air into the mouth, ear, eye, etc. of people or animals.
14. Do not use the inflator when it's being charged.
15. The battery level bar display will display lower than current charge while the inflator is in operation due to the large
current output
HOT
Specifications
Size
Weight
Battery
Working Current
Charge Mode
Charging Time (hours)
Max. Inflating Pressure
Operating Temperature
55 x 53 x 180 mm
336g
500mAh 12.8V
1-5A
Micro USB
3
150 PSI / 10.3 BAR / 990 KPA / 10.5 kgf/cm²
-10° ~ + 60 ° C
MADE IN CHINA
