Drive PE 1000 BL User manual

pediatric anterior
safety roller
item # PE 1000 BL & PE TYKE
for use with item #
PE 1000 WB & PW 1000 WBK
lifetime limited
warranty
Your Drive brand product is warranted to be free
of defects in materials and workmanship for the
lifetime of the original consumer purchaser.
This device was built to exacting standards and
carefully inspected prior to shipment. This Lifetime
Limited Warranty is an expression of our confi-
dence in the materials and workmanship of our
products and our assurance to the consumer of
years of dependable service.
In the event of a defect covered by this
warranty, we will, at our option, repair or replace
the device.
This warranty does not cover device failure
due to owner misuse or negligence, or normal
wear and tear. The warranty does not extend to
non-durable components, such as rubber
accessories, casters, and grips, which are subject
to normal wear and need periodic replacement.
If you have a question about your Drive device or
this warranty, please contact an authorized Drive
dealer.
© 2006 Medical Depot, Inc. All rights reserved.
Drive is a trademark of Medical Depot, Inc.
Port Washington N.Y. 11050 USA Made in China
Item # PE 1000 BL
Shown
EU Authorized Representative
Drive International, LLC
Globe Lane - Stockport
DUKINFIELD SK16 4RE, GB

set up instructions
1. Remove Safety Roller from carton.
2. Unfold Safety Roller by lifting ring (Fig 2) from left
upright and open frame.
3. Lift handlebar and position over left upright. Make
sure spring button (A) snaps into hole on the
handlebar underside (Fig 1).
figure 1
height adjustments
Recommended handlebar height is at the wrist with
arms fully extended. With your hand placed on the
handgrip, your elbow should be flexed 20° - 30°.
1. Open both height adjustment knobs (B).
2. Push in spring button (C), one side at a time
and raise or lower uprights to desired height.
3. Tighten knobs.
folding instructions
1. Press spring button on left side of handlebar and
lift handlebar.
2. Hold handlebar in right hand and with left hand,
swing left upright outward and squeeze into
Zposition until fully folded.
3. Drop handlebar over folded Safety Roller.
4. Secure uprights by putting the ring over the left
upright and under the spring button.
accessories
Adjustable forearm platforms, variable resistance tabs
on rear wheels, swivel wheel locking brackets, ankle
prompts, trunk support, extended uprights for
additional height, IV pole and oxygen tank holder.
Call an authorized Drive dealer for detailed information
about our accessories.
figure 2
operating safety roller
Make certain that the person for whom the walker is
being fied is standing as naturally upright on a firm,
flat surface. Also, they should be wearing the same style
shoes that they will be wearing when using the walker,
during activities of daily living. In most cases, the height
of the handles should be set to allow a 30˚ bend at the
elbow when taking hold of the hand grips.
1. Stand with feet
together inside lower
frame. Walker will not
move if weight is place
on handles.
2. To move forward
release enough
weight on handles to
allow walker to be
rolled forward.
3. Reapply weight on
handles to lock the
wheels and step
forward with one foot
into lower frame.
4. Place other foot into
frame to complete one
step. Repeat from
number one to continue
moving.
