Egholm City Ranger 2260 User manual

Operator’s
manual
Rotary/mulch mower 1500
City Ranger 2260/2250

2Operator’s Manual City Ranger 2260/2250 Rotary/mulch mower 1500 Operator’s Manual City Ranger 2260/2250 Rotary/mulch mower 1500
Dear Customer
Thank you for choosing an Egholm product
The City Ranger 2260/2250 is a Danish designed and manufactured utility machine, which allows you to
take a very exible approach to maintaining outdoor areas.
Optimal performance from your City Ranger 2260/2250 Rotary/Mulch mower 1500
To ensure optimal performance from your City Ranger 2260/2250 Rotary/Mulch mower 1500, please read
this manual carefully before using the machine. Failure to do so can result in personal injury and damage
to the machine.
Safety
The Rotary/Mulch mower is equipped with various devices to ensure optimal operational safety, both for
the user and the surroundings. We therefore ask you to pay particular attention to Safety section 1.1. The
machine must only be serviced by professionals.
The Rotary/Mulch mower is designed for use by professionals only. On delivery of the machine, the user
will receive thorough training to become a competent operator.
Do not lend the machine or tools to anyone who has not been thoroughly trained and who has not read
this manual carefully.
The operator’s manual should be considered a vital accessory to the machine and so must remain with it
if the machine is sold.
Warnings
Some items in this operator’s manual are marked with this warning symbol. The warning
indicates areas where extra care has to be taken to avoid personal injury or damage to the
machine and its accessories. The warning also explains how you should pay special attention
to the aspect in question.
Reservations
As it is Egholm policy to make continuous improvements, we reserve the right to alter the specications
and equipment at any time without notice. Egholm accepts no liability for errors or shortcomings in the
operator’s manual.
Contact Egholm
Please do not hesitate to contact Egholm should you have questions of any kind regarding your new
Egholm product.
Best regards,
Egholm A/S · Transportvej 27 · DK-7620 Lemvig
T. [phone] · F. [phone]
e-mail: [e-mail] · www.egholm.eu
Introduction
Egholm app - easy access to useful material
Download our Egholm app, enter the serial number of your machine and possibly add
attachments, and get access to videos, manuals, technical specications and much more.
If you agree to receive notications, you will be notied about product and service information,
offers etc. The app is available for Apple and Android mobile phones.

3Operator’s Manual City Ranger 2260/2250 Rotary/mulch mower 1500 Operator’s Manual City Ranger 2260/2250 Rotary/mulch mower 1500
The City Ranger 2260/2250 Rotary/Mulch
mower 1500 operates quickly and effectively to
meet your every cutting need – even on dicult
lawns.
The mulch mower cuts and recuts the grass
into tiny particles and blows them down into
the lawn, which fertilises the soil naturally
throughout the summer. The result is a green
and well-trimmed lawn.
The rotary mower with rear discharge feature
is especially well-suited to rough, tall and even
damp grass, leaving it looking well groomed.
The Egholm mowers are equipped with piano
wheels as standard, which make the mower
follow the steering. This also avoids leaving
tracks on the lawn.
The City Ranger 2260/2250 Rotary/Mulch
mower 1500 can maintain 13,5-15000 m2 per
hour. It simply races around the lawn with a
cutting width of 1,500 mm.
Useful tips
Never allow the radiator grille to become choked
with grass. This reduces the cooling effect.
The mulch mower is designed to cut up to one
third of the grass height. Adjust the mowing
frequency hereafter.
Adjust the speed for the desired result – the
best result is achieved when you avoid driving
too fast.
Ensure the snap couplings are clean before
locking, as this protects the hydraulic system.
Contents
General information ..........................................................................5
1.1 Safety ...............................................................................5
1.2 EC Declaration of Conformity ..........................................................6
1.3 Technical data .........................................................................7
Operator’s manual ...........................................................................9
2.1 Assembly / Disassembly ..............................................................9
2.2 Before start-up ......................................................................11
2.3 Start-up ............................................................................11
2.4 Adjustment .........................................................................13
2.5 Switch between Rotary and Mulch mower .............................................13
2.6 Tilt the mower for maintenance and service procedures ................................14
Service and Maintenance ....................................................................16
3.1 Cleaning ............................................................................16
3.2 Maintenance ........................................................................18
Conditions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
4.1 Warranty ...........................................................................21
4.2 Complaints .........................................................................22
4.3 Disposal ............................................................................22
Notes ....................................................................................23

General information

5
Ophold i knækområdet
er forbudt
Aufenthalt im Knickbereich ist verboten
Activities around the articulation point is forbidden
Ne séjournez jamais dans la zone d’articulation
4
1
3
2
Operator’s Manual City Ranger 2260/2250 Rotary/mulch mower 1500
1.1 Safety
Make sure no-one is standing close
to the machine while it is in use
Make sure that no one is near the
machine while it is in use as there is a
danger of crushing.
NB
As it is articulated, the rear end of the
machine swings out when turning.
Make sure that no one is standing near
the machine while it is in use. (Picture 1)
Avoid crushing ngers
Keep your hands and ngers away
from areas where there is a danger of
crushing. (Picture 2)
Avoid roll-overs
Do not drive the machine in places
where there is a risk that it may slide,
tip or roll. Do not drive on slopes with
an incline of more than 10°. (Picture 3)
Warning! Rotating parts
To avoid personal injury, make sure no
one puts their ngers or toes under the
mower while it is in operation.
(Picture 4)
Warning
Remove stones and branches from
the lawn as they can be unintentionally
thrown out and cause damage to
people and property. Prevent people
from standing in the working area.
Warning
do not stand on mower deck
during transport or cutting.
Do not drive on slopes with an incline of
more than 10°
Max. 10°
Prevent people from standing in the
working area.
Warning label
Warning label
General information

6Operator’s Manual City Ranger 2260/2250 Rotary/mulch mower 1500 Operator’s Manual City Ranger 2260/2250 Rotary/mulch mower 1500
1.2 EC Declaration of Conformity
Manufacturer: Egholm A/S
Address: Transportvej 27 · DK-7620 Lemvig
Telephone: [phone]
hereby declares that
The machine: Rotary/Mulch mower 1500
Type: 22LM15
· has been manufactured in conformity with the provisions of the Machinery Directive 2006/42/EU
Any alteration, rebuilding or addition of implements, accessories or other equipment not
manufactured by Egholm automatically results in the cancellation of type approval, CE approval,
any other approval, as well as any warranty on machine and attachments.
Unless otherwise agreed in writing between the operator, customer and Egholm, Egholm is the
data originator (data originator) of all data generated by the machine and attachments during use.
Place: Lemvig
Date:
Signature:
Rainer Flanz, R&D Manager
General information

7Operator’s Manual City Ranger 2260/2250 Rotary/mulch mower 1500 Operator’s Manual City Ranger 2260/2250 Rotary/mulch mower 1500
General information
1.3 Technical data
Dimensions Attached Storage dimensions
Length (L) .................................................................... 3,080 mm ...........................................................990 mm
Width (W) .................................................................... 1,582 mm ........................................................1,582 mm
Height (H) .................................................................... 1,939 mm ...........................................................490 mm
Technical data
Type ............................................................................................................................................................. 22LM15
Sound power level, Directive 2000/14/EC .......................................................................................108 dB(A)
Own weight (Rotary mower)...... ............................................................................................................... 137 kg
Own weight (Mulch Mower)....... ...............................................................................................................145 kg
Cutting width ...........................................................................................................................................1500 mm
Adjustable cutting height ...................................................................................................................30-80 mm
Performance/hour approx ...................................................................................................up to 15.000 m²/h
Ground clearance below mower ...........................................................................................................135 mm
No. of mower blades .................................................................................................................................... 3 pcs
N.B!
Specications may be changed without prior notice.
Item number
Mulch Mower ......................................................................................................................................E70101232
Rotary Mower ...................................................................................................................................... E70101242
Optional equipment
Toplter (recommended) .................................................................................................................E70201081
Mulch Kit - The rotary mower, can be converted to a mulch mower,
with a mulch kit ................................................................................................................................E65003045

Operator´s manual

9
1
2
3
Operator’s Manual City Ranger 2260/2250 Rotary/mulch mower 1500
2.1 Assembly / Disassembly
Unpacking the mower
The mower is packed and delivered in a cardboard
box, on a pallet. (Picture 1)
Open the cardboard box.
Use a crane or a forklift, to lift the mower out of the
cardboard box. (Picture 3)
Operator’s manual
Mower in cardboard box, on a pallet.
Lifting point marks

10
4
1
3
2
Operator’s Manual City Ranger 2260/2250 Rotary/mulch mower 1500 Operator’s Manual City Ranger 2260/2250 Rotary/mulch mower 1500
2.1 Assembly / Disassembly
Check that the blades are sharp, intact and free from
cracks before attaching the mower. This avoids
unnecessary breakdown while mowing.
Assembly
1. The locking handle on the A-frame of the base
machine must be in the unlocked position. (Picture 1)
2. Drive the base machine right up to the A-frame
of the mower, so the A-frames t into each other.
(Picture 2)
N.B. It is recommended that the A-frame of the
machine is not dropped completely down, as
this may damage the mower paintwork when the
A-frames are tted together.
3. Raise the A-frame by pulling the joystick back
until the support wheels hang free of the ground.
(Picture 3)
4. Switch off the engine.
5. Use the locking handle on the A-frame to lock the
mower in place. (Picture 4). The locking handle can
only be engaged when the engine has been switched
off.
Disassembly
Follow the procedure for tting in reverse order.
Locking handle
Attaching
Lift
U
n
l
o
c
k
e
d
Locking
Operator’s manual

11
4
1
3
2
Operator’s Manual City Ranger 2260/2250 Rotary/mulch mower 1500 Operator’s Manual City Ranger 2260/2250 Rotary/mulch mower 1500
2.2 Before start-up
During transport
Lock the mower in the raised position using the
transport lock. This prevents the attachment from
lowering during transport.
How to use the transport lock
Move the handle to the uppermost position. Lift the
A-frame by moving the joystick up. As the A-frame
lifts, the transport lock is automatically activated.
(Picture 1)
How to unlock the transport lock
Unhitch the handle and lift the A-frame to the
uppermost position. The attachment can now be
lowered again. (Picture 2)
Warning
Make sure to avoid driving over
manhole covers or similar obstacles to
avoid damaging the blades and guard.
2.3 Start-up
1. Start the machine.
2. Lower the rotary mower by moving the joystick
down. (Picture 3)
3. Activate the weight distribution, using the left (red)
button on the joystick. (Picture 4) The mower will
now follow the terrain.
Note
When the weight distribution is on, the A-frame will
lower automatically, after lifting.
Transport lock – locked
Transport lock – unlocked
Joystick
Weight distribution
Operator’s manual

12
1
2
Operator’s Manual City Ranger 2260/2250 Rotary/mulch mower 1500 Operator’s Manual City Ranger 2260/2250 Rotary/mulch mower 1500
PTO-front
2.3 Start-up - continued
4. Push the throttle forward until it is at least half
open. (Picture 1)
5. Start the mower by activating PTO-front. (Picture 2)
6. Push the throttle all the way forward to achieve the
correct cutter speed.
7. Adjust the driving speed to suit the conditions.
8. Make sure to keep the radiator, water cooler and
radiator grilles free from grass. This ensures the
correct cooling effect and protects the engine. (See
Section 3.1 Cleaning)
Warning! Rotating parts
To avoid personal injury, make sure no
one puts their ngers or toes under the
mower while it is in operation.
Warning
Make sure no one is standing close to
the machine while it is in use.
NB
When turning, the rear of the machine
swings out so there is a risk of
crushing or collision.
Push the throttle forward until it is half open
Operator’s manual

13
1
3
2
4
Operator’s Manual City Ranger 2260/2250 Rotary/mulch mower 1500 Operator’s Manual City Ranger 2260/2250 Rotary/mulch mower 1500
Adjustment handle – Lowering the cutting
height
2.4 Adjustment
Adjusting the cutting height
Start with a high cutting height to avoid cutting the
grass too short.
Use the joystick to adjust the cutting height
For a higher cutting height, move the joystick
outwards. (Picture 1)
For a lower cutting height, move the joystick inwards.
(Picture 2)
Check the mower height and repeat the adjustment
until the required cutting height is achieved.
2.5 Switch between Rotary and Mulch
mower
From mulch mower to rotary mower
If you wish to convert your mulch mower into a
rotary mower, remove the mulch mower kit. (See
picture 4)
All triangles, and inside screens, and replace the
blades, with blade set (E65003048)
- See section 3.2 for replacing the blades.
From rotary mower to mulch mower
If you wish to convert your rotary mower into
a mulch mower, mount the mulch mower kit
(E65003045), all triangles, and inside screens, and
replace the blades - See section 3.2 for replacing the
blades.
Adjustment handle – Raising the cutting
height
Height adjustment scale
Operator’s manual
Mulch mower kit

14
1
2
3
4
Operator’s Manual City Ranger 2260/2250 Rotary/mulch mower 1500 Operator’s Manual City Ranger 2260/2250 Rotary/mulch mower 1500
2.6 Tilt the mower for maintenance
and service procedures
1. Lift the A-frame in highest position.
2. Pull the tilt handle to upper position (Picture 1)
3. Tilt the joystick outwards, to tilt the mower
(Picture 2)
4. Stop the machine.
Lower the mower again
1. Start the City Ranger.
2. Tilt the joystick inwards, to lower the mower
(Picture 2)
3. When the mower is down and in place, stop the City
Ranger. Check the tilt handle, is in lower position.
(Picture 4)
Warning
Never start the mower in tilted position.
Operator’s manual
Handle in upper position for tilt.
Joystick - Tilt/lower the mower.
Mower tilted.
Tilt lock - Handle in lower position

Operator’s Manual City Ranger 2260/2250 Rotary/mulch mower 1500 Operator’s Manual City Ranger 2260/2250 Rotary/mulch mower 1500
Service and
maintenance

16
1
2
Operator’s Manual City Ranger 2260/2250 Rotary/mulch mower 1500 Operator’s Manual City Ranger 2260/2250 Rotary/mulch mower 1500
3.1 Cleaning
Daily cleaning and maintenance will extend the
lifetime of both the machine and the attachment.
It is important that the couplings are intact and
clean before mounting the attachment.
If not clean, use a cloth or similar. (Picture 2)
Cleaning the mower
1. Keep the mower mounted on the City Ranger.
2. Tilt the mower up. (See section 2.6 for tilt).
(Picture 1)
3. Clean the mower with water.
4. Avoid high pressure cleaning of the hydraulic
couplings - use a cloth or similar. (Picture 2)
It is recommended to clean the mower immediately
after operation to stop the grass sticking to the
guard and blades
Tip the mower forward.
Clean the snap couplings
Service and Maintenance

17
1
2
Operator’s Manual City Ranger 2260/2250 Rotary/mulch mower 1500 Operator’s Manual City Ranger 2260/2250 Rotary/mulch mower 1500
3.1 Cleaning - continued
Cleaning the water/oil cooler
1. Open the side guards. Detach the side guards if
necessary. (Picture 1)
2. Blow the cover and radiator clean with
compressed air.
3. The radiator can be washed with clean water.
(Picture 2)
4. The radiator guards must be cleaned regularly if
cutting very dry grass.
Warning
Do not use hard implements when
rinsing the radiator, as this can damage
the ns.
Warning
Blow the radiator clean with
compressed air before washing the
machine. Otherwise the dirt will not
wash off.
Open the side guards
Wash the radiators with clean water
Service and Maintenance

18
2
3
4
1
Operator’s Manual City Ranger 2260/2250 Rotary/mulch mower 1500 Operator’s Manual City Ranger 2260/2250 Rotary/mulch mower 1500
Service and Maintenance
3.2 Maintenance
Greasing
Each wheel has 1 greasing nippel - 2 places in total.
(Picture 1)
Replacing the blades
If the blades are damaged, the mower will begin to
vibrate. These are replaced as follows:
1. Tilt the mower. (See section 2.6 for tilting the
mower.)
2. Switch off the machine.
3. Using a chisel or screwdriver, open the locking plate,
that locks the bolt heads (Picture 3)
4. Unschrew the bolts, and remove the locking plate,
and the disc.
5. Attach new blades, with the sharp edge, facing
towards the direction of travel. (Picture 4)
It is recommended to replace the blades, one at a
time, to ensure that they t correctly
6. Ret the locking plate, and bolts. The bolts should
be tighetened to a torque of 85 Nm.
7. Lock the bolts, by bending the locking plate towards
a at side, of each bolt.
8. It is recommended to avoid using locking plate,
more than twice, and to avoid bending it repeatedly.
This prevents the blades, from falling off during
operation.
New blades and locking plates can be ordered from an
authorised Egholm distributor.
Blade sets:
For rotary mower .............................................E65003048
For mulch mower ............................................ E65003049
Tilt the mower
Locking plate and bolts
Direction of blade travel
Greasing (2 places in total)

19Operator’s Manual City Ranger 2260/2250 Rotary/mulch mower 1500 Operator’s Manual City Ranger 2260/2250 Rotary/mulch mower 1500
Service and Maintenance
3.2 Maintenance - continued
Sharpening the blades
1. Tilt the mower (See section 2.6 for tilting the
mower).
2. Switch off the machine.
3. Detach the blades. (See section 3.2 replacing the
blades)
4. The blades should be sharpened equally on both
sides to ensure they are correctly balanced.
5. Attach the blades again. (See section 3.2 replacing
the blades)
Winter storage
When it is time to store the mower for the winter, the
following steps are recommended:
1. Remove any loose paint and repaint any damaged
areas.
2. Spray the mower with protective oil.
3. Make sure all grease points are full.

Operator’s Manual City Ranger 2260/2250 Rotary/mulch mower 1500 Operator’s Manual City Ranger 2260/2250 Rotary/mulch mower 1500
Conditions
