Egholm 2001 User manual

OPERATOR’S MANUAL
Salt & Sand Spreader
90101371-03 UK

INTRODUCTION
2
Dear Customer
Thank you for buying an Egholm product.
The Egholm 2001 is a Danish designed and manufactured product which offers a very flexible way
of maintaining outdoor areas.
Optimal performance of your Egholm Salt and Sand Spreader:
To ensure the optimal performance of your Egholm Salt and Sand Spreader, please read this
operator’s manual carefully before starting to use the machine. Failure to do so can result in personal
injury and damage to the machine.
Safety:
The Salt and Sand Spreader is equipped with various devices to ensure optimal operational safety both
for the user and the surroundings. We ask you to pay particular attention to page 5. The machine must
only be serviced by professionals.
The Salt and Sand Spreader is designed only for use by professionals. On delivery, the user will receive
thorough training to become a competent operator. Do not lend the machine to anyone who has not
been thoroughly trained and has not read this manual carefully.
The operator’s manual should be considered as a permanent part of the machine and so must
remain with it if the machine is sold.
Warnings:
Some items in this operator’s manual are marked with this warning symbol.
The warning indicates areas where extra care has to be taken to avoid personal
injury or damage to the machine and its accessories. The warning also shows
what you should pay special attention to.
Reservations:
As it is the Egholm policy to make continuous improvements, we reserve the right to alter the specifi-
cations and equipment at any time without notice. Egholm Maskiner A/S accepts no liability for errors
or shortcomings in the operator’s manual.
Contact us:
Should you have questions of any kind regarding your new Egholm product, do not hesitate to
contact Egholm Maskiner A/S.
Best regards
Egholm Maskiner A/S - Transportvej 27 - DK - 7620 Lemvig
Tel: [phone] - Fax: [phone]
e-mail: [email protected] - www.egholm.dk

CONTENTS
1. General information Page:
1.1 Safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.2 Technical data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2. Instructions for use
2.1 Assembly of the roller stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.2 Assembly/disassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.3 Start-up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.4 Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.5 Assembly/disassembly of the stirrer system . . . . . . . . . . . . . . . . . . . . 11
2.6 Important! . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.7 Field of application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3. Service and maintenance
3.1 Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4. Conditions
4.1 Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.2 Conditions of complaint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4.3 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4.4 EC Declaration of Conformity for Machinery . . . . . . . . . . . . . . . . . . . . 17
3

1 General information
The Salt and Sand Spreader was designed especially
for the Egholm 2100. It will ensure winter maintenance
by use of salt, sand, gravel and grit.
The Salt and Sand Spreader can ideally be combined
with the Dozer Blade, the Snow Blower and the Snow
Sweeper. In that way the driver is enabled to remove
snow and spread salt at one go and thereby provide a
safe route for the motorists and pedestrians.
A special designed roller stand enables the one person
to safely mount or dismount the spreader. (Picture 1)
The Salt and Sand Spreader features a stainless steel
hopper and a built-in air scoop, supplying the cooler
with fresh air and thereby also protecting the engine of
the basic unit from the fine salt particles.
The construction features only robust components. The
new deflector plate with high wear resistance handles
salt, sand and gravel. (Pictures 2 and 3)
4
1. GENEREL INFORMATION
3
2
1
Roller stand
Deflector plate

Bonnet lock
Deflector plate
Lowering the Salt and Sand Spreader
Lever
1.1 Safety
MMoouunnttiinngg::
Before mounting the Salt and Sand Spreader, check
that the console cover is closed and locked. (Picture 1)
Make sure the Salt and Sand Spreader is mounted
correctly and that the locking handle is left in locked
position. (See section 2.2)
PPrreevveennttaacccciiddeennttssbbeehhiinnddtthheeSSaallttaanndd
SSaannddSSpprreeaaddeerr::
Avoid fingers and toes near the rotating
deflector plate. (Picture 2)
KKeeeeppaassaaffeeddiissttaanncceettootthheeSSaallttaanndd
SSaannddSSpprreeaaddeerr
Make sure there is no one close to the
machine when it is in use.
AAvvooiiddccrruusshhiinnggffiinnggeerrss::
Keep your hands and fingers away from
areas where there is a danger of
crushing. (Picture 3)
AAvvooiiddrroollll--oovveerrss::
Do not drive the machine in a place
where it can slide, tip or roll. Do not drive
on slopes with an incline of more than
10°.
NN..BB..!!
As it is articulated, the rear of the machi-
ne swings out when turning. Make sure
no one is near the machine while it is in
use.
AAvvooiiddbblloowwssffrroommtthheelleevveerrwwhheenn
mmoouunnttiinnggtthheesspprreeaaddeerr::
Avoid blows from the lever when
lowering the spreader. Keep a firm grip
on the lever until the spreader rests
safely on the machine. (Picture 4)
1. GENEREL INFORMATION
4
3
2
1
5

Safety grating
SSaaffeettyyggrraattiinngg::
Never use the Salt and Sand Spreader unless the
container is covered by a meshed grid safety grating.
(Picture 1)
FFiilllliinnggiinnssaallttaannddggrraavveell::
Never fill the container with material to a higher level
than the container edges. The top point of the material
must not be higher than the edges of the container.
RReeaarrpprrootteeccttiivveegguuaarrdd::
The rear protective guard must always remain in its
holders except during cleaning (see section 3.1).
Before removing the guard, always stop the machine
and detach the hydraulic hoses to the Salt and Sand
Spreader. Be very careful - there are hot hydraulic
parts, a rotating feed screw as well as a rotating
deflector plate behind the guard.
Make sure you are fully familiar with the warning labels
on the guard. (Pictures 2-4)
TThheeddeefflleeccttoorrppllaattee::
Keep away from the deflector plate when the machine
is in use.
6
1. GENERAL INFORMATION
1
2
3
4

1.2 Technical data
MMoouunntteedd::
Length: 2225 mm
Width: 1015 mm
Height: 1265 mm
Weight: 574 kg
DDiissmmoouunntteeddoonnrroolllleerrssttaanndd::
Length: 1175 mm
Width 800 mm
Height: 1350 mm
WWeeiigghhtt
Roller Stand: 31 kg
Salt and Sand Spreader: 89 kg
SSppeecciiffiiccaattiioonnss
Volume: 210 Litres
Spread width: 1-5 metres.
NNBB!!
Specifications may be changed without prior notice.
Side view
Front view
Mounted on the roller stand
7
1. GENERAL INFORMATION
1
2
3
L
W
H

2.1 Assembly of the roller stand
On delivery, you will find the roller stand collapsed. Before
use the roller stand is to be assembled as follows:
A) Unpack and unfold the roller stand.
B) Assemble the roller stand with the two bolts included
and it is ready for use. (Picture 1)
2.2 Assembly/disassembly
FFiittttiinnggtthheevvaallvveelleevveerrbbrraacckkeett::
Before starting use of the Salt and Sand Spreader, the
bracket for the valve lever must be fitted in order for the
valve lever to stay in activated position. Unscrew the bolt
to the right of the valve block and fit the bracket in the
shown position with the enclosed nut and bolt. (Picture 2)
MMoouunnttiinnggtthheeSSaallttaannddSSaannddSSpprreeaaddeerr::
A) Make sure that the console cover is closed before
mounting the Salt and Sand Spreader. (See page 5,
picture 1)
B) Back up the basic unit to the Salt and Sand Spreader
which is stored on the roller stand. When the console
is placed directly beneath the Salt and Sand
Spreader, stop the engine. (See operator's manual for
the basic unit, section 2.2)
C) Press down the lever, the beard releases the locking
pawl and allows the Salt and Sand Spreader to be
lowered onto the basic unit. (Picture 3)
CCaauuttiio
onn!!
Avoid getting your fingers and feet caught
when lowering the Salt and Sand Spreader.
D) Release and pull away the roller stand.
E) Push the Salt and Sand Spreader forward into place.
F) The locking handle on the basic unit is activated and
the Salt and Sand Spreader is now in position.
Lower the Salt and Sand Spreader
Locking handle
8
2. INSTRUCTIONS FOR USE
Two bolts on roller stand
1
2
3
4
Valve lever bracket

G) Make sure that the locking handle is left in locked
position - the Salt and Sand Spreader is locked in
place. (Picture 1). Pull the Salt and Sand Spreader
to test a correct fit - it must not move.
H) Connect the hydraulic hoses:
If mounted, disconnect the snap couplings of the
rear lifter.
Connect the snap couplings of the Salt and Sand
Spreader to the connectors C1 and C2. (Picture 2)
For Salt and Sand Spreaders with a magnetic
valve, connect the 12V plug to the output on the
right side of the basic unit. (Picture 3)
DDiissaasssseemmbbllyy
Reverse the above procedure.
CCaauuttiioonn!!
Make sure that all hydraulic hoses (and
the electrical plug) are disconnected and
that they are not caught in something
when driving away from the Salt and
Sand Spreader.
2.3 Start-up
Start the basic unit. Then place lever C in the bracket.
(Picture 4)
If the Salt and Sand Spreader is equipped with a
magnetic valve (for switching the spreader on and off
electrically), activate the switch for the power outlet.
(Picture 5)
The Salt and Sand Spreader is now activated.
NNBB!!
Before start-up, make sure the rear
guard is positioned correctly.
Switch for power outlet
The Salt and Sand Spreader is in place
C2 C1
9
2. INSTRUCTIONS FOR USE
4
3
2
1
5
Power outlet

2.4 Adjustment
AAmmoouunnttsspprreeaadd::
To adjust the amount spread, turn the front knob on
the left-hand side of the spreader. (Picture 1)
Turn the knob clockwise to reduce the amount spread
per m2.
Turn the knob counter-clockwise to increase the
amount spread per m2.
For additional details about spread settings, see the
enclosed spreading chart.
SSpprreeaaddwwiiddtthh::
Spread width is the width of material spread by the
spreader. The material will be spread in a semicircular
pattern with equal amounts spread on either side of the
basic unit.
To adjust the spread width, turn the rear knob. The
spread width is adjustable from 1 to 5 m. (Picture 2)
Turn the knob clockwise to decrease and counter-
clockwise to increase the spread width.
For additional details about spread settings, see the
enclosed spreading chart.
SSpprreeaaddppaatttteerrnn::
The spread pattern refers to the way the material is
spread on the ground, when the basic unit is not
moving. Let the basic unit stand still for a few seconds
and the spread pattern will be visible on the ground. To
achieve an even spread pattern, turn the adjusting
knob on the back of the Salt and Sand Spreader.
(Picture 3) This will alter the spread pattern.
Turn the knob clockwise to increase the amount spre-
ad to the left.
Turn the knob counter-clockwise to increase the
amount spread to the right.
For additional details about spread settings, see the
enclosed spreading chart.
Amount spread
Spread width
Spread pattern
10
2. INSTRUCTIONS FOR USE
3
2
1
