REPAIR GUIDELINE
PART 1: Blade Replacement - LM2010E Lawn Mower

Table of Contents
NO. Contents Page
1 Blade Removal 3-5
2 Blade Installation 6-9
LM2010E Lawn Mower

1. Release switches and remove the battery pack from the mower.
2. While wearing protective gloves, turn the mower on its side (Fig. 1).
3. Place a metal rod (e.g., a thick bit) with a diameter less than 11mm into the fixing hole to act as a
stabilizer and place another metal rod (e.g., a thin bit) with a diameter less than 6.35 mm into the
holes (the through holes in the fan with the holes in the blade) to act as another stabilizer (Fig. 2).
1. Blade Removal
3
Another
Stabilizer
Stabilizer
2
LM2010E Lawn Mower
1
Fixing hole

4. Use a 14mm wrench to turn the blade bolt counterclockwise to loosen it.
1. Blade Removal
4
Another Stabilizer
Loosen
Stabilizer
LM2010E Lawn Mower

5. Remove the bolt, outer flange and the blade. Replace any broken or worn parts.
6. Remove the inner flange and fan from the motor shaft, then replace any broken or worn parts.
1. Blade Removal
Description
Part Number
SPEC
Flange Bolt
5640226001
M10×25
Outer Flange
5650510001
---
Blade
3706023001
---
Inner Flange
3520852002
---
Fan
3127847001
---
5
Motor shaft
Blade
Fan
Outer flange
Bolt
Inner flange
LM2010E Lawn Mower

Fan
Inner flange
1. Fix the inner flange into the fan.
2. Mount the fan and the inner flange onto the motor shaft with the fan blades towards the deck.
2. Blade Installation
6
Wrong assembly of
the fan
Fan blades towards deck
Fan
Motor shaft
LM2010E Lawn Mower

3. Mount the blade onto the inner flange with the
surface stating “THIS SIDE FACING GRASS” facing
outwards (Fig. 1) .
4. Aligning the flat position of the outer flange with
the corresponding flat position on the motor
shaft, mount the outer flange in place(Fig. 2).
2. Blade Installation
Flat position
Out flange
2
Flat position
7
This side facing outside
Flat position on the motor shaft
1
LM2010E Lawn Mower

5. Mount the bolt into the shaft and pre-tighten it in a clockwise direction by hand.
2. Blade Installation
8
Out flange
Bolt
Pre-tighten by hand
LM2010E Lawn Mower

6. Turn the blade by hand to align the holes in blade with the through holes in the inner flange(Fig. 1).
7. Place a metal rod (e.g. a thin bit) with a diameter less than 6.35mm into the aligning holes to act as
a stabilizer. Place another metal rod (e.g. a thick bit) with a diameter less than 11mm into the fixing
hole on the deck to act as another stabilizer(Fig. 2).
8. Use a torque wrench(S=14mm) to tighten the bolt clockwise. The recommended torque for the
blade bolt is 50±5N·m.
2. Blade Installation
9
Stabilizer 2
Stabilizer 1
Tighten
2
Align the hole
1
THE END
LM2010E Lawn Mower

REPAIR GUIDELINE
PART 2: Side Discharge Door Replacement_LM2010E Lawn Mower

Description
Part Number
Side Discharge Door
3127965001
2
Side Discharge Door Replacement
Side discharge
door
LM2010E Lawn Mower

1. Turn the mower on its back and remove the hexagon socket screws from the mower deck.
2. Take down the side discharge door assembly from the mower deck.
Side Discharge Door Replacement
3
Hexagon socket screw
Side discharge door assembly
Description
Part Number
SPEC
Qty
Hexagon
socket screw
5620213003
M5X10
2
LM2010E Lawn Mower

3. Pull out the shaft from the right side of side discharge door (Fig. 1).
4. Remove the torsion spring from the side discharge door (Fig. 2).
Description
Part Number
SPEC
Shaft
5670384001
Φ6x120
Torsion Spring
3660607001
-
Side Discharge Door Replacement
4
1
Shaft
2
LM2010E Lawn Mower

5. Replace with a new side discharge door, torsion spring or bevel support.
Side Discharge Door Replacement
5
Bevel support
Torsion spring
Side discharge
door
Shaft
Description
Part Number
•SPEC
Bevel Support
3705862001
84x15x25
LM2010E Lawn Mower

6. Assemble the torsion spring, bevel support and shaft into the side discharge door cover
following the figures below.
Side Discharge Door Replacement
6
Insert
Align the holes
Insert
LM2010E Lawn Mower

7. Mount the side discharge door assembly onto the mower deck by tightening two hexagon screw.
Side Discharge Door Replacement
7
THE END
LM2010E Lawn Mower

REPAIR GUIDELINE
PART 3.1: Parts in Power Unit Replacement_LM2010E Lawn Mower

Table of Contents
NO. Contents Page
1 Power Unit Removal 3-8
2 Motor Assembly Replacement 9-20
3 Main PCBA Replacement 21-38
4 Power Unit Assembly 39-44
LM2010E Lawn Mower

Description
Part Number
SPEC
Qty
Service Cover
3127947001
-
1
Tapping Screw
5620157006
M4.2x19
2
3
1. Before replacing or maintaining the parts in power unit or self-propelled unit, loosen the
two screws to remove the service cover from the mower.
1. Power Unit Removal LM2010E Lawn Mower
Service Cover

4
2. Turn the mower on its side and remove
the blade, and fan together with the inner
flange from the motor shaft as Part 1 show.
1. Power Unit Removal
Another
Stabilizer
Loosen
Stabilizer
LM2010E Lawn Mower
Service Cover
