EGO LM1700E-SP User manual

WARNING: To reduce the risk of injury, the user must read and understand the
Operator’s Manual before using this product. Save these instructions for future reference.
OPERATOR’S MANUAL
56 VOLT LITHIUM-ION
CORDLESS MOWER
MODEL NUMBER LM1700E/LM1700E-SP
MNL_EGO_LM1700E LM1700E-SP_AV01.01_210510

1.Self-propel Speed-control Knob
4. Handle
3. Safety Button 2. Switch Lever
5. Full-grass Indicator
6. Grass Bag Handle
7. Rear-Discharge Door
8. Rear Handle
9. Battery-Pack Cover
10. Front Wheel 11. Mower Deck
12. LED Headlights
13. Rear Wheel
14. Cutting-Height
Adjustment Lever
15. Grass Bag
16. Quick-Adjust
Lever
17. Side Rail
18. Handle-
Locking Clamp
A
B C 20. Safety Key Slot 21. Battery-Release
Button
22. Switch Button
for LED
Headlights
23. Power Indicator
19. Self-pro
pel Switch

Bottom Clip
Frame
Side Clips
Frame
E
G
J
F
H1 H2
I
D
Ribs
Locked
Storage
Position
Upper Operating
Position
Middle Operating
Position
Lower Operating
Position
Cutting Height Adjusting Level
Safety Key
Safety Key Slot
Battery-release
Button
Grass Bag Attachment/Removal
Bag Cover Mounting Slot

K L
M1
N O1
O2
M2
P1
3
1
1
1
1
4
2
2
2
2
1
2

V
T
U
P2
R1 R2
Q
Power indicator
Stabilizer 1
Stabilizer 2
S
Fan S-5 Bolt
Inner Flange
Blade
Outer Flange
S-5 Bolt
14mm
Wrench

W

56 VOLT LITHIUM-ION CORDLESS MOWER — LM1700E/LM1700E-SP 7
EN
READ ALL INSTRUCTIONS!
READ OPERATOR’S MANUAL
WARNING: To ensure safety and reliability, all repairs
and replacements should be performed by a qualified
service technician.
Intended use & Foreseeable misuse: The product
is intended for mowing grass in domestic gardens only. It
must not be used to mow unusually high, dry or wet grass,
e.g. pasture grass; or to shred leaves. The product is to
be used only for its prescribed purpose. Any other use is
deemed to be a case of misuse.
SAFETY SYMBOLS
The purpose of safety symbols is to attract your attention to
possible dangers. The safety symbols and the explanations
with them deserve your careful attention and understanding.
The symbol warnings do not, by themselves, eliminate any
danger. The instructions and warnings they give are no
substitutes for proper accident prevention measures.
WARNING: Be sure to read and understand all safety
instructions in this Operator’s Manual, including all safety
alert symbols such as “DANGER,” “WARNING,” and
“CAUTION” before using this tool. Failure to follow all
instructions listed below may result in electric shock, fire,
and/or serious personal injury.
SYMBOL MEANING
SAFETY ALERT SYMBOL: Indicates DANGER,
WARNING, OR CAUTION, may be used in conjunction with
other symbols or pictographs.
WARNING: The operation of any power tools can
result in foreign objects being thrown into your eyes, which
can result in severe eye damage. Before beginning power
tool operation, always wear safety goggles or safety glasses
with side shields and a full face shield when needed.
We recommend a Wide Vision Safety Mask for use over
eyeglasses or standard safety glasses with side shields.
SAFETY INSTRUCTIONS
This page depicts and describes safety symbols that may
appear on this product. Read, understand, and follow all
instructions on the machine before attempting to assemble
and operate it.
Safety Alert Precautions that involve your
safety.
Read
Operator’s
Manual
To reduce the risk of
injury, user must read and
understand operator’s
manual before using this
product.
Keep
Bystanders
Away
Ensure that other people and
pets remain at least 30m
away from the mower when
it is in use.
keep feet &
hand away keep feet & hand away
Beware of
Sharp Blades
Blades continue to rotate
after the motor is switched
off - Remove disabling device
before maintenance. Switch
off and remove detachable
battery pack (or disabling
device) before adjusting or
cleaning.
WEEE
Waste electrical products
should not be disposed of
with household waste. Take
to an authorized recycler.
XX
Noise
Guaranteed sound power
level. Noise emission to the
environment according to
the European community’s
Directive.
IPX4 IP Symbol Protection against ingress of
water degree 4
V Volt Voltage
mm Millimeter Length or size
cm Centimeter Length or size
Direct Current Type or a characteristic of
current
kg Kilogram Weight
Original instructions

56 VOLT LITHIUM-ION CORDLESS MOWER — LM1700E/LM1700E-SP8
EN GENERAL POWER TOOL SAFETY WARNINGS
WARNING: READ ALL SAFETY WARNINGS,
INSTRUCTIONS, ILLUSTRATIONS AND SPECIFICATIONS
PROVIDED WITH THIS POWER TOOL. Failure to follow all
instructions listed below may result in electric shock, fire
and/or serious injury.
SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE
REFERENCE.
The term "power tool" in the warnings refers to your
mains-operated (corded) power tool or battery-operated
(cordless) power tool.
WORK AREA SAFETY
◾Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
◾Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools create
sparks which may ignite the dust or fumes.
◾Keep children and bystanders away while
operating a power tool. Distractions can cause you
to lose control.
ELECTRICAL SAFETY
◾Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets will reduce risk
of electric shock.
◾Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
◾Do not expose power tools to rain or wet
conditions. Water entering a power tool will increase
the risk of electric shock.
◾Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords increase
the risk of electric shock.
◾When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of
a cord suitable for outdoor use reduces the risk of
electric shock.
◾If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
electric shock.
PERSONAL SAFETY
◾Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under
the influence of drugs, alcohol or medication. A
moment of inattention while operating power tools may
result in serious personal injury.
◾Use personal protective equipment. Always wear eye
protection. Protective equipment such as a dust mask,
non-skid safety shoes, hard hat or hearing protection used
for appropriate conditions will reduce personal injuries.
◾Prevent unintentional starting. Ensure the switch
is in the off-position before connecting to power
source and/or battery pack, picking up or carrying
the tool. Carrying power tools with your finger on the
switch or energising power tools that have the switch
on invites accidents.
◾Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached to a
rotating part of the power tool may result in personal injury.
◾Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power
tool in unexpected situations.
◾Dress properly. Do not wear loose clothing or
jewellery. Keep your hair and clothing away from
moving parts. Loose clothes, jewellery or long hair
can be caught in moving parts.
◾If devices are provided for the connection of dust
extraction and collection facilities, ensure these
are connected and properly used. Use of dust
collection can reduce dust-related hazards.
◾Do not let familiarity gained from frequent use of
tools allow you to become complacent and ignore
tool safety principles. A careless action can cause
severe injury within a fraction of a second.
POWER TOOL USE AND CARE
◾Do not force the power tool. Use the correct power
tool for your application. The correct power tool will
do the job better and safer at the rate for which it was
designed.
◾Do not use the power tool if the switch does not turn
it on and off. Any power tool that cannot be controlled
with the switch is dangerous and must be repaired.
◾Disconnect the plug from the power source and/
or remove the battery pack, if detachable, from
the power tool before making any adjustments,
changing accessories, or storing power tools. Such
preventive safety measures reduce the risk of starting
the power tool accidentally.

56 VOLT LITHIUM-ION CORDLESS MOWER — LM1700E/LM1700E-SP 9
EN
◾Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the
power tool or these instructions to operate the
power tool. Power tools are dangerous in the hands of
untrained users.
◾Maintain power tools and accessories. Check for
misalignment or binding of moving parts, breakage
of parts and any other condition that may affect
the power tool’s operation. If damaged, have the
power tool repaired before use. Many accidents are
caused by poorly maintained power tools.
◾Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
◾Use the power tool, accessories and tool bits etc.
in accordance with these instructions, taking into
account the working conditions and the work to be
performed. Use of the power tool for operations different
from those intended could result in a hazardous situation.
◾Keep handles and grasping surfaces dry, clean
and free from oil and grease. Slippery handles and
grasping surfaces do not allow for safe handling and
control of the tool in unexpected situations.
BATTERY TOOL USE AND CARE
◾Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type
of battery pack may create a risk of fire when used
with another battery pack.
◾Use power tools only with specifically designated
battery packs. Use of any other battery packs may
create a risk of injury and fire.
◾When battery pack is not in use, keep it away from
other metal objects, like paper clips, coins, keys,
nails, screws or other small metal objects, that can
make a connection from one terminal to another.
Shorting the battery terminals together may cause
burns or a fire.
◾Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact
accidentally occurs, flush with water. If liquid
contacts eyes, additionally seek medical help. Liquid
ejected from the battery may cause irritation or burns.
◾Do not use a battery pack or tool that is damaged
or modified. Damaged or modified batteries may
exhibit unpredictable behaviour resulting in fire,
explosion or risk of injury.
◾Do not expose a battery pack or tool to fire
or excessive temperature. Exposure to fire or
temperature above 130 °C may cause explosion.
◾Follow all charging instructions and do not charge the
battery pack or tool outside the temperature range
specified in the instructions. Charging improperly or at
temperatures outside the specified range may damage
the battery and increase the risk of fire.
SERVICE
◾Have your power tool serviced by a qualified repair
person using only identical replacement parts.
This will ensure that the safety of the power tool is
maintained.
◾Never service damaged battery packs. Service
of battery packs should only be performed by the
manufacturer or authorized service providers
SAFETY RULES FOR CORDLESS LAWN
MOWER
DANGER: This machine was built to be operated
according to the rules for safe operation included in
this manual. As with any type of power equipment,
carelessness or error on the part of the operator can result
in serious injury. This machine is capable of injuring hands
and feet and throwing objects. Failure to observe all safety
instructions could result in serious injury or death.
WARNING: When using cordless lawn mowers, basic
safety precautions should always be followed to reduce
the risk of fire, electric shock, and personal injury.
IMPORTANT
READ CAREFULLY BEFORE USE. KEEP FOR FUTURE
REFERENCE.
SAFETY RULES FOR CORDLESS LAWNMOWERS:
CAUTION-DO NOT TOUCH ROTATING BLADE!
TRAINING
◾Read the instructions carefully. Be familiar with the
controls and the proper use of the appliance.
◾Never allow people unfamiliar or children with these
instructions to use the appliance. Local regulations can
restrict the age of the operator.
◾Never mow while people, especially children, or pets
are nearby.
◾The operator or user is responsible for accidents or
hazards occurring to other people or their property.
PREPARATION
◾While mowing, always wear substantial footwear and
long trousers.

56 VOLT LITHIUM-ION CORDLESS MOWER — LM1700E/LM1700E-SP10
EN ◾Do not operate the appliance when barefoot or wearing
open sandals. Avoid wearing clothing that is loose
fitting or that has hanging cords or ties.
◾Thoroughly inspect the area where the appliance is to
be used and remove all stones, sticks, wires, bones,
and other foreign objects.
◾Before using, always visually inspect to see that the blades,
blade bolts and cutter assembly are not worn or damaged.
Replace worn or damaged blades and bolts in sets to
preserve balance. Replace damaged or unreadable labels.
OPERATION
◾Mow only in daylight or good artificial light.
◾Avoid operating the appliance in wet grass, where feasible.
◾Always be sure of your footing on slopes.
◾Walk, never run.
◾For wheeled rotary mowers, mow across the face of
slopes, never up and down.
◾Exercise extreme caution when changing direction on
slopes.
◾Do not mow on excessively steep slopes.
◾Use extreme caution when reversing or pulling the
appliance towards you.
◾Stop the blade(s) if the appliance has to be tilted for
transportation when crossing surfaces other than
grass, and when transporting the appliance to and
from the area to be mowed.
◾Never operate the appliance with defective guards
or shields, or without safety devices, for example
deflectors and/or grass catchers, in place.
◾Switch on the motor according to instructions and with
feet well away from the blade(s).
◾Do not tilt the appliance when switching on the motor,
except if the appliance has to be tilted for starting. In
this case, do not tilt it more than absolutely necessary
and lift only the part which is away from the operator.
Always ensure that both hands are in the operating
position before returning the appliance to the ground.
Do not start the machine when standing in front of the
discharge opening.
◾Do not put hands or feet near or under rotating parts.
For rotary mowers, keep clear of the discharge opening
at all times.
◾Never pick up or carry an appliance while the motor
is running.
◾Switch off and remove detachable battery pack (or
disabling device) and make sure that all moving parts have
come to a complete stop before adjusting or cleaning:
◾Whenever you leave the machine;
◾Before clearing a blockage and unclogging chute;
◾Before checking, cleaning or working on the
appliance;
◾After striking a foreign object. Inspect the appliance
for damage and make repairs as necessary.
◾If the appliance starts to vibrate abnormally (check
immediately):
◾Inspect for damage;
◾Replace or repair any damaged parts;
◾Check for the tighten any loose parts.
MAINTENACE AND STORAGE
◾Be careful during adjustment of the machine to prevent
entrapment of the fingers between moving blades and fixed
parts of the appliance.
◾Keep all nuts, bolts, and screws tight to be sure the
appliance is in safe working condition.
◾Check the grass catcher frequently for wear or
deterioration.
◾Replace worn or damaged parts for safety.
◾Cleaning and user maintenance shall not be made by
children without supervision.
◾When servicing the blades be aware that, even though the
power source is switched off, the blades can still be moved.
◾For rotary mowers, ensure that only replacement cutting
means of the right type are used.
PERSONAL SAFETY
Tragic accidents can occur if operator is not alert to the
presence of children. Children are often attracted to the
mower and mowing activity. They do not understand the
dangers. Never assume that children will remain where you
last saw them.
◾Keep children out of the mowing area and under the
watchful care of a responsible adult other than the operator.
◾Be alert and turn the mower off if a child enters the area.
◾Use extreme care when approaching blind corners,
doorways, shrubs, trees, or other objects that may obscure
your vision of a child who may run into the mower.
◾Children should be supervised to ensure that they are not
playing with the mower.
◾Always turn the mower off when removing the battery pack
from the tool. Stop the blade(s) if the appliance has to be
tilted for transportation when crossing surfaces other than
grass, and when transporting the appliance to and from the
area to be mowed.

56 VOLT LITHIUM-ION CORDLESS MOWER — LM1700E/LM1700E-SP 11
EN
OPERATION
GENERAL OPERATION:
◾Read this operator’s manual carefully in its entirety before
attempting to assemble this machine. Read, understand,
and follow all instructions on the machine and in the
manuals before operation. Be completely familiar with the
controls and proper use of this machine before operating
it. Keep this manual in a safe place for future and regular
reference and for ordering replacement parts.
◾Use the right appliance – Do not use the lawn mower
for any job except that for which it is intended.
◾Don’t overreach – Keep proper footing and balance at
all times.
◾Objects struck by the lawn mower blade can cause severe
injuries to persons. The lawn should always be carefully
examined and cleared of all objects prior to each mowing.
◾Before and while moving backwards, look behind and
down for small children and other people.
◾This machine is not a plaything. Therefore, exercise
extreme caution at all times. Your unit has been
designed to perform one job: to mow grass. Do not use
it for any other purpose.
◾Don’t force the lawn mower – it will do the job better
and more safely at the rate for which it was designed.
◾Before using, always visually inspect to see that the
blades, blade bolts and cutter assembly are not worn or
damaged. Replace worn or damaged blades and bolts
and any other components at the same time to preserve
balance. Replace damaged or unreadable labels.
◾Use extreme caution when reversing or pulling the
appliance towards you.
◾Thoroughly inspect the area where the equipment is to
be used. Remove all stones, sticks, wire, toys and other
foreign objects that could be tripped over or picked up
and thrown by the blade. Thrown objects can cause
serious personal injury. Plan your mowing pattern to avoid
discharge of material toward roads, sidewalks, bystanders
and the like. Also, avoid discharging material against walls
or obstructions, which may cause discharged material to
ricochet back toward the operator.
◾To help avoid blade contact or an injury from thrown
objects, stay in the operator zone behind the handles
and keep children, bystanders, helpers and pets at
least 30m from the mower while it is in operation. Stop
the machine if anyone enters the area.
◾Always wear safety glasses or safety goggles during
operation and while performing an adjustment or repair
to protect your eyes. Thrown objects that ricochet can
cause serious injury to the eyes. Always use a face or
dust mask if the operation is dusty.
◾Dress properly – Do not wear loose clothing or jewelry.
They can be caught in moving parts. Use of rubber
gloves and footwear is recommended when working
outdoors. Wear sturdy, rough-soled work shoes and
close-fitting trousers and shirts. Shirts and trousers
that cover the arms and legs and steel-toed shoes are
recommended. Never operate this machine in bare feet,
sandals, slippery or lightweight (e.g., canvas) shoes.
◾Do not put hands or feet near rotating parts or under
the cutting deck. Contact with the blade can injure
hands and feet.
◾A missing or damaged discharge cover can cause
blade contact or injuries from thrown objects.
◾Many injuries occur as a result of the mower being
pulled over the foot during a fall caused by slipping or
tripping. Do not hold onto the mower if you are falling,
release the handle immediately.
◾Never pull the mower back toward you while you are
walking. If you must back the mower away from a
wall or obstruction first look down and behind to avoid
tripping and then following these steps:
◾Step back from mower to fully extend your arms.
◾Be sure you are well balanced with sure footing.
◾Pull the mower back slowly, no more than half way
toward you.
◾Repeat these steps as needed.
◾Do not operate the mower while under the influence of
alcohol or drugs.
◾Stay alert – watch what you are doing. Use common sense.
Do not operate the lawn mower when you are tired.
◾The motor/blade control handle is a safety device.
Never attempt to bypass its operation. Doing so
makes the safety device inoperative and may result
in personal injury through contact with the rotating
blade. The motor/blade control handle must operate
easily in both directions and automatically return to the
disengaged position when released.
◾Avoid dangerous environments – Don’t use lawn
mowers in damp or wet locations.
◾Don’t use in rain.
◾Always be sure of your footing. A slip and fall can
cause serious personal injury. If you feel you are losing
your footing, release the motor/blade control handle
immediately and the blade will stop rotating within
three seconds.
◾Stop the blade when crossing gravel drives, walks or
roads.

56 VOLT LITHIUM-ION CORDLESS MOWER — LM1700E/LM1700E-SP12
EN ◾If the equipment should start to vibrate abnormally,
stop the motor and check immediately for the cause.
Vibration is generally a warning of trouble.
◾Inspect for damage;
◾Replace or repair any user replaceable damaged
parts;
◾Check for and tighten any loose parts.
◾Never operate the mower without the proper trailing
shield, discharge cover, grass bag, mulching insert,
side discharge chute, motor/blade control handle
or other safety protective devices in place and
working. Never operate the mower with damaged
safety devices. Failure to do so can result in
personal injury.
◾If situations occur that are not covered in this manual,
use care and good judgment. Contact EGO Customer
Service for assistance.
◾Use only with the battery packs and chargers listed
below:
BATTERY PACK CHARGER
BA1120E, BA1400, BA2240E,
BA2800, BA3360, BA4200,
BA1400T, BA2800T, BA4200T,
BA5600T
CH5500E,
CH2100E
OPERATION ON A SLOPE:
Slopes are a major factor related to slip-and-fall
accidents, which can result in severe injury. Always
be sure of your footing on slopes. Operation on slopes
requires extra caution. If you feel uneasy on a slope, do
not mow it.
Do:
◾Mow across the face of slopes; never mow up and down.
Exercise extreme caution when changing direction on slopes.
◾Watch for holes, ruts, rocks, hidden objects, or bumps which
can cause you to slip or trip. Tall grass can hide obstacles.
Do not:
◾Do not mow near drop-offs, ditches or embankments; you
could lose your footing or balance.
◾Do not mow slopes greater than 15 degrees.
◾Do not mow on wet grass. Unstable footing could cause
slipping.
SERVICE
WARNING: Grass bag components, the discharge
cover, side discharge chute, mulching insert and trailing
shield are subject to wear and damage, which could expose
moving parts or allow objects to be thrown and could
increase the risk of injury. For safety protection, frequently
check all components and replace damaged components
immediately with identical replacement parts, listed in this
manual. Contact EGO Customer Service or your closest
EGO service center, and repairs or replacements shall be
performed by a qualified service technician!
◾If the mower’s built-in overload protection switch
frequently trips, contact EGO Customer Service or your
closest EGO service center.
◾Do not wash the mower with a hose; avoid getting
water in the motor and electrical connections.
◾Remove the key and store the idle lawn mower indoors
when not in use. Allow the motor to cool before storing it
in any enclosure. The lawn mower should be stored in a
dry, high, or locked-up enclosure, out of reach of children.
◾When servicing, use only identical replacement parts
listed in this manual. Use of parts that do not meet the
original equipment specifications may lead to improper
performance and compromised safety.
◾Remove or disconnect the battery pack before servicing,
cleaning, or removing material from the lawn mower.
◾Follow instructions for changing accessories.
◾Keep handles dry, clean and free from oil and grease.
◾To reduce a fire hazard, keep the motor cover free of
grass, leaves and debris build-up.
◾Check the blade and motor mounting bolts at frequent
intervals for proper tightness. Also, visually inspect the
blade for damage (e.g., bending, cracking and wear.).
Replace the blade only with the identical replacement
blade, listed in this manual.
◾Maintain your mower with care – keep the mower
blade sharp and clean for the best and safest
performance. Mower blades are sharp and can cut.
Wrap the blade or wear gloves and use extra caution
when servicing it.
◾Never remove or tamper with safety devices. Regularly
check their proper operation. Never do anything to
interfere with the intended function of a safety device
or to reduce the protection provided by a safety device.
◾Always stop the motor before making adjustments to a
wheel or a cutting-height adjustment.
◾After striking a foreign object, stop the motor, remove the
key, and thoroughly inspect the mower for any damage.
Repair the damage before operating the mower.
◾Maintain or replace safety and instruction labels,
as necessary. Contact EGO Customer Service or
your closest EGO service center, and repairs or
replacements shall be performed by a qualified service
technician!

56 VOLT LITHIUM-ION CORDLESS MOWER — LM1700E/LM1700E-SP 13
EN
◾SAVE THESE INSTRUCTIONS. Refer to them frequently
and use them to instruct others who may use this tool.
If you lend this tool to someone else, also lend these
instructions to them to prevent misuse of the product
and possibly injury.
BATTERY USE AND CARE
◾To preserve natural resources, please recycle or
dispose of batteries properly. This product contains
lithium-ion batteries. Local or national laws prohibit
disposal of lithium-ion batteries in ordinary rubbish.
Consult your local waste authority for information
regarding available recycling and/or disposal options.
◾Upon removal of the battery pack for disposal or
recycling, cover the battery pack’s terminals with
heavy-duty adhesive tape. Do not attempt to destroy
or disassemble the battery pack or remove any of its
components. Lithium-Ion batteries, must be recycled
or disposed of properly. Also, never touch the terminals
with metal objects and/or body parts as a short circuit
may result. Keep away from children. Failure to comply
with these warnings could result in fire and/or serious
injury.
◾UNDER ABUSIVE CONDITIONS, LIQUID MAY BE
EJECTED FROM THE BATTERY; AVOID CONTACT. IF
CONTACT ACCIDENTALLY OCCURS, FLUSH WITH
WATER. IF LIQUID CONTACTS EYES, ADDITIONALLY
SEEK MEDICAL HELP. Liquid ejected from the battery
may cause irritation or burns.
SPECIFICATIONS
Model Number LM1700E LM1700E-SP
Self Propel System No Yes
Voltage 56 V 56 V
Recommended
Operating Temperature: 0°C-40°C 0°C-40°C
Recommended Storage
Temperature: -20°C-70°C -20°C-70°C
Optimum Charging
Temperature 5 °C-40 °C 5 °C-40 °C
No-load Speed 3000/min 3000/min
Cutting Height 20-80mm 20-80mm
Cutting Height Positions 7 7
Deck Size 46cm 46cm
Cutting Width 42cm 42cm
Grass Bag Volume 55L 55L
Mower Weight (Without
battery pack and
mulching insert)
22 kg 24 kg
Blade Model AB1701 AB1701
Blade Brake YES YES
PACKING LIST
PART NAME QUANTITY
Lawn mower 1
Grass Catcher 1
Safety key 1
Operator’s manual 1
DESCRIPTION
KNOW YOUR MOWER (Fig. A & B & C)
1. Self-propel Speed-control Knob
2. Switch Lever
3. Safety Button
4. Handle
5. Full-grass Indicator
6. Grass Bag Handle
7. Rear-Discharge Door
8. Rear Handle
9. Battery-Pack Cover
10. Front Wheel
11. Mower Deck
12. LED Headlights
13. Rear Wheel
14. Cutting-Height Adjustment Lever
15. Grass Bag
16. Quick-Adjust Lever
17. Side Rail
18. Handle-Locking Clamp
19. Self-propel Switch
20. Safety Key Slot
21. Battery-Release Button
22. Switch Button for LED

56 VOLT LITHIUM-ION CORDLESS MOWER — LM1700E/LM1700E-SP14
EN OPERATION
ASSEMBLING THE GRASS BAG
1) Assemble the two side clips and the bottom clip to
the frame (Fig. D).
2) Align the ribs with the mounting slots on the bag cover
and press the rib down until you hear a “click” (Fig. E).
NOTICE: Under normal usage, bag material is subject to wear.
To reduce the risk of injury, frequently inspect the bag assembly
and replace if there are any signs of wear or deterioration. Use
only grass bags manufactured for this mower.
ADJUSTING THE FOLDABLE HANDLE
WARNING: Do not attempt to start the mower until
the handle has been locked at one of the three preset
operating positions (UPPER OPERATING POSITION, MIDDLE
OPERATING POSITION and LOWER OPERATING POSITION).
Your mower is shipped with the handle in the compact,
LOCKED STORAGE POSITION (Fig. F).
1) Press and hold the quick-adjust lever to release the
handle from the LOCKED STORAGE POSITION.
2) Lift the handle from its folded position, then release
the lever. Gently pivot the handle upward until you hear
and feel the lock pin engage in one of the following
different positions as shown in the Fig. G.
ATTACHING THE GRASS BAG
WARNING: Do not at any time make any adjustment
to the lawn mower without first stopping the motor,
removing the safety key and waiting for the blade to stop
rotating.
NOTICE: Attachany of the attachments to the lawn
mower before mowing.
◾To Attach/Remove the Grass Bag (Fig. H1 & H2)
Insert the board of the grass bag into the mower and
hang the grass bag on the mower.
NOTICE: Remove the mulching insert (Need to be
purchased separately) from the mower before attaching the
grass bag to the mower.
◾To Attach/Remove the Mulching Insert (Fig. I)
Lift the rear-discharge door and insert the mulching insert
into the mower. To remove, just pull it out. Lastly, release
the rear-discharge door.
ADJUSTING THE CUTTING HEIGHT (Fig. G)
WARNING: Keep your feet away from the deck when
adjusting its height. The mower can be set to 7 cutting
heights between 20mm and 80mm. Choose the proper
cutting height according to the types and conditions of the
grass.
NOTICE: When moving the tool, make sure the cutting
height is adjusted at the position of 3 or higher. Failure to do
so, could result in the damage of the blade.
ATTACHING/DETACHING THE BATTERY PACK (Fig. J)
CHARGE BEFORE FIRST USE.
WARNING: If any parts are broken or missing, do not
attempt to attach the battery pack to the mower or operate
the mower until the broken or missing parts are replaced.
Failure to do so could result in serious injury.
◾To Attach
Push the battery pack into the battery compartment until
you hear a “click”.
◾To Detach
Depress the battery-release button in the battery
compartment.
NOTICE: Make sure that the latch on the mower snaps
into place and that the battery pack is secured to the
mower before starting operation.
STARTING/STOPPING THE MOWER
WARNING: The operation of any lawn mower
can result in foreign objects being thrown into your or
other’s eyes, which can damage eyes severely. Always
wear safety glasses while operating the mower, or while
performing any adjustments or repairs on it.
WARNING: Do not use the mower in the rain.
WARNING: Ensure that other people and pets
remain at least 30m away from the mower when it is in
use.
WARNING: The blade will continue to rotate for
a few seconds after the mower is turned off. Allow the
motor/blade to stop rotating before starting it again. Do
not rapidly turn the mower off and on.
SAFETY KEY
In order to prevent accidental start-up or unauthorized
use of your cordless mower, a removable safety key has
been incorporated into the design of your mower. The

56 VOLT LITHIUM-ION CORDLESS MOWER — LM1700E/LM1700E-SP 15
EN
mower will be completely disabled when the safety key
has been removed from the mower.
DANGER: Rotating blades can cause serious injury.
To prevent serious injury, remove the safety key when
the mower is unattended, or when adjusting, cleaning,
servicing, transporting, lifting, or storing the mower.
NOTICE: The motor cannot be started unless:
◾The handle is locked into one of the three operating
positions, see ADJUSTING THE FOLDABLE HANDLE.
◾The side rails are fully extended (Fig. K)
◾Both green handle-locking clamps are securely closed
(Fig. L).
CAUTION: Do not attempt to override the operation of the
safety button and bail switch.
To Start (Fig. M1 & M2)
NOTICE: To prevent serious injury, we recommend you to
start the mower with self-propel function off.
START THE MOWER WITH SELF-PROPEL FUCTION
ON (Fig. M1)
1) Attach the battery pack to the mower, insert the safety
key into the key slot and close the battery cover.
2) According to Fig. M1, depress the safety button down.
3) Pull the bail switch upward to meet the handle and
release the safety button.
4) Depress one of the self-propel switch.
5) With the self-propel and safety button switch
depressed, then turn the self-propel speed-control
knob until you hear a “click”.
START THE MOWER WITH SELF-PROPEL FUCTION
OFF (Fig. M2)
1) Attach the battery pack to the mower, insert the safety
key into the key slot and close the battery cover.
2) According to Fig. M2, depress the safety button
down.
3) With the safety button depressed, pull the bail switch
upward to meet the handle and release the safety
button.
To Stop (Fig. N)
1) Fully release the bail switch.
2) The electric brake in the Automatic Braking
Mechanism will stop the blade rotation within 3
seconds of the bail switch release.
3) Turn the self-propel Speed-control knob off until it
can’t be rotated.
VARIABLE-SPEED SELF-PROPEL SYSTEM
(only for model LM1700E -SP )
LM1700E-SP mower is equipped with variable-speed self-
propel capability. This system is independent of the blade
On-Off switch. it is not dependent on blade rotation.
To operate the system without blade rotation (Fig. O1)
1) Press the one of self-propel switches.
2) Turn the self-propel Speed-control knob until you
hear a “click”.
To turn the self-propel off, release the self-propel switch
and Turn the self-propel Speed-control knob off until it can’t
be rotated. (Fig. O2)
WARNING: To reduce the risk of injury, never attempt
to override the operation of the switch or self-propel
system. Use the self-propel for its intended purpose only.
LED HEADLIGHTS (Fig. A-12)
Press the switch button 1S (Fig. C-26) to turn on/off the LED
headlights in the front of the battery compartment.
FULL-GRASS INDICATOR (Fig. P1 & P2)
THE GRASS BAG IS NOT FULL (Fig. P1).
THE GRASS BAG IS FULL (Fig. P2). Stop the mower and
remove the battery pack, clean your grass bag.
POWER INDICATOR ON THE MOWER (Fig. Q)
The mower is equipped with a power indicator to indicate
the charge status of the battery pack and the working
status of the mower. The power indicator will illuminate
when the blade is rotating or when the LED headlights are
turned on.
Power
Indicator
on
Mower
Meaning Action
Shining
green
Mower is working
properly N/A
Flashing
green
Handle-Locking
Clamp/Quick-
Adjust Lever is not
triggered properly
Re-triggered the
handle-locking clamp/
quick-adjust Lever
Flashing
red
The battery is
depleted
Stop the mower and
charge the battery
pack

56 VOLT LITHIUM-ION CORDLESS MOWER — LM1700E/LM1700E-SP16
EN
Solid
orange
The mower is
overheated
Remove the battery
from the mower, move
them to the shade and
cool them at least 15
minutes
Flashing
orange
The mower is
overloaded
Slow down your pace
or raise up the cut
height to decrease
the load
Red and
green
flashing
alternately
Communication
timeout Connect EGO
MOWER OVERLOAD PROTECTION
To prevent overload conditions, do not try to remove too
much grass at one time. Slow down your cutting pace or
raise the cut height.
Your mower has built-in overload circuit protection. When
the mower is overloaded, the motor will stop and the
power indicator on the mower will flash orange. Remove
the battery pack from the mower. Check to see if grass
has collected beneath the deck and clear it if necessary,
then install the battery and restart the mower.
BATTERY HIGH TEMPERATURE PROTECTION
The heat dissipates more slowly in hot weather. If the
battery temperature exceeds 70°C during operation, the
protection circuit will immediately turn off the mower to
protect the battery pack from damage. The power indicator
on the mower will shine orange and the LED on the battery
will flash orange. Release the bail handle, wait until the
battery pack cools down to approximately 67°C, then
restart the mower.
MAINTENANCE
WARNING:To avoid serious personal injury, always
remove the safety key from the mower before cleaning,
performing any maintenance or transporting the mower.
WARNING: When servicing, use only identical
replacement parts. Use of any other parts may create a
hazard or cause product damage. To ensure safety and
reliability, all repairs and replacements should be performed
by a qualified service technician.
GENERAL MAINTENANCE
WARNING: Always remove the safety key and battery
pack when servicing or transporting the mower.
The underside of mower deck should be cleaned after each
use, as grass clippings, leaves, dirt and other debris will
accumulate.
Remove any build-up of grass on or around the drive shaft
and the motor fan (do not use water). Wipe the mower
clean with a damp cloth.
REMOVING/INSTALLING THE BLADE
WARNING: Always protect your hands by wearing
heavy gloves or wrapping the cutting edges with rags or
other materials when performing any maintenance on
the mower blade. Always remove the battery pack when
servicing or transporting the mower.
◾To Remove the Blade
Following Fig. R1.
NOTICE: If the bolt rotates with the motor shaft when
loosening the bolt, turn the fan by hand to align the
through holes in the fan with the holes in the blade,
and place another metal rod into the aligned holes
(Fig. R2).
◾To Install the Blade
Following the assembly sequence in Fig. S, with the
fan blade towards deck and the printed blade side
towards outside, align the through holes in the fan
with the holes in the blade (Fig. T) and then tighten the
blade as Fig. U shown.
NOTICE: The recommended torque for tightening the
blade bolt is 49-59Nm.
STORING THE MOWER
◾Remove the battery pack from the mower and store it
in a cool, dry and clean location. Do not store it next to
corrosive materials, such as fertilizer or rock salt.
◾Store the mower in a covered, enclosed space, that is
cool and dry and out of the reach of children.
◾Do not cover the lawn mower with a solid plastic sheet.
Plastic coverings trap moisture around the mower,
which causes rust and corrosion.
◾The mower can be stored upright or flat. (Fig. V & W).
WARNING:If the mower tips over from the upright
position, mower damage or personal injury may result.
Always keep the mower stable and out of the reach of
children when it is in the upright position. If possible, lay it
flat for storage.

56 VOLT LITHIUM-ION CORDLESS MOWER — LM1700E/LM1700E-SP 17
EN
Protecting
Do not dispose of electrical appliances as
unsorted municipal waste, use separate
collection facilities.
Contact your local government for
information regarding the collection
systems available.
If electrical appliances are disposed of in
landfills or dumps, hazardous substances
can leak into the groundwater and get into
the food chain, damaging your health and
well-being.

56 VOLT LITHIUM-ION CORDLESS MOWER — LM1700E/LM1700E-SP18
EN TROUBLESHOOTING
WARNING: Always remove the safety key and battery pack when servicing or transporting the mower. Always
protect your hands by wearing heavy gloves or wrapping the cutting edges with rags or other materials when
performing any maintenance on the mower blade.
PROBLEM CAUSE SOLUTION
The mower fails
to start
◾The battery pack is depleted. ◾Charge the battery pack.
◾The battery pack is not mounted in place in
the battery compartment.
◾Attach the battery pack to the
mower; press it until you hear a
click
◾The battery or mower circuitry is too hot.
(The power indicator on the mower will
illuminate in orange for 10 seconds)
◾Allow the battery pack or mower
to cool until the temperature drops
below 67°C.
◾The side rails are not extended to their
maximum length and the clamps are not
locked in position.
◾Fully extend the handle and lock
both clamps.
◾The handle is not set at one of the three
operating positions.
◾Adjust the handle to one of the three
operating positions.
◾The mower deck is clogged with grass and
debris.
◾Clean the mower deck and make
certain that the blade has freedom
of movement.
The mower cuts
unevenly
◾The blade is dull. ◾Sharpen or replace the blade.
◾The cutting height is not set properly. ◾Raise the deck to a higher cutting
height setting.
◾The blade is assembled incorrectly. ◾Reassemble the blade, following the
section “INSTALLING THE BLADE” in
this manual.
The mower stops
while mowing
◾The battery pack is depleted. ◾Charge the battery pack.
◾Mower is in overload condition. ◾Raise the cutting height or slow down
the mowing.
◾Mower deck is clogged with grass and
debris.
◾Unclog the mower deck. Raise
the cutting height, or cut a narrow
swath.
◾The battery or mower circuitry is too hot. (The
power indicator on the mower will illuminate
orange for 10 seconds.)
◾Allow the battery pack or mower
to cool until the temperature drops
below 67°C.
◾The side rail is retracted a little by the
pushing force applying on the handle.
◾Unlock the clamps. Fully extend the
side rails and lock the clamps again.

56 VOLT LITHIUM-ION CORDLESS MOWER — LM1700E/LM1700E-SP 19
EN
PROBLEM CAUSE SOLUTION
The mower does not
mulch properly
◾Wet grass clippings are sticking to the
underside of the deck.
◾Wait until the grass dries before
mowing.
◾The mower is set to cut too much grass at
once.
◾Raise the deck to a higher cutting
height setting.
There is excessive
vibration
◾The cutting blade is loose. ◾Tighten the blade bolt.
◾The cutting blade is unbalanced. ◾Balance the blade following the
instructions.
◾The cutting blade is bent. ◾Replace the blade.
◾The motor shaft is bent. ◾Contact the service center.
The handle locking
clamps cannot be
closed in position.
◾The side rails are not fully extended. ◾Fully extend the side rails, then lock
the clamps.

56 VOLT LITHIUM-ION CORDLESS MOWER — LM1700E/LM1700E-SP20
EN WARRANTY
EGO WARRANTY POLICY
5 years warranty on EGO outdoor power equipment and 3 years warranty on EGO Power+ System battery packs and
chargers.
Please contact EGO customer service on Australia 1300 000 EGO(1300 000 346),
New Zealand 0508 000 EGO (0508 000 346) any time you have questions or warranty claims.
LIMITED SERVICE WARRANTY
FOR TWO YEARS from the date of original retail purchase, this EGO product is warranted against defects in material or
workmanship. Defective product will receive free repair.
FOR ONE YEAR from the date of original retail purchase, the EGO Power+ System battery pack and charger are
warranted against defects in material or workmanship. Defective product will receive free repair.
This warranty does not cover the blade, which is a part that can wear out from normal use within the warranty period.
◾This warranty applies only to the original purchaser at retail and may not be transferred.
◾Warranty for commercial use is 1 year on all product, battery and chargers. The Commercial Series Product Warranty
for commercial users is 2 years for product, battery and charger.
◾This warranty is void if the product has been used for rental purpose.
◾This warranty does not cover the damage resulting from modification, alteration or unauthorised repair.
◾This warranty only covers defects arising under normal usage and does not cover any malfunction, failure or defect
resulting from misuse, abuse (including overloading of the product beyond capacity and exposure to water or rain),
accidents, neglect or lack of proper installation, and improper maintenance or storage.
◾This warranty does not cover normal deterioration of the exterior finish, including but not limited to scratches, dents,
paint chips, or to any corrosion or discoloring by heat, abrasive and chemical cleaners.
HOW TO OBTAIN SERVICE
For warranty service, please contact EGO customer service on Australia 1300 000 EGO(1300 000 346), New Zealand
0508 000 EGO (0508 000 346). When requesting warranty service, you must present the original dated sales receipt. An
authorised service center will be selected to repair the product according to the stated warranty terms.
ADDITIONAL LIMITATIONS
Chervon Australia Pty Ltd ABN 36 165 077 501(“Chervon”) warrants to the original domestic purchaser that this
product will be free from defects in materials and workmanship for 2 years from date of purchase, and any battery or
charger will be free from defects in materials and workmanship for 1 year from date of purchase. To make a claim,
return the faulty item together with proof of purchase directly to your closest service agent or to the place of purchase.
Any handling and transportation costs (and other expenses incurred in claiming this warranty) are not covered by this
warranty and will not be borne by Chervon. The replacement product or part or repaired product will be made available
for your collection at an address nominated by Chervon. Where a valid warranty claim is made, Chervon will replace
the defective product or repair the fault. Where the product is repaired, Chervon may use refurbished parts. This
warranty does not cover normal wear and tear, misuse or abuse. This warranty may also be further limited or voided
as specifically detailed in the product Manual. Chervon has no other liability under this warranty.The benefits to you
given by this warranty are in addition to other rights and remedies imposed by State and Federal legislation that cannot
be excluded. Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are
entitled to a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or
damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure.
Chervon Australia Pty Ltd, Unit Unit 14, 5 Kelletts Road, Rowville, VIC 3178.
Phone Number: Australia 1300 000 EGO(1300 000 346), New Zealand 0508 000 EGO (0508 000 346).
Email address: [email protected].
