Quick Star Guide –
Charging Terminal RFT02
for EHRLE-CarWash-Key
Unpack UnicoCard software and run the setup
Important: When asking “Do you want to install RFTech USB
driver?”, select “Yes” ->
After installation connect desktop reader to PC via USB cable
Start the software by double-clicking on the icon „UnicoCard“
Go to Options ->Language to set the language for the software
After selecting the language, click on the „Read Card“ button ->
Now a password must be entered. This code can be found on the keyreader of the carwash
or on the currency list. For example, the code might be 100-1052-1000. The first 3 digits form
the Administrator, the following 4-digit number forms the location and the last 4-digit part
forms the Access level.
Confirm the password with „OK“.

Reinigungstechnik
CarWash-Systeme
Projektmanagement
EHRLE-GmbH
Industriestraße 3
89165 Dietenheim
USt-IdNr.DE 130839188
Page 2 von 4
Stand07.02.2020
Tel.: [phone]
eMail: [e-mail]
Web: www.ehrle.de
Subject to changes
INITIALIZE NEW KEYS
Take NEW or NOT initialized keys and place them on the desktop reader
o Switch to the „Format“ tab
o You can add the application to your key by clicking the button „Add
Application“
o If the transfer was successful, the following will appear on your screen:
o Now switch to the tab „User data“
o There you can enter the amount you want to load on the key in the “credit” input field.
o By clicking on „Set credit“, the amount will be transferred to the key.
o After the transfer, you can remove the key from the desktop reader.
o The key is now charged and ready to use.

Reinigungstechnik
CarWash-Systeme
Projektmanagement
EHRLE-GmbH
Industriestraße 3
89165 Dietenheim
USt-IdNr.DE 130839188
Page 3 von 4
Stand07.02.2020
Tel.: [phone]
eMail: [e-mail]
Web: www.ehrle.de
Subject to changes
CHARGING AN INITIALIZED KEY
Take the initialized key an place them on the desktop reader
o Click on the button „Open Card“
o If reading the key was successful, the following will appear on your screen:
o Now you can enter the amount you want to load on the key in the „Credit“ input field.
o By clicking on „Set credit“, the amount will be transferred to the key.
o After the transfer, you can remove the key from the desktop reader

Reinigungstechnik
CarWash-Systeme
Projektmanagement
EHRLE-GmbH
Industriestraße 3
89165 Dietenheim
USt-IdNr.DE 130839188
Page 4 von 4
Stand07.02.2020
Tel.: [phone]
eMail: [e-mail]
Web: www.ehrle.de
Subject to changes
ERRORS
The following errors may occur:
o Opening a key without initialization leads to the message :Virgin Key
To resolve this issue, the key must first be initialized. The instructions for this can be read on
page 2.
o If the desktop reader’s code does not match the code of the key, it will result in a message:
CE_AUT_SYSTEM
The code of the desktop reader can be modifies using the „Administrator“ button to fit the
code of the key.
o If the desktop reader does not recognize a key, the following error occurs: Card not present
To fix the error, you need to check if there is a key on the reader at all. If so, it must be in
position, like the key on page 2.
Since the key charging is a radio transmission. Repeated attempts are not to be considered errors!
