Eibach MULTI-PRO-R2 User manual

D3157 - Page 1
Eibach Springs, Inc. | 256 Mariah Circle | Corona | California 92879-1751 | USA
T [phone]
www.eibach.com
MULTI-PRO-R2 | INSTALLATION INSTRUCTIONS
1997-01 Acura Integra, Type-R, DC2
PART NUMBER 4020.713
PERFORMANCE SUSPENSION AUTOMOTIVE OEM/OES HI-TECH INDUSTRIAL
PARTS & HARDWARE LIST
Part Number Description Qty Part Number Description Qty
A 4017.8300 DAMPER ASSY FRONT 2 D PDK4.TOOL 4mm ADJUSTMENT TOOL 1
B 4020.8400 DAMPER ASSY REAR 2 E PDK6.TOOL 6mm ADJUSTMENT TOOL 1
C UB0120 RESERVOIR CLAMP 2 F PDR.TOOL REBOUND TOOL 1
PARTS IDENTIFIER
NOTES: Read All Instructions Before Beginning Installation
Installation of a Eibach Multi-Pro Coil-Over set should only be performed by a qualified mechanic experienced in the
installation and removal of suspension components.
Use of a hoist is highly recommended and will substantially reduce installation time.
Never work on or under a vehicle unless it is properly supported by safety stands and wheels are blocked.
Never use impact wrenches or guns to install or remove shock absorber piston components, shafts and piston rod
nuts.
After installation, it is always important to inspect and adjust the following if necessary:
- Wheel alignment such as camber, caster & toe.
- Tire and/or wheel fender clearance.
- Brake line clearance and attachments.
- Brake anti-locking and anti-skid system sensors.
Alignment: After installation, you will need a full vehicle alignment to ensure proper tire wear and performance.
Height Adjustment – Should be performed with the wheels completely off the ground and with the springs fully
unloaded.
A
D
E
C
B
F

D3157 - Page 2
Eibach Springs, Inc. | 256 Mariah Circle | Corona | California 92879-1751 | USA
T [phone]
www.eibach.com
MULTI-PRO-R2 | INSTALLATION INSTRUCTIONS
1997-01 Acura Integra, Type-R, DC2
PART NUMBER 4020.713
PERFORMANCE SUSPENSION AUTOMOTIVE OEM/OES HI-TECH INDUSTRIAL
FRONT SUSPENSION REMOVAL
1. Raise the car off the ground and make sure it’s
properly supported with jack stands. Note: Never
work on or underneath a car that is not properly
supported with safety stands.
2. Remove the wheels from the vehicle.
3. Loosen and remove the two screws that secure the
brake line to the side of the strut. (See Photo 1)
4. Loosen and remove the bolt and nut that secures
the fork to the lower control arm. (See Photo 2)
5. Loosen and remove the bolt that secures the fork to
the OE strut, then, lower the fork down as shown.
(See Photos 3 & 4)
Photo 3
Photo 1
Photo 5
Photo 4
Photo 2

D3157 - Page 3
Eibach Springs, Inc. | 256 Mariah Circle | Corona | California 92879-1751 | USA
T [phone]
www.eibach.com
MULTI-PRO-R2 | INSTALLATION INSTRUCTIONS
1997-01 Acura Integra, Type-R, DC2
PART NUMBER 4020.713
PERFORMANCE SUSPENSION AUTOMOTIVE OEM/OES HI-TECH INDUSTRIAL
6. Loosen and remove the upper strut mount nuts,
then, remove the strut as shown.
(See Photos 5 & 6)
FRONT SUSPENSION INSTALLATION
1. Install the Eibach Multi Pro coilover into the vehicle
and secure it to the strut tower using the provided
hardware. (See Photo 7)
2. Slide the OE fork onto the bottom of the Eibach
Multi Pro coilover, and secure it with the OE screw.
(See Photo 8)
3. Secure the fork to the lower control arm using the
OE hardware removed in step 4 of the removal
process. Note: Be sure to preload the
suspension prior to tightening this bolt.
Uneven lowering and premature wear to the
control arm bushing will result if not done
properly. (See Photo 9)
Photo 7
Photo 8
Photo 6
Photo 9

D3157 - Page 4
Eibach Springs, Inc. | 256 Mariah Circle | Corona | California 92879-1751 | USA
T [phone]
www.eibach.com
MULTI-PRO-R2 | INSTALLATION INSTRUCTIONS
1997-01 Acura Integra, Type-R, DC2
PART NUMBER 4020.713
PERFORMANCE SUSPENSION AUTOMOTIVE OEM/OES HI-TECH INDUSTRIAL
4. Using a grinder or cut off wheel, cut the tab off of
the brake line bracket (See Arrows) as shown.
Then secure the bracket to the coilover using the
OE hardware and the provided cap screw. (See
Photos 10, 11 & 12)
5. Route the reservoir into the engine compartment
and mount it to a suitable location using the
provided reservoir clamp and hardware.
6. Double check to make sure everything is properly
positioned, then, tighten all hardware.
Photo 12
Photo 11
Photo 10

D3157 - Page 5
Eibach Springs, Inc. | 256 Mariah Circle | Corona | California 92879-1751 | USA
T [phone]
www.eibach.com
MULTI-PRO-R2 | INSTALLATION INSTRUCTIONS
1997-01 Acura Integra, Type-R, DC2
PART NUMBER 4020.713
PERFORMANCE SUSPENSION AUTOMOTIVE OEM/OES HI-TECH INDUSTRIAL
REAR SUSPENSION REMOVAL
1. Remove the interior access panels (both left and
right side) and remove the upper shock mount nuts.
(See Photo 13)
2. Remove the lower shock mount bolt, then, slide the
shock downward, and remove the strut as shown
(See Photos 14, 15 & 16)
Photo 14
Photo 13
Photo 15

D3157 - Page 6
Eibach Springs, Inc. | 256 Mariah Circle | Corona | California 92879-1751 | USA
T [phone]
www.eibach.com
MULTI-PRO-R2 | INSTALLATION INSTRUCTIONS
1997-01 Acura Integra, Type-R, DC2
PART NUMBER 4020.713
PERFORMANCE SUSPENSION AUTOMOTIVE OEM/OES HI-TECH INDUSTRIAL
REAR SUSPENSION INSTALLATION
1. Install the Eibach Multi-Pro coilover into the lower
control arm with the reservoir facing the front of the
car, slide it as far down as possible, then, slide the
coilover upward into the upper OE mounting holes
and secure it with the provided nuts. (See Photos
17, 18 & 19) Note: Do not tighten at this time
2. Secure the coilover to the lower control arm using
the OE hardware. (See Photo 20) Note: Be sure
to preload the suspension prior to tightening
this bolt. Uneven lowering and premature wear
to the control arm bushing will result if not done
properly.
Photo 17
Photo 20
Photo 18
Photo 19

D3157 - Page 7
Eibach Springs, Inc. | 256 Mariah Circle | Corona | California 92879-1751 | USA
T [phone]
www.eibach.com
MULTI-PRO-R2 | INSTALLATION INSTRUCTIONS
1997-01 Acura Integra, Type-R, DC2
PART NUMBER 4020.713
PERFORMANCE SUSPENSION AUTOMOTIVE OEM/OES HI-TECH INDUSTRIAL
ADJUSTMENT PROCEDURE /
RECOMMENDATIONS
COMPRESSION AND REBOUND SETTINGS
1. The shocks in this kit are adjustable for compression
and rebound dampening forces. The following steps
explain the adjustable features of this kit.
2. Turning the compression adjustment knob in a
clockwise or (+ pos.) direction increases the amount of
force necessary to compress the shock. Likewise
turning the knob in a counterclockwise or (–neg.)
direction decreases the amount of force to compress
the shock. Note : The compression adjustment is
located on the reservoir.
Turning the rebound adjustment knob in a clockwise or
(+ pos.) direction increases the rebound forces.
Likewise turning the knob in a counterclockwise or (-
neg.) direction decreases the rebound forces. NOTE:
The rebound adjustment for the coil-over is located
at the top of the shock.
Tightening torque for piston rod nut
Thread Size Nm ft-lb Thread Size Nm ft-lb Thread Size Nm ft-lb
M8 25 18 M12 x 1.25 35 26 M14 x 1.50 50 37
M10 x 1.0 20 15 M12 x 1.50 40 29 M16 x 1.50 50 37
M10 x 1.25 20 15
