LC-XB42
LC-XB42
XGA "Brilliant" Series
4500 ANSI Lumens
Outstanding Features
1. Wide-range (1.6X) short-throw to mid-throw (1.15~1.85:1) zoom lens.
2. Two computer inputs plus one computer monitor output.
3. High brightness and contrast, with up to 3000 hrs est. lamp life.
4. Project straight up or down: projector supports pitch through 360°.
5. UXGA & WXGA compatible. Interlace to Progressive conversion.
6. Turn ON and Show! (Countdown can be optionally skipped.)
7. Turn OFF and Go! (A/C cord can be removed immediately.)
▼4500 ANSI Lumens, 85% uniformity, and 500:1 contrast ratio.
▼Weighs less than 8 lbs! Compact, low-profile design!
▼3panel LCD imaging delivers a rich, color saturated picture.
▼XGA resolution. WXGA, UXGA~VGA and MAC compatible.
▼Quiet operation: fan noise as low as 31 dBA in Eco mode.
▼Smart data compression/expansion, and video scaling.
▼Convenient mid-range 1.6:1 manual zoom and focus lens.
▼Two Dsub15 computer inputs, plus one Dsub15 computer monitor output.
▼Preset image offset. Auto Vertical digital keystone correction.
▼Accepts Composite, S, and Component Video in all major standards.
▼Displays both 4:3 and 16:9 formats. Supports most HDTV resolutions.
▼Converts Interlace to Progressive scan. 3-2 (and 2-2) Pulldown support.
▼Variable Power Management option. Optional local or remote keylock.
▼Custom warm-up screen image option. Factorydefaults reset.
▼Wireless remote control. 16X digital zoom. Auto input search.
▼Green chalkboard projection mode.
Get the rich color imaging of 3-panel LCD technology in a compact,
lightweight projector. More than bright … it’s Brilliant!

SPECIFICATIONS:
LC-XB42 4500 ANSI Lumens
INCLUDED ACCESSORIES:
Quick Start Guide. Owner’s Manual on CD-ROM. AC Power Cord.
VGA-type Computer Input Cable (Dsub15~Dsub15). Dsub9~Mini
DIN-8 cable for RS-232 control. Wireless Remote Control &
Batteries (AA x 2). Soft Carry Bag.
OPTIONAL ACCESSORIES:
Replacement Lamp. Component Video Input Adapter Cable
(Dsub15~3-RCA). Scart Video Input Cable (DSUB15~Scart).
MAC Adapter. MAC Monitor Cable. Luggage-Style ("wheelie")
Carrying Case with Wheels, Telescoping Handle, and Detachable
Computer Compartment. ATA-Style Shipping Case with Wheels
and Telescoping Handle. Ceiling Mount. Ceiling Post and Plate.
10M (33’) Extension Cable for Serial Cable.
Brightness ................................................. upto 4500 ANSI Lumens
Illumination Uniformity ......................................................... 85%
Size of Color Palette .................................................... 16.7 Million
Contrast Ratio ................................................. 500:1 (Full ON/OFF)
Projection Lamp .................................................... 275 Watt NSHA
Estimated Lamp Life ......................................... upto 3000 Hours of Use
Imaging System ........................... 0.8” PolySilicon active matrix TFT Panels x 3
Screen Pixels ...................................... 1024 x 768 in stripe configuration
Total Pixels ........................................... 2,359,296 ((1024 x 768) x 3)
Lens Type .................................................. Manual Zoom and Focus
Lens Specs ....................... Speed: f:1.7~2.5; FL: 19.2~30.2 mm (0.75~1.19 in.)
Lens Ratios ......................... Zoom Max:Min: 1.6:1; Throw:Width: 1.15~1.85:1
Image Diagonal ........................................ 101.6~762 cm (40~300 in.)
Image Width ............................................... 0.67~6.1 m (2.2~20 ft.)
Throw Distance (tele~wide) ............................... 0.93~11.5 m (3.0~37.7 ft.)
Front Elevation ............................................................ Up8.9°
Maximum Pitch ............................ anywhere up to 360° off the horizontal axis
Anti Keystone ............................... Preset Image Offset, Ratio (Top:Bottom) 9:1
Vertical Keystone Correction ............................. Digital: up to 40° up or down
Scanning Frequency ...................... Auto: H Sync. 15-100kHz; V Sync. 50-100Hz
Dot Clock ............................................................... 140 MHz
Image Orientation ........................................ Normal, Reversed, Inverted
Local Control/Power Management ......................... Full Function/Auto Shutdown
Remote Projector Control ...................................... Wireless (Infra Red) x 1
Service Port (for RS-232 control) ................................... Mini DIN 8 Pin x 1
Computer Native Resolution ....................................... 1024 x 768 (XGA)
Computer: Compatibility ............................... UXGA, SXGA+, SXGA, WXGA,
XGA, SVGA, VGA & MAC
Computer: Formats .................................. 1600 x 1200 through 640 x 480
Computer: Higher Resolutions ................... Displayed panned or Smart Compressed
Computer: Lower Resolutions ....................... Displayed normal or Smart Expanded
Video Compatibility ......................... NTSC/PAL/SECAM/NTSC 4.43/PAL-M&N
Video HD Compatibility ......................... 480i/p, 575i/p, 720p, 1035i, 1080i
Formats Supported ................................ Normal 4:3 and Wide Screen 16:9
Video: Image Sizing ........................................ Video Scaling Technology
Image Signal Inputs
Computer 1 ......................................................... DSUB15 x 1
Computer 2/Component Video (w/optional adapter): .................... DSUB15 x 1
Video – Composite: ..................................................... RCA x 1
S-Video: ..................................................... S-Video x 1
Audio Signal Inputs
Computer 1 & 2/Component (Stereo): ............................... MiniStereo x 1
Composite/S-Video (Stereo) .............................................. RCA x 2
Outputs
Computer Monitor: ................................................... DSUB15 x 1
Audio (Stereo) - Variable Line: ....................................... MiniStereo x 1
Sound – Amplifier (Mono): ............................................... 1 Watt RMS
Sound – Speaker: ............................................... 2.8 cm (1.1 in.) x 1
Fan Noise ........................................................ as low as 31 dBA
Cabinet Size (HxWxD) .................. 78 x 334 x 262 mm (3.07 x 13.15 x 10.3 in.)
(Including legs and lens)
Weight ........................................................... 3.6 kg (7.9 lbs.)
Packaged Size (HxWxD) ................. 255 x 408 x 377 mm (10.0 x 16.1 x 14.8 in.)
Packaged Weight ................................................. 6.5 kg (14.3 lbs.)
Power Requirements ........................................ 100-240V AC, 50/60Hz
Power Consumption ................................................ up to 351 Watts
Heat .................................................... up to 302 KC (1198 BTU)
Power Cord ............................................ 3M (10’) Type 3, Detachable
Safety Compliance ..................................................... UL, cUL, IEC
Security Facilities ........................................... Kensington®Security Slot
Operating Temperature........................................... 5~35°C(41~95°F)
User Maintenance ...................................... Clean Air Filter, Replace Lamp
Specifications subject to change without notice.
©2008 EIKI International, Inc. Printed in Japan. 05/15/08
Talk to your EIKI Dealer... the "pro" in projectors.
Projectors... and more!
2345
LC-XB42 4500 ANSI Lumens
Eiki Industrial Co., Ltd.
4-12 Banzai-cho, Kita-Ku, Osaka, Japan
Tel: [phone] •Fax: [phone]
E-mail: [email protected]
EIKI Web Site: http://www.eiki.com
78 mm
262 mm
334 mm
Lamp Contains
Mercury. Do not
put in trash.
Dispose-of-as Hazardous
Waste, according to the
laws in your jurisdiction.
