Eiki LC-XG300 Installation and operation manual

XGA "G" Series Projector
r4500 ANSI Lumens bright, at 90%+ uniformity,
and a 1000:1 contrast ratio.
r3panel LCD imaging for rich, color saturated
computer and video projection.
rXGA resolution. Smart data compression/
expansion, and video scaling.
rIncludes most professional input configurations,
including 5BNC and DVI.
rAccepts analog and digital computer input,
analog and digital w/HDCP video.
rCompatible with computer sources up to
UXGA, Video sources up to 1080i.
rPower zoom and focus. V & H power lens
shift. Digital keystone correction.
rOptional Wideangle and Telephoto lenses.
Instant Lens Change System.
rQuiet operation: fan noise as low as 31 dBA.
rConverts Interlace to Progressive scan.
3-2 (and 2-2) pulldown support.
rVariable Power Management Option.
Optional Local or Remote Keylock.
rCustom Warm-up Screen Image Option.
Built-in Color Auto PictureControl.
rWireless/wired remote w/mouse & laser
pointer.-50%~+700% digital zoom.
r3 Year* Projector Warranty!
LC-XG300 4500 ANSI lumens
LC-XG300 4500 ANSI lumens
Get the rich color imaging of 3 panel LCD technology in a installation
projector with unparalleled brightness and compatibility.
XGA
Outstanding Features
1. High brightness and contrast. Range of optional lenses 0.8~11.3:1.
2. Physically centered lens. Projector supports pitch through 360°.
3. Power Lens Shift: Up 50%, Left or Right 15%.
4. Push-button lens replacement (no dismantling required).
5. One-way cooling system (1 in & 1 out port) simplifies installation.
6. Front-accessed high-capacity air filter simplifies maintenance.
7. Clogged air filter detection with both LED and on-screen warning.
8. Rear-accessed lamphouse makes lamp change easy.
9. Built-in test pattern array for easy adjustments.
Projectors... and more!
2345

Specifications subject to change without notice.
©2006 EIKI International, Inc. Printed in the USA. 11/15/06
Brightness......................................... upto4500ANSILumens
IlluminationUniformity.............................................. 90%+
SizeofColorPalette.......................................... 16.7Million
ContrastRatio....................................... 1000:1(FullON/OFF)
ProjectionLamp......................................... 300WattUHPx1
Estimated Lamp Life . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . up to 3000 Hours of Use
Imaging System . . . . . . . . . . . . . . . . . . . . . . . 1.0” PolySilicon active matrix TFT Panels x 3
Screen Pixels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1024 x 768 in stripe configuration
TotalPixels.................................... 2,359,296((1024x768)x3)
LensType.......................................... PowerZoomandFocus
Lens Specs . . . . . . . . . . . . . . . . . . . . . . Speed: f:1.7~2.1; FL: 1.3~1.69 in. (33 ~ 43 mm)
Lens Ratios . . . . . . . . . . . . . . . . . . . . . Zoom Max:Min: 1.3:1; Throw:Width: 1.64~2.13:1
ImageDiagonal.................................. 30~300in.(76.2~762cm)
ImageWidth...................................... 2.0~20ft.(0.61~6.1m.)
Throw Distance (wide ~ tele) . . . . . . . . . . . . . . . . . . . . . . . . . 3.9~32.8 ft. (1.2~10.0 m.)
FrontElevation............................................... upto5°up
Maximum Pitch . . . . . . . . . . . . . . . . . . . . . . . . anywhere up to 360° off the horizontal axis
Vertical Anti Keystone . . . . . . . . . . . . . . . . . . . . . . . . . . . . Power Lens Shift, Up only, 50%
Horizontal Anti Keystone . . . . . . . . . . . . . . . . . . . . . . . Power Lens Shift, Left or Right, 15%
Vertical Keystone Correction . . . . . . . . . . . . . . . . . . . . . . . Digital: up to 40° Up or Down.
Scanning Frequency . . . . . . . . . . . . . . . . . . Auto: H Sync. 15-100 kHz; V Sync. 50-100 Hz
Dot Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140 MHz Analog / 100 MHz Digital
Image Orientation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Normal, Reversed, Inverted
Local Control / Power Management . . . . . . . . . . . . . . . . . . . . Full Function / Auto Shut-Off
Remote Projector & Mouse Ctrl . . . . . . . . . . . . . . . . . . Wireless/Wired x 1 w/ Laser Pointer
Auxiliary Ports: . . . . . . . . . . . . . . . . . . . . . . Mouse: USB-B x 1, Wired RC: MiniStereo x 1
Control: 8-pinDIN x 1, Network Interface: Option Connector x 1
Computer Native Resolution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1024 x 768 (XGA)
Computer: Compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . UXGA & SXGA+ (analog only)
SXGA, WXGA, XGA, SVGA, VGA & MAC (analog & digital)
Computer: Formats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1600 x 1200 through 640 x 480
Computer: Image Sizing .. . . . . . . . . . . . . . . . Normal, or Smart Compressed or Expanded
Video: System Compatibility . . . . . . . . . . . . . . . NTSC/PAL/SECAM/NTSC 4.43/PAL-M/N
Video: Compatibility . . . . . . . . . . . . . . . . . . 480i/p, 575i/p, 720p, 1035i, 1080i-50/60
Video:FormatsSupported..................................... 4:3and16:9
Video: Image Resizing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Video Scaling Technology
Video: Systems . . . . . . . . . . . . . . . . . . Composite, S-Video, Component Analog, and Digital
Inputs:
1a. either AnalogComputer:................................... HD15x1
1b. or Digital Computer, or Digital Video with HDCP: . . . . . . . . . . . . . . . . . . DVI-D x 1
plus,StereoAudio:................................... MiniStereox1
2a. either AnalogComputer(RGBHV):............................. BNCx5
2b. or Analog Video (Y,Pb/Cb,Pr/Cr) (BNC x 3):
plus,StereoAudio:................................... MiniStereox1
3. either CompositeVideo:.................................... RCAx1
or S-Video: ........................................... S-Video x 1
plus,Stereo Audio: ........................................ RCAx2
Outputs:
AnalogComputer:........................................... HD15x1
Stereo Audio - Variable Line . . . . . . . . . . . . . . . . . . . . . . . . . . . Stereo: MiniStereo x 1
Audio:Amplifier................................ Mono:1WattRMSInternal
Audio:BuiltInSpeaker.................................. 1in.(28mm.)x1
FanNoise............................................. aslowas31dBA
Overall Size (HxWxD) . . . . . . . . . . . . . 6.46 x 13.7 x 17.48 in. (164 x 348.1 x 444 mm.)
(Excluding 7.5 mm Foot) and 2.8mm Lens
Weight................................................. 19.2lb(8.7kg)
Packaged Size (HxWxD) . . . . . . . . . . . . . . . 14.6 x 19.3 x 23.3 in (370 X 490 X 590 mm)
Packaged Weight........................................ 28.0lb(12.7kg
Power Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100-240V AC, 50/60Hz
PowerConsumption....................................... 430~360Watts
Heat ................................1467 BTU (370 KC) ~ 1228 BTU (310 KC)
AC Power Cord . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10’ (3 M) Type 3 detachable x 1
Safety Compliance ............................. IEC(EN)60950,UL60950/CUL
Electromagnetic Compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . FCC Class B, CE Mark
SecurityFacilities.................................... Kensington
®Security Slot
Operating Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41~950F (5~350C)
User Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Clean Air Filter, Replace Lamp
Warranty: (to the original end-use customer)
Projector . . . . . . . . . . . . . . . 3 Years / 6000 Hour Use*(Parts & Labor to Correct Defects)
Lamp . . . . . . . . . . . . . . . . . 90 Days / 500 Hours Use*(Failed Lamp Replaced Pro-Rata)
* whichever occurs first
SPECIFICATIONS: LC-XG300
INCLUDED ACCESSORIES:
Quick Start Guide. Owner’s Manual on CD-ROM. AC Power Cord
10’ (3M) Type 3, Detachable. Lens Cover. VGA (Dsub15~Dsub15)
type Computer Input Cable. Wireless/Wired Remote with Mouse
Control and Laser Pointer & 2 x AAA batteries, USB Cable for
Computer Mouse control.
OPTIONAL ACCESSORIES:
Replacement Lamp. Serial (DB9~8DIN) control cable (RS-232). Soft
Carry Bag with Wheels and Telescoping Handle. ATA-Style Shipping
Case with Wheels and Telescoping Handle. A Range of Wideangle
and Telephoto Lenses. Ceiling Mount. Ceiling Post and Plate. 100’
(30 M) Wired Remote Cable. EZ-250 Local Control. PjNET Network
Interface. NPC-1 Network Control.
Eiki International, Inc.
30251 Esperanza, Rancho Santa Margarita, CA 92688-2130
Tel: [phone]; Fax: [phone], E-mail: [email protected]
In Canada, 310 First St.- Unit 2, P.O. Box 156, Midland, ON L4R 4K8
Phone: [phone], Fax: [phone] E-mail: [email protected]
http://www.eiki.com
Talk to your EIKI Dealer... the"pro" in projectors.
6.46"
13.7”
17.48”
Projectors... and more!
2345
LC-XG300 4500 ANSI lumens
Lamp Contains
Mercury. Do not
put in trash.
Dispose-of-as Hazardous
Waste, according to the
laws in your jurisdiction.
LASER RADIATION–
DO NOT STARE INTO BEAM
MAX OUTPUT : 1mW
WAVE LENGTH : 650≠20nm
CLASS II LASER PRODUCT
+
–
