EINHELL TE-AC 50 Silent User manual

TE-AC 50 Silent
Art.-Nr.: 40.206.20 I.-Nr.: 11019
9
DOriginalbetriebsanleitung
Kompressor
GB Original operating instructions
Compressor
FInstructions d’origine
Compresseur
IIstruzioni per l’uso originali
Compressore
DK/ Original betjeningsvejledning
NKompressor
SOriginal-bruksanvisning
Kompressor
CZ Originální návod k obsluze
Kompresor
SK Originálny návod na obsluhu
Kompresor
NL Originele handleiding
Compressor
EManual de instrucciones original
Compresor
FIN Alkuperäiskäyttöohje
Kompressori
SLO Originalna navodila za uporabo
Kompresor
HEredeti használati utasítás
Kompresszor
GR Πρωτότυπες Οδηγίες χρήσης
Συμπιεστής
Anl_TE_AC_50_Silent_SPK9.indb 1 15.07.2020 13:18:16

- 2 -
2 3
1
1 1 8 7 13 5
9
12
6
11
4
8
13
5 14
14
15
15
612
10
7
4
2
3
21
Anl_TE_AC_50_Silent_SPK9.indb 2 15.07.2020 13:18:17

- 3 -
4a 4b
4c 4d
5 6
2221 23 24 253 18
1
1
3
9
23, 22, 21
19,18
25, 24
4
19 4 20
17
20
17
16
Anl_TE_AC_50_Silent_SPK9.indb 3 15.07.2020 13:18:19

- 4 -
7 8
9
16
17
1
1
9
9
Anl_TE_AC_50_Silent_SPK9.indb 4 15.07.2020 13:18:42

GB
- 15 -
Danger! - Read the operating instructions to reduce the risk of injury.
Caution! Wear ear-muffs. The impact of noise can cause damage to hearing.
Beware of electrical voltage!
Beware of hot parts!
Warning! The unit is remote-controlled and may start-up without warning
Overload switch
Anl_TE_AC_50_Silent_SPK9.indb 15 15.07.2020 13:18:50

GB
- 16 -
Danger!
When using the equipment, a few safety pre-
cautions must be observed to avoid injuries and
damage. Please read the complete operating
instructions and safety regulations with due care.
Keep this manual in a safe place, so that the in-
formation is available at all times. If you give the
equipment to any other person, hand over these
operating instructions and safety regulations as
well. We cannot accept any liability for damage
or accidents which arise due to a failure to follow
these instructions and the safety instructions.
1. Safety regulations
The corresponding safety information can be
found in the enclosed booklet.
Warning!
Read all the safety information, instructions,
illustrations and technical data provided on
or with this power tool. Failure to adhere to the
following instructions may result in electric shock,
re and/or serious injury.
Keep all the safety information and instruc-
tions in a safe place for future use.
This appliance is not intended for use by persons
(including children) with reduced physical, sen-
sory or mental capabilities, or lack of experience
and knowledge, unless they have been given
supervision or instruction concerning use of the
appliance by a person responsible for their safety.
Children should be supervised to ensure that they
do not play with the appliance.
2. Layout and items supplied
2.1 Layout (Fig. 1-4)
1. Intake air lter
2. Pressure tank
3. Wheel
4. Supporting foot
5. Quick-lock coupling (regulated compressed
air)
6. Pressure gauge (for reading the preset tank
pressure)
7. Pressure regulator
8. ON/OFF switch
9. Transport handle
10. Safety valve
11. Drainage screw for condensation water
12. Pressure gauge (for reading the tank pressu-
re)
13. Quick-lock coupling (unregulated com-
pressed air)
14. Non-return valve
15. Overload switch
16. Hexagon key 5 mm
17. Socket head screw for handle
18. Hexagon screw for supporting foot
19. Washer for supporting foot
20. Nut for supporting foot
21. Wheel cap
22. Axle screw
23. Washer
24. Spring washer
25. Nut
2.2 Items supplied
Please check that the article is complete as
specied in the scope of delivery. If parts are
missing, please contact our service center or the
sales outlet where you made your purchase at
the latest within 5 working days after purchasing
the product and upon presentation of a valid bill
of purchase. Also, refer to the warranty table in
the service information at the end of the operating
instructions.
• Open the packaging and take out the equip-
ment with care.
• Remove the packaging material and any
packaging and/or transportation braces (if
available).
• Check to see if all items are supplied.
• Inspect the equipment and accessories for
transport damage.
• If possible, please keep the packaging until
the end of the guarantee period.
Danger!
The equipment and packaging material are
not toys. Do not let children play with plastic
bags, foils or small parts. There is a danger of
swallowing or suffocating!
• Compressor
• Intake air filter (2x)
• Wheel (2x)
• Supporting foot (2x)
• Transport handle
• Hexagon key 5 mm
• Socket head screw for handle (4x)
• Hexagon screw for supporting foot (2x)
• Washer for supporting foot (2x)
• Nut for supporting foot (2x)
• Wheel cap (2x)
Anl_TE_AC_50_Silent_SPK9.indb 16 15.07.2020 13:18:50

GB
- 17 -
• Axle screw (2x)
• Washer (2x)
• Spring washer (2x)
• Nut (2x)
• Original operating instructions
• Safety instructions
3. Proper use
The compressor is designed to generate com-
pressed air for compressed air driven tools.
The equipment is to be used only for its prescri-
bed purpose. Any other use is deemed to be a
case of misuse.The user / operator and not the
manufacturer will be liable for any damage or inju-
ries of any kind caused as a result of this.
Please note that our equipment has not been de-
signed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
machine is used in commercial, trade or industrial
businesses or for equivalent purposes.
4. Technical data
Mains connection:................. 220 -240 V ~ 50 Hz
Motor rating:............................................. 1500 W
Compressor speed rpm: .............................. 1450
Operating pressure bar: ............................max. 8
Pressure tank capacity (in liters): ................... 50
Theoretical suction rate l/min.: ..................... 270
Output rate (compressed air)
at 7 bar: ............................................ 90 liters/min
Output rate (compressed air)
at 4 bar: .......................................... 120 liters/min
Sound power level LWA in dB(A): ..................... 78
Uncertainty KWA ...................................... 3 dB(A)
Sound pressure level LpA in dB(A): ................. 54
Uncertainty KpA ...................................... 3 dB (A)
Protection type: ............................................ IP20
Weight of the unit in kg: .............. approx. 41,5 kg
Noise
The noise emission values were measured in ac-
cordance with EN ISO 3744.
5. Before starting the equipment
Before you connect the equipment to the power
supply make sure that the data on the rating plate
are identical to the supply voltage.
• Check the equipment for damage which may
have occurred in transit. Report any damage
immediately to the transport company which
was used to deliver the compressor.
• Install the compressor in the vicinity of the
point of consumption.
• Avoid long air lines and supply lines (extensi-
on cables).
• Make sure that the intake air is dry and dust-
free.
• Do not install the compressor in a damp or
wet room.
• The compressor may be used only in suitable
rooms (with good ventilation and an ambient
temperature from +5 °C to 40 °C).There must
be no dust, acids, vapors, explosive gases or
inflammable gases in the room.
• The compressor is designed to be used in dry
rooms. It is prohibited to use the compressor
in areas where work is conducted with spray-
ed water.
• Operate the equipment only on a firm, level
surface.
• Use flexible hoses in order to prevent trans-
mitting unacceptable loads to the pipeline
system at the connection between the com-
pressor system and the pipeline system.
• It is essential to use separators, traps and
drains which process the liquids produced by
the compressor before the compressor sys-
tem is put into operation.
• Supply hoses at pressures above 7 bar
should be equipped with a safety cable (e.g.
a wire rope).
6. Assembly and start-up
Important!
You must fully assemble the equipment befo-
re using it for the rst time.
6.1 Fitting the wheels (3)
Fit the supplied wheels (3) as shown in gure 5.
6.2 Fitting the supporting feet (4)
Fit the supplied supporting feet (4) as shown in
gure 6.
Anl_TE_AC_50_Silent_SPK9.indb 17 15.07.2020 13:18:51

GB
- 18 -
6.3 Fitting the transport handle (9)
Screw the transport handle (9) to the compressor
as shown in gures 7 to 8.
6.4 Fitting the air lter (1)
Use a screwdriver to remove the transportation
cover from the air lter connection. Screw in the
supplied air lter (Fig. 9).
6.5 Mains connection
• The motor is fitted with an overload switch
(Fig. 3/Item 15). If the compressor overloads,
the overload switch will switch off the equip-
ment automatically to protect the compressor
from overheating. If the overload switch trig-
gers, switch off the compressor using the ON/
OFF switch (8) and wait until the compressor
cools down.Then press the overload switch
(15) and restart the compressor.
• Long supply cables, extensions, cable reels
etc. cause a drop in voltage and can impede
motor start-up.
• At low temperatures below +5° C, sluggish-
ness may make starting difficult or impossib-
le.
6.6 On/Offswitch (8)
To switch on the compressor, pull out the On/Off
switch (8).
To switch offthe compressor, press the On/Off
switch (8) in again. (Fig. 2)
6.7 Adjusting the pressure:(Fig. 1.2)
• You can adjust the pressure on the pressure
gauge (6) using the pressure regulator (7).
• The set pressure can be taken from the quick-
lock coupling (5).
6.8 Setting the pressure switch
The pressure switch is set at the factory.
Cut-in pressure approx. 6 bar
Cut-out pressure approx. 8 bar
7. Replacing the power cable
Danger!
If the power cable for this equipment is damaged,
it must be replaced by the manufacturer or its
after-sales service or similarly trained personnel
to avoid danger.
8. Cleaning, maintenance and
ordering of spare parts
Danger!
Disconnect the power plug before doing any
cleaning and maintenance work!
Warning!
Wait until the compressor has completely
cooled down. Risk of burns!
Warning!
Always depressurize the tank before carrying
out any cleaning and maintenance work.
Warning!
After use, always switch offthe equipment
immediately and pull out the power plug.
8.1 Cleaning
• Keep all safety devices, air vents and the
motor housing free of dirt and dust as far as
possible. Wipe the equipment with a clean
cloth or blow it with compressed air at low
pressure.
• We recommend that you clean the device
immediately each time you have finished
using it.
• Clean the equipment regularly with a moist
cloth and some soft soap. Do not use
cleaning agents or solvents; these could at-
tack the plastic parts of the equipment. Ensu-
re that no water can seep into the device. The
ingress of water into an electric tool increases
the risk of an electric shock.
• You must disconnect the hose and any
spraying tools from the compressor before
cleaning. Do not clean the compressor with
water, solvents or the like.
8.2 Condensed water (Fig. 1)
Note:To ensure a long service life of the pressure
vessel (2), drain offthe condensed water by ope-
ning the drain screw (11) each time after using.
Check the pressure tank for signs of rust and
damage each time before using. Do not use the
compressor with a damaged or rusty pressure
tank. If you discover any damage, please contact
the customer service workshop.
8.3 Safety valve (10)
The safety valve has been set for the highest per-
mitted pressure of the pressure tank.It is prohibi-
ted to adjust the safety valve or remove its seal.
Anl_TE_AC_50_Silent_SPK9.indb 18 15.07.2020 13:18:51

GB
- 19 -
8.4 Cleaning the intake lter (1)
The intake lter prevents dust and dirt being
drawn in. It is essential to clean this lter after
at least every 300 hours in service. A clogged
intake lter will decrease the compressor‘s per-
formance dramatically. Open the halves of the air
lter housing.Use compressed air at low pressure
(approx. 3 bar) to blow out all the parts of the lter
and then assemble the lter in reverse order.
When cleaning, take adequate precautions
against dust (e.g. use a suitable face mask).
8.5 Storage
Warning!
Pull the mains plug out of the socket and ventilate
the appliance and all connected pneumatic tools.
Switch offthe compressor and make sure that it is
secured in such a way that it cannot be started up
again by any unauthorized person.
Warning!
Store the compressor only in a dry location
which is not accessible to unauthorized per-
sons. Always store upright, never tilted!
8.6 Transport
• Transport the equipment only by carrying it by
the transport handle.
• Protect the equipment against unexpected
knocks and vibrations.
8.7 Ordering replacement parts:
Please quote the following data when ordering
replacement parts:
• Type of machine
• Article number of the machine
• Identification number of the machine
• Replacement part number of the part required
For our latest prices and information please go to
www.isc-gmbh.info
9. Disposal and recycling
The equipment is supplied in packaging to pre-
vent it from being damaged in transit. The raw
materials in this packaging can be reused or
recycled.The equipment and its accessories are
made of various types of material, such as metal
and plastic. Never place defective equipment in
your household refuse.The equipment should
be taken to a suitable collection center for proper
disposal. If you do not know the whereabouts of
such a collection point, you should ask in your
local council offices.
For EU countries only
Never place any electric power tools in your
household refuse.
To comply with European Directive 2012/19/EC
concerning old electric and electronic equipment
and its implementation in national laws, old elec-
tric power tools have to be separated from other
waste and disposed of in an environment-friendly
fashion, e.g. by taking to a recycling depot.
Recycling alternative to the return request:
As an alternative to returning the equipment to
the manufacturer, the owner of the electrical
equipment must make sure that the equipment
is properly disposed of if he no longer wants to
keep the equipment.The old equipment can be
returned to a suitable collection point that will
dispose of the equipment in accordance with the
national recycling and waste disposal regulations.
This does not apply to any accessories or aids
without electrical components supplied with the
old equipment.
The reprinting or reproduction by any other me-
ans, in whole or in part, of documentation and
papers accompanying products is permitted only
with the express consent of the iSC GmbH.
Subject to technical changes
Anl_TE_AC_50_Silent_SPK9.indb 19 15.07.2020 13:18:52

GB
- 20 -
10. Possible causes of failure
Problem Cause Solution
The compressor
does not start
1. No supply voltage.
2. Insufficient supply voltage.
3. Outside temperature is too low
4. Motor is overheated
1. Check the cable, power plug, fuse
and socket-outlet.
2. Make sure that the extension cable
is not too long. Use an extension
cable with large enough wires
cross-sections.
3. Do not use at an outside tempera-
ture below +5° C.
4. Allow the motor to cool down. If
necessary, remedy the cause of the
overheating.
The compressor
starts but there is no
pressure
1. Leak in the non-return valve (14)
2. The seals are damaged.
3. Leak in the drainage screw for con-
densation water
1. Replace non-return valve (14)
2. Check the seals and have any da-
maged seals replaced by a service
center.
3. Tighten the screw by hand.Check
the seal on the screw and replace if
necessary.
The compressor
starts, pressure is
shown on the pres-
sure gauge, but the
tools do not start.
1. Loose hose connections.
2. Leak in a quick-lock coupling.
3. Insufficient pressure set on the
pressure regulator.
1. Check the compressed air hose
and tools and replace if necessary.
2. Check the quick-lock coupling and
replace if necessary.
3. Increase the set pressure with the
pressure regulator (3).
Anl_TE_AC_50_Silent_SPK9.indb 20 15.07.2020 13:18:52

GB
- 21 -
Service information
We have competent service partners in all countries named on the guarantee certicate whose contact
details can also be found on the guarantee certicate. These partners will help you with all service re-
quests such as repairs, spare and wearing part orders or the purchase of consumables.
Please note that the following parts of this product are subject to normal or natural wear and that the
following parts are therefore also required for use as consumables.
Category Example
Wear parts* V-belt, air lter
Consumables*
Missing parts
* Not necessarily included in the scope of delivery!
In the effect of defects or faults, please register the problem on the internet at www.isc-gmbh.info. Ple-
ase ensure that you provide a precise description of the problem and answer the following questions in
all cases:
• Did the equipment work at all or was it defective from the beginning?
• Did you notice anything (symptom or defect) prior to the failure?
• What malfunction does the equipment have in your opinion (main symptom)?
Describe this malfunction.
Anl_TE_AC_50_Silent_SPK9.indb 21 15.07.2020 13:18:53

GB
- 22 -
Warranty certicate
Dear Customer,
All of our products undergo strict quality checks to ensure that they reach you in perfect condition. In the
unlikely event that your device develops a fault, please contact our service department at the address
shown on this guarantee card.You can also contact us by telephone using the service number shown.
Please note the following terms under which guarantee claims can be made:
1. These guarantee terms apply to consumers only, i.e. natural persons intending to use this product
neither for their commercial activities nor for any other self-employed activities. These warranty
terms regulate additional warranty services, which the manufacturer mentioned below promises to
buyers of its new products in addition to their statutory rights of guarantee.Your statutory guarantee
claims are not affected by this guarantee. Our guarantee is free of charge to you.
2. The warranty services cover only defects due to material or manufacturing faults on a product which
you have bought from the manufacturer mentioned below and are limited to either the rectication of
said defects on the product or the replacement of the product, whichever we prefer.
Please note that our devices are not designed for use in commercial, trade or professional applica-
tions. A guarantee contract will not be created if the device has been used by commercial, trade or
industrial business or has been exposed to similar stresses during the guarantee period.
3. The following are not covered by our guarantee:
- Damage to the device caused by a failure to follow the assembly instructions or due to incorrect
installation, a failure to follow the operating instructions (for example connecting it to an incorrect
mains voltage or current type) or a failure to follow the maintenance and safety instructions or by ex-
posing the device to abnormal environmental conditions or by lack of care and maintenance.
- Damage to the device caused by abuse or incorrect use (for example overloading the device or the
use or unapproved tools or accessories), ingress of foreign bodies into the device (such as sand,
stones or dust, transport damage), the use of force or damage caused by external forces (for ex-
ample by dropping it).
- Damage to the device or parts of the device caused by normal or natural wear or tear or by normal
use of the device.
4. The guarantee is valid for a period of 24 months starting from the purchase date of the device. Gu-
arantee claims should be submitted before the end of the guarantee period within two weeks of the
defect being noticed. No guarantee claims will be accepted after the end of the guarantee period.
The original guarantee period remains applicable to the device even if repairs are carried out or
parts are replaced. In such cases, the work performed or parts tted will not result in an extension
of the guarantee period, and no new guarantee will become active for the work performed or parts
tted. This also applies if an on-site service is used.
5. To make a claim under the guarantee, please register the defective device at: www.isc-gmbh.info.
Please keep your bill of purchase or other proof of purchase for the new device. Devices that are
returned without proof of purchase or without a rating plate shall not be covered by the guarantee,
because appropriate identication will not be possible. If the defect is covered by our guarantee,
then the item in question will either be repaired immediately and returned to you or we will send you
a new replacement.
Of course, we are also happy offer a chargeable repair service for any defects which are not covered by
the scope of this guarantee or for units which are no longer covered. To take advantage of this service,
please send the device to our service address.
Also refer to the restrictions of this warranty concerning wear parts, consumables and missing parts as
set out in the service information in these operating instructions.
Anl_TE_AC_50_Silent_SPK9.indb 22 15.07.2020 13:18:53
