Einhell Bt-bo 16 a led Manual

Art.-Nr.: 20.303.50 I.-Nr.: 11011

Art.-Nr.: 20.303.55 I.-Nr.: 11013

Directions for Use

Jumper Cables



BT-BO16 A L E D

BT-BO 25 A LED

Anleitung BT-BO 16A_LED_SPK7__ 16.05.13 10:23 Seite 1

Anleitung BT-BO 16A_LED_SPK7__ 16.05.13 10:23 Seite 2

It is vital to make sure that

쎲the capacitance of the battery supplying the

power (e.g. 45 Ah) does not lie substantially

below that of the discharged battery;

쎲only batteries of identical nominal voltage (e.g.

12 V) are connected together;

쎲there is no contact between the body work of the

vehicles involved (risk of short-circuiting);

쎲sources of ignition (e.g. naked lights, burning

cigarettes or electric sparks) are kept away from

the batteries (risk of detonation) and that you

avoid bending over the batteries due to risk of

caustic burns;

쎲the electrolyte of the discharged battery is still

fluid at low temperature;

쎲the discharged battery is not disconnected from

its vehicleʼs electric system and that the ignition

of both vehicles is switched off before connecting

up the jumper cables: vehicles with manual

transmissions - place the shift lever in neutral;

vehicles with automatic transmissions - place the

selector lever in position „P“ and pull the hand

brake;

쎲the leads of the jumper cable cannot get caught

up in any moving parts inside the engine

compartment;

쎲you know how and in which order you have to

connect and disconnect the jumper cables.

쎲when you remove the leads of the jumper cable

they do not come into contact with any moving

parts of the engine.

Connecting the jumper leads:

Connect the lead with the red pole clamps first to the

positive pole of the discharged battery (see Figure

1/Item 1) and then to the positive pole of the supplier

battery (see Figure 1/Item 2). Now connect the lead

with the black pole clamps to the negative pole of the

supplier battery (see Figure 1/Item 3) and then to

ground on the receiver vehicle, e.g. the ground strap

or some other bare point on the engine block (see

Figure 1/Item 4). Choose a point as far away as

possible from the battery in order to avoid the ignition

of any electrolytic gas which may develop.

Starting:

Start the engine of the supplier vehicle and rev up to

the medium speed range. Then start the engine of

the receiver vehicle. Try for no longer than 15

seconds to start the vehicle, then wait for 1 minute

before trying again.

Disconnecting the jumper leads:

When the engine is running smoothly (after 2 to 3

minutes), disconnect the jumper cables in reverse

order: First disconnect the black pole clamp from the

ground strap or the engine block of the receiver

vehicle (see Figure 1/Position 4). Then disconnect

the other black pole clamp from the negative pole of

the supplier battery (see Figure 1/Item 3). Finally,

remove the two red pole clamps in any order.

Technical data:

BT-BO 16 A LED

Cross cut 25 mm2

Length 3 m

Suitable for petrol engines with max 2500 cc (12 V or

24 V battery)

BT-BO 25 A LED

Cross cut 40 mm2

Length 3.5 m

Suitable for petrol engines with max 5500 cc and

diesel engines with max. 3000 cc (12 V or 24 V

battery)

Notes:

Starting cars with catalytic converters

If the battery is not able to start the engine, only jump

start it with the jump cables and auxiliary battery. If

you attempt to push off the car or tow it, petrol may

get into the exhaust and damage the catalytic

converter. Switch on a large power consumer before

disconnecting so as to prevent voltage surges in the

electrical system. Refer to the ownerʼs manual for the

car or additional equipment (such as car phone, on-

board computer, etc.) for instructions on charging the

battery and jump starting.

Anleitung BT-BO 16A_LED_SPK7__ 16.05.13 10:23 Seite 5

LED light

The LED light can be used to additionally illuminate

the clamping position. To switch on, move the switch

(Fig. 2/Pos. 5) to “I”. To switch off, move the switch (5)

to “0”.

Battery disposal

Two type AG 13 alkaline-manganese button cells are

provided per pole clamp.

Batteries contain materials that are potentially

harmful to the environment. Never place batteries in

your household refuse, in fire or in water. Batteries

should be collected, recycled or disposed of by

environment-friendly means. Send your old batteries

to ISC GmbH, Eschenstrasse 6 in D-94405 Landau.

You can then be sure that the equipment will be

correctly disposed of by the manufacturer.



쾷

Anleitung BT-BO 16A_LED_SPK7__ 16.05.13 10:23 Seite 6

tFor EU countries only

Never place any electric tools in your household refuse.

To comply with European Directive 2002/96/EC concerning old electric and electronic equipment and its

implementation in national laws, old electric tools have to be separated from other waste and disposed of

in an environment-friendly fashion, e.g. by taking to a recycling depot.

Recycling alternative to the demand to return electrical devices:

As an alternative to returning the electrical device, the owner is obliged to cooperate in ensuring that the

device is properly recycled if ownership is relinquished. This can also be done by handing over the used

device to a returns center, which will dispose of it in accordance with national commercial and industrial

waste management legislation. This does not apply to the accessories and auxiliary equipment without

any electrical components which are included with the used device.
