EINHELL BT-WW 1000 User guide

Art.-Nr.: 43.121.03 I.-Nr.: 11012
Original Instruction Manual
Woodworking Lathe
BT-WW 1000
Anleitung_BT_WW_1000_SPK1:_ 29.09.2011 8:04 Uhr Seite 1

2
1
2 3
13
12 3 8
9
12
14 8a
14 14 8
15
11
12
12
7
10
57
4
68
3
6
4 5
6
8
8
8a
8a
Anleitung_BT_WW_1000_SPK1:_ 29.09.2011 8:04 Uhr Seite 2

3
8
7
12 11 9
3
9
17
18
17
16
6
10 9
5
4
6 7 8
8a
10 11
3
16
14
19
17
18
20
13
16
14
2
Anleitung_BT_WW_1000_SPK1:_ 29.09.2011 8:05 Uhr Seite 3

4
12
14
15
14
13
Anleitung_BT_WW_1000_SPK1:_ 29.09.2011 8:05 Uhr Seite 4

5
GB
Important.
When using the equipment, a few safety precautions
must be observed to avoid injuries and damage.
Please read the complete operating instructions and
safety information with due care. Keep this manual in
a safe place so that the information is available at all
times. If you give the equipment to any other person,
hand over these operating instructions and the safety
information as well. We cannot accept any liability for
damage or accidents which arise due to a failure to
follow these instructions and the safety information.
1. Safety information
Please refer to the booklet included in delivery for the
safety information.
CAUTION
Read all the safety information and instructions.
Failure to follow the safety information and
instructions may result in an electric shock, fire and/or
serious injury.
Keep all the safety information and instructions
in a safe place for future use.
2. Layout
1. On/ Off switch
2. Spur Center
3. Toolrest
4. Live center
5. Clamping screw
6. Tailstock
7. Tailstock spindle
8. Handwheel
9. Machine bed
10. Quick release lever for tailstock
11. Quick release lever for toolrest
12. Wingnut
13. Safety screw
14. Spanner/ Allen key
15. Face plate
2.2 Items supplied
Open the packaging and take out the equipment
with care.
Remove the packaging material and any
packaging and/or transportation braces (if
available).
Check to see if all items are supplied.
Inspect the equipment and accessories for
transport damage.
If possible, please keep the packaging until the
end of the guarantee period.
IMPORTANT
The equipment and packaging material are not
toys. Do not let children play with plastic bags,
foils or small parts. There is a danger of
Woodworking lathe
Tailstock
Spur center
Toolrest
Face plate
Original operating instructions
Safety instructions
3. Intended use
This woodworking lathe is designed for working
with wood, using suitable. It is intended for use in
the private sector only.
The equipment is to be used only for its prescribed
purpose. Any other use is deemed to be a case of
misuse. The user / operator and not the manufacturer
will be liable for any damage or injuries of any kind
caused as a result of this.
Please note that our equipment has not been
designed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
equipment is used in commercial, trade or industrial
businesses or for equivalent purposes.
^åäÉáíìåÖ|_q|_a|RMN|pmhTW|==NQKMOKOMNO==UWQN=rÜê==pÉáíÉ=NN
Spanner
Wingnut
Handwheel
Handle (for handwheel)
2.1 Layout (Fig. 1)
8a. Handle (for handwheel)

6
GB
^åäÉáíìåÖ|_q|_a|RMN|pmhTW|==NQKMOKOMNO==UWQN=rÜê==pÉáíÉ=NN
4. Technical data
Power rating: 350 W S2 30 min
Idle speed motor:
Idle speed spindle: 810/ 1180/ 1700/ 2480 min
Bed length: 1000 mm
Lathe diameter: 356 mm
Protection class: IP 20
Load factor:
A load factor of S2 30 min (intermittent periodic duty)
means that you may operate the motor continuously
at its nominal power level (350 W) for no longer than
the time stipulated on the specifications label (30
minutes ON period). If you fail to observe this time
limit the motor will overheat. During the OFF period
the motor will cool again to its starting temperature.
Sound and vibration values were measured in
accordance with EN 61029. The sound at the work-
LWA sound power level 75.5 dB(A)
KWA
5. Before starting the equipment
Pull the power plug before doing any
maintenance or assembly work on the
equipment.
The machine must be set up so that it stands
firmly, i.e. it must be securely screwed to a work
bench or similar.
All covers and safety devices have to be properly
fitted before the machine is switched on.
It must be possible for the grinding wheel to run
freely.
Check that the voltage on the rating plate is the
same as your supply voltage before you connect
the machine to the power supply.
Rated voltage: 230 V ~ 50 Hz
1400 min -1
-1
LpA sound pressure level 62.5 dB(A)
KpA uncertainty 3 dB
uncertainty 3 dB
Weight: 32 kg
Sound:
place can exceed 85 dB (A). In that case sound
is required.
Residual risks
Even if you use this electric power tool in
accordance with instructions, certain residual
risks cannot be rules out. The following hazards
may arise in connection with the equipment’s
construction and layout:
1. Lung damage if no suitable protective dust mask
is used.
2. Damage to hearing if no suitable ear protection is
used.
3. Health damage caused by hand-arm vibrations if
the equipment is used over a prolonged period or
is not properly guided and maintained.
Carry the machine by lifting the machine bed (9).
Consider the weight of the machine (32 kg).
5.1 Assembly (Fig. 2-5)
Screw the wingnut (12) to the toolrest (3) as shown
in Fig. 2.
Push the handwheel (8) onto the tailstock
spindle (7) as shown in Fig. 3. Make sure the allen
screw on the handwheel (8) slides over the flat part
of the tailstock spindle (7). Tighten the Allen screw
with the provided Allen key (Fig. 4) and screw the
handle (8a) onto the hand wheel (8) (Fig. 5).
5.2 Adjusting the tailstock (Fig. 6)
Loosen the lever (10) to slide the tailstock (6) along
the machine bed (9).
Set the optimal clamping pressure via the
handwheel (8). Then secure the tailstock spindle (7)
with the counter nut (5).
5.3 Adjusting the toolrest (Fig. 7)
Loosen the wingnut (12) to change the height of
the toolrest (3).
Loosen the lever (11) to slide the toolrest (3) along the
machine bed (9).
Position the toolrest (3) as close as possible to the
workpiece without touching it.
5.3 Setting the speed (Fig. 8-10)
Pull the power plug.
Loosen the safety screw (13), open the belt cover (16)
and loosen the adjusting bolt (17). Lift the belt pulley
(18) slightly to take the tension of the belt (19).
Change the belt (19) to the required position (be
aware of the aligment!)

7
GB
^åäÉáíìåÖ|_q|_a|RMN|pmhTW|==NQKMOKOMNO==UWQN=rÜê==pÉáíÉ=NN
6. Operation
6.2 On/ Off switch (Fig. 13)
Press the green switch ‘I’ to switch on the machine.
The belt (19) tightens by lowering the motor.
After setting the speed, re-tighten the adjusting
bolt (17), close the belt cover (16) and screw the
safety screws (13) back in.
Refer to the table inside the belt cover (16) for
recommended speeds.
5.4.1 Choosing the correct speed
Always use the lowest speed when working on
a new workpiece and increase the speed slowly.
Choose the speed accoring to the table inside
the belt cover (16). Start on low speed if the
workpiece is not round.
Choosing the right speed depends on various
factors (e.g. size, material, imbalance of the
workpiece)
Rule of thumb: for big, hard, out of round
workpieces - low speed
5.5 Changing from spur center to face plate
Use the supplied spanners (14) to loosen the
(Fig. 11-12)
spur center (2). Put one of the spanners on the
spindle just behind the spur center (2).
Use the second spanner (14) to loosen the spur
center (2) by turning it anti clockwise while
holding with the other spanner against it. Take
the spur center (2) off the spindle.
Screw the face plate (15) onto the thread of the
spindle and tighten it with the two spanners (14).
5.6 Spur center and revolving live center (Fig. 1)
The spur center (2) is used to transfer the motor
power between the centers onto the workpiece.
When positioning a workpiece between the spur
center (2) and the live center (4), make sure the
center hole is drilled deep enough.
Center drill diameter: 5-8 mm.
Clamping pressure not too high. If the clapming
is too high, the workpiece might bent and break.
To avoid damage of the threads and bearings, use
rubber or wood hammer to put the spur center (2)
into position on the face side of the workpiece.
The revolving live center (4) prevents the center
hole in the workpiece to burn out.
6.1 Important operating instructions
Check the workpiece for brnaches and drying
cracks. Only use wood without cracks and big
branches (adjust the clapming pressure
accordingly if the workpiece has small branches).
Always test by hands that the workpiece
is fixed properly. Important! Pull power plug.
Only use original lathe chisels which are properly
sharpened.
Do not stand in the fly circle of the workpiece
when working on a wood disc.
Pre-cut big and imbalanced wood pieces with a
band or drop saw.Big imbalance of the workpiece
risks your safety and the life of the machine.
Always start on the lowest speed when working
on a new workpiece and slowly increase the speed.
Never use wood with shrinkage cracks.
Do not use workpieces bigger than the max. size
allowed (refer to Section 4).
If the machine gets stuck, pull power plug before
doing any repair.
Fix the workpiece between spur center (2) or
face plate (15) and live center (4). First tighten the
tailstock (6) with the release lever (10). Then fix the
workpiece by turning the handwheel (8).
Position yourself at the machine in a way that
enables you to support the lathe chisel on the tool
rest (3).
Press the red switch ‘0’ to switch off the machine.

8
GB
^åäÉáíìåÖ|_q|_a|RMN|pmhTW|==NQKMOKOMNO==UWQN=rÜê==pÉáíÉ=NN
7. Cleaning, maintenance and
ordering of spare parts
Always pull out the mains power plug before
starting any cleaning work.
We recommend that you clean the equipment
immediately after you use it.
Clean the appliance regularly with a damp cloth
and some soft soap. Do not use cleaning agents
or solvents; these may be aggressive to the
plastic parts in the appliance. Ensure that no
water can get into the interior of the equipment.
7.4 Servicing
There are no parts inside the equipment which
require additional maintenance.
Keep all ventilation holes, safety devices and
the motor housing free of dirt and dust as far
as possible. Wipe the machine with a clean
cloth or blow it with compressed air at low
pressure.
7.1 Cleaning
7.2 Motor does not start
If clamping pressure and belt tension are too
high it can cause starting issues, especially at
higher speed.
Troubleshooting
Loosen belt tension.
Decrease clamping pressure via the hand
wheel (8).
Only use high speed for final and detail work on
the workpiece.
7.3 Carbon brushes
In case of excessive sparking, have the carbon
brushes checked only by a qualified electrician.
Important! The carbon brushes should not be rep
laced by anyone but a qualified electrician.
Please quote the following data when ordering
replacement parts:
7.5 Ordering replacement parts
Type of machine
Article number of the machine
Identification number of the machine
Replacement part number of the part required
For our latest prices, information and order details
go to www.einhell.com.au
The unit is supplied in packaging to prevent its
being damaged in transit. This packaging is
raw material and can therefore be reused or can
be returned to the raw material system.
The unit and its accessories are made of various
types of material, such as metal and plastic.
Defective components must be disposed of as
special waste. Ask your dealer or your local
council.
8. Disposal and recycling

The guarantee provided in this Guarantee Certificate is given by Einhell Australia Pty Limited
ACN 134 632 858 of 6/166 Wellington Street, Collingwood, Victoria (Telephone number 1300 922 271)
GUARANTEE CERTIFICATE
EINHELL AUSTRALIA PTY LTD
6/166 Wellington Street
Collingwood VIC 3066
Australia
Phone: [phone]
Dear Customer,
All of our products undergo strict quality checks. In the unlikely event that your device develops a fault, please
contact our service department at the address shown on this guarantee certificate. Of course, if you would
prefer to call us then we are also happy to offer our assistance under the service number printed below.
Please note the following terms under which claims under the Einhell Express Guarantee can be made:
1. The benefits conferred by the Einhell Express Guarantee are in addition to all rights and remedies which
you may be entitled to under the Australian Consumer Law, and anyother statutory rights you may have
under other applicable laws. This Einhell Express Guarantee does not exclude, restrict or modify any
We do not charge you for the Einhell Express Guarantee.
2. Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are
entitled to a replacement or refund for amajor failure and for compensation for any other reasonably
foreseeableloss or damage. You are also entitled to have the goods repaired or replaced if the goods
fail to be of acceptable quality and the failure does not amount to a major failure.
3. The Einhell Express Guarantee only covers problems caused by material or manufacturing defects, and
our liabilityunder the Einhell Express Guarantee is limited, at our discretion, to the rectification of these
defects or replacement of the product. Please note that the product has not been designed for use in
commercial, trade or industrial applications. Consequently, the Einhell Express Guarantee will not apply
if the product is used in commercial, trade or industrial applications or for other equivalent activities.
4. The following are also excluded from the Einhell Express Guarantee: compensation for transport
damage, damage caused by failure to comply with the installation/assemblyinstructions or damage
caused by unprofessional installation, failure to comply with the operating instructions (e.g. connection to
the wrong mains voltage or current type), misuse or inappropriate use (such as overloading of the
product or use of non-approved tools or accessories), failure to comply with the maintenance and safety
regulations, ingress of foreign bodies into the product (e.g. sand, stones or dust), effects of force or
external influences (e.g. damage caused by the product being dropped) and normal wear resulting from
proper operation of the product. The Einhell Express Guarantee will also not applyif any attempt is made
5. The Einhell Express Guarantee is valid for a period of 2 years starting from the purchase date of the
product. Claims made under the Einhell Express Guarantee should be submitted before the end of this
guarantee period and within two weeks of the defect being noticed. No claims under the Einhell Express
Guarantee will be accepted if submitted after the end of this guarantee period. The original guarantee
period remains applicable to the device even if repairs are carried out or parts are replaced. In such
cases, the work performed or parts fitted will not result in an extension of the guarantee period for the
Einhell Express Guarantee, and the Einhell Express Guarantee will notapply for the work performed or
6. To make a claim under the Einhell Express Guarantee, please send the relevant product postage-free to
the address shown below and enclose either the original or a copy of your sales receipt or another dated
proof of purchase. It would help us if you could describe the nature of the problem in as much detail as
possible. If the defect is covered by the Einhell Express Guarantee, yourproduct will be repaired
immediatelyand returned to you,or we will send you a newdevice (at our election).
Any costs incurred by you in making a claim under this Einhell Express Guarantee, unless specified
otherwise in this guarantee certificate, must be borne by you.
Of course, we are also happyto offer a chargeable repair service for any defects which are not covered by the
scope of the Einhell Express Guarantee or for products which are no longer covered by the Einhell Express
Guarantee. To take advantage of this service, please send the product to our service address.
such rights or remedies.
to tamper with the product.
parts fitted. This also applies when an on-site service is used.
(Einhell Express Guarantee).

EH 09/2012 (01)
