Eircom Advantage User manual

eircom advantage Appendices
eircom
advantage
Appendices

eircom advantage Appendices
A PPENDIX I E THERNET C ABLE S PECIFICATIONS
Standard Ethernet Cab e
This type of cable is used if a Hub is connected to the system.
Pin 1 Orange/White
Pin 2 Orange
Pin 3 Green /White
Pin 4 Blue
Pin 5 Blue/White
Pin Green
Pin 7 Brown/White
Pin 8 Brown
Crossover Cab e
This type of cable is used if a direct connection is made from the PC to the system.
Pin 1 Orange/White
Pin 2 Orange
Pin 3 Green /White
Pin 4 Blue
Pin 5 Blue/White
Pin Green
Pin 7 Brown/White
Pin 8 Brown
Pin 1 Orange/White
Pin 2 Orange
Pin 3 Green/White
Pin 4 Blue
Pin 5 Blue/White
Pin Green
Pin 7 Brown/White
Pin 8 Brown
Pin 1 Orange/White
Pin 2 Orange
Pin 3 Green/White
Pin 4 Blue
Pin 5 Blue/White
Pin Green
Pin 7 Brown/White
Pin 8 Brown

eircom advantage Appendices
Wiring the RS232 Seria Port
Use a standard serial cable to connect the system to a PC or a printer. In case of a non-standard interface,
following is the pin-out.
Seria Pin outs
Signal Name System port (9pin D) Printer Port (25pin D) Function
RS-TXD 2 3 Received Data
RS-RXD 3 2 Transmitted Data
RS-DTR 4 20 Data Terminal Ready
RS-0V 5 7 Signal Ground
Signal Name
System port
(9pin D)
PC Prot (9pin
D) Function
RS-TXD 2 2 Transmitted Data
RS-RXD 3 3 Received Data
RS-DTR 4 4 Data Terminal Ready
RS-0V 5 5 Signal Ground
Baud Rate 9600
Data Bits 8
Parity None
Stop Bits 1

eircom advantage Appendices
A PPENDIX II S YSTEM T ONES
The following is a list of tones that are used on the system -
Interna Dia Tone Continuous
Busy Tone 500mS On - 500msS Off - 500mS On - 500mS Off.................
Ringing Tone 1 Sec On - 4 Sec Off - 1 Sec On - 4 Sec Off...................
Ho d Tone 30mS On - 100mS Off - 30mS On - 2 Sec Off - 30mS On - 100mS Off........
Congestion Tone & 250mS On - 250mS Off -250mS On - 250mS Off..................
Ca Proceeding Tone
Success Tone 500mS On - 55mS Off - 500mS On - 55mS Off.................
Fai ure Tone 87mS On - 87mS Off - 87mS On - 87mS Off..................
A ert Tone 5 Sec Off: 120mS On - 9 Sec Off - 120mS On - 9 Sec Off...................
DND/Diversion Tone 500mS On - 55mS Off - 500mS On - 55mS Off.....................
Note: Sec = Seconds
mS = milli-Seconds

eircom advantage Appendices
A PPENDIX III D IALLING C ODE T ABLE
Dia ing Code Tab e
Note: In the table below -
x = extension number ii = index code
g = extension group t = telephone number
m = ringing mode L = Line
RA = Roaming Account RP = Roaming PIN
CODE
To call extension X X
To access a line 9
Line Access Group *91 to *98
Redial *5
Dial entries Common Address Book *4000 to *4199
Dial entries Personal Address Book *800 to *849
Park Call *74
Retrieve Parked Call from an extension *75 X
Unpark a Line *9*L
Unpark an extension *9#X
Universal Pick-up *719
Directed Pick-up *71 X
Directed Pick-off *71 X
Call Transfer Explicit
(at dial tone with two calls on hold)
*72
Conference
(at dial tone with
two calls on hold)
*73
Directed Page
*77 X
Page PA Port *77#
Universal Page *77*
Answering a Universal Page *76*
Answer a Page from an extension *76X
To call an Extension Group 80 - 89
Door Opening Code *78
To access Voice Mail *99
Break-out of Voice Mail *X
Transfer call to Mailbox (at ring-back tone) #99
Call-Back (at busy tone) 5
Intrude (at busy tone) 79
USER PROGRAMMING OPTION CODE
Divert All Calls to an extension
*21* X #
Divert All Calls to Voice Mail
*21**99#
Divert All Calls to
an external number
*210* t #
Clear Divert All Calls #21#
Divert on No Answer to an extension
*61* X #
Divert on No Answer to Voice Mail
*61**99#
Divert on No Answer to an external number
*610* t #
Divert on No Answer to an extension after S seconds *61* X*S#
Clear Divert on No Answer #61#
Divert on Busy to an extension
*67* X #
Divert on Busy to Voice Mail
*67**99#
Clear Divert on Busy #67#
Do Not Disturb
*62#
Clear Do Not Disturb #62#
Program entries in Personal Address Book
**<ii>*<t>#
Clear entry in Personal Address Book #<ii>#
Manual Day/Night Switch
*07*<m>#
CLI Restriction
*30#
CLI Presentation
*31#
Program PIN Code
*70** PIN*PIN #
Change PIN code
*70*OLD
*NEW*NEW#
Clear PIN Code
*70* PIN #
Activate Roaming PIN
*68*
RA * RP #
Deactivate Roaming PIN #68#
Select an external line and activate CLIP for one call only
*0*31#
Select an external line and activate CLIR for one call only *0*30#

eircom advantage Appendices
A
PPENDIX IV T ABLES
EXTENSION SETTINGS TABLE 1 (Digita Extensions)
EXTN New Extension
Number
New Extension Name Line Access
T/L1 T/L2 T/L3 T/L4 T/L5 T/L6 T/L7 T/L8
Leve of Access
1 2 3 4 5 6 7
Extensions with Operator
Functiona ity Enab ed
11
12
13
14
15
1
17
18
19
20
21
22
23
2
4
25
2
27
28
29
30
31
32
33
34
The default settings are - all extensions have access to all lines
- all extensions have unrestricted access Level 5

eircom advantage Appendices
EXTENSION SETTINGS TABLE 1 (Ana ogue Extensions)
EXTN New Extension
Number
New Extension Name Line Access
T/L1 T/L2 T/L3 T/L4 T/L5 T/L6 T/L7 T/L8
Leve of Access
1 2 3 4 5 6 7
Extensions with Operator
Functiona ity Enab ed
41
42
43
44
45
4
47
48
49
50
51
52
53
54
55
5
57
58
59
0
1
2
3
4
The default settings are - all extensions have access to all lines
- all extensions have unrestricted access Level 5

eircom advantage Appendices
EXTENSION SETTINGS TABLE 2 (Digita Extensions)
EXTN.
Externa Ca
Waiting
Interna Ca
Waiting
Intrude Intrude
Protection
Ca Pick-Off
Ca Pick-Up
Do Not Disturb
(DND)
DND Override Ca Diversion
Conference
Interna Paging
Direct Line
Seizure (DLS)
User
Programming
Voice Mai
Voice Mai
Password
Ca Back
Ca ed Party
Missed Ca List
Roaming PIN
Extensions
D N D N D N D N D N D N D N D N D N D N D N D N D N D N D N D N D N D N D N
11 √ - - - - √ √ - √ √ √ - √ √ √ √ - √ -
12 √ - - - - √ √ - √ √ √ - √ √ √ √ - √ -
13 √ - - - - √ √ - √ √ √ - √ √ √ √ - √ -
14 √ - - - - √ √ - √ √ √ - √ √ √ √ - √ -
15 √ - - - - √ √ - √ √ √ - √ √ √ √ - √ -
16 √ - - - - √ √ - √ √ √ - √ √ √ √ - √ -
17 √ - - - - √ √ - √ √ √ - √ √ √ √ - √ -
18 √ - - - - √ √ - √ √ √ - √ √ √ √ - √ -
19 √ - - - - √ √ - √ √ √ - √ √ √ √ - √ -
20 √ - - - - √ √ - √ √ √ - √ √ √ √ - √ -
21 √ - - - - √ √ - √ √ √ - √ √ √ √ - √ -
22 √ - - - - √ √ - √ √ √ - √ √ √ √ - √ -
23 √ - - - - √ √ - √ √ √ - √ √ √ √ - √ -
24 √ - - - - √ √ - √ √ √ - √ √ √ √ - √ -
25 √ - - - - √ √ - √ √ √ - √ √ √ √ - √ -
26 √ - - - - √ √ - √ √ √ - √ √ √ √ - √ -
27 √ - - - - √ √ - √ √ √ - √ √ √ √ - √ -
28 √ - - - - √ √ - √ √ √ - √ √ √ √ - √ -
29 √ - - - - √ √ - √ √ √ - √ √ √ √ - √ -
30 √ - - - - √ √ - √ √ √ - √ √ √ √ - √ -
31 √ - - - - √ √ - √ √ √ - √ √ √ √ - √ -
32 √ - - - - √ √ - √ √ √ - √ √ √ √ - √ -
33 √ - - - - √ √ - √ √ √ - √ √ √ √ - √ -
34 √ - - - - √ √ - √ √ √ - √ √ √ √ - √ -
D: Default Setting N: New Setting

eircom advantage Appendices
EXTENSION SETTINGS TABLE 2 (Ana ogue Extensions)
EXTN.
Externa Ca
Waiting
Interna Ca
Waiting
Intrude Intrude
Protection
Ca Pick-Off
Ca Pick-Up
Do Not Disturb
(DND)
DND Override Ca Diversion
Conference
Interna Paging
Direct Line
Seizure (DLS)
User
Programming
Voice Mai
Voice Mai
Password
Ca Back
Ca ed Party
Missed Ca List
Roaming PIN
Exrensions
D N D N D N D N D N D N D N D N D N D N D N D N D N D N D N D N D N D N D N
41 √ - √ - - √ √ - √ √ √ - √ √ - √ - √ -
42 √ - √ - - √ √ - √ √ √ - √ √ - √ - √ -
43 √ - √ - - √ √ - √ √ √ - √ √ - √ - √ -
44 √ - √ - - √ √ - √ √ √ - √ √ - √ - √ -
45 √ - √ - - √ √ - √ √ √ - √ √ - √ - √ -
46 √ - √ - - √ √ - √ √ √ - √ √ - √ - √ -
47 √ - √ - - √ √ - √ √ √ - √ √ - √ - √ -
48 √ - √ - - √ √ - √ √ √ - √ √ - √ - √ -
49 √ - √ - - √ √ - √ √ √ - √ √ - √ - √ -
50 √ - √ - - √ √ - √ √ √ - √ √ - √ - √ -
51 √ - √ - - √ √ - √ √ √ - √ √ - √ - √ -
52 √ - √ - - √ √ - √ √ √ - √ √ - √ - √ -
53 √ - √ - - √ √ - √ √ √ - √ √ - √ - √ -
54 √ - √ - - √ √ - √ √ √ - √ √ - √ - √ -
55 √ - √ - - √ √ - √ √ √ - √ √ - √ - √ -
56 √ - √ - - √ √ - √ √ √ - √ √ - √ - √ -
57 √ - √ - - √ √ - √ √ √ - √ √ - √ - √ -
58 √ - √ - - √ √ - √ √ √ - √ √ - √ - √ -
59 √ - √ - - √ √ - √ √ √ - √ √ - √ - √ -
60 √ - √ - - √ √ - √ √ √ - √ √ - √ - √ -
61 √ - √ - - √ √ - √ √ √ - √ √ - √ - √ -
62 √ - √ - - √ √ - √ √ √ - √ √ - √ - √ -
63 √ - √ - - √ √ - √ √ √ - √ √ - √ - √ -
64 √ - √ - - √ √ - √ √ √ - √ √ - √ - √ -
D: Default Setting N: New Setting

eircom advantage Appendices
RINGING ASSIGNMENT TABLE
Index
MSN/ LINE NUMBER
RINGING ASSIGNMENT
(Enter the extensions to ring for the MSN/Line for each ringing mode)
DAY RINGING
NIGHT RINGING
MODE 3
MODE 4
MODE 5
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50

eircom advantage Appendices
EXTENSION CLI TABLE
EXTN CLI NUMBER CLI
RESTRICTION
SET
EXTN CLI NUMBER CLI
RESTRICTION
SET
11
11
12
12
13
13
14
14
15
15
16
16
17
17
18
18
19
19
20
20
21
21
22
22
23
23
24
24
25
25
26
26
27
27
28
28
29
29
30
30
31
31
32
32
33
33
34
34

eircom advantage Appendices
MISCELLANEOUS TIMER SETTINGS
No TIMER Defau t New Setting Maximum Minimum
1 Transfer Timeout 30 secs 3 mins 5 secs
2 Parked Call Timeout 3 mins 15 mins 10 secs
3 Divert No Answer Timeout 20 secs 3 mins 5 secs
4 Normal Disconnect Timer 20 secs 1 min 0 secs
5 Handsfree Disconnect Timer 3 secs 1 min 0 secs
Pause Timer 2 secs 1 min 0 secs
7 Maximum Voice Message Length 90 secs 180 secs 0 secs
8 Browser Timeout 15 mins 15 mins 30 secs
9 Phone Menu Timeout 0 secs 3 mins 15 secs
10 Call Back Timer 1 10 secs 15 mins 0 secs
11 Call Back Timer 2 20 secs 15 mins 0 secs
12 Call Back Timer 3 0 mins 4 hours 1 min
13 Roaming PIN Timer 30 secs 15 mins 0 secs
14 Hotline Timer 10 secs 0 secs 0 secs
15 Internet Disconnect Timer 3 mins 999 secs 1 secs
1 Line To Line Timer 2 mins 999 secs 10 secs
17 Line Supervision 90 msecs 999 msecs 0 msecs

eircom advantage Appendices
Common Address Book Tab e
NUMBER NAME
Barred
Prefix
NUMBER NAME
Barred
Prefix
NUMBER NAME
Barred
Prefix
NUMBER NAME
Barred
Prefix
1 51 101 151
2 52 102 152
3 53 103 153
4 54 104 154
5 55 105 155
6 56 106 156
7 57 107 157
8 58 108 158
9 59 109 159
10 60 110 160
11 61 111 161
12 62 112 162
13 63 113 163
14 64 114 164
15 65 115 165
16 66 116 166
17 67 117 167
18 68 118 168
19 69 119 169
20 70 120 170
21 71 121 171
22 72 122 172
23 73 123 173
24 74 124 174
25 75 125 175
26 76 126 176
27 77 127 177
28 78 128 178
29 79 129 179
30 80 130 180
31 81 131 181
32 82 132 182
33 83 133 183
34 84 134 184
35 85 135 185
36 86 136 186
37 87 137 187
38 88 138 188
39 89 139 189
40 90 140 190
41 91 141 191
42 92 142 192
43 93 143 193
44 94 144 194
45 95 145 195
46 96 146 196
47 97 147 197
48 98 148 198
49 99 149 199
50 100 150 200

eircom advantage Appendices
Internet Access Tab e
System Details
DEFAULT
SETTING
NEW
SETTING
IP Address 192.1 8.0.100 ___ . ___ . ___ .
___
Subnet Mask 255.255.255.0 ___ . ___ . ___ .
___
HTTP Port 80
DATA CALL
MANAGEMENT
Maximum
Number of Data
Calls
4
Maximum
Number of ISP
Calls
1
Maximum
Number of RAS
Calls
2
Number of Users
per ISP Call 4
RAS ACCOUNTS
REMOTE ACCESS SERVER
RAS IP ADRESSES
INDEX USERNAME PASSWORD Index IP Address
1 1
2 2
3 3
4 4
5 5
7 7
8 8
9
10
ISP DETAILS
ISP Telephone
Number
Account Name
Password
REMOTE
ACCESS
NUMBERS
MSN
1
CLI LIST
1
2
3
4
5
6
7
8
9
10
INTERNET BARRING
INDEX
PC NAME
(to identify IP Address with a user)
IP NUMBER
BARRED
(tick if barred)
1
2
3
4
5
7
8
9
10
11
12
13
14
15
1
17
18
19
20
