Eizo Color Edge CX240 User manual

Important
Please read PRECAUTIONS, this User’s Manual, and the Setup Guide
(separate volume) carefully to familiarize yourself with safe and
effective usage.
• Please refer to the Setup Guide for basic information ranging from
connection of the monitor to a PC to using the monitor.
• The latest User’s Manual is available for download from our web site:
http://www.eizo.com
Cover

2
Location of Caution Statement
This product has been adjusted specically for use in the region to which it was originally shipped. If operated
outside this region, the product may not perform as stated in the specications.
No part of this manual may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means,
electronic, mechanical, or otherwise, without the prior written permission of EIZO NANAO CORPORATION.
EIZO NANAO CORPORATION is under no obligation to hold any submitted material or information condential
unless prior arrangements are made pursuant to EIZO NANAO CORPORATION’s receipt of said information.
Although every effort has been made to ensure that this manual provides up-to-date information, please note that
EIZO monitor specications are subject to change without notice.

3
Noticeforthismonitor
Notice for this monitor
Aside from general purposes like creating documents, viewing multimedia content, this product is also suited to
applications such as creations of images and graphics, and digital photo processing, where accurate color reproduction
is a priority.
This product has been adjusted specically for use in the region to which it was originally shipped. If the product is
used outside the region, it may not operate as specied in the specications.
This product may not be covered by warranty for uses other than those described in this manual.
The specications noted in this manual are only applicable when the following are used:
· Power cords provided with the product
· Signal cables specied by us
Only use optional products manufactured or specied by us with this product.
As it takes about 7 minutes (under our measurement conditions) for the performance of electrical parts to stabilize,
adjust the monitor 7 minutes or more after the monitor power has been turned on.
Monitors should be set to a lower brightness to reduce changes in luminosity caused by long-term use and maintain a
stable display.
When the screen image is changed after displaying the same image for extended periods of time, an afterimage may
appear. Use the screen saver or power save function to avoid displaying the same image for extended periods of time.
Periodic cleaning is recommended to keep the monitor looking new and to prolong its operation lifetime (refer to
“Cleaning” (page 4)).
The LCD panel is manufactured using high-precision technology. Although, missing pixels or lit pixels may appear on
the LCD panel, this is not a malfunction. Percentage of effective dots: 99.9994% or higher.
The backlight of the LCD panel has a xed lifetime. When the screen becomes dark or begins to icker, please contact
your local EIZO representative.
Do not press on the panel or edge of the frame strongly, as this may result in display malfunctions, such as interference
patterns, etc. If pressure is continually applied to the panel, it may deteriorate or damage your panel. (If the pressure
marks remain on the panel, leave the monitor with a black or white screen. The symptom may disappear.)
Do not scratch or press on the panel with any sharp objects, as this may result in damage to the panel. Do not attempt
to brush with tissues as this may scratch the panel.
When the monitor is cold and brought into a room or the room temperature goes up quickly, dew condensation may
occur on the interior and exterior surfaces of the monitor. In that case, do not turn the monitor on. Instead wait until
the dew condensation disappears, otherwise it may cause some damage to the monitor.

4Noticeforthismonitor
Cleaning
Attention
• Chemicals such as alcohol and antiseptic solution may cause gloss variation, tarnishing, and fading of the cabinet or panel,
and also quality deterioration of the image.
• Never use any thinner, benzene, wax, and abrasive cleaner, which may damage the cabinet or panel.
Note
• The optional ScreenCleaner is recommended for cleaning the cabinet and panel surface.
If necessary, the stains on the cabinet and panel surface can be removed by moistening part of a soft cloth with
water.
To use the monitor comfortably
• An excessively dark or bright screen may affect your eyes. Adjust the brightness of the monitor according to
the environmental conditions.
• Staring at the monitor for a long time tires your eyes. Take a 10-minute rest every hour.

5
CONTENTS
CONTENTS
Cover ...................................................................... 1
Notice for this monitor ......................................... 3
Cleaning .................................................................... 4
To use the monitor comfortably ............................. 4
CONTENTS ............................................................. 5
Chapter 1 Introduction ....................................... 7
1-1. Features ......................................................... 7
1-2. Controls and Functions ............................... 9
1-3. EIZO LCD Utility Disk...................................10
●Diskcontentsandsoftwareoverview............10
●TouseColorNavigator...................................10
1-4. Basic Operations and Functions ...............11
●BasicAdjustmentmenuoperations...............11
●ShowingButtonGuide...................................12
●Functions........................................................13
Chapter 2 Adjusting Screens .......................... 15
2-1. Compatible Resolutions .............................15
●AnalogInput(DVI-I).......................................15
●DigitalInput(DVI/DisplayPort)....................15
●DigitalInput(HDMI)........................................15
2-2. Setting the Resolution ................................16
●Windows7......................................................16
●WindowsVista................................................16
●WindowsXP...................................................16
●MacOSX.......................................................16
2-3. Adjusting Color ............................................17
●Toselectthedisplaymode(colormode).......17
●Toperformadvancedadjustments................18
●Adjustablesettingsineachmode..................18
●AdjustingBrightness......................................19
●Adjustingthetemperature..............................19
●AdjustingGamma.......................................... 20
●AdjustingHue................................................ 20
●AdjustingSaturation...................................... 20
●Toenable/disableContrastEnhancer............21
●Toenhanceoutlineofimage..........................21
●Tosetclipping............................................... 22
●AdjustingGain............................................... 23
●Adjusting6Colors......................................... 23
2-4. Adjusting Screens ...................................... 24
●DigitalSignalInput.........................................24
●AnalogSignalInput........................................24
2-5. Expanding Signal Output Range .............. 27
2-6. Selecting Screen Size ................................ 28
●DVI,DP(PCsignal)input.............................. 28
●HDMI(HDsignal)input................................. 28
●HDMI(SDsignal)input................................. 29
2-7. Conguring Moving Image Performance . 29
2-8. Specifying Color Space ............................. 30
2-9. Reducing Noise ........................................... 30
Chapter 3 Setting Monitor ............................... 31
3-1. Enabling/Disabling Mode Selection ..........31
3-2. Selecting the Language ..............................31
3-3. Setting Orientation ......................................31
3-4. Changing Adjustment Menu Display
Position ........................................................ 32
3-5. Showing and Hiding the EIZO Logo ......... 32
3-6. Locking Buttons .......................................... 32
3-7. Setting Signal Bandwidth .......................... 33
●ToconnectDVI/DisplayPort........................ 33
3-8. Switching USB Port Automatically ........... 33
3-9. Changing DUE (Digital Uniformity
Equalizer) Setting ....................................... 34
3-10. Reset to default ........................................... 34
●Toresetthecoloradjustments...................... 34
●Toresetalladjustmentstothedefault
settings.......................................................... 35
Chapter 4 SelfCorrection ................................. 36
4-1. Executing SelfCorrection .......................... 36
Chapter 5 Power Saving Functions ................ 37
5-1. Setting Power Save ......................................37
5-2. Enabling/Disabling Automatic
Brightness Adjustment .............................. 38
5-3. Checking the Power Saving Level ............ 38
5-4. Adjusting the Brightness of Indicator ...... 38
5-5. Setting USB Power Save ............................ 39
5-6. Setting DisplayPort Power Save ............... 39
Chapter 6 Troubleshooting .............................. 40
6-1. No picture .................................................... 40
6-2. Imaging problems ........................................41
6-3. Other problems ........................................... 42
6-4. Built-in correction sensor and
SelfCorrection problems ........................... 43
Chapter 7 Reference ........................................44
7-1. Attaching the Optional Arm ....................... 44
7-2. Connecting Multiple External Devices ..... 45
●Toswitchamonginputsignals...................... 46
●Tosetinputsignalselection“Input
Selection”...................................................... 46
7-3. Making Use of USB (Universal Serial
Bus) ............................................................... 46
●SystemRequirement..................................... 46

6CONTENTS
●Procedure.......................................................47
7-4. Showing Monitor Information.....................47
●Displayingsignalinformation“SignalInfo”....47
●DisplayingMonitorInformation“Monitor
Info”............................................................... 48
7-5. Specications ............................................. 49
7-6. Preset Timing ...............................................51
7-7. Glossary ....................................................... 52
Appendix .............................................................. 54
Trademark ............................................................... 54
License .................................................................... 54
TCO .......................................................................... 54
FCC Declaration of Conformity ............................ 55
Hinweise zur Auswahl des richtigen
Schwenkarms für Ihren Monitor ........................... 56
Hinweis zur Ergonomie : ....................................... 56
LIMITED WARRANTY ............................................. 57
China Measures for RoHS Compliance in
ChinaRoHS .............................................................. 66
Recycling Information ........................................... 67

7
Chapter1Introduction
Chapter 1 Introduction
1-1. Features
• 24.1″ wide format LCD
• Wide color gamut of 97% of Adobe®RGB
• Applicable to the resolution of 1920 × 1200.
• IPS panel with 89˚ horizontal and vertical viewing angles
• Frame synchronization mode supported (23.75 - 30.5Hz, 47.5 - 61.0Hz)
• DisplayPort connector (applicable to 8 bit and 10 bit)*1
• HDMI connector (applicable to 8 bit, 10 bit, and 12 bit)*1
*1 Not applicable to audio signals.
• 3 signal input terminals (DVI-D × 1, HDMI × 1, DisplayPort × 1)
• Color Mode function
Reproduces a color gamut and gamma compliant with the following standard.
- Adobe®RGB
The Paper mode reproduces a printed paper effect on the monitor.
See “To select the display mode (color mode)” (page 17).
• Supports portrait and landscape format
• This product is equipped with a built-in correction sensor, and supports SelfCorrection in which the monitor
executes display correction independently.
See “Chapter 4 SelfCorrection” (page 36).
• The provided “ColorNavigator” calibration software enables you to calibrate monitor characteristics and
generate color proles (Not applicable to some product types).
See “1-3. EIZO LCD Utility Disk” (page 10).
• The software “ScreenManager Pro for LCD” to adjust the screen using the mouse and keyboard is included.
This software can be downloaded from our web site (http://www.eizo.com).
• Supports Color Vision Deciency Simulation Software “UniColor Pro”
This software can be downloaded from our web site (http://www.eizo.com).
• Power saving function
Suppressing the power consumption reduces the carbon dioxide emissions. This product is equipped with power saving
function.
- 0 W when the main power is off
Equipped with main power switch.
Turning off the main power switch completely shuts off power supply to the monitor while the monitor is not used.
- Auto EcoView function
The ambient light sensor on the front side of the monitor detects the environmental brightness to adjust the screen
brightness automatically and comfortably. Excessively high brightness may increase power consumption and cause
unwanted environmental effects. It may also lead to fatigue of your eyes. Use the Auto EcoView to reduce the
brightness.
See “5-2. Enabling/Disabling Automatic Brightness Adjustment” (page 38).
• HDCP (High-bandwidth Digital Content Protection)

8Chapter1Introduction
Attention
Be careful of the following points when using the built-in correction sensor.
Do not touch the built-in correction sensor.
Itmayreducethemeasurementaccuracyofthebuilt-incorrectionsensor,orresultininjury
orequipmentdamage.
Attention
• A high temperature or high humidity environment may affect the measurement accuracy of the built-in correction
sensor. We suggest storing and using the monitor under the following conditions.
- Temperature 30˚C or less
- Humidity 70% or less
Avoid storing or using the sensor where it may be exposed to direct sunlight.
Note
• This monitor supports both portrait and landscape format. You can change the orientation of the Setting menu when
using the monitor screen in vertical display position. (see “3-3. Setting Orientation” (page 31))
• For using the monitor with “Portrait” position, the graphics board supporting portrait display is required. When placing
the monitor in a “Portrait” position, settings of your graphics board need to be changed. Refer to the User’s Manual of
the graphics board for details.

9
Chapter1Introduction
1-2. Controls and Functions
Adjustment
menu*1
16
17
1011 12 13
1
14
15
78 92 4 53
6
1. Built-in correction sensor Executesdisplaycorrectionforanindependentmonitor.SelfCorrectionfunction
(page36)
2. Ambient Light Sensor Measuresambientlight.
3. button Switchesinputsignalsfordisplay(page46).
4. button ChangesColorMode(page17).
5. button Cancelsthesetting/adjustmentandexitstheAdjustmentmenu.
6. button
• Choosesandincreases/decreasesadjustmentsettingsforadvanced
adjustmentusingtheAdjustmentmenu.
• DisplaystheBrightnessmenu(page19).
7. button DisplaystheAdjustmentmenu,determinesanitemonthemenuscreen,andsaves
valuesadjusted(page11).
8. button Turnsthepoweronoroff.
9. Power Indicator
Indicatesthemonitor’soperationstatus.
Blue: Operating
Flashingblue
(2timesforeach):
Inthefollowingcases,thisnotiesthatdisplayre-correction
isrequired.
• WhenthetimerissetinColorNavigator(CALmode)
Orange: Powersavingmode
OFF: Mainpower/Poweroff
10. Main power switch Turnsthemainpoweronoroff.
11. Power connector Connectsthepowercord.
12. Input signal connectors Left:DVI-Iconnector/Center:HDMIconnector/Right:DisplayPortconnector
13. USB upstream port
ConnectstheUSBcabletousethesoftwarethatneedsUSBconnection,ortouse
USBhubfunction(page46).
Attention
• By default, USB upstream port 1 is enabled. Connect the cable to USB upstream port 1
rst.
14. USB downstream port ConnectsaperipheralUSBdevice.
15. Stand*2 Usedtoadjusttheheightandangleofthemonitorscreen.
16. Security lock slot ComplieswithKensington’sMicroSaversecuritysystem.
17. Cable holder Coversthemonitorcables.
*1 For details, see “1-4. Basic Operations and Functions” (page 11).
*2 An optional arm (or an optional stand) can be attached by removing the stand section (see “7-1. Attaching the Optional Arm”
(page 44)).

10 Chapter1Introduction
1-3. EIZO LCD Utility Disk
An “EIZO LCD Utility Disk” (CD-ROM) is supplied with this product. The following table shows the disk contents
and the overview of the software programs.
●Disk contents and software overview
The disk includes application software programs for adjustment, and User’s Manual. Refer to “Readme.txt” or
the “read me” le on the disk for software startup procedures or le access procedures.
Contents Overview Windows Macintosh
A“Readme.txt”or“readme”le √ √
ColorNavigator*1 Anapplicationsoftwareforcalibratingmonitor
characteristicsandgeneratingICCproles(for
Windows)andAppleColorSyncproles(for
Macintosh).
(APCmustbeconnectedtothemonitorwith
thesuppliedUSBcable.)
√ √
Screenadjustmentpatternles Usedwhenadjustingtheimageoftheanalog
signalinputmanually. √ -
User’sManualofthismonitor(PDFle) √ √
*1 Only ColorNavigator Licensed models
●To use ColorNavigator
Attention
• If “ColorNavigator License” in the monitor information screen is “Not Registered”, the ColorNavigator license must be
purchased and registered to the monitor. For the purchase of the license, contact your local EIZO representative.
Refer to the corresponding User’s Manual on the CD-ROM disk in order to install and use the software.
When using this software, you will need to connect a PC to the monitor with the supplied USB cable. For
details of the USB cable connection, see “7-3. Making Use of USB (Universal Serial Bus)” (page 46).

11
Chapter1Introduction
1-4. Basic Operations and Functions
●Basic Adjustment menu operations
1. Displaying Adjustment Menu
1. Press . The Adjustment menu appears.
Currentmode
Menutitle
Setting
Menu
Item
2.
Adjusting/Setting
1. Choose a menu to adjust/set with , , and then press .
2. Choose an item to adjust/set with , , and then press .
3. Adjust/set the selected item with , , and then press .
3.
Exiting the software
1. Press a few times. The Adjustment menu nishes.

12 Chapter1Introduction
●Showing Button Guide
Press the front buttons (except button), the button guide appears above the button. (When using the monitor
with “Portrait” position, the button guide appears next to the button.)
ButtonGuide
Controlbutton
Note
• The button guide will continue to appear while the Adjustment menu or Mode menu is showing.
• The button guide is displayed differently depending on the selected menu or status.
• In CAL mode, although Button Guide are displayed above the and buttons, the brightness cannot be adjusted.

13
Chapter1Introduction
●Functions
The following table shows all the Adjustment menu’s adjustment and setting menus.
Main Menu Item Reference
Color*1 Brightness “2-3.AdjustingColor”(page17)
Temperature
Gamma
Advanced
Settings Hue
Saturation
Contrast
Enhancer
OutlineEnhancer
Clipping
Gain
6Colors
ColorReset “3-10.Resettodefault”(page34)
SelfCorrection Execute “4-1.ExecutingSelfCorrection”(page36)
Screen ScreenSize “2-6.SelectingScreenSize”(page28)
Overdrive “2-7.ConguringMovingImage
Performance”(page29)
ColorSpace “2-8.SpecifyingColorSpace”(page30)
RangeExtension “2-5.ExpandingSignalOutputRange”(page
27)
HDMISettings*2 NoiseReduction “2-9.ReducingNoise”(page30)
Analog
Adjustment*3 AutoAdjustment “2-4.AdjustingScreens”(page24)
RangeAdjustment
Clock
Phase
Hor.Position
Ver.Position
Power
Manager PowerSave “5-1.SettingPowerSave”(page37)
AutoEcoView “5-2.Enabling/DisablingAutomatic
BrightnessAdjustment”(page38)
Indicator “5-4.AdjustingtheBrightnessofIndicator”
(page38)
EcoViewIndex “5-3.CheckingthePowerSavingLevel”
(page38)
MenuSettings Language “3-2.SelectingtheLanguage”(page31)
Orientation “3-3.SettingOrientation”(page31)
MenuPosition “3-4.ChangingAdjustmentMenuDisplay
Position”(page32)

14 Chapter1Introduction
Tools InputSelection “Toswitchamonginputsignals”(page46)
ModePreset “3-1.Enabling/DisablingModeSelection”(page
31)
USB
Selection
DVI “3-8.SwitchingUSBPortAutomatically”(page33)
DisplayPort
HDMI
SignalInfo “7-4.ShowingMonitorInformation”(page47)
MonitorInfo
AllReset “3-10.Resettodefault”(page34)
*1 The adjustment/settings available on the “Color” menu depend on the selected mode. (See “2-3. Adjusting Color”
(page 17))
*2 This setting can be adjusted with HDMI signal input.
*3 These functions can be adjusted with analog input.

15
Chapter2AdjustingScreens
Chapter 2 Adjusting Screens
2-1. Compatible Resolutions
The monitor supports the following resolutions.
●Analog Input (DVI-I)
Resolution Applicable Signals Vertical scan
frequency Dot clock
640×480 VGA 60Hz
164.5MHz
(Max.)
720×400 VGATEXT 70Hz
800×600 VESA 60Hz
1024×768 VESA 60Hz
1280×960 VESA 60Hz
1280×1024 VESA 60Hz
1600×1200 VESA 60Hz
1680×1050 VESACVT,VESACVTRB 60Hz
1920×1080 VESACVTRB 60Hz
1920×1200*1 VESACVTRB 60Hz
●Digital Input (DVI / DisplayPort)
Resolution Applicable Signals Vertical scan
frequency Dot clock
640×480 VGA 60Hz
164.5MHz
(Max.)
720×400 VGATEXT 70Hz
800×600 VESA 60Hz
1024×768 VESA 60Hz
1280×960 VESA 60Hz
1280×1024 VESA 60Hz
1600×1200 VESA 60Hz
1680×1050 VESACVT,VESACVTRB 60Hz
1920×1080 VESACVTRB 60Hz
1920×1200*1 VESACVTRB 60Hz
●Digital Input (HDMI)
• Video signal
- VGA / 480i,480p,1080i,720p,1080p: 60 Hz
- 576i,576p,1080i,720p,1080p: 50 Hz
- 1080p: 24 Hz, 25 Hz, 30 Hz
AgraphicsboardinconformancewiththeVESAandCEA-861standardsisrequired.
See“3-7.SettingSignalBandwidth”(page33).
*1 Recommended resolution

16 Chapter2AdjustingScreens
2-2. Setting the Resolution
When you connect the monitor to the PC and nd that the resolution is improper, or when you want to change the
resolution, follow the procedure below.
●Windows 7
1. Right-click the mouse anywhere on the desktop except for icons.
2. From the displayed menu, click “Screen resolution”.
3. On the “Screen Resolution” dialog box, select the monitor.
4. Click “Resolution” to select the desired resolution.
5. Click the “OK” button.
6. When a conrmation dialog box is displayed, click “Keep changes”.
●Windows Vista
1. Right-click the mouse anywhere on the desktop except for icons.
2. From the displayed menu, click “Personalize”.
3. On the “Personalization” window, click “Display Settings”.
4. On the “Display Settings” dialog box, select the “Monitor” tab and select desired resolution in the
“Resolution” eld.
5. Click the “OK” button.
6. When a conrmation dialog box is displayed, click “Yes”.
●Windows XP
1. Right-click the mouse anywhere on the desktop except for icons.
2. From the displayed menu, click “Properties”.
3. When the “Display Properties” dialog box is displayed, click the “Settings” tab and select desired resolution
for “Screen resolution” under “Display”.
4. Click the “OK” button to close the dialog box.
●Mac OS X
1. Select “System Preferences” from the Apple menu.
2. When the “System Preferences” dialog box is displayed, click “Displays” for “Hardware”.
3. On the displayed dialog box, select the “Display” tab and select desired resolution in the “Resolutions” eld.
4. Your selection will be reected immediately. When you are satised with the selected resolution, close the
window.

17
Chapter2AdjustingScreens
2-3. Adjusting Color
●To select the display mode (color mode)
This function allows easy selection of a desired mode according to monitor application.
Display Modes
Mode Purpose
1-User1 Availableforthecolorsettingsaccordingtoyourpreference.
2-User2
3-User3
4-Paper Producesaprintedpapereffectbydecreasingcontrastandcolortemperature.
5-Adobe®RGB SuitableforcolormatchingwithAdobe®RGBcompatibleperipherals.
6-sRGB SuitableforcolormatchingwithsRGBcompatibleperipherals.
7-CAL Displaysthescreenadjustedby“ColorNavigator”calibrationsoftware.
Note
• In CAL mode, ColorNavigator can be used for adjustment.
• Available CAL mode differs depending on each input signal.
Attention
• Avoid operating any function of the monitor while using ColorNavigator. Regarding ColorNavigator, see “To use
ColorNavigator” (page 10).
Example:AtDVIinput
Themodemenu
appears.
1-User1←→2-User2←→3-User3←→4-Paper
7-CAL←→6-sRGB←→5-Adobe®RGB
Procedure
1. Press .
The mode menu appears at the bottom left of the screen.
2. The mode among the list is highlighted in turn each time is pressed.
You can switch the mode with or while the mode menu is displayed.
Note
• The Adjustment menu and the Mode menu cannot be displayed at the same time.
• You can disable a specic mode to be selected. For more information, see “3-1. Enabling/Disabling Mode Selection”
(page 31).
• “ScreenManager Pro for LCD” allows you to select the color mode automatically according to the application used (see
“Chapter 3 Auto FineContrast” in the “ScreenManager Pro for LCD” User’s Manual).

18 Chapter2AdjustingScreens
●To perform advanced adjustments
“Color” of the Adjustment menu allows you to congure and save a separate set of color settings for each
mode.
Attention
• As it takes about 7 minutes (under our measurement conditions) for the performance of electrical parts to stabilize,
adjust the monitor 7 minutes or more after the monitor power has been turned on.
• Perform the range adjustment rst when adjusting color for analog signals (see “To adjust color gradation automatically”
(page 27)).
• The same image may be seen in different colors on multiple monitors due to their monitor-specic characteristics. Make
ne color adjustment visually when matching colors on multiple monitors.
Note
• The values shown in “%” or “K” are available only as reference.
• Using the “ScreenManager Pro for LCD” allows you to perform the color adjustment by using the mouse and
keyboard of your PC. The adjusted conditions can be stored as the color data to be read in later. (See “Chapter 4 Color
Adjustment” in the User’s Manual for “ScreenManager Pro for LCD”.)
●Adjustable settings in each mode
The adjustable settings depend on the mode. (You cannot select any non-adjustable or non-settable function.)
The adjustments or settings made for each mode are applied to all input signals.
√: Adjustable -: Not adjustable
Icon Function
Color Mode
1-User1 2-User2 3-User3 4-Paper 5-Adobe®
RGB 6-sRGB 7-CAL
Brightness √√√√√√-
Temperature √√√√√√-
Gamma √ √ √ - √ √ -
Hue √ √ √ - - - -
Saturation √ √ √ - - - -
Contrast
Enhancer √ √ √ - - - -
OutlineEnhancer √√√√√√-
Clipping - - - - √ √ -
Gain √ √ √ - - - -
6Colors √ √ √ - - - -

19
Chapter2AdjustingScreens
●Adjusting Brightness
The screen brightness is adjusted by changing the brightness of the backlight (light source from the LCD back
panel).
Setting Range
50 cd/m2 to 300 cd/m2
Procedure
1. Press or .
The Brightness menu appears.
2. Use or for adjustment.
3. Press to exit.
Attention
• If the entered value cannot be set, the value will appear in magenta. In such a case, change the value.
Note
• Alternatively, you can use “Brightness” under “Color” in the Adjustment menu to adjust it.
• The values shown in “cd/m2” are available only as reference.
●Adjusting the temperature
The color temperature can be adjusted.
The color temperature is normally used to express the hue of “White” and/or “Black” by a numerical value.
The value is expressed in degrees “K” (Kelvin).
The screen becomes reddish at a low color temperature, and bluish at a high color temperature, like the ame
temperature. The gain preset values are set for each color temperature setting value.
Setting Range
Native, 4000K-10000K (specied every 100K), Standard
Procedure
1. Choose “Color” from the Adjustment menu, and press .
2. Choose “Temperature” from “Color”, and press .
3. Use or for adjustment.
4. Press to exit.
Note
• “Gain” allows you to perform more advanced adjustment (see “Adjusting Gain” (page 23)).
• If you set “Native”, the image is displayed in the preset color of the monitor (Gain: 100% for each RGB).
• When gain is changed, the color temperature is changed to “User”.
• The default setting for each Adobe®RGB/sRGB mode is set to “Standard”, which is the temperature in conformity with
each standard.

20 Chapter2AdjustingScreens
●Adjusting Gamma
Gamma can be adjusted. The brightness of the monitor varies depending on the input signal, however, the
variation rate is not proportional to the input signal. To keep the balance between the input signal and the
brightness of the monitor is called as “Gamma correction”.
Setting Range
1.6-2.7, Standard
Procedure
1. Choose “Color” from the Adjustment menu, and press .
2. Choose “Gamma” from “Color”, and press .
3. Use or for adjustment.
4. Press to exit.
Note
• The default setting for each Adobe®RGB/sRGB mode is set to “Standard”, which is the gamma in conformity with each
standard.
●Adjusting Hue
This function allows you to adjust the hue.
Setting Range
-100 to 100
Procedure
1. Choose “Color” from the Adjustment menu, and press .
2. Choose “Advanced Settings” from “Color”, and press .
3. Choose “Hue”, and press .
4. Use or for adjustment.
5. Press to exit.
Attention
• Using this function may make some color gradations unavailable for display.
●Adjusting Saturation
This function allows you to adjust color saturation.
Setting Range
-100 to 100
Procedure
1. Choose “Color” from the Adjustment menu, and press .
2. Choose “Advanced Settings” from “Color”, and press .
3. Choose “Saturation”, and press .
4. Use or for adjustment.
5. Press to exit.
Attention
• Using this function may make some color gradations unavailable for display.
Note
• The minimum value (-100) changes the screen to monochrome.
